Prestige 630 ADSL USB Modem Quick Start Guide
1
Installing Your Modem
Needed Information
Fill in the table below with information from your Internet Service Provider (ISP) and telephone company
before installation. You may not need to fill in every blank.
REQUIRED INFORMATION: FILL IN THE BLANKS
Driver:
RFC 1483, PPPoA or PPPoE.
RFC 1483 Mode:
Bridged or Routed (only when using RFC 1483).
VPI:
The Virtual Path Identifier number identifies a bundle of virtual
channels.
VCI:
The Virtual Channel Identifier number identifies a logical
connection between end stations.
Setup Type:
LLC or VCMUX.
User Name:
Lets your ISP know which account you are logging into.
Password:
Protects your account from unauthorized use.
Installation Procedure
Have your system operating disk handy during the installation.
Step 1. Close all Windows programs and applications.

Prestige 630 ADSL USB Modem Quick Start Guide
2
Step 2. Plug the square end of the USB cable into the back of your modem and then plug the rectangular
end of the USB cable into the back of your computer. The instructions will tell you when to plug
in the telephone wire.
These instructions show how to do a custom ZyXEL installation without using the
Windows installation wizard.

Prestige 630 ADSL USB Modem Quick Start Guide
3
Click Yes or Continue Anyway if Windows 2000 or XP displays Digital Signature Not
Found or Windows Logo Testing alerts.
Step 3. Insert the supporting CD and click the Windows Start button (usually bottom left) and select
Run. Then do as shown next.
Step 4. Click Next in the Welcome screen to display the License Agreement screen.
Use Browse to find
Setup.exe on the
supporting CD
Then click
OK
Click Cancel.

Prestige 630 ADSL USB Modem Quick Start Guide
4
Step 5. Read the license agreement and click Yes to agree to the terms and bring up the Read Me screen.
Step 6. The Read Me screen gives instructions for installing and uninstalling the modem, along with
some troubleshooting information. Use the scroll bars to read the text and click Next to go to the
Driver Components screen.
Step 7. In the Driver Components screen, select the driver if your ISP has not pre-configured it for you.
Type the VPI and VCI specified by your telephone company and click Next.
Step 8. Select the framing type specified by your ISP and click Next.
Step 9. When using RFC 1483, the RFC 1483 Modes screen appears. Select the mode that your ISP
supports and click Next. Just go to the next step for PPPoA or PPPoE.
Step 10. Screens pop up to report the progress of the installation. The Setup Status is displayed briefly.
You do not need to click anything until the InstallShield Wizard Complete screen is displayed.
Step 11. Click Finish in the InstallShield Wizard Complete screen to bring up the Rebooting Machine
screen.
Step 12. Click “Yes, I want to restart my computer now.” in the Rebooting Machine screen. Then click
OK.
Step 13. The Found New Hardware screen appears, wait for it to disappear when the configuration is
complete.
Step 14. Use a telephone wire to connect the ADSL port to the wall jack.
You may opt to buy a telephone microfilter to install between the wall jack and your
telephone(s). A microfilter acts as a low pass filter that screens out possible
interference.
Connecting
Step 15. In Windows, click Start (usually in the bottom left-hand corner)Settings Control Panel and
double-click the ADSL Control and Status icon to bring up the ADSL Control and Status
window.

Prestige 630 ADSL USB Modem Quick Start Guide
5
Step 16. Use the Connect button in the ADSL Control and Status window to initiate a connection with
your ISP. The button text changes to Disconnect after a connection is established.
Step 17. Click Close to close the ADSL Control and Status window after your connection has been made
(the modem stays connected).
If you are using RFC 1483, you are done installing your modem! Visit www.zyxel.com to test your Internet
connection and discover other exciting products from ZyXEL! For PPPoA or PPPoE, go on to the next
section.
PPPoA and PPPoE Setup
Click
Connect.

Prestige 630 ADSL USB Modem Quick Start Guide
6
From the Windows desktop, double-click the Shortcut to ZyXEL ADSL icon to open a connection window.
Type the user name and password from your ISP and click Dial (or Connect depending on your OS).
