2gig Technologies Go!Control Panel Installation guide

Go!Control
Installation and Programming
Technical Training

HARDWARE
•System Capabilities
•What’s Inside
•The Transformer
•Terminal Block
•GSM Unit

SYSTEM CAPABILITIES
•48 Wireless Zones
•2 Hardwired Zones
•8 Keyfobs
•4 Secondary Keypads
•2-Way Over GSM (default)
•2-Way Over POTS (optional)
•232 Z-Wave devices

HARDWARE
WHAT’S IN THE PANEL
•Third Hand
•RJ45 Connector (POTS)
•24 HR Back-Up Battery
•345Mhz Receiver
•Terminal Block
•GSM Antenna Compartment
•Pop-In Style GSM Unit
•85dB Siren/Speaker

HARDWARE
THE TRANSFORMER
•VDC Positive (+)
•VDC Negative (-)
Wire to port 1 (+) inside the panel
Wire to port 2 (-) inside the panel

HARDWARE
TERMINAL BLOCK
•8) Hardwire Zone 2
•7) Hardwire Zone 1
•6) External Bell (-)
•5) External Bell (+) (6-12 VDC @ 120mA max)
•4) Open Collector Output (250mA @16VDC max)
•3) Ground (hardwire zones)
•2) 14VDC Input (-) from Transformer negative (-)
•1) 14VDC Input (+) from Transformer positive (+)

HARDWARE
GSM MODULE
•Mounting Screws
•Antenna Port
•IMEI# (Serial Number)

PROGRAMMING
•Installer Toolbox
–System Configuration
•Programming a Zone
•Programming a Keyfob
•Programming a Keypad
–Radio Status
–System Restore
–Walk Test
–Disable Sounder

PROGRAMMING
INSTALLER TOOLBOX
Press
SECURITY

PROGRAMMING
INSTALLER TOOLBOX
Press
MENU

PROGRAMMING
INSTALLER TOOLBOX
Press
TOOLBOX

PROGRAMMING
INSTALLER TOOLBOX
Press
RIGHT ARROW

PROGRAMMING
INSTALLER TOOLBOX
Press
RIGHT ARROW

PROGRAMMING
INSTALLER TOOLBOX
Press
INSTALLER TOOLBOX

PROGRAMMING
INSTALLER TOOLBOX
Installer Code (1561)

PROGRAMMING
INSTALLER TOOLBOX
Press
SYSTEM CONFIGURATION

PROGRAMMING
SYSTEM CONFIGURATION
NAVIGATION
•Navigated by Questions
rather than Field Values
–Q1: Wireless Zones
–Q2: Hardwire Zones
–Q3: Keyfobs
–Q4: Wireless Keypads
–Q5-Q86: System Settings
•Press GO TO followed by the two-
digit Question (01-86)

PROGRAMMING
SYSTEM CONFIGURATION
•Q1 –Q4
Use the and arrows to move
back and forth between SUB-QUESTIONS
Use the and arrows to scroll
through the different options

PROGRAMMING
SYSTEM CONFIGURATION
•Q5 –Q86
Use the and arrows to move
back and forth between QUESTIONS
Use the and arrows to scroll
through the different options

PROGRAMMING
Q1: RF SENSORS
Select RF Sensor # (01-48)
•Up to 48 wireless RF sensors can be
used with each Control Panel. The
options for each sensor are
programmed with sub-questions.
–Begin by entering the RF sensor number or
select it using the ← or → arrows.
–After selecting the sensor number,
program the sensor details by using the
↑ and ↓ arrows to select each of the sub-
options.
Press the ↓ arrow to continue
