ZFS3216P - 16-Port 10/100Mbps Switch
Quick Installation Gui e
P
Pa ac ck ka ag ge e C Co on nt te en nt ts s
•One ZFS3216P
•One Quick Installation Guide
•One Power Adapter
•Four Rubber Pads
F
Fr ro on nt t P Pa an ne el l
LED in icators
ED Status Operation
Power Green
Steady: Power is ON
NK/ACT Green
Steady: Network cable connected and connection established
Flash: Data packets are transmitting
Off: Network cable is unplug
Diagram
R
Re ea ar r P Pa an ne el l
1 Power Connector
16 RJ-45 ports

I
In ns st ta al ll la at ti io on n
1. Connect the provided power adapter to the Power connector of the ZFS3216P
2. Connect your network devices to the RJ-45 ports of the ZFS3216P with UTP/STP Category 3/4/5 cables
C
Ca au ut ti io on n
•The switch must put on a surface that is able to hold at least 5kgs weight
•Power adapter must be connected to the switch properly and securely
•Suggested at least 10cm empty space around the unit for sufficient ventilation and cooling
•Do not recommend to put any items on top of the switch
•ZFS3216P is not ideally to work in a high electromagnetic environment, under direct sunlight, dust and
vibrating surfaces
•Maximum distance between the switch and the end node is 100 meters
•Must use an unshielded or shielded twisted-pair (UTP/STP) Category 5 or better cables to ensure proper
transmission
•oss of data packet may encounter when using cable other than Category 5
T
Tr ro ou ub bl le es sh ho oo ot ti in ng g
1. Check the power adapter and power wall-jet to make sure they are function properly. Check if the switch
is turned-ON and power ED is steady.
2. Check all cable connections between computer and the switch to make sure they are connected properly.
3. Maximum distance is 100 meters from the switch to end nodes.
4. ink ED(s) is ON/flashing at the connected port(s) of the switch.
5. Test your computer’s network adapter to make sure it is installed and functioned properly.
6. Check issues such as network collisions, domain limitations, and other physical installation aspects. Make
sure they all meet IEEE standard network installation requirements, more details can be found at
www.ieee.org.
7. If problem still persists, write down your software/hardware configuration and ED error indications and
contact your local retailer or the store purchased for further assistance.
