Zodiac V1 User manual
H0351306.B1 AUGUST 2011
Owner's Manual
WARNING
FOR YOUR SAFETY - For anything other than the routine cleaning and maintenance described
in this manual, this product must be serviced by a contractor who is licensed and qualied in pool
equipment by the jurisdiction in which the product will be installed where such state or local
requirements exist. In the event no such state or local requirement exists, the maintainer must be
a professional with sufcient experience in pool equipment installation and maintenance so that all
of the instructions in this manual can be followed exactly. Improper installation and/or operation will
void the warranty.
TM
Page 2
THANK YOU FOR PURCHASING THE ZODIAC V1 ROBOTIC CLEANER.
YOUR ZODIAC V1 ROBOTIC CLEANER HAS BEEN DESIGNED AND MANUFACTURED TO BE EASILY
INSTALLED AND TO PROVIDE LOW MAINTENANCE OPERATION. PRIOR TO INSTALLING YOUR NEW
ZODIAC V1, PLEASE DO THE FOLLOWING:
1) Complete and return the warranty card.
2) Record your purchase information on the spaces provided below.
3) Attach your invoice (or a copy) to this page.
Taking these steps will help ensure prompt warranty service, should it be required. If service is required, please
contact your original dealer. If the original dealer does not perform warranty service, please visit
www.zodiac.com.au to locate an independent service company near you. If you are unable to locate a service
company, please call our Technical Support Department on 1800 688 552.
RECORD YOUR ZODIAC V1 POOL CLEANER DATA HERE:
Date of Purchase Purchased From Serial Number:
(On ID Plate Located on Bottom of Control Unit)
City State Post Code
Table of Contents
Section 1. Important Safety Instructions .........4
Section 2. Zodiac V1 Specications................6
2.1 General Specications ...................6
Section 3. Assembly and Initial Usage............6
3.1 Unpacking ......................................6
3.2 Attaching the Control Unit to a
Wall ................................................6
3.3 Electrical Connection .....................7
Section 4. Operation .......................................7
4.1 Submerging the Cleaner ................7
4.2 Operating the Cleaner ....................7
4.3 Removing the Cleaner from Pool ...8
Section 5. Cleaning and Maintenance ............9
5.1 Cleaning the Filter Canister ............9
5.2 Replacing the Filter Canister ..........9
5.3 Cleaning and Storing the Cleaner ..10
5.4 Replacing the Brushes ...................10
5.5 Replacing the Tyres on the
Cleaner ...........................................11
Section 6. Troubleshooting .............................12
6.1 General Troubleshooting ................12
Page 3
To reduce risk of electrical shock:
• Connect unit to receptacle protected by a Ground Fault Circuit Interrupter (GFCI) or a Residual Current Device
(RCD) having a rated residual operating current not exceeding 30mA.
• While the control unit is water resistant, it is not intended for any type of sustained contact with water.
Therefore, it should be installed at least 3 metres from the inside wall of your swimming pool. Never submerge
the control unit.
• Be sure to follow all applicable local and national electrical and installation codes.
• The cleaner is for fixed installations only and to be used in conjunction with swimming pool equipment. The
cleaner is to be installed in accordance with the relevant requirements of the Australian wiring rules AS/NZS
3000. Also refer to the installation instructions relating to the swimming pool equipment for which the cleaner
will be an integral part. The cleaner is to be supplied through a Residual Current Device (RCD) with a rated
residual operating current of 30mA.
• Do not enter pool while the Zodiac V1 is in water.
• Do not bury cord. Locate cord so as to prevent it from being damaged by lawn mowers, hedge trimmers and
other equipment.
• To reduce the risk of electrical shock, do not use the Zodiac V1 robotic cleaner or control unit if the cord is
worn or damaged. Contact Zodiac Group Australia. technical support immediately for a replacement cord.
• Double insulation—For continued protection against possible electric shock, use only identical replacement
parts when servicing. Do not attempt repair of the Zodiac V1 robotic cleaner, control unit, power cord, or
floating cable.
• NEVER OPEN CONTROL UNIT.
• Do not use an extension cord to connect the unit to electric supply; provide a properly located outlet. The
control unit should be placed near the outlet box.
• To reduce the risk of injury, do not permit children to operate this product.
• Do not let anyone, especially small children, sit, step, lean, or climb on any equipment installed as part of
your pool’s operational system.
Congratulations on purchasing the Zodiac V1 robotic cleaner. Please take a moment to read through the entire manual
before installing your new robotic pool cleaner. Your cleaner must be installed and operated as specied.
Page 4
• The Zodiac V1 must be installed and operated as specified.
• This product is intended for use with permanently-installed pools. Do not use with storable pools. A
permanently-installed pool is constructed in or on the ground or in a building such that it cannot be readily
disassembled for storage. A storable pool is constructed so that it is capable of being readily disassembled for
storage and reassembled to its original integrity.
• Turn the Zodiac V1 off before removing it from water, and do not operate out of water.
• Clean the filter canister in the Zodiac V1 after each use.
• Do not use the product in your pool if the water temperature is above 35˚ C or below 13˚ C.
USE OF THE ZODIAC V1 ROBOTIC CLEANER IN A VINYL LINER POOL
Certain vinyl liner patterns are particularly susceptible to rapid surface wear of pattern removal caused by
objects coming into contact with the vinyl surface, including pool brushes, pool toys, floats, fountains, chlorine
dispensers, and automatic pool cleaners. Some vinyl liner patterns can be seriously scratched or abraded
simply by rubbing the surface with a pool brush. Ink from the pattern can also rub off during the installation
process or when it comes into contact with objects in the pool. Zodiac Group Australia, is not responsible for,
and the Limited Warranty does not cover, pattern removal, abrasion or markings on vinyl liners.
Page 5
The general specications for the Zodiac V1 are as
follows:
Control unit voltage: 240 VAC, 50 Hz
short-circuit-proof
safety isolating type
Zodiac V1 supply
voltage:
30 V DC, max.
Installed load: 70 W max
Cable length: 15 m
Weight of cleaner: 6 kg
Filtration efciency: 200 microns
Cycle length: 2 hrs
The Zodiac V1 is a double-insulated product. A
double-insulated electrical appliance is one which has
been designed in such a way that it does not require a
safety connection to ground. The basic requirement for
double-insulation is that no single failure can result in
dangerous voltage becoming exposed so that it might
cause an electric shock and that this is achieved without
relying on an earthed (grounded) metal casing. This is
achieved by having two (2) layers of insulating material
surrounding live parts or by using reinforced insulation.
Therefore, devices having double-insulated
construction, such as the Zodiac V1, do not utilize a
grounded (three-prong) cord/plug.
The packaging should contain the following items
(Refer to Figure 1):
• Zodiac V1 robotic cleaner
• Control unit
• Hardware and template
• Owner's Manual
Check that the unit has not been damaged during
transport. If you detect damage, contact Zodiac Group
Australia on 1800 688 552 before using your Zodiac V1
robotic cleaner.
To unpack the Zodiac V1 and its components:
1. Open the top aps of the carton.
2 Remove the control unit from the carton.
3. Remove the oating cable and then the cleaner
from the carton.
1. Place the template, provided with the unit, on the
wall where you want to attach the control unit.
2. Using the appropriate drill bit, drill three (3) holes.
Screw the three (3) 1/4" (6mm) screws, provided
with the unit, into the holes and place the control
unit onto the screws. Refer to Figure 2.
Cleaner
Control Unit
Floating Cable
Page 6
Failure to comply with the following warnings can
result in permanent injury, electric shock or drowning.
• Keep the control unit at least 3 metres from the
edge of the pool. Never submerge the control unit.
• Only connect the control unit to a receptacle
protected by a Residual Current Device (RCD),
having a rated residual operating current not
exceeding 30mA. Contact a certified electrician if
you cannot verify that the receptacle is protected
by a RCD.
• Do not use an extension cord to connect the
control unit.
• Do not allow anyone to swim while the Zodiac V1
robotic cleaner is in the pool.
For your safety and to obtain the best possible
performance from your Zodiac V1, connect the
cleaner’s oating cable to the cleaner's control unit by
twisting the threaded connector until it is snug. Do not
overtighten. Refer to Figure 3.
1. While holding the cleaner by the handle, submerge
the cleaner in the pool and remove any air trapped
inside by keeping the unit vertical. Make sure that
the cleaner sinks to the bottom of the pool. Refer
to Figure 4.
2. Spread the oating cable out over the pool,
ensuring there are no kinks or bends in the cable.
Refer to Figure 5.
1. To start your Zodiac V1 robotic cleaner, press
the ON/OFF button. Refer to Figure 6. The green
indicator light will illuminate briey and the
cleaner will start up after just a few seconds.
NOTE: The cleaner will clean the oor and lower portion
of the pool wall. The cleaner will not reach the
water line.
2. If you wish to stop the cleaner during the cleaning
cycle, press the ON/OFF and ensure that the green
LED light goes off. Refer to Figure 6.
3. At the end of the cycle, the cleaner needs a cool
down period of 15 minutes to prevent damage to
the seals. During this period, the green indicator
light stays ON permanently.
Control Unit
Floating Cable
Threaded Connector
The green indicator light on the control unit will
illuminate for a short period to indicate that the cycle
is ready to start. Do not try to start a cycle until the
indicator is illuminated.
• The Zodiac V1 control unit is equipped with an
automatic shut off feature to prevent overheating if
operated in direct sunlight for an extended period of
time.
The Zodiac V1 control unit is water-resistant, not
waterproof. In order to prevent the risk of electric
shock which could result in serious injury or death,
never submerge the control unit.
Page 7
4. After the cool down period is complete, the green
indicator will turn off. The unit can be removed
from the pool.
NOTE The Zodiac V1 includes a safety feature that
automatically stops the cleaner if it is powered
ON when it is not submerged in the water. For
pools equipped with a beach area, this safety
feature allows the cleaner to reverse, and go
back into the pool.
1. Remove the Zodiac V1 from the pool after the
cleaning cycle is completed.
To prevent damage to the cleaner, never lift the
Zodiac V1 robotic cleaner out of the pool using the
floating cable.
Remove the Zodiac V1 from pool when super
chlorinating.
Do not handle cleaner while it is in operation.
2. Never lift the Zodiac V1 out of the pool by the
floating cable. Always use the handle to remove
it from the pool. Drain the remaining water from
the cleaner by keeping the cleaner in a vertical
position. Refer to Figures 7 and 8.
3. Disconnect the control unit cable from the
electrical outlet.
4. Disconnect the cable from the control unit.
5. At the end of each cycle, coil the cable starting at
the cleaner and go toward the connection point at
control unit. Remove coils or twists along the way.
6. Store cleaner out of direct sunlight.
• Use your Zodiac V1 robotic cleaner as often as
needed to keep your pool clean.
• Clean the lter canister after each cleaning cycle.
• Do not leave your cleaner in the pool on a
permanent basis.
• At the end of each cycle, remove the cleaner from
the pool. Start at the cleaner head and untangle any
coils in the hose before storing the cleaner.
ON/OFF
Button
Page 8
To avoid electric shock and other hazards which
could result in permanent injury or death, disconnect
(unplug) the cleaner from the electrical outlet before
performing any cleaning and maintenance.
The lter canister should be cleaned at the end of
each cycle.
1. Ensure that the control unit cable has been
disconnected from the electrical outlet.
2. Set the unit on its wheels.
3. Push the cover latch and lift the cover. Refer to
Figure 9.
Cleaner
Top Cover
Cover
Latch
4. Remove the lter assembly from the body, as
shown in Figure 10.
1. Position the lter canister hooks on the top cover
receiving pins, as shown in Figure 12.
5. Press the canister clip with your nger to separate
the lter canister from the top cover, as shown in
Figure 11.
6. Wash the lter canister with water using a hose.
Top Cover
Receiving Pins
Top Cover
2. Rotate the lter canister and lock it in place using
the front clip. Refer to Figure 13. When the lter
canister is installed properly on the top cover, it
will be rmly attached.
3. Locate the top cover hinges under the body
shoulders, as shown in Figure 14.
4. Lower the cover and allow the cover latch to lock
the top cover in place. Refer to Figure 9.
Page 9
The cleaner must be cleaned regularly using slightly
soapy clean water, do not use solvents. Rinse the cleaner
generously using clean water. Store the cleaner in a cool
dry place.
NOTE: The cleaner cable must be disconnected from
the control unit before removing the cleaner
from the pool.
The cleaner is tted with a PVC brush. To maintain
cleaner performance at its best, you will need to replace
the brushes when they are worn.
1. Place the cleaner upside-down so that you can
access the brush. Refer to Figure 15.
2. Push on one of the arms of the brush to remove its
shaft from the bushing, as shown in Figure 15.
3. Lift the brush and then remove it from the cleaner.
Refer to Figure 16.
4. Install the new brush shaft in its bushing. Refer to
Figure 16.
5. Install the second shaft (on the other side) of the
new brush in its bushing. Refer to Figure 16.
Front Clip
Brush
Shaft
Brush
Bushing
Page 10
1. Using your ngers, pull on the inside of the old
tyre to remove the tyre lip from the wheel. See
Figure 17.
2. Remove the old tyre as shown in Figure 18.
3. To replace the tyre, position the new tyre on the
wheel making sure to orient the tyre so that the
tyre groove pattern is on the outer side of the
wheel. See Figure 19.
4. Push one side of the tyre on to the wheel and t
the tyre onto the wheel as shown in Figure 20.
5. Work the tyre around and onto the wheel. Refer to
Figure 21.
Page 11
The cleaner
does not move
and the green
indicator light
does not
illuminate.
Unit is OFF. Make sure the ON/OFF button is turned ON.
Cleaner is not supplied
with electricity.
1. The electrical outlet the control unit is connected to is not supplying
electrical power.
2. Plug main power cord into another electrical outlet that is powered and
ensure the green light ashes once.
3. If the green indicator does not illuminate, contact your local pool shop.
The green
indicator light
ashes after you
press the ON/
OFF button.
Control unit needs to
be reset/not properly
connected.
Submerge the cleaner following the procedure in Section 4.1,
"Submerging the Cleaner".
1. To reset the supply:
a. Unplug the main power cord from the electrical receptacle.
b. Disconnect the oating cable connector from the control unit and then
reconnect it following the procedures in Section 3.3,
"Electrical Connection".
c. Plug the main cord in the electrical receptacle and check if the green
indicator light illuminates.
d. Press the ON/OFF button. If the green indicator does not illuminate
or ashes, contact your local Zodiac service representative.
The cleaner
does not suck
the debris.
The lter is full or dirty. Clean the lter canister following the procedure Section 5.1, "Cleaning the
Filter Canister".
The impeller is clogged or
damaged.
Make a visual check of the impeller. If the impeller is clogged, unplug the
main power cord from electrical receptacle then, remove debris. If the
impeller is damaged contact your local Zodiac service representative.
The cleaner
does not stay
rmly on the pool
bottom.
There is air in the
appliance casing.
Submerge the cleaner following the procedure in Section 4.1,
"Submerging the Cleaner".
The impeller is clogged or
damaged.
Make a visual check of the impeller. If the impeller is clogged, unplug the
main power cord from electrical receptacle then, remove debris. If the
impeller is damaged contact your local Zodiac service representative.
The cleaner's
ability to climb
the pool sides is
reduced.
NOTE: The
cleaner is not
designed to
climb up to the
waterline.
The lter is full or dirty. Clean the lter canister following the procedure Section 5.1,
"Cleaning the Filter Canister".
Tyres are worn. Replace the tyres following the procedure in Section 5.5,
"Replacing the Tyres on the Cleaner."
Sides of pool are slippery
or slimy. Although the
water seems clear,
microscopic algae,
invisible to the human
eye, are present in the
pool. As a result the pool
sides become slippery
and prevent the cleaner
from climbing.
Ensure that your pool's chemicals are balanced. If the chemicals are
balanced, contact your local Zodiac service representative.
The cleaner
seems to be
performing less
efciently.
The brushes have
become worn.
Replace the brushes following the procedure in Section 5.4,
"Replacing the Brushes".
Filter canister is full or
dirty.
Clean the lter canister following the procedure in Section 5.1,
"Cleaning the Filter Canister".
Floating cable is
excessively coiled or
kinked.
Make sure the oating cable is spread out over the pool.
Lay out the oating cable in a straight line in the sun for a few hours to
remove the kinks. Refer to 4.3, "Removing the Cleaner from Pool",
for proper cable handling.
Table 1 lists some of the more common symptoms, causes and solutions encountered when using the cleaner.
In order to prevent the risk of electric shock which could result in serious injury or death, DO NOT open the control
unit.
H0351306.B1
87 002 641 965
Zodiac Group Australia Pty Ltd
219 Woodpark Rd, Smitheld, NSW 2164 • PO Box 7238 Wetherill Park NSW 2164
TEL 1800 688 552 FAX 1300 781 688
© 2011 Zodiac Group Australia Pty.Ltd
Zodiac® is a registered trademark of Zodiac International, S.A.S.U., used under licence.
TM
Express Warranty
Zodiac Group Australia Pty Ltd (Zodiac Australia) warrants that the Zodiac
V1 robotic cleaner will be free from defects in materials and workmanship
for the period of 2 years from date of purchase. Normal replacement items
such as tyres and the lter canister which have been worn out by use or
improper installation are not covered by this warranty.
Conditions
1 This express warranty only applies if the Product has been purchased
from a dealer authorised by Zodiac Australia to supply it (Authorised
Dealer).
Purchase from an Authorised Dealer ensures that the product is a
genuine Zodiac product, that it is the version designed for Asia Pacic
conditions, and that the Purchaser has access to appropriate technical
knowledge and advice.
2 Zodiac Australia's liability under this express warranty is limited, at its
option, to the repair or replacement of the Product or the payment of
the cost of having the Product repaired or replaced.
3 This express warranty does not apply in the following circumstances:
(a) if the Product has not been installed in accordance with Zodiac's
installation instructions;
(b) if the Product has been modied other than as authorised by Zodiac
Australia or if a component part has been replaced by a part that is
not a genuine Zodiac product;
(c) if a defect results from use of the Product outside recommended
operating conditions; or
(d) if a defect results from damage (including damage to any internal
electronics) caused by a power surge or lightning strike.
Zodiac chlorinators are designed and tested in accordance with
International Standard EN 61000-6-1 immunity measurements. They
are designed to tolerate minor uctuations (2000 volts) in power supply
that can be reasonably expected to occur in the energy grid. They will
not tolerate power surges outside these limits nor will they withstand
lightning strikes.
4 Without limiting 3 above, products sold by Zodiac Australia are designed
for use with swimming pool water balanced in accordance with Australian
Standard AS3633-1989 with a pH range of 7.0 - 7.8. Maximum chlorine
readings should not exceed 4ppm. Where pool water is not maintained
within these parameters, Zodiac Australia will not be responsible under
this express warranty for any resulting damage, including damage
caused by corrosion, scaling or stress loading.
5 Replacement parts supplied under this express warranty are warranted
to be free from defects in materials and workmanship for the remainder of
the warranty period or for 12 months from the supply of the replacement,
whichever is longer.
6 Warranty claims relating to replacement of the electrodes for LM series,
C series, Duo Clear and D series chlorinators are subject to the following
pro-rata pricing procedure. The Purchaser must pay for the replacement
electrode a proportion of the cost equal to that proportion of the warranty
period during which the original electrode functioned effectively. The
warranty period for the replacement electrode is the remainder of the
warranty period for the original electrode or 12 months from the supply
of the replacement, whichever is longer. The Purchaser must pay full
cost for any replacement electrodes after the rst replacement.
Product warranty registration
7 Purchasers should register their Products as soon as conveniently
possible after purchase by completing a Product Warranty Registration
Form and posting it to Zodiac Australia at the address shown on the
Form or by registering online at www.zodiac.com.au.
8 Product registration must occur, and proof of purchase must be received
by Zodiac Australia, prior to any warranty work being approved. Where
applicable, a serial number, installation date and name of installer is
required as part of the registration process.
How to make a warranty claim
9 The Purchaser must telephone or email Zodiac Australia Customer
Service and obtain a warranty ID number for the warranty claim.
Contact details are:
Zodiac Group Australia Pty Ltd
219 Woodpark Road
Smitheld NSW 2164
Customer Service
Telephone: 1800 688 552
Email address: [email protected]
10 Zodiac Australia reserves the right to determine, in relation to each
warranty claim, whether the Product should be returned to the Authorised
Dealer at the address where the Purchaser purchased the Product or
whether warranty service will be provided in the eld, repaired at a Zodiac
workshop or at the premises of an authorized Zodiac warranty agent.
11 If it is necessary for the Purchaser to incur freight charges in making
a valid claim under this warranty, Zodiac Australia will reimburse the
Purchaser for charges reasonably incurred upon proof of the charges.
Additional guarantees, rights and remedies
Australian Purchasers - Guarantees under the Australian
Consumer Law
12 The benets of this express warranty are in addition to other guarantees,
rights and remedies Australian consumers have under the Australian
Consumer Law.
13 Zodiac Australia products come with guarantees that cannot be excluded
under the Australian Consumer Law. You are entitled to a replacement or
refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Purchasers in other Countries
14 The laws and regulations of other countries may confer on Purchasers
in those countries additional rights and remedies. To the extent that they
cannot be excluded or modied, Purchasers have the benets of those
rights and remedies in addition to the benets of this express warranty.
To the full extent that it is permissible to do so, those additional rights and
remedies are excluded or modied so as to be consistent with Zodiac
Australia's express warranty.
INCONSISTENCY WITH WARRANTY STATEMENTS IN PRODUCT
MANUALS OR OTHER DOCUMENTS ACCOMPANYING PRODUCTS
If any warranty statements in a Zodiac Australia product manual or other
document are inconsistent with the above Express Warranty and Guarantees,
the above overrides and replaces the inconsistent statements.
Zodiac Australia - Express Warranty and Guarantees
SAA 110779EA
Other manuals for V1
1
Table of contents
Other Zodiac Swimming Pool Vacuum manuals
Zodiac
Zodiac EN11 Series User manual
Zodiac
Zodiac Nature 2 Express User manual
Zodiac
Zodiac ALPHA iQ User manual
Zodiac
Zodiac Vortex 3 User manual
Zodiac
Zodiac BARACUDA 1500 User manual
Zodiac
Zodiac CyclonX User manual
Zodiac
Zodiac Vortex OV 3400 User manual
Zodiac
Zodiac Zippy User manual
Zodiac
Zodiac ALPHA iQ User manual
Zodiac
Zodiac Vortex OV 3450 User manual
Zodiac
Zodiac MX6 Elite User manual
Zodiac
Zodiac Genius User manual
Zodiac
Zodiac VX55 4WD User manual
Zodiac
Zodiac Baracuda Pacer User manual
Zodiac
Zodiac G4 User manual
Zodiac
Zodiac T3 User manual
Zodiac
Zodiac Activ AX 10 User manual
Zodiac
Zodiac T5 Duo User manual
Zodiac
Zodiac G2 User manual
Zodiac
Zodiac Baracuda G3 User manual
