ZIGBEE PR412 User manual

REV FWD COMCOM
PR412
L N
PR412 Curtain Control
Quick Start Guide

2
Safety Handling
WARNING: Failure to follow these safety notices could
result in 󽗉re, electric shock, other injuries, or damage to
the Curtain motor driver and other property. Read all the
safety notices below before using Curtain motor driver.
• Avoid high humidity or extreme temperatures.
• Avoid long exposure to direct sunlight or strong ultraviolet
light.
• Do not drop or expose the unit to intense vibration.
• Do not disassemble or try to repair the unit yourself.
• Do not expose the unit or its accessories to 󽗊ammable
liquids, gases or other explosives.

3
Technical Speci󽗉cations
Wireless Connectivity • Zigbee 2.4GHz IEEE 802.15.4
RF Characteristics
• Operating frequency: 2.4GHz
• Internal PCB Antenna
• Range outdoor: 100m
ZigBee Pro󽗉le • ZigBee HA1.2
Operating Voltage • 100~240 VAC 50/60 Hz
Operating
environment
• Temperature: -20℃ ~+55℃
• Humidity:
≤ 91% non-condensing
Max Load Current • 5A
Dimension • 64 x 45 x 15 (L) mm
Weight • 77g

4
Welcome
1
The Curtain Motor Driver PR412 is a ZigBee-enabled and
allows you to control your curtains manually using a wall
mounted switch or remotely using a mobile phone.
This guide will provide you with an overview of the product
and help you get through the initial setup and installation.
REV FWD COMCOM
PR412
L N

5
Installation
2
Please refer to the installation diagram below to install the
curtain motor driver.
Please make sure the main power in your facility is o󽗈 before
installing.

6
REV FWD COMCOM
PR412
L N
Reverse motor
Live
Neutral
Forward motor
Common
Common
Down
Up
Wiring diagram
High voltage output to motor
Optional physical input

7
Get to know your device
3
LED indicator Reset button
Reset button:
Press and hold the Reset button for about ten seconds until
the LED indicator 󽗊ashes three times to restore the curtain
motor driver to default factory settings.
REV FWD COMCOM
PR412
L N

8
LED status What it means
LED 󽗊ashing Device has not joined a
network.
Solid Device has joined a network.
Green LED solid Open/close the curtain
Red LED solid Stop the curtain.
Green LED 󽗊ashing
three times (0.5s On/O󽗈) Return to Factory Settings.
LED indicator
The LED status gives the following information:

9
Con󽗉gure Network
4
4.1 To get started, you will need:
• Zigbee Gateway.
• A mobile phone with a mobile APP installed.
4.2 Adding to the gateway’s network
1. Install the curtain motor driver and the LED indicator will
start 󽗊ashing (reset the curtain motor driver if not).
2. Set your ZigBee gateway to permit joining and the curtain
motor driver will join the gateway's network automatically,
the LED indicator will turn steady when successfully joined.
3. Check your mobile App, and you will be able to see your
curtain motor driver under the "Automation" interface. If it
is not, reset the curtain motor driver and repeat step 2.
