INSTALLATION AND OPERATING INSTRUCTIONS:PowerStop
DDOC00335 / b EN / 2023-08-07
ZimmerGmbH•ImSalmenkopf5•77866 Rheinau, Germany • [phone] • www.zimmer-group.com
Content

4
14 Decommissioning/disposal ...................................................................................................................................................... 31
15 Declaration of Incorporation ..................................................................................................................................................... 32
ZimmerGmbH•ImSalmenkopf5•77866 Rheinau, Germany • [phone] • www.zimmer-group.com
INSTALLATION AND OPERATING INSTRUCTIONS:PowerStop
DDOC00335 / b EN / 2023-08-07

5
1 Supporting documents
NOTICE
Read through the installation and operating instructions before installing or working with the product.
The installation and operating instructions contain important notes for your personal safety. They must be read
and understood by all persons who work with or handle the product during any phase of the product lifetime.
The documents listed below are available for download on our website www.zimmer-group.com.
• Installation and operating instructions
• Catalogs, drawings, CAD data, performance data
• Information on accessories
• Technical data sheets
• General Terms and Conditions, including warranty information.
ÖOnly those documents currently available on the website are valid.
In these installation and operating instructions, "product" refers to the product designation on the title page!
1.1 Notices and graphics in the installation and operating instructions
DANGER
This notice warns of an imminent danger to the life and health of people. Ignoring these notices can lead to
serious injury or even death.
►You absolutely must comply with the described measures for avoiding these dangers!
ÖThe warning symbols are assigned according to the type of danger.
WARNING
This notice warns of a situation that is potentially hazardous to personal health. Ignoring these notices can cause
serious injury or damage to health.
►You absolutely must comply with the described measures for avoiding these dangers!
ÖThe warning symbols are assigned according to the type of danger.
CAUTION
This notice warns of a situation that is potentially hazardous to persons. Ignoring these notices can cause minor,
reversible injuries.
►You absolutely must comply with the described measures for avoiding these dangers!
ÖThe warning symbols are assigned according to the type of danger.
NOTICE
This notice warns of possible material and environmental damage. Ignoring these notices can result in damage to
the product or the environment.
►You absolutely must comply with the described measures for avoiding these dangers!
ÖThe warning symbols are assigned according to the type of danger.
INFORMATION
Thiscategorycontainsusefultipsforhandlingtheproducte󹱺ciently.Failuretoobservethesetipswillnotresult
in damage to the product. This information does not include any information relevant to health or workplace
safety.
INSTALLATION AND OPERATING INSTRUCTIONS:PowerStop
DDOC00335 / b EN / 2023-08-07
ZimmerGmbH•ImSalmenkopf5•77866 Rheinau, Germany • [phone] • www.zimmer-group.com

6
2 Safety notices
CAUTION
Risk of injury and material damage in case of non-compliance
Installation,commissioning,maintenanceandrepairsmayonlybeperformedbyqualiedspecialistsin
accordance with these installation and operating instructions.
The product is state-of-the-art.
It is mounted on industrial machines and used for damping loads, workpieces and similar applications.
Thefollowingareexamplesofsituationsinwhichtheproductmaycauseahazard:
• The product is not properly installed, used or maintained.
• The product is not used for its designated purpose.
• The locally applicable regulations, laws, directives or guidelines are not observed.
►The product may only be used in accordance with these installation and operating instructions and the
product'stechnicaldata.Anychangesoradditionstotheintendeduseoftheproduct,aswellasmodications
totheproduct,suchasthoseinthefollowingexamples,requirethewrittenpermissionofthemanufacturer:
• Useoftheproductunderextremeconditions,suchasaggressiveuidsorabrasivedusts
• Additional drilled holes or threads
ÖZimmer GmbH shall accept no liability for any damage caused by improper use. The operator bears sole
responsibility.
►Notethecorrespondingprotectionvariantsiftheproductistobeusedunderextremeconditions.
►For more information, refer to the "Protection variants" section.
►Make sure that the power supply is disconnected before you mount, adjust, modify, maintain or repair the
product.
►Whenever work is carried out on the product, make sure that the product cannot be actuated by mistake.
►Do not reach into the operational range of the product.
ZimmerGmbH•ImSalmenkopf5•77866 Rheinau, Germany • [phone] • www.zimmer-group.com
INSTALLATION AND OPERATING INSTRUCTIONS:PowerStop
DDOC00335 / b EN / 2023-08-07

7
3 Proper use
NOTICE
The product is only to be used in its original state with its original accessories, with no unauthorized changes and
within the stipulated parameter limits and operating conditions.
Any other or secondary use is deemed improper.
►Operate the product only in compliance with the associated installation and operating instructions.
►Operate the product only when it is in a technical condition that corresponds to the guaranteed parameters
and operating conditions.
►The piston rod of the product may only be subjected to pressure.
►Never subject the piston rod to tension.
ÖZimmer GmbH shall accept no liability for any damage caused by improper use. The operator bears sole
responsibility.
NOTICE
Malfunction in case of non-compliance
►When selecting the product, check that all parameters are being observed.
• Maximumenergyabsorptionperstroke
• Maximumenergyabsorptionperhour
• Pressure when used in a pressure chamber
• Forceatxedstop
• Maximumimpactangle
• Permitted temperature range
• The product is intended for industrial use.
INSTALLATION AND OPERATING INSTRUCTIONS:PowerStop
DDOC00335 / b EN / 2023-08-07
ZimmerGmbH•ImSalmenkopf5•77866 Rheinau, Germany • [phone] • www.zimmer-group.com

8
4 Personnel qualication
WARNING
Injuries and material damage due to inadequate qualication
Ifinadequatelyqualiedpersonnelperformworkontheproduct,thiscancauseseriousinjuriesandsignicant
material damage.
►Allworkontheproductmustbeperformedbyqualiedpersonnel.
►Before working with the product, read the document in its entirety and make sure that you have understood
everything.
►Observecountry-specicaccidentpreventionregulationsandthegeneralsafetynotices.
Thefollowingqualicationsareaprerequisiteforperformingvariousworkontheproduct.
4.1 Electricians
Electricians are able to perform work on electrical systems, can recognize and avoid possible dangers and know the
relevantstandardsandprovisionsduetotheirtechnicaltraining,knowledgeandexperience.
4.2 Specialists
Specialists are able to perform the assigned work, can recognize and avoid possible dangers and know the relevant
standardsandprovisionsduetotheirtechnicaltraining,knowledgeandexperience.
4.3 Instructed personnel
Instructed personnel have been trained by the operating company on the tasks and possible dangers of improper behavior.
4.4 Service personnel
Service personnel are able to perform the assigned work and can recognize and avoid possible dangers due to their
technicaltraining,knowledgeandexperience.
4.5 Additional qualications
Persons who work with the product must be familiar with the valid safety regulations and laws as well as the standards,
guidelines and laws listed in this document.
Personnelwhoworkwiththeproductmusthavefacility-issuedauthorizationtocommission,program,congure,operate,
maintain and also decommission this product.
ZimmerGmbH•ImSalmenkopf5•77866 Rheinau, Germany • [phone] • www.zimmer-group.com
INSTALLATION AND OPERATING INSTRUCTIONS:PowerStop
DDOC00335 / b EN / 2023-08-07

9
5 Product description
The product is a pressure-loaded shock absorber. It is used to brake moving masses in the end position.
INFORMATION
►Determine the energy absorption and the impact velocity using the Product Finder on our website or see the
corresponding catalog pages.
►Usethechecklistsonourwebsitetondtherightproductforyourapplication.
INFORMATION
►Information about connecting products in parallel or series, transforming rotations or calculating lever
translations can be found in the description in the catalog.
5.1 Hydraulic uid properties
Theproductislledwithabio-oilbasedonsyntheticester(HEES).
• Biologically degradable
• PWIS-free
• H1certicationforuseinthefoodindustry
• Lowvaporizationinclination,whichisbenecialforuseincleanroomapplications.
5.2 Stroke variants
Avarietyofstrokevariantsareavailableforthisproduct:
• Normal stroke (N)
• Long stroke (L)
• Extra-longstroke(V)
5.3 Degrees of hardness
The degree of hardness describes the damping characteristics according to the impact velocity of the moving mass on the
product.
Therearefourdeneddegreesofhardness:
• Hard (H)
• Medium (M)
• Soft (S)
• Super soft (W)
Theenergyabsorptioninaccordancewiththetechnicalspecicationsisreachedinthespeciedspeedrange.
NOTICE
Material damage and malfunction in case of non-compliance
►Pleasenotethattheproductreactswithanincreasedcounterforceifthespeciedspeedrangeisexceeded.
ÖThe product can be overloaded because of this.
►Pleasenotethattheproductreactswithareducedcounterforceifthespeedrangefallsshortofthespecied
value.
ÖThe product cannot achieve the full energy absorption because of this.
INSTALLATION AND OPERATING INSTRUCTIONS:PowerStop
DDOC00335 / b EN / 2023-08-07
ZimmerGmbH•ImSalmenkopf5•77866 Rheinau, Germany • [phone] • www.zimmer-group.com

10
5.4 Protection variants
INFORMATION
►Please note that the No protection, Felt ring and Wiper variants are also available with the side load adapter
accessory as optional protection.
►For more information, refer to the "Installing the side load adapter (PBV)" section.
You can choose from the following protection variants for the product.
No protection (D)
If the product is used in a dirt-free environment, additional protection is
unnecessary.
Felt ring (F)
The felt ring protects the product against dirt, dust and chips, such as
wood dust and metal swarf.
Wiper (A)
The wiper protects the product against liquids and aerosols, such as
cooling lubricants, oils, oil mist and hydraulic media.
Bellows (B)
Thebellowsoffermaximumprotectionwhenusedinadirtyenvironment.
It protects the product against dirt and liquids.
ZimmerGmbH•ImSalmenkopf5•77866 Rheinau, Germany • [phone] • www.zimmer-group.com
INSTALLATION AND OPERATING INSTRUCTIONS:PowerStop
DDOC00335 / b EN / 2023-08-07

11
5.5 Head variants
INFORMATION
►Pleasenotetheavailabilityandeffectoftheintegratedxedstopforthedifferentheadvariants.
►Formoreinformation,refertothe"Settingthestrokeandxedstop"section.
Thecounterpiecethatimpactstheproductmustexhibitthehighestpossiblehardnessinordertominimizewearonthe
counterpiece.Incaseofsoftermaterials,theuseofasteelorplasticheadisrecommendedtoreducesurfacepressure.
For even greater durability at inclined impact angles, all heads are rounded in order to absorb the load with reduced
transverse force. For a secure hold, the heads are glued as well as crimped via lateral grooves for reliable positioning with
the piston rod.
Short piston rod no head(D)
Thepistonrodextendsoutofthehousingbythemaximumstrokeofthe
respectiveproduct.Becauseofthis,theproducthasanintegratedxed
stop.
Long piston rod no head(E)
Thepistonrodextendsfurtheroutofthehousingthanthemaximum
stroke of the respective product. Because of this, the product does not
haveanintegratedxedstop.
Steel head (S)
The steel head has an enlarged surface, thus reducing the surface
pressure during impact. The steel head is suitable for soft opposing
materials.
The distance between the housing and the bottom of the head
correspondstothemaximumstrokeoftherespectiveproduct.Because
ofthis,theproducthasanintegratedxedstop.
Plastic head (K)
The plastic head consists of an intake made of steel with an insert made
of a TPC material. The plastic head is suitable for soft opposing materials
and for noise reduction.
The distance between the housing and the bottom of the head
correspondstothemaximumstrokeoftherespectiveproduct.Because
ofthis,theproducthasanintegratedxedstop.
INSTALLATION AND OPERATING INSTRUCTIONS:PowerStop
DDOC00335 / b EN / 2023-08-07
ZimmerGmbH•ImSalmenkopf5•77866 Rheinau, Germany • [phone] • www.zimmer-group.com

12
6 Functional description
The braking of moving masses in the end position is performed by converting kinetic energy into heat using hydraulic
damping.
6.1 Shock absorber characteristic curve
The shock absorber characteristic curve describes the development of force over the stroke of the product. This
development is the result of the design-based buildup of the internal hydraulic friction and throttle effect via the spiral
groove as well as the velocity-dependent loading of the product.
Itdependsonthefollowingparametersandcanvarywithinthespeciedranges:
• Type, viscosity and density of the oil
• Impact velocity
• Energy load due to the impact process
• Temperature
• Wear
6.1.1 Velocity-dependent behavior
Thespeciedtechnicaldataapplytotheuseofthemaximumdamperstroke.
The force that the product generates depends on the impact velocity.
• A higher velocity corresponds to a higher product force.
• The force curve over the stroke yields the energy absorption per stroke.
INFORMATION
►Duringthedesignprocess,makesurethattheenergyloadoftheapplicationisnotgreaterthanthemaximum
energy absorption per stroke.
Theproductisdesignedsothatthemaximumenergyabsorptionperstrokeispresentwithaminimumimpactvelocity.
Uptoreachingthemaximumimpactvelocity,themaximumenergyabsorptionperstrokeremainsthesameinorderto
prevent the product from being overloaded.
Belowtheminimumvelocity,theproductrespondsmoresoftlyandnolongerachievesthemaximumenergyabsorptionper
stroke.
NOTICE
Non-compliance may result in material damage.
►Makesurethatthemaximumimpactvelocityoftheproductisnotexceeded.
ÖThe resulting high forces can cause an overload, thus damaging the product.
ÖBecause the oil cannot drain quickly enough through the throttle cross-section, bouncing can occur above the
maximumimpactvelocity.
The individual degrees of hardness tend toward the following character-
isticsintheshockabsorbercharacteristiccurve:
1
2
3
1
2
3
Stroke [mm]
Force [N]
Hard
Medium
Soft/Supersoft
Asarule,themaximumforceincreasesfromtheminimumtomaximum
impact velocity, whereby the energy is absorbed in an earlier stroke than
themaximumstroke.
Thus the stroke that results or that is necessary for the application can
belowerthanthemaximumstrokeoftheproduct.
►Formoreinformation,refertothe"Settingthestrokeandxedstop"
section.
ZimmerGmbH•ImSalmenkopf5•77866 Rheinau, Germany • [phone] • www.zimmer-group.com
INSTALLATION AND OPERATING INSTRUCTIONS:PowerStop
DDOC00335 / b EN / 2023-08-07

13
6.1.2 Bypass function
The Adjustable Energy series has an internal bypass whose opening can be manually adjusted from the outside using a
knurled nut.
The adjustment of the additional throttle cross-section allows the product to be used over the entire speed range. This is
only possible for products from the Mini Energy, Standard Energy and High Energy series using preset degrees of
hardness.
Level 0
The bypass is completely closed. Closed position Open position
0% flow 100% flow
Thisallowsthemaximumenergyabsorptioninthespeedrangeofthe
Hard (H) degree of hardness.
Levels 1–4
The bypass is partially open.
For softer damping operations, as higher speeds are approached or for
lower energy absorption levels, the bypass must be opened.
Level 5
The bypass is completely open.
Using this setting, the highest speed or the lowest speed is possible.
It is not possible to assign a degree of hardness from stage 0–5.
6.2 Ambient temperature
The force of the product and thus the shock absorber characteristic curve and energy absorption depend on the viscosity
and density of the oil and thus on the ambient temperature.
• At lower ambient temperatures, the viscosity and density of the oil increase, which can result in higher forces and energy
absorption levels per stroke.
• The low ambient temperature can be counteracted due to the heating of the product as a result of damping using a
corresponding cycle time in continuous operation.
• At higher ambient temperatures, the viscosity and density of the oil decrease, which can result in lower forces and lower
maximumenergyabsorptionperstroke.
6.3 Energy absorption per hour
NOTICE
Material damage from overheating of the product
►Makesurethattheenergyabsorptionperhourdoesnotexceedthemaximumenergyabsorption.
The energy absorption per hour at which the product is placed under load results from the energy absorption per stroke
and the cycle time in continuous operation.
INSTALLATION AND OPERATING INSTRUCTIONS:PowerStop
DDOC00335 / b EN / 2023-08-07
ZimmerGmbH•ImSalmenkopf5•77866 Rheinau, Germany • [phone] • www.zimmer-group.com

14
6.4 Operation modes
6.4.1 Continuous operation
Continuous operation represents continuous loading of the product with a certain number of cycles per unit of time.
This results in the product heating up, which yields a certain operating temperature prevailing from the thermal balance
between heat absorption due to damping and heat dissipation to the surroundings.
NOTICE
Malfunction in case of non-compliance
►When the system is at a standstill, make sure that the product does not remain in the actuated state in order to
ensurethattheproductcanberesettothestartingpositionwiththepistonrodextended.
NOTICE
Non-compliance may result in material damage.
►Ensuresu󹱺cientheatdissipationsothattheproductdoesnotheatupabovethepermittedmaximum
temperature.
6.4.2 Emergency stop operation
INFORMATION
►Please note that several products can absorb higher energy per stroke in emergency stop operation.
In emergency stop operation, the product is only used in emergencies, e.g. a failure of the machine control system.
Emergencystopoperationcancauseirregularloadingoftheproductatunpredictableintervals.
6.5 Impact angle
The impact angle results from the angular deviation between the movement of the impacting mass and the piston rod of the
product. In cases with rotational loads, the distance of the product to the instant center plays an important role. In addition,
incaseofrotationalmovements,thepositionoftheswivelingcomponenttobedampedcaninuencetheimpactanglein
the impact point and in the end position.
INFORMATION
Theproductisapprovedforamaximumimpactangle,whichlimitsthemaximumlateralforcesactinguponit.
►Pleasenotethatasideloadadaptermustbeinstalledifthemaximumpermittedimpactangleisexceeded.
►For more information, refer to the "Installing the side load adapter (PBV)" section.
ZimmerGmbH•ImSalmenkopf5•77866 Rheinau, Germany • [phone] • www.zimmer-group.com
INSTALLATION AND OPERATING INSTRUCTIONS:PowerStop
DDOC00335 / b EN / 2023-08-07

15
7 Technical data
The technical data is determined under laboratory conditions.
►For more information, refer to the "Service life" section.
INFORMATION
►Youcanndtheinformationinthetechnicaldatasheetonourwebsite.
Thisdatavarieswithintheseries,dependingonthespecicdesign.
►Please contact Customer Service if you have any questions.
INFORMATION
►Please note that the manual adjustability of the function parameters must be taken into account for products
from the Adjustable Energy series.
INFORMATION
Thespeciedtechnicaldataapplytoanambienttemperatureof20–25°C.
►PleasecontactCustomerServiceforhelpdesigningtheproductforambienttemperaturesof<0°Cand>
40°C.
INSTALLATION AND OPERATING INSTRUCTIONS:PowerStop
DDOC00335 / b EN / 2023-08-07
ZimmerGmbH•ImSalmenkopf5•77866 Rheinau, Germany • [phone] • www.zimmer-group.com

16
8 Accessories
INFORMATION
If any accessories not sold or authorized by Zimmer GmbH are used, the function of the product cannot be
guaranteed.ZimmerGmbHaccessoriesarespecicallytailoredtotheindividualproducts.
►For optional accessories and those included in the scope of delivery, refer to our website.
9 Transportation/storage/preservation
►Transport and storage of the product must be done only with the original packaging.
►If the product has already been installed on the superordinate machine unit, care must be taken during transport to
ensurethatnounexpectedmovementscanoccur.
►Before commissioning the product and after transport, check all power and communication connections as well as
all mechanical connections.
►Iftheproductisstoredforanextendedperiod,thefollowingpointsaretobeobserved:
►Keep the storage location as dust-free and dry as possible.
►Avoidtemperatureuctuations.
►Avoid wind/drafts/water condensation formation.
►Packtheproductanddonotexposeittodirectsunlightduringstorage.
►Remove all foreign substances.
ZimmerGmbH•ImSalmenkopf5•77866 Rheinau, Germany • [phone] • www.zimmer-group.com
INSTALLATION AND OPERATING INSTRUCTIONS:PowerStop
DDOC00335 / b EN / 2023-08-07

17
10 Installation
WARNING
Risk of injury due to uncontrolled movements
Riskofinjuryincaseofunexpectedmovementofthemachineorsystemintowhichtheproductistobeinstalled.
►Switch off the energy supply of the machine before any work.
►Secure the power supply against being switched on unintentionally.
►Check the machine for any residual energy that may be present.
CAUTION
Risk of injury in case of non-compliance
►Please note that the product has sharp edges and corners.
ÖContact can result in injuries.
►Wear suitable protective equipment.
NOTICE
Installationmayonlybecarriedoutbyqualiedpersonnelinaccordancewiththeseinstallationandoperating
instructions.
►Switch off the power supply before any assembly, installation or maintenance work.
►Makesurethatthemountingpieceissu󹱺cientlyrigid.
►Comply with the tightening torques of the mounting screws.
►Verify the permitted load capacity of the required screw connections in accordance with VDI 2230.
►Whentighteningthelocknut,adheretothespeciedtighteningtorquewithamaximumdeviationof±10%.
►Pleasenotethattheangulardeviationbetweentheproductandtheweighttobedampedmustnotexceedthemaximum
impact angle.
INFORMATION
Furtherinstallationinformation:
• The lock nut is included in the scope of delivery.
• Aclampangecanbeusedasanalternativeforinstallation.
INSTALLATION AND OPERATING INSTRUCTIONS:PowerStop
DDOC00335 / b EN / 2023-08-07
ZimmerGmbH•ImSalmenkopf5•77866 Rheinau, Germany • [phone] • www.zimmer-group.com

18
10.1 Installing the product
10.1.1 Installing Mini Energy, Standard Energy, High Energy
►Install the product at the desired position on
the housing using the thread.
Mini Energy
12
Standard Energy/High Energy
12
►Positiontheproductwiththehexagonusing
ahexagonkey.
►Secure the product using the lock nut.
1Hexagonkey
2Lock nut
10.1.2 Installing Adjustable Energy
►Install the product at the desired position on
the housing using the thread.
2
1
►Positiontheproductwiththehexagonusing
ahexagonkey.
►Secure the product using the lock nut.
1Hexagonkey
2Lock nut
ZimmerGmbH•ImSalmenkopf5•77866 Rheinau, Germany • [phone] • www.zimmer-group.com
INSTALLATION AND OPERATING INSTRUCTIONS:PowerStop
DDOC00335 / b EN / 2023-08-07

19
10.1.3 Setting Adjustable Energy
NOTICE
Non-compliance may result in material damage.
If the product setting is too soft, the energy is not entirely absorbed.
Iftheproductsettingistoohard,bouncingandexcessiveforcesmayresult.
►Observetheprocedureforsettingtheproduct.
►Adjust the product accordingly for the energy load.
NOTICE
Material damage and malfunction in case of non-compliance
If the load of the product cannot be adapted iteratively while the system is being started up, it is necessary to
select a level for the start.
►Level5isnotrecommendedforthestart.
ÖIncomplete energy absorption can cause damage to the system.
►Pleasenotethefollowinginformationwhenstartingwithlevel0:
ÖThereisadangerthattheproductwillrespondwithexcessiveforce,whichcancausedamagetothe
product.
ÖAnoverloadofthestructureispossible.Theriskofdamagetothesystemislessforlevel0thanforlevel5.
►At the beginning, avoid any cycle time over multiple cycles until you have determined the optimum setting.
►Loosen the countersunk screw.
ÖThis enables the knurled nut to move.
1
►Use the knurled nut to set the desired
damping.
►Secure the knurled nut using the
countersunk screw.
►Tighten the countersunk screw hand-tight.
ÖThe product cannot be adjusted any more
during operation.
1Knurled nut
►Start with a load on the product that is as low as possible.
►Increase the load gradually until the actual operating point of the system is reached.
►Adjust the settings of the product iteratively.
INSTALLATION AND OPERATING INSTRUCTIONS:PowerStop
DDOC00335 / b EN / 2023-08-07
ZimmerGmbH•ImSalmenkopf5•77866 Rheinau, Germany • [phone] • www.zimmer-group.com

20
10.1.4 Setting the stroke and xed stop
NOTICE
Non-compliance may result in material damage.
If the stroke is reduced too much, the product and mounting piece are loaded with the residual energy.
►Makesurethatthestrokeissu󹱺cientforthecompleteabsorptionoftheenergyoftheimpact.
NOTICE
Malfunction in case of non-compliance
Makesurethatahublimitof<50%relativetothemaximumstrokeismaintained.
ÖThis will avoid worsened return behavior of the piston rod.
NOTICE
Non-compliance may result in material damage.
Iftheintegratedxedstopoftheproductisusedincontinuousoperation,thiscanreducetheservicelife.
►Incontinuousoperation,useanexternalxedstop.
ÖThis reduces the product load.
Thefollowingproductvariantshaveanintegratedxedstop.Here,thebottomoftheheadmovestothexedstopofthe
product.
IntheShortpistonrodnoheadvariant,thebrakedcomponentsitsonthexedstopafterthemaximumstrokehasbeen
reached.Thistakesplaceunderconsiderationofthemaximumforcesspeciedinthecatalog.
Short piston rod no head (D) Steel head (S)
#P01#B7100#FA#
Plastic head (K)
INFORMATION
►Useanexternalxedstoptosetthedampingstroke.
ÖAs a result, the energy absorption of the product is limited to the necessary stroke. Under some circum-
stances, this can save time compared to the full stroke.
Externalxedstopsfortheversionwithoutbellowsusingaccessories:
• Stop sleeve
• Sensor stop sleeve
Externalxedstopsusingthemountingpiece:
• Embedding in the mounting piece
• Adjusting a stop screw
ZimmerGmbH•ImSalmenkopf5•77866 Rheinau, Germany • [phone] • www.zimmer-group.com
INSTALLATION AND OPERATING INSTRUCTIONS:PowerStop
DDOC00335 / b EN / 2023-08-07
