Owner’s Manual
and Quick Assembly
Instructions
AUTOMATIC ABOVEGROUND POOL CLEANER

THANK YOU FOR PURCHASING THE KONTIKI™.
YOUR KONTIKI HAS BEEN DESIGNED AND MANUFACTURED TO BE EASILY
INSTALLED AND TO PROVIDE YEARS OF LOW MAINTENANCE OPERATION.
PRIOR TO INSTALLING YOUR NEW KONTIKI, PLEASE DO THE FOLLOWING:
1) Complete and return the warranty card.
2) Record your purchase information on the spaces provided below.
3) Attach your invoice (or a copy) to this page.
These actions will insure prompt warranty service, should it be required. Simply present your owner’s manual, along with the invoice at any of our
authorized warranty centers nationwide.
RECORD YOUR KONTIKI POOL CLEANER DATA HERE:
Date of Purchase_____________________________________________________________________________________________________________
Purchased From _____________________________________________________________________________________________________________
City __________________________________________________ State ______________________________ Zip Code _________________________
Serial Number: ____________________________________________________ (serial number located on underside of machine head)
KONTIKI LIMITED WARRANTY
KONTIKI POOL CLEANER IS WARRANTED AGAINST ALL MANUFACTURING DEFECTS AND ALL WEAR AND TEAR FOR ONE (1) YEAR. ALL
WARRANTIES ARE EFFECTIVE FROM THE DATE OF PURCHASE.
Should this product prove defective in workmanship, materials or wear during the applicable warranty period, the consumer’s sole and exclusive remedy shall be such
repair or replacement of the product as provided below.
THIS LIMITED WARRANTY EXCLUDES THE FOLLOWING:
1. Discoloration of the KONTIKI pool cleaner. This is caused by reaction to ultraviolet rays and the chemicals used in the pool water. Discoloration does not affect the
operating ability of the KONTIKI. Therefore, this Limited Warranty does not cover the replacement of discolored parts.
2. Damage to or malfunction of the unit resulting from excess chlorination or improper water chemistry balance.
3. Replacement of parts which fail or become defective as a result of improper installation, negligence, misuse, abuse or tampering by unauthorized repair personnel.
4. Age, pool water imbalance, and improper installation can cause vinyl pool liners to become brittle or unduly wrinkled. Corrosion of the supporting walls and/or
irregularities in the pool base may also cause liner failure. The use of this product in such an environment is at the pool owner’s risk. Therefore, the pool owner hereby
releases the manufacturer from any and all claims for damage where these conditions exist.
5. The KONTIKI is designed for use in aboveground pools only. If unit is used in any other application, the pool owner hereby releases the manufacturer from any and
all claims. This misuse will void all warranty on the unit.
THE LIMITED WARRANTY PROVIDED HEREIN IS THE SOLE AND EXCLUSIVE WRITTEN WARRANTY WITH RESPECT TO THE KONTIKI
POOL CLEANER. ALL IMPLIED WARRANTIES IMPOSED BY APPLICABLE LAW, INCLUDING ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FORA PARTICULAR PURPOSE,WITH RESPECT TO EACH COMPONENT OF THE KONTIKIARE LIMITED TO
THE DURATION OF THE EXPRESS LIMITED WARRANTY WITH RESPECT TO SUCH COMPONENT. SOME STATES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THEABOVE LIMITATION MAY NOT APPLY TO YOU.
In no event shall Kontiki be liable in contract or in tort, or under any other legal theory, for lost profits or revenues, loss of use or similar economic loss, or for indirect,
special, incidental, consequential or similar damages, even if it has been advised of the possibility of such claim. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation or exclusion may not apply to you.
No claim under this Limited Warranty will be recognized unless the registration card, included in your box, is completed and returned within fifteen (15) days of the
purchase date. Only the original purchaser may submit a claim under this Limited Warranty.Purchaser’s claims against Kontiki, shall be limited to those claims which
may be asserted under the Limited Warranty relating to any defect, malfunction or wear of the Kontiki.
To obtain warranty replacements or repair, the unit should be returned, freight prepaid, to Kontiki, 2028 NW 25th Ave, Pompano Beach, FL, 33069. Call for
authorization at 888-786-7797. When submitting a claim, always supply serial number, evidence of purchase date, retailer and a brief description of the problems/defects
encountered. Kontiki reserves the right to repair or replace all defective or worn parts covered by this Limited Warranty and return same to purchaser, freight collect.
Kontiki assumes no responsibility for any warranties or representations made by other individuals or businesses beyond the express terms contained in this LimitedWarranty.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
IMPORTANT: FOR VINYL LINER POOL OWNERS
Vinyl liners are subject to deterioration or damage due to age, the effect of chemicals, corrosion or failure of the supporting walls; as well as improper installation,
maintenance or cleaning of the supporting walls or base.
Before installing the Kontiki, examine the interior of your pool carefully. If your vinyl liner is brittle or has stones, wrinkles, roots or metal corrosion in contact with the underside
of the liner, or has damage to the base material or supporting walls, do not install the Kontiki before having a qualified professional perform the necessary repairs.
Kontiki will not be responsible for liner damage caused by (1) a Kontiki cleaner which is out of warranty or in disrepair, or (2) a Kontiki cleaner used in a pool
having a aged or deteriorated liner. YOU ARE RESPONSIBLE FOR LINER DAMAGE IF YOU USE THE KONTIKI UNDER CONDITION (1) OR (2).
For sale and use in the United States only. This pool cleaner is not warranted or guaranteed outside of the United States.
This pool cleaner is covered by one or more of the following U.S. and Canadian patents and registered design:
U.S. patent nos. 4642833, 4742593, 5450645, 6122794 and 5315728. Canadian patent nos. 1254105, 1256262 and 2134220.
Other Patents Pending.
2

Check that the following parts are included:
TABLE OF CONTENTS
Pool Preparation ................................................................................... 4
Disc Installation.................................................................................... 5
Hose Assembly ..................................................................................... 5
Wheel Deflector Installation................................................................. 6
Romoving Air from Hose..................................................................... 6
Installation ............................................................................................ 6
Achieving Proper Flow......................................................................... 8
Care and Maintenance.......................................................................... 9
Troubleshooting.................................................................................... 10
Accessories ........................................................................................... 10
Parts Diagram ....................................................................................... 11
(1) Flowkeeper Valve
(1) Cleaner Head
(1) 45-degree Elbow (1) Pool PulseTM (10) Hose Sections
(1) Above-ground Cuff
(1) Combi Disc
3
(1) Wheel Deflector
(1) Hose Connector
If assistance is required, call 1-888-786-7797
POOL COMPONENTS
•Become familiar with the components of your pool shown.
•All diagrams are provided for reference of terminology used throughout this manual.Your pool may vary.
POOL
SKIMMER
RETURN
FLOW
INLET
PUMP
FILTER
IMPORTANT!
Return flow must be directed
toward pool bottom as shown.

STEP 1 - POOL PREPARATION
•Before installing the Kontiki, examine the interior of your pool carefully. If your vinyl liner is brittle or has stones, wrinkles,
roots or metal corrosion in contact with the underside of the liner, or has damage to the base material or supporting walls,
do not install the pool cleaner before having a qualified professional perform the necessary repairs.
•Manually vacuum the pool. This eliminates unnecessary adjustment later.
•Clean the pool filter and empty the skimmer and pump strainer baskets. Filter pressure rises as debris is cleaned from the water,
thus reducing flow.
•Divert the pool return inlets downward - (IMPORTANT!).Your Kontiki must move randomly throughout the pool. Water
circulating at the surface will influence the hose and limit coverage.
•To adjust the return inlet, loosen the lock ring and redirect the eyeball downward, then retighten the lock ring. If the eyeball is
difficult to adjust, insert a screwdriver inside the eyeball and gently adjust downward.
•If the return inlets cannot be pointed downward, then you MUST install Kontiki return line diverters, which are available through
your dealer.
TOP VIEW
SIDE VIEW
BEFORE ADJUSTMENT
AFTER ADJUSTMENT
FOR POOLS WITH RETURN INLET
DIRECTIONAL FITTINGS
Replace the directional eyeball
with retrofit eyeball return line
diverter and reinstall eyeball
retaining ring.
Part #W90153 for
11/2" return lines
Part #W90155 for
2" return lines
IF UNABLE TO ADJUST RETURN INLETS
OR FOR POOLS WITHOUT RETURN
INLET DIRECTIONAL FITTINGS
Use universal return line
diverter (Part #W24100).
Pinch wires together and
insert fully into return inlet.
TOP VIEW
SIDE VIEW
4

STEP 2 - DISC INSTALLATION
Slide the disc over the base of the cleaner head. Be sure it fits properly in the grooves provided.
The fins on the disc point upward.
Note:You may not need to use all or you may need more hose sections, depending upon your pool size.
SKIMMER / WALL
VACUUM FITTING
SKIMMER / WALL
VACUUM FITTING
FOR CENTER INSTALLATIONS
Use enough hose sections to reach the farthest point in the pool,
plus two (2) sections.
STEP 3 - HOSE ASSEMBLY
FOR CORNER OR END INSTALLATIONS
Use enough hose sections to reach the farthest point in the pool,
plus one (1) section.
5

STEP 5 - REMOVING AIR FROM HOSE
•Turn on the filtration system.
•Fill the hose with water by placing the end over a return
inlet.
•Submerge the pool cleaner head. When bubbles stop
coming from the extension pipe, attach the cleaner head to
the female end of the hose.
RETURN
INLET
Female End
Wheel Deflector
STEP 4 - WHEEL DEFLECTOR INSTALLATION
•Slide the wheel deflector on to the female end of the hose.
The female end will eventually attach to the Kontiki head.
6

•Using the parts shown, choose a fitting combination best suited for your pool from figures A or B and install. You may have
parts left over.
(1) Flowkeeper Valve (1) 41/2" Connector
(1) Valve Cuff
A
BC D
The Flowkeeper Valve MUST BE used on all installations. The pool pump
provides more gallon per minute flow than your pool cleaner requires. The
Flowkeeper provides a way to regulate the flow with a by-pass so the pool
pump and the pool cleaner run properly.
Skimming action is maintained through a bypass throat in the valve. As the
filter collects debris, the valve automatically maintains the correct flow to the
cleaner. The Flowkeeper Valve comes preset at the setting required for your
cleaner. There are a total of three setting options. The lower the setting
number, the lower the flow to the cleaner head. Should readjustment become
necessary, pull the adjustment handle to raise or lower the setting. The red tab
on the valve can be used to keep the bypass open, which in most cases, will
cause the cleaner to stop.
FLOWKEEPER VALVE
STEP 6 - INSTALLATION
(1) 45° Elbow
FIGURE A
Skimmer Installation FIGURE B
Vacuum Line Installation
Important: To help prevent suction entrapment accidents, wall
vacuum fittings should have a safety vac lock installed. Contact your
builder or retail pool professional for details.
D
A
B
C
CAB
7

STEP 7 - ACHIEVING PROPER FLOW
•Remove the cleaner head.
•Attach the Pool Pulse®to the hose and keep it under water as shown in Figure 1.
•Turn on the filtration system.
•Insure the Pool Pulse is in the ideal range when viewed from the side.
•Keeping the hose under water, remove the Pool Pulse.
•Submerge the cleaner head, and when the bubbles stop coming from the extension pipe, attach the hose end.
Your installation is now complete.
POOL PULSE®
The Pool Pulse is a flow meter that measures the volume of water flowing through your Kontiki cleaner. It must be used to properly
set the flow and can be used as a diagnostic tool when the cleaner isn't running properly.
IDEAL TOO HIGH TOO LOW
If the flow is in the low range, review the installation procedures. A dirty pool filter or clogged basket is usually the main cause of
low flow. Other types of hydraulic problems may require a professional pool repairman. If your pool has multiple skimmers and flow
is in the low range, close the skimmer the cleaner is not attached to.
If the flow is in the high range, review the installation procedures. Lower Flowkeeper setting to #1.
Note: If the automatic pool cleaner is climbing the walls excessively, that is an indication that the flow is too high. Review the installation
procedures and insure the Flowkeeper is set at setting #1. For additional assistance contact Technical Service 1-888-786-7797.
Figure 1
Figure 2
8

Quick Access Cassette System
Foreign objects, such as children’s toys, tree branches and rocks, should be removed manually from your pool prior to operating your
Kontiki. If a blockage should occur, the Quick Access Cassette System will allow you to check the diaphragm for damage and remove
the blockage in minutes at poolside.
DIAPHRAGM REMOVAL
Holding the frame assembly in one hand, grasp the cassette handnut firmly and turn it counter-clockwise (Step 1). Pull the complete
cassette out of the frame (Step 2). Holding the cassette at each end, unscrew the cassette pipe from the diaphragm chamber two full
turns (Step 3). Grasp the lip of the diaphragm and pull the diaphragm out (Step 4). The inner pipe will be attached and will make a loud
noise. Pull the diaphragm off of the inner pipe, leaving the retaining ring on the diaphragm (Step 5).
Inspect the diaphragm for the blockage or damage. If damage is evident, i.e., a cut or hole on the sides of the diaphragm, contact your
dealer for a replacement.
If a blockage is apparent, grasp it and remove it. If this can’t be done, a garden hose may be used to flush the obstacle through. Do not
use any sharp objects to probe or push an obstruction as this may damage the diaphragm.
DIAPHRAGM ASSEMBLY
Attach the diaphragm to the inner extension pipe using the retaining ring (Step 6). Slide the inner extension pipe into the diaphragm
chamber. Pressing on the underside of the diaphragm’s ridges, push the diaphragm into the chamber (Step 7). Holding the cassette at
each end, tighten the cassette pipe until snug. Do not overtighten. (Step 8). Insert the cassette into the frame assembly and twist the
handnut clockwise until it locks into place (Step 9).
NOTE: The indicator line on the handnut will line up with the center ridge on the frame assembly (Step 10).
Step 1 Step 2 Step 3 Step 4 Step 5
Step 6 Step 7 Step 8
To maintain quality, performance and increase the lifespan of your Kontiki, please do the following:
1. Thoroughly clean the skimmer basket, pump basket and pool filter on a regular basis. Always disconnect the hose from the
skimmer before backwashing.
2. REMOVE THE CLEANER BEFORE SUPER CHLORINATING OR ADDING POOL CHEMICALS. Reinstall the
Kontiki when the imbalance is corrected or after a minimum of 4 hours from super chlorination. Chemical damage is not covered
under warranty.
3. NEVER COIL THE HOSE when the cleaner is removed from the pool. A coiled hose can be straightened with hot water or by
laying it on a warm pool deck for several hours.
INCORRECTCORRECT
X
4. Remove disc and store it flat during the off-season. Store the cleaner head in a warm and dry place.
KONTIKI CARE AND MAINTENANCE
Step 9 Step 10
9

TROUBLESHOOTING
KONTIKI ACCESSORIES
PART ILLUSTRATION PART NO. DESCRIPTION
1. W24100 Return Line Diverter
Use when no other return inlet
return inlet directional fittings exist.
2A. W90153 Retrofit Eyeball Return
(for 11/2" return inlet) Line Diverter
Use to replace standard
2B. W90155 directional inlet eyeballs
(for 2" return inlet)
3. W26705 The Leaf Catcher
with 41/2" Hose Connector
Use when heavy debris or
leaf situations exist.
3. W46155 Large Wheel Deflector
Use when extra clearance is
needed at steps or other
obstacles.
3
2A
1
2B
4
If you experience a problem with your Kontiki, please review the installation section and insure all steps have been followed
correctly.
PROBLEM SOLUTION
1. Machine does not move, or moves sluggishly. • Insure ideal flow is being attained using Pool Pulse.
Note: In water 60˚ F or less, it may be necessary to increase flow to
compensate for the reduced flexibility of the hose and diaphragm.
•Check diaphragm for damage or wear (see Care and Maintenance).
•Backwash filter and empty pump basket.
•Check for air in system. If water level in pump basket drops, check
hose connections, tighten all fittings at pump, check gasket in pump
basket for wear.
2. Machine does not cover entire pool. • Insure ideal flow is being attained using Pool Pulse.
•Point return jets as far down as possible.
•Make sure hose does not have memory from being coiled
(see Care and Maintenance).
•Confirm proper hose length
3. Machine sticks on ladder. • Insure ideal flow is being attained using Pool Pulse.
•Remove ladder if possible
•Install large wheel deflector.
4. Machine sticks in steps. • Insure correct amount of hose is being used (see Assembly).
Shorten if necessary.
•Insure the Flowkeeper is on the number 1 setting.
•Install large wheel deflector.
5. Machine stays on walls or edge of pool. • Insure the Flowkeeper is on the number 1 setting.
IF FURTHER ASSISTANCE IS REQUIRED, PLEASE CALL 1-888-786-7797.
10

KONTIKI™PARTS DIAGRAM
PART NO. DESCRIPTION QTY
1. W33205 4 1/2” Connector 1
2. W46055 Wheel Deflector - Medium 1
3. W72070 Cassette Pipe w/Handnut 1
4. W74000 Compression Ring 1
5. W81741 Diaphragm Chamber 1
6. W40925 Kontiki Head 1
7. W47725 Combi Disc 1
8. W81710 Aboveground Cassette Diaphragm 1
9. W81600 Diaphragm Retaining Ring 1
10. W56525 Threaded Inner Extension 1
11. W21205 Hose Kit - 11 x 1 Meter - White 1
12. W60050 Flowkeeper Valve 1
13. W44800 Pool PulseTM 1
14. W90146 45˚ Elbow 1
15. W64700 Above-Ground Valve Cuff 1
1
13
15
14
2
4
3
5
10
9
8
6
7
11
12
11

If you are having a coverage problem you cannot solve, mail or fax us the following information along with a sketch of your pool shape,
including dished out or hopper areas if they exist, and indicating the location of skimmers, inlets, ladders, and the filter system.
Also include a brief description of the problem. (Send a photocopy and retain this page for future use.)
MAIL TO: ZODIAC POOL CARE, INC.
2028 NW 25TH Avenue, Pompano Beach, FL 33069 • Fax: [phone]
CUSTOMER NAME: ____________________________________TELEPHONE NO: (_______) ___________________
ADDRESS: ________________________________________________________________________________________
CITY: _________________________________________________STATE: ___________ ZIP CODE: _______________
SERIAL NO.:___________________________________________PURCHASED FROM: _________________________
POOL SIZE: ___________________________________________PUMP SIZE (H.P.):____________________________
FILTER (circle one): SAND D.E. CARTRIDGE FILTER SIZE (or Model No.)_________________________
LET KONTIKI HELP!
Indicate problem:___________________________________________________________________________
_________________________________________________________________________________________
_________________________________________________________________________________________
ZODIAC POOL CARE, INC.
2028 N.W, 25th Avenue
Pompano Beach, FL 33069
1-888-786-7797
www.zodiacpoolcare.com
W83326
