4EVAC LOOPDRIVE FIM-RC User manual

Field Remote Control Module - FIM-RC
Detect - Locate - Isolate
Hacousto Holland bv - Industrieweg 87 - Berkel en
Rodenrijs - Netherlands - www.4evac.com!
NOTE
FIM-RC IS NOT EQUIPPED WITH ISOLATOR FUNCTION
DC Power supply (from LDB)
19 - 30 VDC, nominal 30 VDC
Volume override (from VACIE)
20kHz fade-in: 0,3s / fade-out: 1,s
Default threshold: 5Vac!
Adjustable Threshold range: 3 - 17Vac
DC Power consumption
idle current
100 μA continuous
max. power consumption
20mW
LOOP connection
DC
30V
AC Voltage
100Vrms
AC Frequency range
40Hz - 20kHz (-3dB)
Wiring Loop
2-wire. Max. 2,5mm2 / Max. Loop length: 1000m
Pilots-tone
20kHz
T-Branch output
2x relay contact
2x 2-pol change-over contact
max. AC switching load
2000W (230VAC/8A)
Grounding
optional earth loop through third connection pin
Mechanical
Housing
PP plastic with transparent cover
Dimensions (WxHxD)
IP 21 housing, 110 x 130 x 55 mm (Basic)
IP 33 extension included. 110 x 180 x 55 mm (Optional)
Ordering information. Part No.
FIM-RC
1x IP21 housing with transparent cover and PCB
1 x release tool / 1 x compression gland for speaker mounting
Certification and Approvals
Complies with
n.a.
European patent
n.a.
FIM-RC QIG - V02R01! Quickguide
LOOPDRIVE
The FIM-RC acts as a remote contact interface that can activate or
deactivate a third party instrument or equipment that needs to be triggered
during a live-broadcast of an evacuation event. The FIM-RC sits in the LOOP
and receives the broadcast audio message. As soon as the broadcast audio
message contains a 20kHz pilote-tone, the on-board relays of the FIM-RC
will change state into ‘override’ mode. The state change is latched as long
as the pilote-tone is received.
Depending on the function of the third party instrument or equipment, the
FIM-RC offers two potential free NC and a NO switching contacts.
The Loopdrive - Fault Isolator Module (FIM) is the successor in our range of
loudspeaker loop-isolator devices that are using our patent technology to
deliver a higher level of security of evacuation loudspeaker lines that are
installed according to the return-loop principle.
16

Field
Lorem ipsum dolor
Sitananita ametete, consecteturity adipisicing elit, sed do eiusmod tempor incididunt ut
Detect - Isolate - repair
The FIM-RC has two potential-free switching contacts that connect to third party
instrument or equipment. Using these triggering relay contacts, a local source
automatically overrides when emergency paging from the VACIE is applied or a
local instrument can be energised. The FIM-RC is equipped with a power
capacitor that is charged by the LDB and has enough capacity to operate at least
two emergency cycles without the need for re-charging. The LED indicator(s) on
the FIM-RC are flashing with intervals to indicate quiescent or fault condition. The
FIM has two indicators that are related to the status of either LOOP-A or LOOP-B
side (Loop feed). Please refer to the User and Installation manual V01R01 for
detailed information on the various indications of these indicators.
The FIM-RC is equipped with clearly market connectors. The FIM-RC has a
LOOP -FEED and LOOP-RETURN connection that are not sensitive to
feeding direction. LOOP has a DC-carrier for charging and communication
purposes. !
Please observe correct connectivity:!
RED = PHASE / PLUS!
BLUE = ZERO / MINUS!
Detect - Locate - Isolate
NOTE:
The T-Branch switching load is maximised to 2000W. .!
The OVERRIDE signal must be sent together with any emergency message.
The override pilots-tone must be: 20kHz / 5Vrms (by default)
WAGO-quick-fit
The FIM is equipped with WAGO push-
terminals that accept up to 2,5 mm2 core
installation cable. A special tool is provided to
quickly remove all three wires in one run.
(Release-tool is included)
LOOPDRIVE
Field Remote Control Module - FIM-RC
FIM-RC QIG - V02R01! Quickguide
Trigger threshold adjustment:!
Holding the reset button for 10-sec will force the FIM-RC in measurement state.
(Fast blinking) In this state it measures any HF signal on the line (>16kHz) and sets
it trigger threshold 2Vac above measured HF signal. !
!
Confirmation of new setting: Alternate blinking of indicators BLUE (5s-Fast).!
Rejection of new setting: Alternate blinking of indicators: ORANGE (5s-Fast
Activation at Threshold: Alternate blinking of indicators BLUE Slow
