ZIGBEE 613 User manual

SMART LED DRIVER
INPUT: 100-277VAC 0.40A 50/60Hz
OUTPUT: 24-38VDC Max 950mA
MAX current can be set by app
ta: 40ºC tc: 85ºC
AC In Output
V+
CL-
WL-
L
N
SLC613 LED Lighting Driver
Dimming/CCT
Quick Start Guide

2
Introduction
1
The LED Lighting Driver allows you to remotely control your lighting or even
apply schedules for automatic switching from mobile phone.
This guide will provide you with an overview of the product and help you
get through the initial setup and installation.
SMART LED DRIVER
INPUT: 100-277VAC 0.40A 50/60Hz
OUTPUT: 24-38VDC Max 950mA
MAX current can be set by app
ta: 40ºC tc: 85ºC
AC In Output
V+
CL-
WL-
L
N
Get started
2
Warning!
• The LED Lighting Driver must be installed and serviced only by qualified
electrical personnel.
• Do not touch the terminals of the device during testing.
• Turn off all power supplying this equipment before installing.
• Make sure that the power supply is off before connecting or disconnecting
it to the auxiliary device.
• Always use a properly rated voltage sensing device to confirm power is off.
• Replace all devices, doors and covers before turning on power to this
equipment.
Failure to follow these instructions will result in death or serious injury.

3
3.1 To get started, you will need:
A Gateway
The mobile app
3.2 Installation
The in-wall switch must be installed by qualified electrical personnel, keep
the wiring diagram below for future reference.
SMART LED DRIVER
INPUT: 100-277VAC 0.40A 50/60Hz
OUTPUT: 24-38VDC Max 950mA
MAX current can be set by app
ta: 40ºC tc: 85ºC
AC In Output
V+
CL-
WL-
L
N
Wiring Diagram

4
3.3 Connect to the gateway’s network
1. Set your gateway to permit joining.
2. The LED panel light connected to the LED Lighting Driver will start
flashing after installation indicating it is ready to join the gateway's network.
3. The LED Lighting Driver will join the gateway automatically and the LED
panel light will turn steady when successfully joined.
4. Now you can find the LED Lighting Driver under the Automation interface
of the mobile app.
Note: If the LED Lighting Driver fails to join the gateway's network within
one minute, simply reset the LED Lighting Driver and retry.
Reset. Turn ON, and turn OFF. Repeat this action three times using a
physically connected power supply. The LED panel light will start flashing
when reset successfully. Try three more times if this fails.

5
3Technical Specifications
Wireless Connectivity • ZigBee 2.4GHz IEEE 802.15.4
RF Characteristics
• Operating frequency: 2.4GHz
• Range outdoor/indoor:
100m/30m
• Internal PCB antenna
ZigBee Profile • ZigBee Lighting Link Profile
Power Input • 100-277VAC 0.4A 50/60Hz
Output • 24-38VDC MAX 950mA
Operation temperature • ta: 40ºC , tc: 85ºC
Dimensions • 190 x 86 x 37 (W) mm
Weight • 418g

6
Safety Notice
WARNING: Failure to follow these safety notices could result in fire,
electric shock, other injuries, or damage to the LED Lighting Driver and
other property. Read all the safety notices below before using the LED
Lighting Driver.
4
• Avoid high humidity or extreme temperatures.
• Avoid long exposure to direct sunlight or strong ultraviolet light.
• Do not drop or expose the unit to intense vibration.
• Do not disassemble or try to repair the unit yourself.
• Do not expose the unit or its accessories to flammable liquids, gases or
other explosives.
