Zohd MKIII Series User manual

Thank you for supporting us
buying a ZOHD Alpha Strike
User Guide
Inspiring The Future
Stay connected with us through our social media channels:
Contact us: [email protected] [email protected]
Customer service: [email protected]
www.zohd.net
Mount the main wings with the provided thumbscrews.
Don’t forget to place the main spar first.
The vertical fins are removable and can be fixed by the
2 provided thumbscrews.
You can add the nose of your choice using the provided screw.
Once you placed all your FPV gear, be sure both hatches
fit flushed against the fuse.
Attach the Teflon skin protection for landings according to the figure.
You will fix the motor seat with the 2 provided screws.
Be sure is aligned and firmly tighten.

10-12mm
RECOMMENDED THROWS
Empty weight (PNP): 441g
Min. recommended speed: 25-33km/h
Max. Speed (with default power combo): 185+km/h
Cruise speed (with default power combo): 86km/h @ 5A
Max Speed tested without structural failure:
192km/h with no structural damage or twist on elevons
Max recommended takeoff weight:
900 grams (with default power combo)
Reflex on elevons: 3mm at level
Recommended max. Throws:
10-12mm depending on your style
Recommended expo for manual:
55-75 depending your style/skills
CG=75mm
This model requires experience to setup and fly. It’s by no means designed for
beginners. If you’re starting in the hobby, please check some of our other products
that will be more suitable for beginners. This is a powerful unit considering the size
and weight and will require you to have strong orientation abilities, specially flying
line of sight. We also recommend you to fly this unit with stabilization (flight controller)
unless you’re extremely skilled with the sticks.
Finally consider adding lead weights to achieve a perfect CG balance. Enjoy!
