4. Pull cable through the knockout with the Heyco
tting and into the low voltage compartment.
5. Strip back the insulation jacket of the cable
approximately 6" (15 cm).
6. Strip each wire ¼" (6 mm) and connect to the
red, 4-pin connector on the power center PCB. A
multiplex kit (P/N 6584) may be required if there
are more than two (2) cables running to a red, 4-pin
connector on the PCB.
Potentially high voltages in the power center can
create dangerous electrical hazards, possibly
causing death, serious injury or property damage.
Turn off power at the main circuit feeding the power
center to disconnect the power center from the
system.
Never run high voltage and low voltage in the same
conduit.
1. Turn off all power to the power center.
2. Find a suitable place inside your home to mount the
iAquaLink J-box.
3. Install the iAqualink J-box at least six (6) feet (1,8
m) above the ground and at least ve (5) feet
(1,5 m) away from other transceiver J-boxes.
To improve performance of the transceiver,
mount the J-box more than six (6) feet (1,8 m)
above the ground.
4. Open the door to the power center and remove the
dead panel.
5. Pull cable through the knockout with the Heyco
or equivalent tting and into the low voltage
compartment. See Figure 4.
6. Strip back the insulation jacket of the cable
approximately 6" (15 cm).
7. Strip each wire ¼" (6 mm) and connect to the
red, 4-pin connector on the power center PCB. A
multiplex kit (P/N 6584) may be required if there
are more than two (2) cables running to a red, 4-pin
connector on the power center PCB.
The iAquaLink Web Connect Device is pre-configured
at the factory for WiFi connection. If using wired
connection skip to Section 4.4.
1. Remove the two (2) screws from the cover of the
iAquaLink J-box. Remove the gasket and cover.
See Figure 5.
The iAquaLink J-Box should NOT be connected to
the power center at this time.
2. Using a USB cable, connect the iAquaLink J-Box
to the computer.
3. To proceed with the installation, go to www.
iAquaLink.com/ssid and follow the online
installation instructions.
Internet Service
Provider
Internet
iAquaLink
J-Box
Router
Computer
Wireless
or
Wired Connection
Red 4-Pin
Terminal Bar
Low
Voltage
Area
