4WD SNATCH BLOCK
INSTRUCTION MANUAL

2
Contents
Page
WELCOME ....................................................................................................................... 3
INTENDED USE .................................................................................................................4
CONTENTS ........................................................................................................................4
SPECIFICATIONS...............................................................................................................4
SAFETY WARNING ..........................................................................................................5
INSTRUCTIONS FOR USE ..........................................................................................6-9
CARE AND MAINTENANCE ....................................................................................... 10
DISPOSAL ..................................................................................................................... 10

Satised customers have repeatedly attested to the positive outcome of a
simple phone call in resolving misunderstandings and gaining positive insight
into product usages.
This product is manufactured to the highest standards of
safety and performance.
Please read instructions carefully before use.
Unless directions are followed physical injury or property
damage may result.
Save these instructions for future reference.
In the event you require assistance with your purchase please
contact one of our experienced customer service team on
1300 883 104, who will be happy to assist with your enquiry.
Congratulations on choosing to buy a 4X4 TOUGH® product.
WELCOME
3

4
INTENDED USE
The 4X4 TOUGH® Snatch block is designed to improve the functionality of a winch.
If you have a winch, putting a snatch block in your recovery kit is essential.
It provides a means to increase the winch’s pulling power, and also provides more
options in self-recovery situations.
This product is intended for private vehicle use only, and is not intended for
commercial, trade or industrial use.
CONTENTS
1 x Snatch block
1 x Instruction manual
SPECIFICATIONS
Working Load: 8000kg
Breaking Strength 12000kg
Side Plate Material: Steel
Pulley Material: Steel
Pulley Diameter: Outer 98mm / Inner 84mm
Winch Line Size: Maximum 14mm
Weight: 2.4kg
Greasable: Yes

5
SAFETY WARNING
WARNING!
Under no circumstance should you exceed the snatch blocks rated working load.
This could result in serious injury or death.
• DO NOT use this product for lifting, climbing, or any life-safety use.
• DO NOT use this product for towing or any on-road use.
• Ensure that the snatch block is not damaged and is in usable condition prior to
heading o road.
• Always wear protective gloves and glasses when performing a recovery.
• When introducing snatch blocks into a recovery situation, you’ll nd that the
amount of winch line you need increases depending on how many snatch blocks
being used. DO NOT operate your winch with less than FOUR full wraps of line on
the drum as your chance of a breakage is much more likely than on the outer
layers of line. In these situations carry a decent length winch extension strap
(sold separately) to make up the distance whilst keeping line on your winch.
• The user is responsible for evaluating each recovery situation and taking the
appropriate actions. The safety of the user and others in the recovery area should
be the rst priority. Keep any onlookers well away from the recovery area to ensure
their safety.
• The snatch block is simple in design, but using one properly requires creative
thinking. Make sure you practice rigging your winch with the snatch block before
you head out on your o road adventure.
Read and follow your Snatch Block instructions
and safety precautions before using the snatch
block.

INSTRUCTIONS FOR USE
“TFAS”; Think First Act Second. This is the golden rule with all recovery
options. Take the time to access the situation before commencing the recovery.
• To begin with nd a suitable anchor point. If the anchor point is a tree; place a
tree trunk protector around the tree. Leave the snatch block open, with a rated
shackle ready to lock it.
• Run out enough winch line to get from the vehicle to the anchor point and back
to the vehicle.
• Place the winch line into the snatch block and then close the block.
• Ensure the winch line is tangle free and has no cross overs in the layout of the
line, as this may inadvertently happen with both winch lines running side by side.
• With the snatch block closed, attach the block to the tree trunk protector using a
rated bow shackle. (sold separately).
• Ensure that the bow of the shackle is against the strap and the pin is against the
snatch block’s eye. This is to stop the strap binding in against the pin. Tighten the
pin in the shackle and then back the pin o by a half a turn – if the pin is not
backed o by a half turn, the pin can bind up under load and become impossible to
loosen.
• Run the winch hook back to the vehicle and attach it to a rated recovery point on
the vehicle. Attach a damper blanket to BOTH winch lines. One damper should be
towards the snatch block, while the other should be towards the winch hook on the
vehicle. Check and stop during winching to adjust the dampers as needed.
• Move everyone away from the winching area and begin to take up the slack
while watching for any twisting or crosses in the line. When everyone is clear and
the slack is taken up, begin to winch, remembering to stop and adjust the winch
damper as it moves away from the snatch block.
6

7
BE AWARE!
With every snatch block used in the winch pull, the overall pulling power of the
winch is enhanced. With each additional pulley the speed with which the vehicle
will move is decreased however, a slower and more controlled speed is often
preferable when you’re stuck.
Example
• One snatch block = double the pulling power, half the winch speed.
• Two snatch blocks = triple the pulling power, and a third of the winch speed.
SINGLE LINE
DOUBLE LINE
TRIPLE LINE

A snatch block has two primary functions in recovery winching.
1. Change the direction of your winch line when the anchor point is oset.
2. Increase the pulling power of your winch.
8
USING A SNATCH BLOCK TO CHANGE PULLING DIRECTION
Winch Line
Winch hook
Rated recovery point
Winch Line
Rated Bow Shackle
Tree
Tree Trunk Protector
SNATCH BLOCK

Tree
Tree Trunk Protector
SNATCH BLOCK
SNATCH BLOCK
DOUBLE LINE
TRIPLE LINE
Winch Line
Winch Line
Rated Bow Shackle
Rated Bow Shackle
Rated Bow Shackle
Rated Bow Shackle
Rated recovery point
Winch Hook
Tree
Tree Trunk Protector
Rated recovery point
Tree Trunk Protector
Winch Hook
SNATCH BLOCK
USING A SNATCH BLOCK TO INCREASE WINCH PULLING POWER
9

10
CHOKER HOLE
GREASE NIPPLE
CARE AND MAINTENANCE
STEP 1
Always inspect the Snatch Block before use for any damage. If the choker hole
elongates (becomes oval-shaped), the maximum capacity has been exceeded and
the Snatch Block should be immediately discarded and replaced.
STEP 2
Using the grease nipple, grease the pulley pivot point with wheel bearing grease
after each use. Your new snatch block has been pre-greased.
DISPOSAL
Consult your local council waste authority for information regarding disposal
options.
