Zohd Nano Talon Instruction manual

Nano Talon Quick Start Manual
Diagram for ZOHD Stabilizer
Specificaon
Data: Configuraon:
Wingspan: 860mm(33.85in) Motor: 2204-1870KV
Length: 570mm(22.44in) ESC: 30A w/BEC 1A
Flying Weight: 410~450g Baery: 3S 1300~1800mAh
Flying Time: 30 Minutes Servo: 8g*3pcs Digital
Material: Lightweight EPP Propeller: 6x3
Note
Shutdown all the mix control of your radio before using this Stabilizer.
Do not trim any channel while flying.
Red Indicator means 3-axis stabling mode for advanced user.
Blue Indicator means 6-axis autostability/take-off mode for beginner.
They can be changed by the Mode Switch channel during flying.
When calibrang the stabilizer, both red and blue indicator will quick flashing,
do not move the stabilizer while calibrang,the calibrang will be finished aer
blue and red indicator quick flashing for about 5 seconds. Slow flashing means error.
Safety Aenons
1. Do not fly in raining, snowing, or windy weather.
2. Do not fly near HV power cable, signal staon, signal tower
or Wi-Fi hot spot, to avoid signal interference.
3. Do not fly around no-fly zone according to local law.
Throle Calibraon
You have to calibrate the throle of this Nano Talon when you fly it for the first me
or change a radio, or there will be unusual beeps.
Calibraon Step:
1. Turn on the radio and keep the throle on the top posion.
2. Power on the ESC.
3. Pull the throle scker to the lowest posion aer the motor with two short beeps.
4. Calibraon finished aer motor with two long beeps.
