Keba Kemro MM 280/A Installation and operation manual

Kemro
MM 280/A
Motor Control Module
Project engineering manual 1.04
Translation of the original instructions

Document : 1.04 / article no.: 1000120
Filename : mm280apjen.pdf
Pages : 28
.
© KEBA 2011
Specifications are subject to change due to further technical developments. Details presented may be subject to correction.
All rights reserved.
A: KEBA AG, Gewerbepark Urfahr, A-4041 Linz, Tel.: [phone], Fax: [phone], E-Mail: [email protected]
D: KEBA GmbH Automation, Leonhard-Weiss-Straße 40, D-73037 Göppingen, Tel.: [phone], Fax:
[phone], E-Mail: [email protected]
US: KEBA Corp., 100 West Big Beaver Road, Troy, MI 48084, US, Tel.: [phone], Fax: [phone], E-Mail:
[email protected]
CN: Beijing Austrian KEBA Science and Technology Development Ltd., Room B516, Nan Xin Cang Tower, A22 Dong Si Shi Tiao, Dong Cheng District, Beijing, 100027, P.R. China, Tel. [phone], Fax [phone], E-Mail:
[email protected]
www.keba.com

Record of Revision
Version Date Change in chapter Description changed by
V1.00 10-2005 Newly created. meis
V1.01 11-2005 Configuration Updated meis
V1.02 11-2005 Technical data Detailed power ratings meis
1.03 08-2010 EC directives and
standards, Declara-
tion of conformity
update to EN 61131-2:2007 hasl
1.04 08-2011 Introduction Hint "not for end customers" added, various minor up-
dates. fstl
MM 280/A Record of Revision
© KEBA 2011
Project engineering manual 1.04 3

Table of Contents
1 Introduction....................................................................................................................... 7
1.1 Purpose of the document........................................................................................ 7
1.2 Preconditions.......................................................................................................... 7
1.3 Intended use........................................................................................................... 8
1.4 Notes on this document.......................................................................................... 8
1.5 Documentation for further reading.......................................................................... 8
2 Safety notes...................................................................................................................... 9
2.1 Representation........................................................................................................ 9
2.2 General safety instructions...................................................................................... 9
3 Description of the module............................................................................................. 11
3.1 Front view.............................................................................................................. 11
3.2 Accessories........................................................................................................... 12
3.2.1 Connector strip....................................................................................... 12
4 Connections and wiring................................................................................................. 13
4.1 Power supply......................................................................................................... 13
4.2 Motor bridges (PWM outputs)............................................................................... 14
4.2.1 Connection example............................................................................... 14
4.2.2 Connection digramm.............................................................................. 15
4.3 Encoder inputs...................................................................................................... 15
4.3.1 Connection example............................................................................... 16
4.3.2 Connection diagramm............................................................................ 17
4.4 EMC and wiring guidelines.................................................................................... 17
5 Configuration.................................................................................................................. 18
5.1 Setting the K-Bus address.................................................................................... 18
6 Functional description................................................................................................... 20
6.1 Overview of functions............................................................................................ 20
6.2 Position measurement.......................................................................................... 20
6.3 Position counter.................................................................................................... 21
7 Operating behavior......................................................................................................... 22
7.1 Status displays...................................................................................................... 22
7.2 Behavior of motor bridges (PWM outputs)............................................................ 22
7.2.1 Switching inductive loads:...................................................................... 22
7.2.2 Motor bridges......................................................................................... 22
7.2.3 Short circuit and overload response....................................................... 22
8 Disposal........................................................................................................................... 24
8.1 Disposal of the module.......................................................................................... 24
9 Technical data................................................................................................................. 25
9.1 In general.............................................................................................................. 25
MM 280/A Table of Contents
© KEBA 2011
Project engineering manual 1.04 5

9.2 Environmental conditions...................................................................................... 25
9.3 Position counter.................................................................................................... 25
9.4 Motor bridges (PWM outputs)............................................................................... 25
9.5 Encoder inputs...................................................................................................... 26
9.6 Interfaces.............................................................................................................. 26
9.7 Dimensions........................................................................................................... 26
10 EC directives and standards......................................................................................... 27
10.1 EC directives......................................................................................................... 27
10.2 Standards.............................................................................................................. 27
10.2.1 General procedures and safety principles.............................................. 27
10.2.2 EMC guideline........................................................................................ 27
10.2.3 Electrical safety and fire protection........................................................ 27
10.2.4 Environmental and surrounding conditions............................................ 27
10.3 Standards for the American market...................................................................... 27
10.3.1 UL test for industrial control equipment.................................................. 27
11 Declaration of conformity.............................................................................................. 28
Table of Contents MM 280/A
© KEBA 2011
Project engineering manual 1.046

1 Introduction
1.1 Purpose of the document
This document describes the structure of the MM 280/A
(motor control module).
Information
This manual is not adressed to end costumers! Necessary safety notes for
theendcostumerhavetobetakenintothecostumermanualintherespective
national language by the machine builders and system providers.
1.2 Preconditions
This document contains information for persons with the following skills:
Target group Knowledge and skills pre-requirement
Project engineer
Basic technical training (University of Applied Science/University level,
engineering degree or corresponding professional experience).
Knowledge in:
●working mode of a PLC,
●safety regulations,
●the application.
Operator
Basic technical training (Vocational high school, engineering degree or
corresponding professional experience).
Knowledge in:
●safety regulations,
●working mode of machine or plant,
●principal functions of the application,
●system analysis and troubleshooting,
●setting options at the operating installations.
Service technician
Basic technical training (Vocational high school, engineering degree or
corresponding professional experience).
Knowledge in:
●working mode of a PLC,
●safety regulations,
●working mode of machine or plant,
●diagnosis possibilities,
●systematic error analysis and rectification.
MM 280/A Introduction
© KEBA 2011
Project engineering manual 1.04 7

1.3 Intended use
The MM 280/A was developed for control applications in industrial machines.
The typical applications areas include injection molding machines, robots,
presses, machine tools and similar.
TheMM 280/A may onlybe used for thetypes of use describedin the technical
descriptions and only in conjunction with recommended/approved third-party
equipment/installations.
The MM 280/A has been developed, manufactured, tested and documented
in accordance with the appropriate safety standards. Therefore, the products
do not pose any danger to the health of persons or a risk of damage to other
property or equipment under normal circumstances, provided that the instruc-
tionsandsafetyprecautionsrelatingtotheintendeduseareproperlyobserved.
1.4 Notes on this document
This manual is integral part of the product. It is to be retained over the entire
life cycle of the product and should be forwarded to any subsequent owners
or users of the product.
1.5 Documentation for further reading
Thefollowingdocumentsaretobeobserveddependingonthesystemsolution
used:
If you are using the KeStudio U2 tool suite:
Doc.No. Name Target group
DE: 65352
EN: 65353 K2-200 automation system manual
●Project engineer
●Electrician
●Programmer
●Commissioning foreman
●Service technician
If you are using the KeStudio U3 tool suite:
Doc.No. Name Target group
DE: 1000868
EN: 1000869 System manual Kemro automation
system
●Project engineer
●Electrician
●Programmer
●Commissioning foreman
●Service technician
Introduction MM 280/A
© KEBA 2011
Project engineering manual 1.048

2 Safety notes
2.1 Representation
At various points in this manual you will see notes and precautionary warnings
regarding possible hazards. The symbols used have the following meaning:
DANGER!
●indicates an imminently hazardous situation which will result in death or
serious bodily injury if the corresponding precautions are not taken.
WARNING!
●indicates a potentially hazardous situation which can result in death or se-
rious bodily injury if the corresponding precautions are not taken.
CAUTION!
●meansthat ifthe corresponding safetymeasures arenottaken, apotentially
hazardous situation can occur that may result in property injury or slight
bodily injury.
CAUTION
●CAUTION used without the safety alert symbol indicates a potentially haz-
ardous situation which, if not avoided, may result in damage to property.
●This symbol reminds you of the possible consequences of touching elec-
trostatically sensitive components.
Information
Useful practical tips and information on the use of equipment are identified
by the “Information” symbol. They do not contain any information that warns
about potentially dangerous or harmful functions.
2.2 General safety instructions
WARNING!
●It is absolutely essential to observe the safety instructions in the system
manual.
●The module is defined as "open type equipment" (UL508) or as "offenes
Betriebsmittel" (EN 61131-2) and must therefore be installed in a control
cabinet.
MM 280/A Safety notes
© KEBA 2011
Project engineering manual 1.04 9

CAUTION
Improper use of the assembly or the control system leads to irreparable dam-
age!
●Turn off the power supply before inserting or removing the module. Other-
wise, the module can be destroyed or undefined signal states can lead to
damage of the control system.
Safety notes MM 280/A
© KEBA 2011
Project engineering manual 1.0410

3 Description of the module
The MM 280/A is an motor control module with 2 motor bridges and 2 encoder
inputs.
3.1 Front view
Fig.3-1: MM 280/A Front view
1... 2 motor bridges (DO0/DO1 and DO2/DO3)
2... 2 encoder inputs
Information
●The incremental interface module MM 280/A is not designed for drive
control.
●The type plate is stored on the module in an EEPROM and can be read
out by the application.
MM 280/A Description of the module
© KEBA 2011
Project engineering manual 1.04 11

3.2 Accessories
3.2.1 Connector strip
Input-/output signals: Standard male connectors with grid dimension 5.08 mm
The following female connectors can be used for the MM 280/A:
Female connector Color Order no. Weidmüller
2-pole sw BLZF 5.08/2 SN SW - 170769
4-pole sw BLZF 5.08/4 SN SW - 170771
6-pole sw BLZF 5.08/6 SN SW - 170773
8-pole sw BLZF 5.08/8 SN SW - 170775
Information
Larger terminal blocks may be used to group multiple signals. The current
carrying capacity of the terminal block is thus, however, reduced (according
to derating curve of the terminal block manufacturer.)
The appropriate female connectors are not included in the delivery of KEBA,
but can be purchased from KEBA.
The technical data for the terminals are contained in the technical data sheet
of the manufacturer of the female connectors.
For further information see System manual.
Description of the module MM 280/A
© KEBA 2011
Project engineering manual 1.0412

4 Connections and wiring
4.1 Power supply
WARNING!
Danger of personal injury due to electric shock!
●Supply the device exclusively from power sources that have an extra low
voltage (e.g. SELV or PELV according to EN 61131-2)
●Connect only voltages and power circuits to connections, terminals and
interfaces up to 50 V rated voltage that have a secure disconnect for haz-
ardous voltages (e.g. with sufficient isolation).
CAUTION!
Fire hazard during module failure!
●Providesuitable fusesfor the24 VDC powersupply forthe finalapplication.
Only fuses with a maximum nominal disconnecting current of 10 A may be
used.
MM 280/A Connections and wiring
© KEBA 2011
Project engineering manual 1.04 13

4.2 Motor bridges (PWM outputs)
4.2.1 Connection example
Motor bridge Proportional valve
Tab.4-1: Connection example for PWM outputs
Connections and wiring MM 280/A
© KEBA 2011
Project engineering manual 1.0414

4.2.2 Connection digramm
Fig.4-2: Connection diagramm motor bridges
4.3 Encoder inputs
The MM 280/A has 2 encoder outputs with 12-bit resolution.
MM 280/A Connections and wiring
© KEBA 2011
Project engineering manual 1.04 15

4.3.1 Connection example
Fig.4-3: Connection example for encoder inputs
Information
●Theterminal0Vdeterminethereferencepotentialfortheencoderinputs.
●To run the rotary encoders, it is necessary to supply the MM 280/A via
the terminals 0 V and 24 V.
Power supply is via the 24 V terminal at the front. The 24 V are looped through
secured. In addition, 5 V are generated internally from the 24 V. The 5 V trans-
ducer supply can carry loads of up to 100 mA each.
Connections and wiring MM 280/A
© KEBA 2011
Project engineering manual 1.0416

4.3.2 Connection diagramm
Fig.4-4: Encoder input diagramm
4.4 EMC and wiring guidelines
Pay attention from the outset to careful wiring and shielding.
Further information: See system manual.
MM 280/A Connections and wiring
© KEBA 2011
Project engineering manual 1.04 17

5 Configuration
General information
A Kemro system needs data for the configuration of system performance, its
I/O-devices and interfaces. The system reads this data during the start-up op-
eration and allocates them to its components and devices.
Configuration data is created by included configuration tools or by editing con-
figuration files.
For further information to the configuration see the documentation of the in-
cluded configuration tool.
For further information to the configuration see the documentation of the in-
cluded configuration tool.
5.1 Setting the K-Bus address
The module is addressed via the address switch.
The number of modules that can be added on is limited as follows:
●8 pieces MM 280/A to a CPU module (permitted address switch positions
0 - 7).
●5 pieces MM 280/A to a bus link module BL 250/A (permitted address
switch positions 0 - 4).
●2 pieces MM 280/A to a bus link module BL 210/A (permitted address
switch positions 0, 1).
Theaddress switch is located onthe right side underneath thelowercover (the
K-Bus plug is located underneath the upper cover).
Fig.5-1: Position of the address switch
1... Address switch
On leaving the factory all modules are set to address 0 and both covers are
closed.
Configuration MM 280/A
© KEBA 2011
Project engineering manual 1.0418

Information
Modules of the same type that are installed within the same line must have
different address switch positions. Different modules (e.g.: AI 240/A and DI
260/A) may have the same address switch positions.
The two covers for the K-Bus plug and the address switch must remain locked
at the last module in the line (to protect against dirt and damage through elec-
trostatic discharge on contact).
MM 280/A Configuration
© KEBA 2011
Project engineering manual 1.04 19

6 Functional description
6.1 Overview of functions
The MM 280/A provides the following function:
●Positionmeasurement:Forward/backwardcounterofincrements(position
measurement) via A and B track with 4-fold evaluation.
6.2 Position measurement
Position measurements are taken from the evaluation of an incremental pulse
position transducer with 2 pulse signals (A, B), which are phase-shifted by 90°.
Alledgescanbeevaluated.Thepossibleresolutionamounts1/4oftheperiod's
duration (4-fold evaluation).
Position measurement 4-fold
Fig.6-1: Impulse signals of the position transducer, resolution 4-fold
A, B ... Pulse signals of the position transducer P... Cycle Time
Q... Resolution 4-fold
The direction of the movement is detected by the evaluation of the phase po-
sition of the pulse signals A and B. See following figure:
Functional description MM 280/A
© KEBA 2011
Project engineering manual 1.0420
