ZKaccess F18 User manual

www.zkaccess.com

Safety Precautions
H
ow to place a finger
Product Contents
Product
PIN Diagram
Product
Dimensions
Cables and Connectors
Installation
of Back Plate
Power Connection
Ethernet
Connection
PC
RS485 Connection
FR1200
RS485 Connection
Lock
Relay Connection
Weigand
Input Connection
Weigand
Output Connection
Installation
Reference
Specifications
Electrical
Specifications
Troubleshooting
Specifications
1
02
04
07
09
11
12
13
14
15
17
18
19
21
22
23
27
28
26

2
1
Safety Precautions
The following precautions are to keep user’s safe and prevent any damage. Please read carefully before installation.
Do not install the device in an area subject to
direct sunlight, humidity or dust
Do not place a magnet near the product. Magnetic
field from magnets, CRT, TV, monitor or speaker
may damage the device.
Do not place the device next to
heating equipment.
Be careful not to let liquid like
water, drinks or chemicals leak
inside the device.
Clean the device often to remove
dust on it
Do not let children touch the
device without supervision.

3
1
Safety Precautions
The following precautions are to keep user’s safe and prevent any damage. Please read carefully before installation.
Do not drop the device. Do not use the device for any
other purpose than specified.
Do not disassemble, repair or
alter the device.
In cleaning, do not splash water
on the device but wipe it out with
smooth cloth or towel.
Contact your nearest dealer in
case of a trouble or problem.
Do not damage the device

4
1
How to Place a Finger
ZkTeco’s fingerprint readers will give optimal results for fingerprint matching if the following recommendations and
suggestions are followed.
Select a finger to enroll
It is recommended to use an index finger or a middle finger.
Thumb, ring or little finger are relatively difficult to place in the correct position
How to place a finger on a sensor
Place a finger such that it completely covers the sensor area with maximum contact.
Place core of the fingerprint at the center of the sensor. The core of a fingerprint is a center where the spiral of ridges is
dense.
Usually core of fingerprint is the opposite side of the lower part of a nail.
Place a finger such that the bottom end of a nail is located at the center of a sensor.
If a finger is placed as shown in the right, only a small area of a finger is captured. So it is recommended to place a finger as
shown on the left.

5
1
How to Place a Finger
Tips for different fingerprint conditions
ZKTeco’s fingerprint products are designed to verify fingerprints with highest security irrespective of the
conditions of the skin of the finger. However, in case a fingerprint is not read on the sensor, please refer to the
followings tips.
•If a finger is stained with sweat or water, scan after wiping moisture off.
•If a finger is covered with dust or impurities, scan after wiping them off.
•If a finger is way too dry, please blow some warm air from your mouth on the finger tip.
Tips for fingerprint enrollment
In fingerprint recognition, enrollment process is very important. When enrolling a fingerprint, please try to place the
finger correctly with utmost care.
In case of low acceptance ratio, the following actions are recommended.
•Delete the enrolled fingerprint and re-enroll the finger.
•Enroll the same fingerprint again.
•Try another finger if a finger is not easy to enroll due to scar or cuts.
In case of an enrolled fingerprint cannot be used due to injury or if the hand is full, it is recommended to enroll more
than two fingers per user.

6
1
How Does F18 work
Fingerprint database
Register finger Identification Feature extraction
Verify feature
Verified
successfully
Verification
failed
Create
Please try again !
Thank you !
Event logs
Open door
Door closed
Stored

Basic Contents
F18
Wall Mounting Screws –4 pcs. Wall Plugs–4 pcsScrew Driver –2 pcs.
Product Contents
7
Star-shape Screw for
Mounting Plate -2 pcs Mini-USB Cable -1 pcs
2 pin, 4 pin, 7 pin, 8 pin,
10 pin cables –each 1 pcs
Mounting Paper
Metallic Back Plate

Optional accessories
Product Contents
8
Weigand Card Reader
USB Memory
K1-1 Exit Button
Alarm
FR1200 Slave Fingerprint Reader
RS485 Convertor
12VDC, 3A Power
Adaptor
Prox Card

Front
Product PIN Diagram
9
2.4 inch TFT LCD
Keypad & RF Card Area
Door Bell & LED Indicator
ZK Optical Sensor
USB Memory slot
Reset Switch
Speaker Slot
Side

Bottom
Product PIN Diagram
10
Back
Star-shaped screw hole for fixing reader to the back plate
4 pin Cable connectors –Ethernet (TCP/IP)
7 pin Cable connectors
8 pin Cable connectors
2 pin Cable connectors -Power In
10 pin Cable connectors
Beep, LED
Weigand In
Power Out
Weigand Out
RS232
RS485
Door Sensor
Button
Lock
Bell
Alarm
Tamper alarm button
（At the back of the mounting plate ）

Product Dimension
11
Front Side
183mm
(7.20in.)
80mm
(3.15in.)
183mm
(7.20in.)
42mm
(1.65in.)
183mm
(7.20in.)
80mm
(3.15in.)
Back Plate

Cables and Connectors
12
Digital input and Relay output
Weigand output and RS485
Weigand input and Power out
Ethernet
Power In
1
10
1
8
1
7
1
4
1
2
TCP/IP
Weigand
Input LED Power Out Beep
Weigand
Output RS232 RS485
Alarm Lock Button Door
Sensor
Door Bell
Power In

Installation of Wall-mount
13
Fix back plate to the wall
using wall mounting screws
Mount F18 terminal on the
Back plate
Secure F18 and back plate
using a star shape screw.
Star-shaped screw
Star-shaped screw
driver
Wall mounting screws

Power Connection
14
GND
12V DC12V DC (Red)
GND (Black)
Without UPS
With UPS
12V DC (Red)
GND (Black) GND
12V DC
(Optional)
Recommended power supply
12V ±10%, at least 500mA.
Comply with standard IEC/EN 60950-1.
To share the power with other devices, use a power supply with higher current ratings

Ethernet Connection
15
TCP/IP TCP/IP
Ethernet Connection

Ethernet Connection
16
TCP/IP
Direct Connection to PC

PC RS485 Connection
17
RS485B
RS485A
GND
RS232
1. RS485 communication wires should be a shielded
or twisted pair cable. RS485 communication wires
should be connected in a bus cascade instead of a star
form, to achieve a better shielding effect by reducing
signal reflection during communications.
PC RS485 Connection
Important Notes Do’s and Dont’s for RS485 connection
3. Adjust the communication speed as needed , The
signal quality vary depending on wiring conditions,
and it maybe necessary to lower the baudrates.
4. The GND Signal may be omitted if and only if the
GND potential difference is less than ±5V

FR1200 RS485 Connection
18
12V DC (Red)
GND (Black)
GND (Black)
485+ (Purple)
485- (Yellow)
12V DC (Red)
GND (Black)
GND (Black)
485A (blue)
485B (Yellow)
Important Notes
1.Steps to activate the master and salve functionality between
F18 and FR1200 is shown in the diagram on the left.
2. There are six DIP switches on the back of FR1200 , Switches
1-4 is for RS485 address , switch 5 is reserved , switch 6 is for
reducing noise on long RS485 cable.
3. If FR1200 is powered from F18 terminal ,the length of wire
should be less than 100 meters or 330 ft.
4. If the cable length is more than 200 meters or 600 ft. , the
number 6 switch should be ON as below
Distance
More than 200 meters
12
3
Menu -> User Management -> Access Setting
-> Anti-Passback setting -> 485Reader Fun(Y)
Power Out

Lock Relay Connection
For Normally Open -Lock
1
10
SEN
GND
NO1
COM
NC1
12V DC
GND
Sensor
Sensor
12V DC GND
F18
Lock
19
FR107
