ZKTeco Bio30R User manual

User Manual
Bio30R
Date: June 2020
Doc Version: 1.0
English
Thank you for choosing our product. Please read the instructions carefully
before operation. Follow these instructions to ensure that the product is
functioning properly. The images shown in this manual are for illustrative
purposes only.
For fu r t h e r det a i ls, p leas e v isi t o u r Co m p any ’s we b site
www.zkteco.com.

Overview
1.
1
The Bio30R biological fingerprint reader is a small and portable
semiconductor fingerprint scanner developed by ZKTeco.
It uses the ARM9 processor and international semiconductor fingerprint
sensor. It has the characteristics of fast fingerprint data acquisition
speed and excellent image quality.
It even supports scanning of dry, damp, and rough finger skin and
provides a good image quality.

2
Dimensions
2.
Front
20mm
50mm
83mm
Side

Features
3.
3
Standard high-precision fingerprint recognition technology and
optimized image processing.
Supports low false accept rate, high recognition rate, and rotated
fingerprint.
Adopts international top semiconductor sensors, precise imaging, and
fast acquisition speed.
Good imaging quality of dry/damp/rough finger skin suitable for a
wide range of people.
Drive free fingerprint scanner, not required to install a driver; plug and
play.
Supports Windows, Android, Linux, and other Operating System
development.

Semiconductor
Sensor Type
Resolution 508DPI
<1%
Aberration Rate
256 gray
Gray Scale
18.0 * 12.8 mm / 0.709 * 0.504 inch
Collecting Area
18.0 * 12.8 mm / 0.709 * 0.504 inch
Effective Collecting Area
256 * 360 pixels
Image Size
Interface USB2.0 / USB1.1
-10°C ~ 50°C / 14°F ~ 122°F
0% ~ 93% RH
83 * 50 * 20 mm / 3.268 * 1.969 * 0.787 inch
5.0 ± 0.25V
≥15KV
About 90KB
Operating Temperature
Humidity
Dimension (L*W*H)
Supply Voltage
Antistatic Property
Template Size
≤150mA (Active) / 80mA (Standby)
Power Current
FCC, CE, RoHS
Technical Parameters
4.
4
Data Rate <6ms
Certification
OS Supports
Windows XP / 2000 / 2000 server / Vista / 7 / 8 / 10
Linux
Android

Demo Testing Procedure
5.
5
Connect to Bio30R, and then press the finger on the fingerprint sensor
to scan and collect the fingerprint image.

Operating Instructions
6.
6
Guide to Place the Finger
1. Proper Positioning of Finger
2. Improper Positioning of Finger
Not to place the finger
in an uplifted position.
Not to place the finger
in sideways.
Not to place the finger
in a corner.
Not to place the finger
away from the center.
Recommended to use the index finger, middle finger or the little finger
for registration.
Note: The finger needs to be pressed flatly
over the Sensor area, and make sure the
finger is placed exactly on the Sensor area.

Please avoid using the thumb and pinky fingers, because these two
are clumsy when pressing on the Sensor Area.
Some issues may cause difficulties to recognize the Registered fingers or
during new Registration. They are:
1. Smoothed out fingers;
2. Too many wrinkles on fingers;
3. Layer of any material on fingers;
4. Extremely dry and wet fingers.
Make sure the fingers are clean when using the Fingerprint Scanner.
1.
4.
Recommended to use the index, middle or little finger for Registration.
3.
Place the finger correctly.
2.
7
Cautions
Suggestion
Please keep the sensor away from dust.
1.
Please make sure the Sensor area is clean after each use.
4.
Please use a wool-free cloth to wipe the Sensor area.
3.
Please use adhesive tape to clean the Sensor area.
2.
Do not use water or other detergents, which may damage the sensor.
Possible Complications

8
Solutions
1.
2.
Always try to maximize the Contact Area of the finger.
3.
ZKTeco suggests registering alternative Fingerprints.
4.
5.
If the user experiences any difficulty during Registration, they can
either delete the fingerprint and re-register, or can try using any
other fingers.
It is recommended to choose the suitable finger with fewer wrinkles,
no peeling, and clean finger for Registration.
Soaked alcohol cotton is used for cleansing if the fingers are dry, and
a clean napkin is used for cleansing if the fingers are wet.

Our o t h er govern m e n t - oriented finger p r i nt i ng devi c e s or d e ve l o p me nt tools can
capture original images of citizens' fingerprints. As to whether or not this constitutes
infringement of your rights, please contact your government or the final supplier of the device.
As the manufacturers of the device, we will assume no legal liability.
If you would like to dispute human rights or privacy issues concerning your use of our
product, please directly contact your employer.
All of our civilian fingerprint recognition devices capture characteristics, not fingerprint
images, and do not involve privacy protection.
Thank you for choosing this hybrid biometric recognition product, which was designed and
manufactured by ZKTeco. As a world-renowned provider of core biometric recognition
technologies, we are constantly developing and researching new products, and strive to follow
the privacy laws of each country where our products are sold.
4.
There shall be no illegal arrest, detention, search, or infringement of persons;
1.
Personal dignity as related to personal freedom shall not be infringed upon;
2.
3. A citizen's house may not be infringed upon;
1.
4.
3.
2.
The law includes the following provisions on the personal freedoms of its citizens:
Dear Customers
We declare that
Note
9
Statement on the Right to Privacy
As a final point we would like to further emphasize that biometric recognition is an advanced
technology that will undoubtedly be used in e-commerce, banking, insurance, legal, and other
sectors in the future. Every year the world is subjected to major losses due to simple combination
of passwords. Biometric products serve to protect your identity in high-security environments.
A citizen's right to communication and the confidentiality of that communication is
protected by law.
None of the fingerprint characteristics that we capture can be used to reconstruct an image
of the original fingerprint, and do not involve privacy protection.
As the provider of this device, we will assume no direct or indirect responsibility for any
consequences that may result from your use of this device.
