ZyAura ZG106 User manual

ZG106 CO2and Temperature Monitor Operating Instructions
ZG106 is a portable, accurate handheld CO2monitor. In addition to measuring the CO2concentration, this device can also measure the
ambient temperature. It uses Dual Beam NDIR technology to improve the long term stability.
Features:
□
VThe built-in Data logger can store 48 sets of CO2and temperature in the past 24 hours; one log per 30 minutes.
□
VMax/Min mode can record the maximum and minimum concentration of CO2since the device has been last turned on.
□
VThe Alarm mode will sound at 1000 PPM, the ASHRAE limit. The Alarm Level can be modified, and the Alarm sound can be turned off.
□
VThe RCFS Mode can recover the original factory settings after the CO2device has been recalibrated, altered, or damaged.
MODE FUNCTIONS
There are several Modes which we can adjust the setting parameters. These modes are Alti Mode, Alarm Mode, Outside Mode, Ucal Mode,
Datalogger Mode, MaxMin Mode and rcFS Mode in sequence.
ALTI Compensate the pressure changes with appropriate altitude of location when measure.
ALARM Alarm while CO2concentration exceed one threshold, which can be modified.
The Alarm sound can be turn on/off while the “speaker Icon” flashes.
OUTSIDE Modify the outside CO2concentration, for defining the ventilation rate.
CALI Calibrate the sensor while the reading deviates from the actual CO2concentration.
DATALOGGER Show the past CO2and Temperature records in the past 24 hours.
MaxMin Show the Max and Min CO2reading before being cleared or powered off after PowerOn.
rcFS Recover the factory setting, if the device cannot show accurate reading.
OPERATION INSTRUCTIONS
■PowerOn
Press Power button (○
1) to turn on the device after placing 4 AA batteries into the battery holder or AC adapter plug into the DC socket.
Once power on, CO2reading will show after 15 seconds of warm up.
■WarmUp
It lasts approximately 1min before WARMUP disappears; all the functions will not response during warm up.
■UserMode
After warm up, the device will stabilize and display the normal CO2Reading (Upper Display) - remain visible at all times.
1. Power Button 6. LCD Display 11. RJ45 socket
2. Enter Button 7. LED Light 12. Housing Stand
3. Down Button 8. Function Label 13. Battery Cover
4. Up Button 9. Gas Entry Hole 14. AA Batteries*4
5. Mode Button 10. Power inlet
(Display Features and Modes)

■Temp and Ventilation Rates (Lower Display)
The Up/Down button (○
4/○ 3) allows you to scroll through the Temperature and Ventilation Modes. When pressing the Up button, the
lower display will go through the following sequence: Temp°C -> Temp°F -> Vent Rate lps -> Vent Rate cfm/p
*Note: lps refers to Liter Per Second Per Person; cfm/p refers to Cubic Feet Per Minute Per Person
■Operation of Mode Adjustment
1. ALTI Mode:
1.1. Press the Mode Button (○
5), ALTI flashes
1.2. Press Mode (○
5) to alter between m (meters) and ft (feet).
1.3. Press Up/Down (○
4/○ 3) to adjust the altitude (Step=100m/500ft)
1.4. Press the Enter Button (○
2), save or leave the ALTI Mode, return to UserMode
2. ALARM Mode
2.1.Adjust the alarm level
2.1.1. Press the Mode button (○
5), until ALARM flashes
2.1.2. Press Enter Button (○
2), “CO2” icon flashes
2.1.3. Press Up/Down(○
4/○ 3) to adjust the alarm level (≧1,000 ppm, interval is ±100ppm;＜1,000ppm,interval is ±50 ppm)
2.1.4. Press the Enter (○
2), save the setting and return to UserMode.
2.2. Turn ON/OFF the ALARM
2.2.1. Press the Mode button (○
5), until “Speaker Icon” flashes.
2.2.2. Press Enter Button (○
2)
2.2.3. Press Up/Down (○
4/○ 3) to turn on/off the ALARM,
2.2.4. Press the Enter (○
2), save the setting and return to UserMode.
3. OUTSIDE Mode
** Note: Ventilation Rate
Ventilate rate represents how much air is introduced into the indoor space from the outside. Low values indicate low ventilation rates and
potentially poor air quality. High levels indicate excessive ventilation and potential excessive energy usage. To obtain an accurate
measurement, reading should be taken 2~3 hours after occupancy has stabilized in a space or at a peak in daily CO2
concentrations. In indoor air quality control, CO2value is an indicator of ventilation rate. 400ppm (Parts Per Million) is the default CO2
concentration outside (according to ASHRAE: American Society of Heating, Refrigeration and Air conditioning Engineers)
3.1. Press the Mode button (○
5), until OUTSIDE flashes
3.2. Press Enter (○
2), show OUTSIDE, CO2and PPM flash
Press Up/Down (○
4/○ 3) to adjust the reading
3.3. Press the Enter (○
2), save the setting and return to UserMode
After modification, the VENT Rate will change
4. CALI Mode
The CO2monitor has been calibrated in the factory. Sensor drift usually occurs in linearity. Please follow below steps.
4.1. If battery icon shows low power, please replace new batteries or use AC adapter
4.2. Press the Mode button (○
5), until CALI flashes
4.3. Press Enter (○
2), CALI shows on display
4.4. Adjust the lower display to ambient CO2value by Up/Down (○
4/○ 3) Button.
4.5. Press Mode button (○
5) more than 10 sec., CALIBRATING flashes.
Calibration will be done after about 3 min and LCD will appear “PASS”. If LCD appears “FAIL”, please calibrate once again.
4.6. Press Enter (○
2), return to UserMode
5. DATA LOGGER Mode
The device has a built-in data logger, which can provide users the past CO2and temperature readings within the past 24 hours.
5.1. Press the Mode button (○
5), until DATALOGGER flashes
5.2. Press Enter (○
2), CO2and Temperature show up
Press Up/Down (○
4/○ 3) to page up/down the reading.
5.3. Press the Enter (○
2), return to UserMode
6. MaxMin Mode
The device has a built-in MaxMin mode, which can provide users the Maximum and Minimum CO2readings since the device has last been
turned on.
6.1. Press the Mode button (○
5), until MAX MIN flashes
6.2. Press Enter button (○
2), MAX and MIN CO2reading alternatively shows.
6.3. “CLR” will flash if press Up/Down (○
4/○ 3)
Press Enter (○
2), to CLEAR the MAX and MIN record.
6.4. Press Mode or enter (○
5), return to UserMode

Ref.No.：082019
7. rcFSMode:
If user set or calibrated the sensor wrongly, you can recover the factory setting
7.1. Press the Mode button (○
5), until rcFS flashes on the lower display
7.2. Press Enter (○
2), “no” shows on the upper display
7.3. Press Up/Down (○
4/○ 3), “no” change to “yes”
Press Enter (○
2), Factory Setting will reload, return to UserMode;
7.4. Press Mode (○
5), leave rcFS Mode, return to UserMode
SPECIFICATIONS (Preliminary Version)
Method - Dual Beam (NDIR Non-Dispersive-Infrared)
Display - LCD
Independent CO2and Temperature readings.
Calculates and Displays Ventilation Rates
Sample Method -Diffusion or flow through (50 ~200 ml/min)
■Performance - CO2
Measurement Range 0-3,000 ppm display
Display Resolution 1ppm at 0~1,000ppm; 5ppm at 1,001~2,000ppm; 10ppm at 2,001~3,000ppm
Accuracy ±50 ppm or ±5% of reading
Repeatability ±20 ppm
Temperature Dependence Typ. ±0.1% of reading per °C or ±2 ppm per °C, whichever is greater, referenced to 25°C
Pressure Dependence 0.13% of reading per mm Hg (Corrected via user input for altitude)
Response Time About 2min for 63% of step change
Warm-Up Time <60 seconds at 22°C
■Performance - Temperature
Temperature Range Display 32 to 122°F (0 to 50°C)
Display Resolution 0.1°F (0.1°C)
Display Options °F / °C, or Off. Set with Up / Down button
Accuracy ±2°F (±1°C) When the fan blows to the device directly, the accuracy of temperature is + / -1.5 degC .
Response Time 20-30 minutes (case must equilibrate with environment)
■Outputs
OC: Normally Low, 100mA max. @ 24 VDC. Adjustable setpoint, factory setting is 1000ppm, hysteresis is 50ppm
■Power Supply
Two power supply types
Battery type: Alkaline, AA* 4 (80 hours)
External: 6 VDC from external AC/DC adapter which is included in package (Use specified AC adapter only)
Power Requirement
160 mA Peak, 15 mA average from 6V
CAUTION
The device can be supplied either by batteries or an AC adapter.
DO NOT install batteries and plug in an AC adapter at the same time.
■General Operating Conditions
Operating Temperature: 32-122°F (0-50°C) 0-95% RH, non-condensing
Storage Temperature: -4 to 140°F (-20 to 60°C)
■ Dimensions：24.3×81.1×165 mm (0.96×3.19×6.50 inch)
Weight (including batteries)：273.6 grams (9.65 oz)
■LCD ERROR MESSAGES
The device incorporates visual diagnostic messages as follows:
「 」 Error 3, it is displayed when the temperature being measured is outside of the measurement range.
「」
「」
Error 5~6, it is necessary to reset the device. To reset it, turn the instrument off, remove the batter
y
and wait for a
minimum of one minute, reinsert the batter
y
and turn on. If the error messa
g
e remains please contact the Service
Department for further assistance.
Radiant Innovation Inc. Http://www.ZyAura.com
1F, No.3, Industrial East 9th Road, Science-Based Industrial Park, HsinChu, Taiwan 300.
