Zodiac MX6 Elite User manual

1

2
A BETTER LIFE
For over 100 years we have been motivated by innovation...
and innovation has inspired our greatest successes. Every day
we strive to supply the highest quality products... and constantly
seek to develop INNOVATIVE products.
Innovation, is what we create every day... for everyone...
for a better life: Because the pool is a source of PLEASURE and JOY...
a place to REUNITE FAMILIES... which CREATES RELATIONSHIPS
and memories... a place where time stands still. That’s the magic of a pool!
At Zodiac®, we manufacture more than just pool equipment... we create
A BETTER LIFE.
Zodiac South Africa strives to offer world-class excellence in both
products and service. Complemented by a team of dedicated staff
throughout the country, we guarantee premium after sales services.
Should you require assistance on your Zodiac product, need to locate
a dealer near you or just wish to nd out more information, call our
Customer Care Helpline on 0860 ZODIAC (0860 963 422) or go to
www.zodiac.co.za.
IMPORTANT INFORMATION
PLEASE READ THIS INFORMATION BEFORE
INSTALLATION. ALWAYS READ THE OWNER’S MANUAL
BEFORE USING THIS PRODUCT.
PLEASE SEND US YOUR WARRANTY CARD TO ENSURE
YOUR WARRANTY IS REGISTERED AND RETAIN YOUR
PROOF OF PURCHASE IN THE UNLIKELY EVENT OF
FUTURE WARRANTY CLAIMS.

3
INDEX
INTRODUCTION 5
SECTION 1 – INSTALLATION 6
Preparing your Pool 6
Assembling the Hoses 7
Assembling the Weir ttings 8
Check Cleaner Flow 9
SECTION 2 – CORRECT SETTINGS 10
Auto Weir Valve 10
SECTION 3 – CARE AND MAINTENANCE 11
General 11
Removing Debris from the Engine 12
SECTION 4 – PARTS IDENTIFICATION 13
SECTION 5 – TROUBLESHOOTING 14
SECTION 6 – OPTIONAL ACCESSORIES 16
SECTION 7 – THE PERFECT PARTNER FOR YOUR MX™6 17
SECTION 8 – GETTING TO KNOW YOU BETTER 18
SECTION 9 – AT YOUR SERVICE 19

4
IMPORTANT INFORMATION
WARNING
RISK OF SUCTION ENTRAPMENT HAZARD WHICH, IF NOT
AVOIDED, CAN RESULT IN SERIOUS INJURY OR DEATH.
READ THIS MANUAL IN ITS ENTIRETY BEFORE INSTALLING
AND OPERATING THE CLEANER.
Do not block the suction fittings in the pool, the suction opening on the
cleaner, or the cleaner hoses with any part of your body.
Do not expose your hair, loose clothing, jewellery, etc, to any suction
outlet fittings in the pool / spa or on the cleaner.
• Clean the weir basket, pump basket and backwash the pool filter
before installing the cleaner and on a regular basis thereafter.
• Always disconnect the cleaner from the weir before cleaning or
backwashing the pool filter. After cleaning or backwashing,
let the filtration system run for at least ve (5) minutes before
re-connecting the cleaner.
• Remove the cleaner from the pool before chemical or shock
treatments. Wait a minimum of four (4) hours after super
chlorination before re-installing the cleaner.
Read owner’s manual completely before operating the cleaner.
Do not operate outside of the pool.
Do not let children play with cleaner.

5
INTRODUCTION
Dear Customer,
Thank you for purchasing the MX™6. It is through customers
such as you that our position as worldwide market leader in pool care
remains unchallenged. At Zodiac, we are constantly striving to bring the
latest innovation and technology to your pool via our range of products.
The MX™6 uses brand new technology which will take pool
cleaning to a new level
In the event of requiring under-warranty repairs, please take your
MX™6 to your closest pool shop, or alternatively please
phone our Customer Care Helpline 0860 ZODIAC (0860 963 422) and
we will direct you to the ZODIAC warranty agent nearest to you.
THE CONTENTS IN YOUR MX™6 BOX ARE AS FOLLOWS:
• One MX™6 Pool Cleaner
• 7 x 1.2m of Long-Life Twist Lock Hose Lengths
• One Flow Regulator Valve
• One Hose Float
• One Auto Weir Valve with 90˚ Elbow
• One Hose Protector
• One Warranty Card
• One Quick Start Guide
This Pool Cleaner has several patents pending.
MX™6 is a Trade Mark of ZODIAC Pool Care South Africa (Pty) Ltd.
Specifications and equipment are subject to change without prior notice.

6
While the MX™6 is designed for easy installation,
some preliminary steps will assist the installation process.
Where possible, assembly should take place as close to the weir
as possible.
PREPARING YOUR POOL AND FILTRATION SYSTEM
1) Empty the weir basket.
2) Clean the pump basket.
3) Backwash and rinse the filter until the sight glass is clear.
4) Adjust all return jets (whether your pool has one, two or more) to
point downwards and towards the center of the pool so that you DO
NOT see a circular water ow or ripples on the surface of your pool.
5) Ensure your water chemistry is correct. See page 11 or below for
more on this.
* When using chemicals, always follow manufacturer’s directions and follow the advice of your
pool professional. Always use protective clothing, gloves and glasses. Store and use chemicals
out of the reach of children.
Pool Type
pH pH Free Chlorine (ppm)
Cyanuric Acid
(ppm)
Calcium Hardness
(ppm)
Total Alkalinity
(ppm)
Marbelite 7.4 - 7.6 2 - 4 ppm 40 ppm 200 - 250 ppm 80 - 125 ppm
Vinyl/
Fibreglass
Painted
7.6 2 - 4 ppm 40 ppm 175 - 225 ppm 125 - 150 ppm

7
1. The hose oat is already fitted on
one of the hoses, connect this length
of hose to the Flow Regulator Valve
and twist until it locks into place.
2. Insert the second length of hose into the pool vertically in order to fill it
with water. Insert the male cuff of the rst hose length into the female cuff
of the second hose length, and twist until the two lock together. The hoses
must connect fairly tightly. Continue attaching hose lengths until you reach
the required length of your pool, submerging each hose length as you go.
3. Required hose length: use enough
hose to reach the furthest point
of the pool plus add another section
as shown in the diagram. (Step 3)
4. Connect your cleaner to this
length of hose by pushing the
Flow Regulator Valve onto the
cleaner swivel. When you hear a
click, it is securely connected.
Now submerge your cleaner by
filling it with water ensuring all
trapped air has escaped.
Before connecting to the weir
ensure that all the hoses are filled
with water and all the air has
been expelled.
ASSEMBLING THE HOSES
With your swimming pool preparation complete, you are ready to
begin installation.
WARNING: To avoid severe injury, make sure to turn off the
pool pump prior to completing these steps.
SECTION 1 – INSTALLATION
Weir
Weir
Step 1
Step 3

8
SECTION 1 – INSTALLATION
ASSEMBLING THE WEIR FITTINGS
With your hose lengths and cleaner connected, add the hose protector to
the last hose which will be connected to the weir.
1. Place the hose into one half of the Hose Protector.
2 . Place the other half of the Hose Protector over the hose ensuring that
the clips line up.
3 . Apply pressure to both halves of the Hose Protector until both halves
clip into place.
POSITIONING THE WEIR FITTINGS
The ideal position to t the Hose Protector is directly after the hose cuff.
Note:If the hose is connected directly to the Auto Weir Valve (not
advised), position the Hose Protector approximately 10cm from the
hose cuff.
Now connect this hose to the 90º Elbow and Auto Weir Valve as shown
in Figure 1. Plug the Auto Weir Valve and hose into the weir. Your cleaner
should begin cleaning your pool.
To Automatic
Pool Cleaner
(APC)
Male Hose Cuff
Fig. 1

9
SECTION 1 – INSTALLATION
CHECK CLEANER FLOW
When holding the MX™6 head under water, watch the yellow wheel
marker, use a stopwatch to time 10 wheel rotations.
Wait for wheels to change
direction, then begin
counting. If wheel reverses
during timing, start over.
10 rotations seconds
IF
+
_
.
... .
Time is...
26-50
20-25
10-19
Result...
Poor Performance
Possible Damage
Adjust Flow...
Increase Flow
Decrease Flow
Adjust flow as described on the next page

10
SECTION 2 – CORRECT SETTINGS
ADJUSTMENT SETTINGS
You will only need to adjust the Auto Weir Valve if the following occurs:
AUTO WEIR VALVE
The Zodiac Auto Weir Valve is preset at the factory to obtain maximum
pool cleaning efciency. Your MX™6 is preset on setting 2. However, if
you do experience difculties, it can be manually adjusted to one of the
three settings – high, medium or low (see Adjustment Settings below).
TURNINGYOUR MX™6
OFF IS MADE
EASY WITH
THE AUTO
WEIR VALVE
You no longer need
to remove the
Zodiac Auto Weir
Valve from the weir.
®
TURNINGYOUR MX™6
OFF IS MADE
EASY WITH
THE AUTO
WEIR VALVE
You no longer need
to remove the
Zodiac Auto Weir
Valve from the weir.
®
NOTE: To obtain maximun
Diaphragm efficiency, please
ensure a genuine Zodiac
Auto Weir Valve is used.
®
PROBLEM SOLUTION
Your MX™6 Pool Cleaner
is performing too fast and/
or climbing above the
level of water
Reduce Auto Weir Valve
to medium(2) or low(1)
setting
Your MX™6 Pool Cleaner
is performing slowly and/
or not climbing the pool
walls
Increase Auto Weir Valve
to medium(2) or high(3)
setting

11
SECTION 3 – CARE AND MAINTENANCE
Sunlight, water and pool chemicals create a harsh environment. With care
and regular maintenance your MX™6 will remain in the best
possible condition.
To properly care for your unit: –
1. Remove the MX™6 from the
pool before shock treatment and
reinstall at least four hours later.
2. The weir basket, pump basket,
cartridge, sand filter (which ever
is applicable) should be thoroughly
cleaned on a regular basis to ensure
optimum pool cleaner efciency.
3. Before backwashing your filter,
always disconnect the hose from
the weir.
4. Never “coil” the hose and always
store them straight.
Note: Your pool cleaner will
discolour over time, but this will
not change the performance of
the unit.
5. Large foreign objects, such as toys
and branches should be removed
manually from the pool cleaner.
Zodiac®recommends the following water chemistry readings for optimal
performance of any pool equipment:
* When using chemicals, always follow manufacturer’s directions and follow the advice of
your pool professional. Always use protective clothing, gloves and glasses. Store and use
chemicals out of the reach of children.
incorrect
correct
Pool Type pH Free Chlorine
(ppm)
Cyanuric Acid
(ppm)
Calcium
Hardness(ppm)
Total Alkalinity
(ppm)
Marbelite 7.4 -7.6 2 - 4 ppm 40 ppm 200 - 250 ppm 80 - 125 ppm
Vinyl/
Fibreglass
Painted 7.6 2 - 4 ppm 40 ppm 175 - 225 ppm 125 - 150 ppm

12
1. Push the yellow release button on
the top of the cleaner.
2. Rotate the top cover back until it
clicks into an upward position.
3. Look into engine and remove
debris that is present.
4. If needed, slowly push engine
paddles forward and/or
backwards to move stuck debris
to an accessible position and
then remove it. When moving
the engine paddles, make sure
the cleaner tracks are allowed to
move freely as they will turn as
the engine paddles rotate.
5. Close top cover and ensure it
clicks into place.
WARNING:To avoid serious injury, make sure that the cleaner is
disconnected from the hose and the suction pump is turned off prior
to starting this operation.
REMOVING DEBRIS FROM ENGINE
SECTION 3 – CARE AND MAINTENANCE

13
SECTION 4 – PARTS IDENTIFICATION
No No Description Qty
1 Hose Float 1
2Flow Regulator Valve 1
3Top Cover W/Swivel Assembly 1
4 Screw, M4x12mm, Phillips #2 Pan Head 10
5Middle Engine HousingW/Ramp & 2 Seals 1
6 Cover Latch 1
7Pulley Coupler Assembly 1
8 Bearing (Wheel & Engine) 10
9Engine Assembly 1
10 Drive Shaft Assembly 1
11 Body Panel, Right (D) 1
12 Lower Engine Housing 1
13 Body Panel, Rear (B) 1
14 Screw,Thread Forming, #6-18 7/8in Type A,
Phillips #2 Pan Head
1
No No Description Qty
15 Direction Control Device, Side A 1
16 Body Panel, Left ( C ) 1
17 Track 2
18 Wheel Pin 4
19 Wheel 4
20 Chassis Assembly 1
21 Body Panel, Front (A) 1
22 Lower Body Housing 1
23 Fan Assembly 1
24 Pearl Blue Twist Lock Hose - 1.2m 7
25 Auto Weir Valve 1
26 In-ground Valve Cuff 1
27 90° Twist Lock Elbow 1
1
2
3
4
5
6
7
8
11
13
14
24
25
26
27
16
17
15
12
8
8
8
10
9
17
18
19
21
22
19
23
20
18
8
8

14
SECTION 5 – TROUBLESHOOTING
PROBLEM SOLUTIONS
Your MX™6 does not move
or moves slowly.
Check Cleaner flow to verify proper ow (pg 9).
Check for debris jammed in engine (pg 12).
Backwash filter and empty pump basket.
Check for air in system. If the water level in pump basket drops
or you see excessive air bubbles in the pump basket or coming
from the return lines, there is air in the system. Check hose
connections, tighten all fittings at pump and check o-ring at
pump basket for wear.
Your MX™6 coverage is poor.
For example, the cleaner does
not reach parts of the pool
and leaves large uncleaned
patches.
Check Cleaner flow to verify proper ow (pg 9).
Ensure return jets are directed down.Add a return diverter if
necessary. (see optional accessories)
Make sure hose is not kinked or coiled.
Conrm proper hose length. (pg 7)
Observe cleaner for more than ve (5) minutes and ensure that
each drive track is periodically reversing. If it is not, contact your
dealer or service center for help.

15
SECTION 5 – TROUBLESHOOTING
PROBLEM SOLUTIONS
Your MX™6
gets stuck at steps.
Observe cleaner for more than ve (5) minutes and ensure that
each drive track is periodically reversing direction. If it is not,
contact your dealer or service center for help.
Ensure the swivel on top of the cleaner rotates freely.
Check Cleaner flow to verify proper ow. (pg 9)
Conrm proper hose length. Shorten if necessary. (pg 7)
Your MX™6 won’t climb walls. Increase flow to Setting 3 on the Auto Weir Valve. (pg 10)
Your MX™6 climbs too much Reduce the flow on the Auto Weir Valve to setting 1. (pg 10)
For additional assistance, contact our Customer Care Helpline on
0860 ZODIAC (0860 963 422)

16
SECTION 6 – OPTIONAL ACCESSORIES
3. AIM FLOW DIVERTOR
To allow pool cleaner to clean
close to return ow.
5. CYCLONIC LEAF CATCHERTM
An in-line filter which collects all the leaves, seeds,
twigs and grit before they reach the weir, using
an innovative vortex technology. Connects in-line
with the hoses (suitable for Twist Lock and
standard pool hose).
1. WEIR ADAPTOR
Fits suction inlets from
40 to 60mm
2. WEIR COMBINATIONS
Auto Weir Valve and Weir Elbows illustrating
some of the different combinations that can
be used.

17
SECTION 7 – THE PERFECT PARTNER FOR YOUR MX™8
A Salt Chlorinator from Zodiac®
Installing a Zodiac Salt Chlorinator is the effortless way to having a crystal
clear pool, all the time.
Zodiac®Salt Chlorinators offer both convenience and peace of mind.
Innovative technology means that you are assured of quality and product
excellence. Zodiac®is by, far the most widely chosen brand of Salt
Chlorinator available in South Africa today.
Your purchase will ensure that you get the best of both worlds. Firstly,
you will enjoy the convenience of a fully automatic product, which allows
you to spend time relaxing at the poolside – perfect for a modern-day
lifestyle. You will also experience the fantastic soft feeling that only a salt
chlorinated pool can offer.
No more red eyes or itchy skin, just smiles all the way!
A PowerFirst Premium Heat Pump from Zodiac®
Extend your swimming season and get even more pleasure from your
pool by installing a PowerFirst Premium Heat Pump.
This market-leading range of heat pumps from Zodiac utilises only the
best components and materials, ensuring you total peace of mind and
enjoyment of your pool.
PowerFirst Premium is not only the most energy efcient range of heat
pumps available today, but also the most environmentally friendly.

18
SECTION 8 – GETTING TO KNOW YOU BETTER
At Zodiac®, we strive to give our consumers superior quality products, as
well as service excellence.To help us improve, please spare a moment of
your time and let us understand your needs a little better. Once you have
lled in the following survey, please fax a copy to [phone].
Title ..................................................................................................................................
Name & Surname ..........................................................................................................
Email Address .................................................................................................................
Are you male or female? .............................................................................................
Date of birth ..................................................................................................................
How long have you owned your current pool? .....................................................
Do you own any other Zodiac®products? .............................................................
If so, which ones? ...........................................................................................................
Which of our products would you like to own? ....................................................
Describe how you feel about owning a pool (love it / hate it)? .........................
Why did you choose to purchase a Zodiac®product? .........................................
Why did you choose to purchase your MX™6? .....................................................
.........................................................................................................
Have you ever called our Call Centre? ....................................................................
If so, please rate it on a scale of 1 - 5
1. Extremely poor 4. Good
2. Poor 5. Extremely good
3. Acceptable
Would you like to register for Aquasense, our monthly communication lled
with information, tips and trends on pool care? (If yes, state here and ll in
your email address above) ................................................................................

19
SECTION 9 – AT YOUR SERVICE
If you are having a problem you cannot solve, mail or fax us the following
information, along with a sketch of your pool shape, indicating the location
of all weirs, inlets, stairs, ladders, waterfalls or any other signicant features,
and briey describe the problem in the space below.
(Send a photocopy and retain this page for future use.)
Mail to: Zodiac® Pool Care SA, Private Bag X127, Halfway House, 1685
Fax to: [phone]
Name ........................................................Tel No. ................................................
Postal Address ...............................................................................Code..............
Serial Number ........................................................................................................
Purchased from ................................................ Date of Purchase...../....../.......
Pool Surface (Tick one): Plaster Vinyl Fibreglass Other
If other, please stipulate .......................................................................................
Pool Size (Litres)................................................ Pump Size ...............................
Type of Filter (Tick one): Sand D.E. Cartridge
Filter Size (or Model No.)....................................................................................
My pool looks like this:
Briey describe the problem ......................................................................................
...........................................................................................................................................
...........................................................................................................................................
...........................................................................................................................................
Customer Care Helpline: 0860 ZODIAC (0860 963 422)
www.zodiac.co.za

20
ZODIAC POOL CARE SOUTH AFRICA (PTY) LTD
Private Bag X127
Halfway House
1685
Customer Care Helpline
0860 ZODIAC (0860 963 422)
www.zodiac.co.za
WARNING: In terms of Section 2 of the Import and Export Control Act of 1989 (Act 45 of 1983), it is
illegal to export Automatic Pool Cleaners and parts thereof. Section 4 of the Act provides that anyone
convicted of exporting Automatic Pool Cleaners and parts thereof may be sentenced to a 10 (ten) year
term of imprisonment and a ne of R40 000 (forty thousand Rand).
