PRODUCT DATA
24-Port Gigabit Switch
ZFS3424E
Features:
The Fast and Simple Network Expansion
Delivers up to 2000Mbps throughput
per port in Full Duplex Mode
No Software or Configuration Required
Compact 11" Rackmount-able Metal
Case
Auto-MDIX
The Zonet ZFS3424E - 24-Port Gigabit Switch gives your office network a Gigabit
Speed and capacity. The Auto-MDIX feature on each port automatically detects and adjusts
connection type with either straight-through or crossover cable as well as full/half-duplex sensing.
Users can take advantage of the ability to deliver large amounts of multimedia, image, and video
information between workgroups, labs and departments within your network.
WIREDW I R E D
10/100/1000Mbps
WIREDW I R E D
GIGA
MDIX

Specification
Zonet is a registered trademark.Other Brands and product namesare trademarks of their respectiveholders. Information provided in thisdocument pertains to
Zonet products and issubject to change atany time, without notice.For the most recentproduct information please visit
http://www.zonetusa.com
Copyright© Zonet. All Rights Reserved.
Zonet USA Corporation
18513 East Gale Ave. City of Industry, CA 91748
Tel: [phone] Fax: [phone]
Contact Us:
1.888.883.8880
[email protected]
www.zonetusa.com
Related Products:
ZEN3301E
ZFS3305E
ZFS3308E
ZFS3416E
One ZFS3424E
One Quick Installation Guide
One Rack-mount Kit
One Power Cord
Four Rubber Pads
Package content:
Gigabit 32-bit PCI Adapter
5-Port Gigabit Switch
8-Port Gigabit Switch
16-Port Gigabit Switch
24-Port Gigabit Switch
ZFS3424E
WIREDW I R E D
10/100/1000Mbps
WIREDW I R E D
GIGA
- Complies with IEEE802.3, IEEE 802.3u, IEEE 802.3ab standards
- Supports IEEE802.3x flow control for Full Duplex mode and backpressure for half-duplex mode
- 24 10/100/1000Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX
- Supports the Auto-MDI/MDIX function
- Supports MAC address auto-learning and auto-aging
- Every port has independent bandwidth
- LED indicators for monitoring power, link/activity
- Support UPnP
- Compact 11" Rackmount-able Metal Case
Standards and Protocol
Chipset
Transfer Mode
Access Method
Ports
Connector
Network Media
Frame Filtering & Forward Rate
MAC Address Table
Buffer Memory
Backplane Bandwidth
Dimension (L x W x H)
Power
Environment
IEEE802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
VSC7389HO-BGA596-VITESSE
Store and Forward
CSMA/CD
24
RJ-45
10Base-T: UTP category 3, 4, 5 cable (max. 100m)
EIA/TIA-568 100ÙSTP (max. 100m)
100Base-Tx: UTP category 5, 5e cable (max. 100m)
EIA/TIA-568 100ÙSTP (max. 100m)
10Mbps: 14880pps
100Mbps: 148800pps
1000Mbps: 1488000pps
8K
EEPROM:16K
48Gbps
280 x 180 x 44 mm or 11 x 7.1 x 1.73 In.
DC 12V / 2.1A
Operating Temperature: 0 C~ 40 C ( 32 F~ 122 F )
Storage Temperature: -40 C~70 C ( -4 F~ 158 F )
Operating Humidity: 10%~90% non-condensing
Storage humidity: 5%~90% non-condensing
