Zip HYDROCHILL HC10 Series Manual

1
INSTALLATION INSTRUCTIONS & USER MANUAL
T210012 V1.00 FEB 2018 -ZIP HYDROCHILL 10
TECHNICAL SUPPORT TEL: [phone] EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
ZIP
HYDROCHILL
INSTALLATION INSTRUCTIONS & USER MANUAL
MODEL NUMBER:
HC10 range
High capacity chiller systems

2
INSTALLATION INSTRUCTIONS & USER MANUAL
T210012 V1.00 FEB 2018 -ZIP HYDROCHILL 10
TECHNICAL SUPPORT TEL: [phone] EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
PRECAUTIONS AND GENERAL RECOMMENDATIONS
TABLE OF CONTENTS
Precautions and recommendations....................................................................... 2
Before installing the HydroChill ............................................................................ 3
Product approvals & product description.............................................................. 4
Technical features ................................................................................................ 5
Technical data .................................................................................................... 10
Installation ........................................................................................................... 11
General CO2 cylinder safety guidelines ............................................................. 17
Filtration (inc.Ultra violet (UV) filtration)............................................................... 18
Sanitisation.......................................................................................................... 20
Maintenance........................................................................................................ 21
Safeguarding the environment ............................................................................ 22
Warranty.............................................................................................................. 23
Contact details..................................................................................................... 24
• Appliance for internal use only.
Place the unit away from water
jets.
• Always connect the water cooler
to a water main that supplies
wholesome drinking water only.
• Before each installation, the unit
must be sanitized by an authorized technician.
• After installation, ensure that the unit is not resting on the power cable.
• Check that the unit is level and that it is resting on a surface with sufcient
load bearing capacity, in an environment that is suitable for its dimensions
and its use.
• Before any maintenance or cleaning operation is carried out, remove the plug
from the socket or disconnect the power supply.
• Ensure that the product is not sited close to sources of heat.
• To guarantee adequate ventilation, leave at least 10 cm of space around the
unit.
• Install the product in a clean, dry, well-ventilated environment. The product
is designed to function in environments with a temperature range of between
5°C and 32°C - Climate Class N.
• Take care not to damage the cooling uid circuit: it is lled with R290, which
is a highly ammable gas. It is essential to ensure that the tubes of the
refrigerant circuit are not damaged.
• Ensure that it is possible to disconnect the power supply either by removing
the plug or via a two-pole circuit-breaker, with a contact separation of at least
!

3
INSTALLATION INSTRUCTIONS & USER MANUAL
T210012 V1.00 FEB 2018 -ZIP HYDROCHILL 10
TECHNICAL SUPPORT TEL: [phone] EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
PRECAUTIONS AND GENERAL RECOMMENDATIONS
3mm in all poles.
• The Appliance must be protected by an RCD or RCBO.
• Check that the voltage shown on the serial number plate corresponds to the
voltage being supplied at the installation site.
• The unit must not be cleaned with a water jet. Do not position other electrical
equipment in the immediate vicinity of the water cooler.
• Turn off the main water inlet tap if the unit is not to be used for a long period.
• Keep the areas surrounding the unit dry to avoid the risk of people slipping.
• CO2: You can have serious health problems if breathing air containing
concentrations of CO2up to 15000ppm (1.5%) for more than 10 minutes.
Proper ventilation must be provided to ensure that, in case of escape,
concentrations of CO2remain below this level.
• If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualied person in order to avoid a hazard
• Do not use extension leads or adapters.
• This appliance is intended to be used by persons (including children
aged from 8 years) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, provided that they
have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the
appliance.
• The appliance is only to be installed in locations where it can be
overseen by trained personnel.
• This equipment is to be installed in compliance with the local plumbing
regulations.
• Water pipe connections and xtures directly connected to a wholesome
(cat 1) water supply shall be sized, installed, and maintained in
accordance with federal, state, and local codes.
• This publication is based on information available when approved for printing.
• Continuing design renements could cause changes that may not be included
in this publication.
BEFORE INSTALLING THE HYDROCHILL
• Congratulations for choosing a HydroChill product.
• We have designed and manufactured this product with great care to ensure
that it will dispense water of the highest quality.
• In order to get the most out of your water cooler, please read the instructions
in this manual and retain the manual for future reference.

4
INSTALLATION INSTRUCTIONS & USER MANUAL
T210012 V1.00 FEB 2018 -ZIP HYDROCHILL 10
TECHNICAL SUPPORT TEL: [phone] EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
APPROVALS
This water cooler is designed, manufactured and marketed in compliance with:
• The safety objectives of the Machinery Directive 2006/42/C
• The protection requirements of the Electromagnetic Compatibility Directive
2014/30/EU.
The electrical safety of the product is ensured only when it is properly connected
to an efcient, legally compliant grounding circuit.
PRODUCT DESCRIPTION
Compact, powerful and entirely made of stainless steel, HydroChill HC10
is the smallest cooler of the range: perfect for your home and ofce, with
professional performance.
The main features of the unit are as
follows:
DRY COOLING technology:
a noiseless, low maintenance and
innovative system, allowing you to get
great performances in a small size.
High quality stainless steel buttons,
wear resistant and easy to use.
3 dispensing options: ltered chilled
water, ltered ambient temperature
water, ltered ,sparkling water (model
dependant).
Modern and compact design in strong
stainless steel.
Fast and easy installation for home and
ofce usage
Filtration: on request, a UV lamp can be
placed on the dispensing point.

5
INSTALLATION INSTRUCTIONS & USER MANUAL
T210012 V1.00 FEB 2018 -ZIP HYDROCHILL 10
TECHNICAL SUPPORT TEL: [phone] EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
TECHNICAL FEATURES
Stainless steel buttons
Drip tray with grid
Detachable water dispensing
nozzle
1
2
3
1
2
3
Front of product
Explanation of HydroChill range product code
HC HydroChill
Range
Product group
10 range
20 range
50 range
C Chilled only
* Chilled sparkling
*T* Dispensing tap
IT* Buttons
BIT Bridge
XX
HC X XXX XXX
Dispensing tap
2A 2 Tap
2P 2 Tap + badge
3A 3 Tap
3P 3 Tap + badge
** None
Control
Conguration
XXX
U With UV
* Without UV
UV FILTRATION
Capacity (l)
30
60
80
150
280
Example
HC50CBITU280 Is a HC50, chilled only, bridge tap, with UV, 280 lire capacity.
* digit suppressed in product code.

6
INSTALLATION INSTRUCTIONS & USER MANUAL
T210012 V1.00 FEB 2018 -ZIP HYDROCHILL 10
TECHNICAL SUPPORT TEL: [phone] EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
TECHNICAL FEATURES - REAR
Slide cover
IEC outlet power cable
Power button
Drinking water inlet pipe joint Ø5/16” (8mm)
CO2inlet pipe joint Ø5/16” (8mm)
Adjustable thermostat
Support feet
30 model 45 model
1
6
2
3
4
5
7
1
2
3
4
5
6
7
Rear of product

7
INSTALLATION INSTRUCTIONS & USER MANUAL
T210012 V1.00 FEB 2018 -ZIP HYDROCHILL 10
TECHNICAL SUPPORT TEL: [phone] EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
TECHNICAL FEATURES
Rating plate
Class N
Made in ItalySerial no.
PRODUCT
230V ~ 50 Hz KW A
RoHS
COMPLIANT
2011/65/EU
Wholesome
water only
GAS g
(situated on the back
of product)
Class N
Made in ItalySerial no.
PRODUCT
230V ~ 50 Hz KW A
RoHS
COMPLIANT
2011/65/EU
wholesome
water only
GAS g
Product identifying
part number
Supply voltage
Unique product
serial number
Refrigerant gas
type & weight
Conformity to EU product
directives
Power rating Current rating
Conformity to EU
environmental
directives
Climate class
Country of origin
Water supply
requirements

8
INSTALLATION INSTRUCTIONS & USER MANUAL
T210012 V1.00 FEB 2018 -ZIP HYDROCHILL 10
TECHNICAL SUPPORT TEL: [phone] EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
TECHNICAL FEATURES - DISPENSING BUTTONS
Filtered chilled water
Filtered sparkling water (model specic)
Filtered ambient water
1
2
3
1 2 3
Operation of dispensing buttons - press to dispense

9
INSTALLATION INSTRUCTIONS & USER MANUAL
T210012 V1.00 FEB 2018 -ZIP HYDROCHILL 10
TECHNICAL SUPPORT TEL: [phone] EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
TECHNICAL FEATURES
30 model
45 model
Dimensions (sparkling model shown for ref. only)
57
499
261
418 276
28
57
499
318
470
329
28

10
INSTALLATION INSTRUCTIONS & USER MANUAL
T210012 V1.00 FEB 2018 -ZIP HYDROCHILL 10
TECHNICAL SUPPORT TEL: [phone] EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
TECHNICAL DATA
Technical Data Sheet 30 45
Cooling capacity 30 lt/h 45 lt/h
Continuous supply 6 lt 12 lt
Cold water temperature 5 - 12°C *
Cooling technology Aluminium fusion block heat exchanger
Cold Water Coil Stainless Steel AISI 316
Pump Professional membrane carbonation pump
Condensation Ventilated
Adjustable Thermostat Yes
Refrigerant gas R290
Supply 230 V - 50 Hz
Compressor power 1/8 HP 1/5 HP
Watt 230 W - 1 A 300 W - 1,3 A
Inlet water Pipe Ø 8 mm (5/16”)
Inlet water pressure 2.5 bar (0.25 MPa) - 3.5 bar (0.35 MPa)
Inlet CO2Pipe Ø 8 mm (5/16”)
Dispensing area height 280 mm 331 mm
Dimensions LxDxH
(mm) 261x499x418 318x499x470
Packaging dimensions
LxDxH (mm) 310x540x470 390x590x540
Net weight (kg) 28 31
Gross weight (kg) 31 35
* Rated at a room temp. of 25°C and inlet water temp. of 20°C
For the technical data of other models, examine the rating plate attached to each product.

11
INSTALLATION INSTRUCTIONS & USER MANUAL
T210012 V1.00 FEB 2018 -ZIP HYDROCHILL 10
TECHNICAL SUPPORT TEL: [phone] EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
INSTALLATION
Unpacking
• Remove the HydroChill from the box and remove the inner packing.
• In 30 model, the packaging can be
easily moved by the handles on the
two sides of the box (see 1, Fig 1).
• Once you have unpacked the
unit,ensure that it is not damaged. You
must inform the reseller about any
damages as soon as possible after
delivery.
• If the unit has been shipped
horizontally or at an angle, it will be
necessary to wait at least 8 hours
before setting it up, in order to allow
the cooling circuit to reset itself.
• Ensure that the unit is installed and
connected to the main supply by a
qualied technician in compliance with the manufacturer’s instructions and the
local safety guidelines.
Note there are no user serviceable part
inside the HydroChill.
1
Fig 1
Fig 2

12
INSTALLATION INSTRUCTIONS & USER MANUAL
T210012 V1.00 FEB 2018 -ZIP HYDROCHILL 10
TECHNICAL SUPPORT TEL: [phone] EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
INSTALLATION
1
Siting the product
• Wear safety gloves when handling the
unit.
• The unit must be handled by two people.
• Site the unit away from sources of heat.
• Do not place on inclined surfaces. Leave
at least 10cm around the unit to allow for
ventilation.
Sanitise the product as described in the
paragraph on page 20. Fig 3
Water supply connection kit
Line counter
Ø8mm - Ø1/4”
coupler
1/4” pipe Ø8mm pipe
Filter head
1/4” stem elbow for tight
radius lter head connections
Water block
15mm to 1/2”
coupler
1/2” BSP - 1/4”
push t
Fig 4

13
INSTALLATION INSTRUCTIONS & USER MANUAL
T210012 V1.00 FEB 2018 -ZIP HYDROCHILL 10
TECHNICAL SUPPORT TEL: [phone] EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
INSTALLATION
Water supply connection detail, assembled
Incoming cold
mains water
supply
Isolation valve
(not supplied)
Water block
15mm to 1/2”
coupler
1/2” BSP - 1/4”
push t
Filter head
Filter
(supplied)
Line counter
1/4” pipe Ø8mm pipe
To HydroChill
Ø8mm - Ø1/4”
coupler
Fig 5

14
INSTALLATION INSTRUCTIONS & USER MANUAL
T210012 V1.00 FEB 2018 -ZIP HYDROCHILL 10
TECHNICAL SUPPORT TEL: [phone] EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
Connection to the mains water supply
!
• To connect the HydroChill to the mains
water supply, always use a new set of
connectors, pipes & ttings.
• Mains water pressure limits, see
Technical data page 10.
• To enhance the quality of the sparkling
water dispensed, an incoming ow rate
in excess of 3.5 l/min is recommended.
• Connect incoming water tube (1above)
to the drinking-water main, ideally with a
tap upstream of the HydroChill.
• Connect the drip tray (provided closed
- 2) to a drainage pipe, drill out, max.
Ø7mm (2) and inserting a pipe on the
drain connection Ø10 (3) located below
the machine.
• HydroChill models are equipped with a non-return valve combined in the
water block.
• Once the pipes are attached, turn on the tap. Ensure there are no leaks.
• Before drinking the water from the system, perform a thorough rinse of the
circuit by dispensing water from each product line.
WARNING (also see
precautions pages 2 & 3) 2
INSTALLATION
3
Fig 6
Fig 7

15
INSTALLATION INSTRUCTIONS & USER MANUAL
T210012 V1.00 FEB 2018 -ZIP HYDROCHILL 10
TECHNICAL SUPPORT TEL: [phone] EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
INSTALLATION
Electrical connection
Fig 9
Fig 10
• The connections must comply with
local regulations.
• The HydroChill must be earthed.
• Connect the power cord to the IEC
inlet (1) and to a socket.
• Turn the unit on by selecting the “I”
position on the main on/off rocker
switch (2).
• The compressor and fan are now
activated.
• On the sparkling models, the
carbonator pump is also activated.
• Press the “Sparkling Water” button
on the right of the keypad (4) in order
to release any air in the circuit and to
allow the pump to ll the carbonator
with water.
• After around 1-2 minutes, the
sparkling water pump stops.
1
2
3
4
Fig 11
Thermostat
• The thermostat (3) is set in the
maximum position to control the
water temperature.
• Turn the thermostat screw to
adjust the water temperature.

16
INSTALLATION INSTRUCTIONS & USER MANUAL
T210012 V1.00 FEB 2018 -ZIP HYDROCHILL 10
TECHNICAL SUPPORT TEL: [phone] EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
INSTALLATION
Installing the CO2cylinder (sparkling models)
(Not supplied by Zip)
Fig 12
Fig 13
Fig 14
1
2
4
3
• The area must be properly
ventilated.
• The CO2cylinder must be used
in a vertical position, and must be
restrained safely, to prevent it falling
over.
• Double check that the cylinder
is the correct CO2gas for this
application (see below).
• Once the unit is connected to the
mains water and electricity, you can
install the E290 food-grade carbon
dioxide (CO2) cylinder.
• Attach the regulator & CO2pipe to
the cylinder valve.
• Insert the CO2inlet tube from the
cylinder into the tting (1). Be sure
to remove any air in the hydraulic
circuit and to achieve a good level
of carbonation, before opening the
valve on the CO2cylinder pull the
ring of the remote safety valve (2)
until water comes out of it.
• When the cylinder is open, to
increase or decrease the level
of carbonation of the water, you
need to adjust the screw (3) on the
pressure reducer.
• Turning it clockwise increases the
level of carbonation.
• We recommend that you do not
exceed 4 bar of pressure (4).
• To achieve a good level of
carbonation, you need to wait until
the water is sufciently cold – i.e. at
least one hour after installation.
!
WARNING (also see precautions
pages 2 & 3)

17
INSTALLATION INSTRUCTIONS & USER MANUAL
T210012 V1.00 FEB 2018 -ZIP HYDROCHILL 10
TECHNICAL SUPPORT TEL: [phone] EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
CO2(SPARKLING MODELS)
General CO2cylinder safety guidelines
1
2
3
4
5
1Cap
2Valve connection
3Markings
4Shoulder
5Body
• All of the cylinders must be tted with a
valve protector cap, which must be on tight
at all times when the cylinder is not in use.
• The cylinders must be handled with care. It
is essential to avoid:
Clashes with other cylinders or surfaces;
dropping the cylinders; or
subjecting them to mechanical stress.
• All of the above may compromise their
integrity and resistance.
• The cylinders must not be lifted by the
cap, or dragged, rolled or slid along the
oor even if only being moved for short
distances.
• An appropriate hand cart or other suitable
means of transport should be used.
• Do not use magnetic lifters or slings with
rope.
!
WARNING (also see precautions
pages 2 & 3)
CO2connection (sparkling models)
CO2cylinder
(not supplied)
CO2regulator
Ø8mm pipe
To
HydroChill
Fig 15
Fig 16

18
INSTALLATION INSTRUCTIONS & USER MANUAL
T210012 V1.00 FEB 2018 -ZIP HYDROCHILL 10
TECHNICAL SUPPORT TEL: [phone] EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
FILTRATION
If the HydroChill is switched off for a long period of time
(e.g. more than a weekend), run water through the chilled
water outlet for at least 5 minutes before consumption.
Caution Water will drip as the cartridge is removed.
Do not tilt the cartridge as water may spill from it if
tilted.
• Isolate the water supply.
• Unpack replacement cartridge and remove sanitary
cap, write today’s date where shown on the label.
Avoid touching the lter o-rings and lter opening as
this may cause bacterial contamination of the cartridge.
• Moisten the o-rings with water, align the front cartridge
label to the left (as shown in the “insert lter” diagram
below), and push the new cartridge up into the lter
head.
• Turn the cartridge a quarter turn anticlockwise until
it comes to a complete stop and locks, with the front
label facing forward.
• Turn on the water supply.
• Flush the lter by dispensing chilled or ambient water
for 5 mins.
When completed, clean up and dispose of old cartridge
and packaging.
Remove lter
Insert lter
Rotate
Insert
!
WARNING
!
Filter removal, replacement & ush
Rotate
Pull
Fig 17

19
INSTALLATION INSTRUCTIONS & USER MANUAL
T210012 V1.00 FEB 2018 -ZIP HYDROCHILL 10
TECHNICAL SUPPORT TEL: [phone] EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
ULTRAVIOLET (UV) FILTRATION
!
WARNING
The light emitted by the ultraviolet lamp
may cause serious burns to the eyes and
skin.
Installation repair and maintenance shall
only be reformed by personnel qualied to
work on UV products.
Sterilizing UV lter
• Alongside the carbon lter, it is also possible
to have your water cooler tted with a UV-C
(λ=254 nm) sterilizing lter on the dispensing
point
• The UV-C light emitted by the special 4W
mercury vapour lamp is lethal for all micro-
organisms (bacteria, viruses, mould, algae,
etc.); for this reason, water treated with the UV-C sterilizer will be micro-
biologically pure.
Technical data
• Material AISI 304 and quartz tube
• Power rating 24V AC
• Power consumption 4Wh
• Maximum capacity of the lamp 9.000 h (max 12 months)
The UV sterilizer complies with European quality and safety guidelines.
Fig 18

20
INSTALLATION INSTRUCTIONS & USER MANUAL
T210012 V1.00 FEB 2018 -ZIP HYDROCHILL 10
TECHNICAL SUPPORT TEL: [phone] EMAIL: SERVICE@ZIPINDUSTRIES .CO.UK
WWW.ZIPWATER.CO.UK
SANITISATION
General guidelines
• The HydroChill should be sanitized at rst installation or
• When the hydraulic components are being replaced, or
• When the lter is being changed, or in any case at least once a year.
• This operation must be carried out by Zip qualied technical personnel who
have completed specic training courses on hygiene and sanitization.
