Zoom Zoom ADSL X3 5560 User manual

Zoom
ADSL X3
Model 5560
The Zoom ADSL X3 Modem Model 5560 is a full rate ADSL modem and a powerful
gateway/router in a single affordable product.
The Zoom X3 delivers up to 8 Mbps data speeds over existing telephone wires in a
home or office. All popular ADSL standards are supported, including: Full Rate ANSI
T1.413, G.DMT ITU G.992.1 and Splitterless G.Lite ITU G.992.2.
With its built-in Internet gateway, the X3 can also provide ADSL access to up to 253
computers. The X3's router assigns individual IP addresses, to give each computer
independent access to the Internet. Plug the X3 into a simple hub to give ADSL service
to a wired network of computers. Or plug the X3 into a wireless access point to
provide your computers with wireless Internet access.
The Zoom X3 is designed for easy installation on any computer with an Ethernet port.
Most operating systems are supported including Windows 95, 98, 98SE, 2000, XP
and Me, Linux, Unix and MacOS. Setup is easy using a Web browser and the
product’s intuitive graphical user interface.
High-speed “al-
ways-on” Internet
access
ADSL modem plus
user-selectable
router with built-in-
NAT firewall
Works with all
popular ADSL ser-
vices
Fast and easy
installation
Includes two phone
jacks to support an
attached telephone
as well as ADSL
service
Software
upgradeable
Ethernet interface
for use with most
operating systems
Works great with
wireless access
points or gateways
Documentation and
software provided
in Danish, Dutch,
English, French and
Portuguese and
Spanish
Two year warranty
Modem + Router + Gateway with Ethernet Interface
Specifications
ADSL Compliance • Compliant with ADSL standards:
- Full-rate ANSI T1.413 Issue 2 and ITU G.dmt (G.992.1) standards
- Splitterless G.lite (G.992.2) specification
- Annex A
• DMT modulation and demodulation
• Full-rate adaptive modem
- Maximum downstream rate of 8 Mbps
- Maximum upstream rate of 1 Mbps
• Tone detection for low power mode
• Supports splitterless ADSL implementation
• Supports DSLAM notification on power loss (Dying gasp)
• Interoperable with all major DSLAM manufacturers
ATM Protocols • WAN mode support: PPP over ATM (RFC 2364) and PPP over
Ethernet (RFC 2516)
• LAN mode support: bridged/routed Ethernet over ATM (RFC 1483) and
Classical IP over ATM (RFC 1577)
• ATM Forum UNI 3.1/4.0 PVC
• Up to eight virtual circuits
• ATM segmentation and re-assembly
• ATM AAL5 (adaption layer type 5)
• OAM F4/F5

Specifications (continued)
Bridge Mode • Ethernet to ADSL self learning - Transparent Bridging (IEEE 802.1D)
• Supports up to 128 MAC learning addresses
Router Mode • IP routing - RIP v2
• Static routing
• DNS Proxy
• Port Forwarding
• DHCP (Dynamic Host Configuration Protocol) server and client
• NAT (Network Address Translation)
• NAPT (Network Address and Port Translation)
• Simultaneous USB and Ethernet operation
Security • User authentication for PPP
• PAP (Password Authentication Protocol)
• CHAP (Challenge Authentication Protocol)
• Password protected system management
Ethernet Interface • IEEE 802.3 compliant
• 10/100 BaseT - RJ45
Web-based • HTTP Graphical User Interface
• Password protected access
• Firmware upgrade via FTP
• WAN and LAN side connection statistics
• Configuration of static routes and routing table
• Configuration of NAT/NAPT
• Selection of bridge or router mode
• PPP user ID and password
• Configuration of virtual circuits
Warranty • 2 years
Size • 14.6cm x 11.2cm x 2.8cm
Regulatory Approval • CE, EN5502, EN55024, IE C69950
ADSL X3
ADSL Modem + Router + Gateway with Ethernet Interface
00000000
Model 5560
Package contents:
• Ethernet modem
• Ethernet cable
• Phone cable
• CD ROM disk
• User manual
• Power adapter
• Filters and phone adapters:
Filters and/or phone adapters may be included
in some markets. Please check the package for
specifics or ask your dealer. An ADSL filter
allows a telephone, facsimile machine, or other
telephone instrument to be used even when you
are online with your ADSL modem.
