ZFS3015P
5-Port 10/100Mbps Switch
PRODUCT DATA
Features
The Fast and Simple Network Expansion
Delivers up to 200Mbps throughput
per port in Full Duplex Mode
IEEE 802.3x Flow Control supported
Provide 1K MAC address entries
Built-in 1Mega bits Memory Buffer
Store-and-Forward Switching method
Non-blocking Architecture
No Software or Configuration Required
WIRED
10/100
The Zonet ZFS3015P – 5-Port 10/100Mpbs
Switch provides a simple solution for expanding
your network. Connect the ZFS3015P to a router
and share high-speed Internet access with up to
four additional computers. By sharing the
Internet, your users can check e-mail, browse the
web, and chat with friends and family online
using their own computer. With Zonet ZFS3015P
– 5-Port 10/100Mbps Switch you can also add a
print server and Internet camera to increase the
functionality of your network.

Package Contents
• One ZFS3105P
• One Quick Install. Guide
• One AC Power Adapter
Specifications
Standard IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ports 5 x 10/100Mbps RJ45 ports, Auto MDI/MDI-X
Network Media 10Base-T: Cat. 3 or above UTP
100Base-TX: Cat. 5 UTP
Performance
Bandwidth: 1.6 Gbps (Non-blocking)
Packet transferring rate:
-100Mbps port: 1,480,000Mpps
-10Mbps port: 1,480,000Mpps
Switching Mode Store-and-Forward, On-chip packet buffering
LED Indicator Link/ACT, PWR
Dimension 140mm x 90mm x 30mm
Temperature Operating: 0ºC ~ 40 ºC (32º ~ 103ºF)
Storage: -40ºC ~ 70ºC (-40º ~ 157ºF)
Humidity Operating: 10% ~ 90% RH
Storage: 5% ~90% RH (Non-condensing)
Power output 9V / 600mA
Warranty 3 years Manufacturer Warranty
