WELCOME
simple phone call in resolving misunderstandings and gaining positive insights
into product usage.
This product is manufactured to the highest standards
of safety and performance.
Please read instructions carefully before use.
Unless directions are followed physical injury or property
damage may result.
Save these instructions for future reference.
Congratulations on choosing to buy a 4X4 TOUGH® product.
3
In the event you require assistance with your
purchase please contact one of our experienced
customer service team on 1300 883 104.

INTENDED USE
Accessing the roof racks or tray top on your four wheel drive is made simple with this handy 4x4
wheel step. Designed to t most 4WD & SUV tyre sizes, the step also folds at for easy storage
while travelling..
CONTENTS
1 x 4WD Tyre step
1 x Instruction Manual
SPECIFICATIONS
Composition Steel
Dimensions folded 555×390×110 mm
Dimensions opened 555×640×355 mm
Standing platform 545×187mm
Rated load capacity 150kg
Suitability: Minimum tyre size 195/65/R15
Maximum tyre size 275/50/R20
INSTRUCTIONS FOR USE
How to adjust your wheel step to suit your tyre.
UNFOLD THE WHEEL STEP.
1. Check the width of the tyre, then adjust the tyre steps width to the most suitable and secure
position. Suitable for tyres with a width of 195 – 275mm.
The product has 5 width adjustments.
1A. Insert the supplied bolt into position and secure with the R-Clip on both sides of the wheel
step to secure the position.
2.Hook the step over your wheel and ensure it is secure
3. Adjust the height setting to the height of choice. This can be done with ease while the tyre step
is mounted on the tyre. The product has 4 height adjustments.
3A. Insert the supplied bolt into position and secure with the R-Clip on both sides of the wheel
step.
4. Use the adjustable rubber bumpers to protect your wheels and ensure the step is sturdy and
level.
NOTE In order to prevent the screws from loosening when in use, the screws must
be screwed inside as far as possible, preferably parallel to the other hole of the
square tube.
The Wheel step is now ready to use.
DO NOT FORGET TO REMOVE THE QUICK STEP FROM THE
VEHICLE’S WHEEL IMMEDIATELY AFTER USE
WARNINGS AND SAFEGUARDS
• The Product is designed to be used by 1 person only standing on the platform.
• Never exceed the Rated load capacity of 150kgs.
• Do not jump on the platform when the step is in use.
• Cracked steps and uprights or loose or missing parts can result in total collapse of the Tyre
Step.
• DO NOT attempt to reposition the Tyre Step while standing on it.
• When ascending or descending, always face the Tyre Step.
• DO NOT over reach. If you need to stretch or go up on your tip-toes while on the Tyre Step,
either reposition the Adjustable Tyre Step or use a ladder.
• Make sure the vehicle transmission is in park or neutral and the emergency brake is on before
using the Tyre Step.
CARE AND MAINTENANCE
