ZIGBEE 622 User manual

LED622 CCT Tunable LED Bulb
Quick Start Guide

2
1. Introduction
The LED622 ZigBee CCT Tunable LED bulb allows you to switch it ON
and OFF, adjust its brightness and color temperature and set a
switching schedules from the mobile app.
2. Get started
To get started, you will need:
A ZigBee Gateway
A LED622 ZigBee CCT Tunable LED Bulb
The mobile app
Then follow the steps below:
Step 1: Power on your LED622 LED Bulb. The LED Bulb will turn from
warm light - cool light - warm light and flash once. If not, please
refer to the FAQ section to reset the bulb to factory default setting.
If yes, continue to step 2.
Step 2: Power OFF the LED Bulb.
Step 3: Select “Add new devices” in the menu of the app.

3
Tip: for this step, you can also press the “Z” button of the gateway
for two seconds until the LED indicator turns solid blue.
Step 4: Power ON the LED Bulb and it will turn from warm light - cool
light - warm light and flash once.
Step 5: The LED Bulb will flash once more when it is successfully
joined in the gateway. Now you can go to the APP and look for your
LED bulb. You may now use your phone to ON/OFF the bulb, adjust
brightness and color temperature.

4
3. FAQ
Q1. How can I return this device to default factory settings?
A1: Turn on then turn off within 3 seconds and repeat 6 times (off,
on, off, on, off, on, off, on, off, on, off, on) and the bulb will turn
warm light –cool light –warm light and flash once to indicate it has
successfully restore to factory default setting.
Q2. Can I use a dimmer switch to control LED622 LED bulb rather
than the mobile app?
A2: Yes. Please see the SLC603 dimmer switch user guide.

5
4. Technical Specifications
Operating Voltage
E27: 220-240V
E26: 120V
Operating Wattage
9W
Lumen
806lm
Average Lifetime
25000Hrs
CCT
2700 ~ 6500k
CRI
80
Beam Angle
240°
Dimensions
Diameter: 60mm
Height: 120mm
Weight
72g
Mounting Type
Mounted on bracket

6
5. Safety Notice
WARNING: Failure to follow these safety notices could
result in fire, electric shock, other injuries, or damage to
the device or other property. Read all the safety notices
below before using the device.
Avoid high humidity or extreme temperatures.
Avoid long exposure to direct sunlight or strong ultraviolet light.
Do not drop or expose the unit to intense vibration.
Do not disassemble or try to repair the unit yourself.
Do not expose the unit or its accessories to flammable liquids,
gases or other explosives.
