ZyXEL Communications XMG3512-B10A User manual

1/2 Copyright © 2016 Zyxel Communications Corp. All Rights Reserved
XMG3512-B10A
Dual-Band Wireless AC/N VDSL2 Bonding
Gateway with USB
Internet Setup
Username: admin
Password: 1234
Quick Start
IP Address: 192.168.1.1
Hardware Connections
4
INTERNET
2Internet is not ready.
Go to Internet Setup.
Internet is ready.
Go to Wireless Setup.
1-b
3
1-a
USB
POWER
INTERNET
OFF
INTERNET
ON
SFP
DSL
ETHERNET
WAN
5
1-c
2
4
1
Check LEDs.
5
Connect a broadband modem or
router (1-a) using an Ethernet cable.
OR
Connect a DSL splitter (1-b) using
the gray telephone cable.
OR
Connect a switch or PON device (1-c)
that has Internet access by using an
SFP active optical fiber cable,
SFP Direct Copper (DAC) cable,
PON SFP transceiver module or SFP
transceiver module.
Connect a USB memory stick for file
sharing.
3
Connect the power adapter.
Connect a computer using the
yellow Ethernet cable.
W
SFP
DSL1
DSL2
WiFi 5G
iFi 2.4G
Quick Start Guide

Wireless Setup
WPS
No WPS
SSID
Wireless key
1
(>5 seconds)
1Press the WPS button until the
WiFi LEDs blink orange.
2Press the WPS button on the client.
1
The SSID and wireless key are on the
device sticker.
2Find the device with this SSID.
Enter wireless key to connect.
12
W
SFP
DSL1
DSL2
Wi Fi 5 G
iF i 2. 4G
2/2 Copyright © 2016 Zyxel Communications Corp. All Rights Reserved
EU Importer: Zyxel Communication A/S | Generatorvej 8D, 2860 Søborg, Denmark | http://www.zyxel.dk
US Importer: Zyxel Communications, Inc | 1130 North Miller Street Anaheim, CA92806-2001 | http://www.us.zyxel.com
Dual-Band Wireless AC/N VDSL2 Bonding Gateway with USB
This product complies with FCC 47CFR Part 68.
This device complies with Part 15 of the FCC Rules/Industry Canada
licence-exempt RSS standard(s). Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
CAN ICES-3 (B)/NMB-3(B)
FCC ID: I88XMG3512-B10A
US: 1RODL01AXMG3512
IC: 2468C-XMG3512B10A
USOC JACK:RJ14
REN: 0.1A
Power Rating: 12V ,3.5A
Caution: to reduce the risk of fire, use only NO.26AWG or larger(e.g.,24AWG)
UL Listed or CSA Certified Telecommunication Line Cord
This product contains in part some free software distributed under GPL license terms and/or GPL like
licenses. Please visit www.us.zyxel.com/opensource/ for source code and additional information.
Model Number:XMG3512-B10A
3PPH
Communications Corporation
Serial Number: S160Y03010835
MAC Address: E8377AFB135A
SSID (2.4GHz):
SSID (5-GHz):
Wireless Key:
Default IP Address:
Username:
Password:
ZyXEL_1354
ZyXEL_1354_5G
URTPPHJJED
192.168.1.1
admin
1234
