Ziton ZP2-AF1-S User manual

ZP2-A Series Operation
Manual
P/N 00-3281-505-2003-01 • ISS 05AUG22

Copyright
©
2022 Carrier. All rights reserved.
Trademarks and
patents
ZP2
-A Series is a trademark of Carrier.
Other trade names used in this
document may be trademarks or
registered trademarks of the manufacturers or vendors of the
respective products.
Manufacturer
Carrier Manufacturing Poland
Spółka Z o.o.
Ul. Kolejowa 24. 39
-100 Ropczyce, Poland.
Authorized EU manufacturing representative:
Carrier Fire & Security B.V.,
Kelvinstraat 7, 6003 DH Weert,
Netherlands.
Revision
01
Firmware
compatibility
This
publication covers control panels with firmware version 4.0 or
later.
Conformity
European Union
directives
2014/30/EU
(EMC Directive). Hereby, Carrier declares that this
device is in compliance with the essential requirements and other
relevant provisions of Directive
2014/30/EU.
2012/19/EU (WEEE
Directive): Products marked with this symbol
cannot be disposed of as unsorted municipal waste in the Eu
ropean
Union. For proper recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
recycleth
is.info.
2006/66/EC (
Battery Directive): This product contains a battery that
cannot be disposed of as unsorted municipal waste in the European
Union. See the product documentation for specific battery
information. The battery is marked with this symbo
l, which may
include lettering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the battery to your supplier or to a
designated collection point. For more information see:
recyc
lethis.info.
Contact information
and product
documentation
For contact information or to download the latest product
documentation, visit
firesecurityproducts.com.

ZP2-A Series Operation Manual i
Content
Important information ii
Limitation of liability ii
Product warnings and disclaimers ii
Advisory messages iii
Introduction 1
Firmware compatibility 1
Product range 1
Product overview 3
The user interface 3
Front panel controls and indicators 6
LCD controls and indicators 11
Acoustic indicators 13
Conditions 14
Status indications 15
Control panel operation 19
User levels 19
Operation controls and procedures 21
Public level operation 22
Operator level operation 25
Maintenance 31
Menu maps 32
Regulatory information 33

ii ZP2-A Series Operation Manual
Important information
Limitation of liability
To the maximum extent permitted by applicable law, in no event will Carrier be
liable for any lost profits or business opportunities, loss of use, business
interruption, loss of data, or any other indirect, special, incidental, or
consequential damages under any theory of liability, whether based in contract,
tort, negligence, product liability, or otherwise. Because some jurisdictions do not
allow the exclusion or limitation of liability for consequential or incidental
damages the preceding limitation may not apply to you. In any event the total
liability of Carrier shall not exceed the purchase price of the product. The
foregoing limitation will apply to the maximum extent permitted by applicable law,
regardless of whether Carrier has been advised of the possibility of such
damages and regardless of whether any remedy fails of its essential purpose.
Installation in accordance with this manual, applicable codes, and the instructions
of the authority having jurisdiction is mandatory.
While every precaution has been taken during the preparation of this manual to
ensure the accuracy of its contents, Carrier assumes no responsibility for errors
or omissions.
Product warnings and disclaimers
THESE PRODUCTS ARE INTENDED FOR SALE TO AND INSTALLATION BY
QUALIFIED PROFESSIONALS. CARRIER FIRE & SECURITY B.V. CANNOT
PROVIDE ANY ASSURANCE THAT ANY PERSON OR ENTITY BUYING ITS
PRODUCTS, INCLUDING ANY “AUTHORIZED DEALER” OR “AUTHORIZED
RESELLER”, IS PROPERLY TRAINED OR EXPERIENCED TO CORRECTLY
INSTALL FIRE AND SECURITY RELATED PRODUCTS.
For more information on warranty disclaimers and product safety information,
please check https://firesecurityproducts.com/policy/product-warning/ or scan the
QR code:

ZP2-A Series Operation Manual iii
Advisory messages
Advisory messages alert you to conditions or practices that can cause unwanted
results. The advisory messages used in this document are shown and described
below.
WARNING: Warning messages advise you of hazards that could result in injury
or loss of life. They tell you which actions to take or to avoid in order to prevent
the injury or loss of life.
Caution: Caution messages advise you of possible equipment damage. They tell
you which actions to take or to avoid in order to prevent the damage.
Note: Note messages advise you of the possible loss of time or effort. They
describe how to avoid the loss. Notes are also used to point out important
information that you should read.

iv ZP2-A Series Operation Manual

ZP2-A Series Operation Manual 1
Introduction
This is the operation manual for the ZP2-A Series fire alarm, repeater, and
evacuation control panels. Read these instructions and all related documentation
entirely before operating this product.
Firmware compatibility
Information in this document covers control panels with firmware version 4.0 or
later. This document must not be used as a guide to operation of control panels
with an earlier firmware version.
To check the firmware version of your control panel, see the Revision report in
the Reports menu. For more information, see “Viewing reports” on page 28.
Product range
The ZP2-A Series includes control panels with the following power options:
• Small cabinet control panels with up to 4 A output
• Large cabinet control panels with up to 6 A output
• Large cabinet control panels with up to 10 A output (-P variants)
The complete range of control panels is shown in the following tables.
Table 1: Small cabinet control panels with up to 4 A output
Model
Description
ZP2
-AF1-S One-loop addressable fire alarm control panel
ZP2
-AF1-FB-S One-loop addressable fire alarm control panel with fire routing and fire
protection controls
ZP2
-AF2-S Two-loop addressable fire alarm control panel
ZP2
-AF2-FB-S Two-loop addressable fire alarm control panel with fire routing and fire
protection controls
ZP2
-AFR-S Addressable fire alarm repeater panel
ZP2
-AFR-FB-S Addressable fire alarm repeater panel with fire routing and fire
protection controls
Table 2: Large cabinet control panels with up to 6 A output
Model
Description
ZP2
-AE1 One-loop addressable fire and evacuation alarm control panel
ZP2
-AF1 One-loop addressable fire alarm control panel
ZP2
-AF1-FB One-loop addressable fire alarm control panel with fire routing and fire
protection controls
ZP2
-AE2 Two-loop addressable fire and evacuation alarm control panel
ZP2
-AF2 Two-loop addressable fire alarm control panel

2 ZP2-A Series Operation Manual
Model
Description
ZP2
-AF2-K Two-loop addressable fire alarm control panel [1]
ZP2
-AF2-PRT Two-loop addressable fire alarm control panel with internal printer
ZP2
-AF2-FB Two-loop addressable fire alarm control panel with fire routing and fire
protection controls
ZP2
-AF2-FB-PRT Two-loop addressable fire alarm control panel with fire routing and fire
protection controls and internal printer
ZP2
-AFR Addressable fire alarm repeater panel
ZP2
-AFR-FB Addressable fire alarm repeater panel with fire routing and fire
protection controls
[1] Includes a fireman's key.
Table 3: Large cabinet control panels with up to 10 A output (-P variants)
Model
Description
ZP2
-AF2-P Two-loop addressable fire alarm control panel
ZP2
-AF2-PRT-P Two-loop addressable fire alarm control panel with internal printer
ZP2
-AF2-FB-P Two-loop addressable fire-P alarm
control panel with fire routing and fire
protection contrFols
ZP2
-AF2-FB-PRT-P Two-loop addressable fire alarm control panel with fire routing and fire
protection controls and internal printer
Repeater functionality
All control panels in a fire network can be configured for repeater functionality,
provided that they have a network board installed.
For more information on this feature, contact your installation or maintenance
contractor.
Fire routing and fire protection control and indication
In this document, information on control and indication for fire routing and fire
protection applies only to control panels that include those features.

ZP2-A Series Operation Manual 3
Product overview
This topic provides an introduction to the control panel user interface, LCD,
operator controls, and indicators.
For a detailed overview of front panel controls and indicators, see “Front panel
controls and indicators” on page 6.
The user interface
Figure 1: Fire panel user interface (with fire routing and fire protection controls)
1
. Supply LED
2
. General Test LED
3
. General Disable LED
4
. General Fault LED
5
. Alarm LED
6
. LCD
7
. Sounder Delay button and LED
8
. Sounder Fault/Disabled/Test LED
9
. Programmable output group start/stop
button and LED
10
. Jog dial and function buttons
11
. Reset button and LED
12. Panel Silence button and LED
13. Sounder Start/Stop Button and LED
14. System Fault LED
15. Low Battery LED
16. Earth Fault LED
17. Supply Fault LED
18. Fire Protection Fault/Disabled/Test LED
19. Fire Protection Delay button and LED
20. Fire Protection On/Acknowledged button
and LED
21. Fire Routing Fault/Disabled/Test LED
22. Fire Routing Delay button and LED
23. Fire Routing On/Acknowledged button and
LED
Note: For more information on the operations associated with programmable
buttons, contact your installation or maintenance contractor.

4 ZP2-A Series Operation Manual
Figure 2: Evacuation panel user interface
1
. Supply LED
2
. General Test LED
3
. General Disable LED
4
. General Fault LED
5
. Alarm LED
6
. LCD
7
. Sounder Delay button and LED
8
. Sounder Fault/Disabled/Test LED
9
. Confirm button
10
. All Output Groups Start/Stop Button and
LED
11
. Programmable output group start/stop
buttons and LEDs
12
. Jog dial and function buttons
13. Reset button and LED
14. Panel Silence button and LED
15. Sounder Start/Stop Button and LED
16. System Fault LED
17. Low Battery LED
18. Earth Fault LED
19. Supply Fault LED
20. Fire Protection Fault/Disabled/Test LED
21. Fire Protection Delay button and LED
22. Fire Protection On/Acknowledged button
and LED
23. Fire Routing Fault/Disabled/Test LED
24. Fire Routing Delay button and LED
25. Fire Routing On/Acknowledged button and
LED
Note: For more information on the operations associated with programmable
buttons, contact your installation or maintenance contractor.

ZP2-A Series Operation Manual 5
Configuration options
Depending on your configuration, the labels for some interface buttons may
change. See Table 4 below.
Table 4: Configured changes to interface buttons and LEDs
Item
EN 54 NEN 2575
10
All Output Groups Start/Stop All Evacuation Start/Stop
11
Programmable output group start/stop Evacuation area sounders start/stop
15
Sounder Start/Stop Fire Sounder Start/Stop

6 ZP2-A Series Operation Manual
Front panel controls and indicators
Operational features described in this section are not available to all users. More
information on control panel operation and access restrictions can be found in
the topic “User levels” on page 19.
Common controls and indicators
The table below includes information for the common controls and indicators
available for fire, repeater, and evacuation panels.
Table 5: Common controls and indicators
Control/LED
LED colour Description
Supply LED Green Indicates that the system is powered up.
General Test LED Yellow Indicates that one or more features or devices are
being tested.
General Disable LED Yellow Indicates that one or more features or devices are
disabled.
General Fault LED Yellow Indicates a general fault. The fault LED for the
corresponding device or feature also flashes.
Alarm LED Red Indicates a fire alarm.
A flashing LED indicates that the alarm was
activated by a detector. A steady LED indicates that
the alarm was activated by a manual call point.
Fire Routing
On/Acknowledged button
and LED
Red Cancels a previously configured delay as it counts
down and activates fire routing.
A flashing LED indicates that fire routing has been
activated. A steady LED indicates that the fire
routing signal has been acknowledged by the
remote monitoring equipment.
Fire Routing Delay button
and LED
Yellow Enables or disables a previously configured fire
routing delay. Cancels a delay as it counts down and
activates fire routing.
A steady LED indicates that a delay is configured
and enabled.
A flashing LED indicates that a delay is
counting (fire routing is activated when the
configured delay elapses or when the delay is
cancelled).
The countdown for an active (counting) fire routing
delay or extended fire routing delay is also displayed
on the product LCD (see Figure 3 on page 11):
• When a fire routing delay is counting (and has
not been extended), the LCD displays FR in T1:
xxx sec.
• When an extended fire routing delay is counting
(investigation time), the LCD displays FR in T2:
xxx sec.
Fire
Routing
Fault/Disabled/Test LED
Yellow Indicates a fire routing fault, disablement, or test.
A flashing LED indicates a fault. A steady LED
indicates a disablement or a test.

ZP2-A Series Operation Manual 7
Control/LED
LED colour Description
Fire Protection
On/Acknowledged button
and LED
Red Cancels a previously configured delay as it counts
down and activates fire protection.
A flashing LED indicates that fire protection has
been activated. A steady LED indicates that the fire
protection signal has been acknowledged by the
remote monitoring equipment.
Fire Protection De
lay button
and LED
Yellow Enables or disables a previously configured fire
protection delay. Cancels a delay as it counts down
and activates fire protection.
A steady LED indicates that a delay is configured
and enabled. A flashing LED indicates that a del
ay is
counting (fire protection is activated when the
configured delay elapses or when the delay is
cancelled).
Fire Protection
Fault/Disabled/Test LED
Yellow Indicates a fire protection fault, disablement, or test.
A flashing LED indicates a fault. A steady LED
indicates a disablement or a test.
Sounder Delay button and
LED
Yellow
Enables or disables a previously configured sounder
delay. Cancels a delay as it counts down and
activates sounders.
A steady LED indicates that a sounder delay is
configured and enabled. A flashing LED indicates
that a sounder delay is counting (sounders are
activated when the configured delay elapses or
when the delay is cancelled).
Sounder
Fault/Disabled
/Test LED
Yellow Indicates a sounder fault, disablement, or test.
A flashing LED indicates a fault. A steady LED
indicates a disablement or a test.
Programmable start/stop
button and LED
Yellow Starts or stops the output group associated with the
programmable button.
A steady yellow LED indicates that the output group
associated with the button is active. A flashing
yellow LED indicates that a delay is counting (the
output group is activated when the configured delay
elapses or when the delay is cancelled).
Supply Fault LED Yellow Indicates a power supply fault.
A flashing LED indicates a battery fault. A steady
LED indicates a mains or mains fuse fault.
Earth Fault LED Yellow Indicates an earth isolation fault.
Low Battery LED Yellow Indicates that the control panel is running on battery
power and that the remaining charge may be
insufficient to guarantee continued operation.
System Fault LED Yellow Indicates a control panel system failure or that one
or more reported events (alarm, zone alarm, fault,
condition, etc.) exceed the maximum limit of 512.
See “System Fault LED indication – maximum limit
for event type reporting” on page 10 for more
information.

8 ZP2-A Series Operation Manual
Control/LED
LED colour Description
Sounder Start/Stop
button and LED
Red
The LED indicates what happens when the button is
pressed:
If the LED is on (flashing or steady), pressing the
button silences the sounders.
If the LED is off, pressing the button activates the
sounders (if the control panel status and operating
mode allow manual activation of sounders).
The LED also indicates the status of the sounders:
•
Steady indicates that sounders are active (or will
be activated shortly)
• Flashing indicates that a delay is counting
(sounders are activated when the configured
delay elapses or when the delay is cancelled)
• Off indicates that the sounders are off (or will be
deactivated shortly)
To prevent the immediate silencing of sounders
when an alarm is first reported, the Sounder
Start/Stop button may be temporarily blocked when
a configured sounder delay is counting down. For
more information, see “Stopping sounders or
restarting stopped sounders” on page 26.
Depending on the size of the installation, processing
commands to start or stop sounders may take a few
seconds to travel through the system. This is why,
for example, the LED may be steady but sounders
may not initially be audible.
Panel Silence button and
LED
Yellow Silences the buzzer.
A steady LED indicates that the buzzer has been
silenced.
Reset button and LED Yellow Resets the control panel and clears all current
system events.
A steady LED indicates that the control panel can be
reset in the current access level.

ZP2-A Series Operation Manual 9
Evacuation panel controls and indicators
The table below includes information for the additional controls and indicators for
evacuation panels.
Note: If the evacuation panel is operating in NEN 2575 mode, only sounder
output groups can be associated with the programmable start/stop buttons.
Table 6: Evacuation panel controls and indicators
Control/LED
LED colour Description
Confirm button
Confirms the starting or stopping of the output group
associated with a programmable button (when pressed
with the corresponding programmable button).
Confirms the starting or stopping of all output groups
associated with all programmable buttons (when
pressed with the All Output Groups Start/Stop button).
All Output Groups
Start/Stop button and
LED
Red Starts or stops all output groups associated with the
programmable buttons (when pressed with the Confirm
button).
A steady red LED indicates that all output groups
associated with the buttons are active. A flashing red
LED indicates that a delay is counting (the output
groups are activated when the configured delay elapses
or when the delay is cancelled).
Programmable
start/stop buttons and
LEDs
Red/Yellow Starts or stops the output group associated with the
programmable button (when pressed with the Confirm
button).
A steady red LED indicates that the output group
associated with the button is active. A flashing red LED
indicates that a delay is counting (the output group is
activated when the configured delay elapses or when
the delay is cancelled).
A flashing yellow LED indicates a fault. A steady yellow
LED indicates a disablement or a test.

10 ZP2-A Series Operation Manual
Sounder, fire routing, and fire protection indications
The control panel may be configured by your installer to have several sounder,
fire routing, or fire protection groups. As groups of a single type may not always
share the same status, the front panel indications for the corresponding group
type display the general status for all groups. In the case of conflicting status, the
highest priority status is displayed.
Note: For evacuation panels, indications for operations associated with the
programmable buttons use the corresponding programmable button LEDs.
The following examples illustrate this operation.
There are three sounder groups, the first in fault status, the second in delayed
status, and the third in activated status. The sounder LED indications display the
fault status of the first group, the delay status of the second group, and the
activated status of the third group.
There are two fire routing groups, the first is in activated status and the second is
in acknowledged status. The fire routing indication displays the acknowledged
status but not the activation status (the acknowledgement status takes priority).
For more information on your control panel configuration and indications, contact
your installation or maintenance contractor.
System Fault LED indication – maximum limit for event type reporting
A maximum limit of 512 events applies to each type of reported event (alarm,
zone alarm, fault, condition, etc.). This limit applies at panel level and per system
(including repeater panels).
The control panel indicates a System Fault when one or more event types
exceed the maximum limit (the fire panel continues to operate during the System
Fault indication).
A “System Overload” event is added to the Event log when one or more event
type exceeds the maximum limit.
Reset the control panel to clear the System Fault indication and reset the event
limit (see “Resetting the control panel” on page 25).

ZP2-A Series Operation Manual 11
LCD controls and indicators
Figure 3: LCD controls and indicators
1. Day/night mode indicator
2. System date and time (and active fire routing delay or extended fire routing delay countdown)
3. Control panel network status (stand-alone, networked, repeater)
4. Current alarm, fault, and condition events counter
5. Message display area
6. Soft keys (menu options linked to function buttons F1, F2, F3, and F4)
7. Jog dial
8. Function buttons F1, F2, F3, and F4
9. Local control panel ID (in a fire network)

12 ZP2-A Series Operation Manual
Icons displayed on the LCD
Icons displayed on the LCD are shown below.
Table 7: LCD icons and descriptions
Icon
Description
Day mode (network)
This icon indicates that the primary sensitivity mode
setting for control panels in the fire network is day
mode.
Day mode (control panel)
This icon indicates that the sensitivity mode for the
local control panel is day mode. Other control panels in
the fire network may have a different sensitivity mode
setting.
Night mode (network)
This icon indicates that the primary sensitivity mode
setting for control panels in the fire network is night
mode.
Night mode (control panel)
This icon indicates that the sensitivity mode for the
local control panel is night mode. Other control panels
in the fire network may have a different sensitivity
mode setting.
Fire alarms [2]
The number beside this icon indicates the number of
zones with an active fire alarm. Alarm information for
the first and last zones to report an alarm is displayed
in the LCD message area.
Faults [2]
The number beside this icon indicates the number of
active faults. Additional information is available by
pressing F1 (Show Events).
Conditions [2]
The number beside this icon indicates the number of
active system conditions (events). Additional
information is available by pressing F1 (Show Events).
Stand-alone This icon indicates that the control panel is not
connected to the fire network.
Networked This icon indicates that the control panel is connected
to the fire network.
Repeater
This icon indicates that the control panel is configured
to operate as a repeater and is connected to the fire
network.
Detector alarm [1] This icon indicates a detector alarm.
Manual call point alarm [1] This icon indicates a manual call point alarm.

ZP2-A Series Operation Manual 13
Icon
Description
Manual call point alarm
(sprinkler) [1]
This icon indicates a manual call point alarm
(sprinkler).
Manual call point alarm
(“hausalarm”) [1]
This icon indicates a manual call point alarm
(“hausalarm”). This is a local alarm with no fire routing
activation.
[1] These icons appear in the message display area with the notification details.
[2]
A maximum limit of 512 events applies to each type of reported event. If one or more event
type exceeds the maximum limit, then a System Fault is indicated. See “
System Fault LED
indication – maximum limit for event type reporting” on page 10 for more information.
Indication of remote and local events on the LCD
The local control panel ID is always displayed on the LCD (see Figure 3 on page
11).
If your control panel forms part of a fire network, the event notification includes
the panel ID reporting the event as follows:
• If the panel ID matches the local ID, then the event relates to the local control
panel.
• If the panel ID does not match the local ID, then the event is reported by the
remote control panel with the panel ID indicated.
Acoustic indicators
The control panel uses the following acoustic indicators to highlight system
events.
Caution: The information in the table below describes the default buzzer
configuration – the installer may have configured your control panel so that the
buzzer does not activate for some event types.
Table 8: Control panel acoustic indicators
Indication
Description
The buzzer sounds
continuously Indicates a fire alarm or a system fault
The buzzer sounds
intermittently (long tone) [1] Indicates all other faults
The buzzer sounds intermittently (short tone) [1]
Indicates a condition
[1] A long tone is 50% ON and 50% OFF. A short tone is 25% ON and 75% OFF.

14 ZP2-A Series Operation Manual
Conditions
A summary of system events logged as conditions is shown below.
Table 9: System events logged as conditions
Condition type
Description
Alert
A device is in alarm but the system is waiting for an
additional alarm event to confirm the zone alarm
Configuration device connected
A control panel configuration session is initiated via an
external device (PC, laptop, etc.)
Date and time not set
The system started but the date and time are not set
Change password
The default Operator, Maintenance, or Installer password
should be changed.
Disablements
A control panel feature or device is disabled
Event log full
The control panel event log is full
Extinguishing status [1]
Extinguishing is blocked, disabled, or has a fault
Extinguishing I/O device [1]
An extinguishing I/O device is active, being tested, is
disabled, or has a fault
Incompatible firmware version
An expansion board (for example, a loop board, a network
board, or DACT board) has an incompatible firmware
version. The control panel firmware version should be
updated.
Input activation
An input is activated (subject to configuration)
Loop device not configured
A loop device is detected that is not configured
Loop power
A loop power status is OFF
Loop
recovery A loop is in the recovery process (this may happen when a
short circuit fault is detected or after a reset if there was a
fault on the loop).
Maximum conventional zones
exceeded in a network
The number of conventional zones in a fire network
exceeds the maximum allowed
Maximum loops exceeded in a
network
The number of loops in a fire network exceeds the
maximum allowed
New node in the fire network
A control panel has been added to the fire network
Output group activation
An output group is activated
Prealarm
A device (and corresponding zone) is in prealarm
Sounder, fire routing, and fire
protection delays
A sounder, fire routing, or fire protection delay is enabled or
disabled
Tests
A control panel feature or device is being tested
[1] These condition types only apply if an extinguishing panel is included in the fire network.
