Introduction / H4n Pro features
H4n Pro features
࠮(UHSSPUVULOHUK`YLJVYKLY
The H4n Pro is lightweight (294 g) with a very compact design and is equipped
with high quality stereo condenser microphones arranged in an XY pickup
pattern, a built-in speaker, SD card recording, a mixer and internal effects.
You can enjoy recording and creating your own music anytime, anywhere with
the H4n Pro.
࠮=LYZH[PSLÄLSKYLJVYKLY^P[OT\S[P[YHJRJHWHIPSP[`
The H4n Pro is capable of recording in several different operation modes.
STEREO mode enables high-quality stereo recording. 4CH mode can record 2
sound sources simultaneously in stereo. MTR mode allows playback of 4 tracks
DQGUHFRUGLQJRIWUDFNVVLPXOWDQHRXVO\<RXFDQXVHLWDVDÀHOGUHFRUGHUWR
UHFRUGPHORGLHVDQGEDQGSHUIRUPDQFHVRQWKHÁ\DQGWRFDSWXUHVRXQGHIIHFWV
You can also use it as a multitrack recorder to make songs by overdubbing instru-
ments and vocals. Furthermore, in STAMINA mode you can record in stereo for
up to 11 hours using batteries only.
࠮5L^ ]HYPHISL?@Z[LYLVTPJ
The H4n Pro allows you to adjust the angle of the onboard microphones to address
a wider range of recording scenarios. Set the microphones to 120° for a wider area
of sound, or set them to 90° for a more focused sound source. Either way, the
PLFVUHWDLQWKHLU;<FRQÀJXUDWLRQVR\RXFDQUHFRUGQDWXUDOVWHUHRVRXQGZLWK
no phase cancellation.
࠮*VUULJ[TPJZHUKN\P[HYZKPYLJ[S`\ZPUNJVTIPULK?39
Z[HUKHYKWOVULQHJRZ
The H4n Pro includes input jacks for connections that can accommodate a variety
of recording styles. Microphones, including stereo mics and condensers, electric
guitars, basses and keyboards can all be connected directly.
࠮<ZLHZHUH\KPVPU[LYMHJLHUK:+JHYK^P[OHJVTW\[LY
An onboard USB 2.0 Hi-Speed port allows direct connection to a computer. You
can use it as an audio interface with built-in effects (sampling rate limited to 44.1
kHz when using the effects). You can also use the H4n Pro as an SD card reader
IRU\RXUFRPSXWHU<RXFDQWUDQVIHUUHFRUGHGÀOHVWR\RXUFRPSXWHUDQGXVHWKHP
to create audio CDs or work with them in DAW software.
࠮;\ULYTL[YVUVTLRHYHVRLHUK]HYPV\ZV[OLYM\UJ[PVUZ
The tuner functions include not only a standard chromatic tuner, but also support
less common tunings, such as for 7-string guitars and 5-string basses. The metro-
nome function is convenient for practice and multitrack recording. You can also
use the H4n Pro as a practice device.
Use the SPEED function to adjust the playback speed from 50–150%. The
.$5$2.(IXQFWLRQVLQFOXGHFHQWHUFDQFHOLQJIRUVWHUHRÀOHVDQGYDULDEOHNH\
control, making it valuable for language learning and voice training.
Thank you very much for purchasing our ZOOM H4n Pro Handy Recorder.
The H4n Pro has the following special features.
Please read this manual carefully to fully understand the functions of the H4n Pro so that you can make the most of it for many years.
After reading this manual, please keep it with the warranty in a safe place.
