70mai Dash Cam Pro Plus+ User Manual

1
Product Overview
Note: Illustrations of the product, accessories, and user interface in the user manual are for reference
purposes only. The actual product and functions may vary due to product enhancements.
Please read this manual carefully before using the product and keep it in a safe place.
1
2
3
4
5
6
8
7
9
10
11
Function Buttons
Power Button
Display
Power Port
Rear Camera Port
Memory Card Slot
Speaker
Camera
12
3
4
6
5
7
9
8
10
11
Mounting Slot
Microphone
Indicator

2 3
Installation
1. Installing the electrostatic sticker.
Clean your windshield and put the electrostatic sticker on the
recommended area as shown in the figure. Make sure you remove
air bubbles between the sticker and the glass.
2. Installing the memory card.
Insert the memory card into the card slot with its contacts facing
up until you hear a click. The memory card is well-installed.
3. Installing the mount.
Attach the mount to the slot and slide up, as shown in the figure.
You will hear a snap when it is in place. Make sure the mount is
securely installed to the dash cam.
'&,1 0LFUR6'
4. Mounting the dash cam.
Peel off the protective film from the adhesive sticker on the base of the
mount, and paste the dash cam onto the electrostatic sticker in the
dotted area.
5. Connecting the power supply.
As shown in the figure, run the power cord along the top of the
windshield, down the A-pillar, and around the glove compartment,
so that the power connector is near the cigarette lighter. Connect the
power cord to the car charger, then plug the charger into the cigarette
lighter socket.
6. Adjusting the dash cam angle.
Turn on the dash cam and adjust the camera angle based on the preview
screen to ensure that the camera is facing the front of the vehicle.
Note: Make sure to stick the electrostatic sticker on a flat and smooth part of the windshield, press it firmly,
and avoid sticking it on the edge of the windshield's film to prevent it from falling down.
Note:
● Use the included crowbar to hide the power cord underneath the vehicle's headliner and rubber seal
along the A-pillar.
● Depending on the vehicle, the cigarette lighter socket may be located in a different position. The above
figure is for reference only.

4 5
Download 70mai App
This product may be used in conjunction with
the 70mai App. Please search for "70mai" in
the App Store or scan the following QR code
to download and install the App.
Note: Android 4.4 & iOS 9.0 or above is required
to connect to the dash cam's Wi-Fi hotspot with a
mobile phone.
Online Guide
Scan the below QR code to access the
online guide. The guide provides detailed
product information including descriptions
of functions. Please carefully read this guide
before use in order to avoid damage due to
incorrect use.
Accessories (optional)
The rear recording function of this product
needs to be used with the rear cameras. Scan
the QR code below to obtain the operation
guide for rear camera.
Note: To avoide the rear camera malfunction due
to device incompatibility, it is recommended to
use a rear camera from 70mai brand.
Packing list
1. 70mai Dash Cam Pro Plus+ ×1
2. Mount ×1
3. Power cord×1
4. Dual USB Car Charger×1
5. Wiring crowbar×1
6. Electrostatic Sticker × 2
7. Adhesive Sticker × 2 (with 1 pre-applied to
the mount)
8 . User manual×1

6 7
Memory Card Instructions
● A memory card (sold separately) must be installed in the dash cam before use.
● The dash cam supports standard MicroSD cards. Please use memory cards with the capacity
of 16 GB ~ 128 GB and a speed rating of Class 10 or higher.
● The default file partition format of the memory card may be inconsistent with the format
supported by the dash cam. When inserting the memory card for the first time, please format
it in the dash came before use. Formatting the memory card will delete all files on the card.
Please back up important data to another device beforehand.
● The memory card may become damaged or deteriorate after repeated cycles of overwriting,
and this may affect its ability to save video and image files. If this occurs, immediately replace
it with a new memory card.
● Please use a high-quality memory card purchased from a reputable vendor. Inferior memory
cards may have issues such as actual reading/writing speeds that do not match the stated
speeds, and an actual storage capacity that does not match the stated storage capacity.
We shall not be held liable for lost or damaged videos caused by the use of a low-quality
memory card.
● In order to avoid reading and writing speeds decreasing after prolonged use, it is
recommended to format the memory card in the dash cam every two weeks.
● Do not insert or remove a memory card while the dash cam is turned on.
Precautions
Before using this dash cam, please read all the precautions and the online guide to ensure correct and safe
use.
● This dash cam is intended to assist drivers with the purpose of recording the environment outside the
vehicle. The dash cam does not guarantee the user's driving safety. We shall not be held liable for any
accident, damage, or loss of information caused by operating the dash cam while driving.
● Due to differences in vehicle conditions, driving style, driving environment, etc., some functions may
not work properly. A power failure, usage in environments outside the normal operating temperature or
humidity range, a collision, or a damaged memory card may cause the dash cam to function abnormally.
There is no guarantee that this dash cam will function normally under all circumstances. Videos recorded
by this dash cam are for reference only.
● Please install this dash cam correctly, and do not block the driver's line of sight, nor block the vehicle's
airbag, in order to avoid product failure or personal injury.
● Please use the included car charger, power cord, and other accessories in order to avoid product failure
due to non-conformance. We shall not be held liable for any loss or damage caused by the use of a non-
genuine car charger or power cord.
● If the battery becomes deformed, swollen, or starts leaking during use or storage, stop using the dash
cam immediately in order to avoid safety issues, and contact after-sales service.
● Please keep this dash cam away from any strong magnetic fields, as they may cause damage to the dash
cam.
● Do not use this dash cam in environments with temperatures over 60°C or below -10°C.
● Please only use this dash cam within the scope permitted by law.

8 9
FCC
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 20 cm between the radiator
& your body. This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
WEEE Information
EU Declaration of Conformity
All products bearing this symbol are waste electrical and electronic equipment (WEEE
as in directive 2012/19/EU) which should not be mixed with unsorted household waste.
Instead, you should protect human health and the environment by handing over your
waste equipment to a designated collection point for the recycling of waste electrical and
electronic equipment, appointed by the government or local authorities. Correct disposal
and recycling will help prevent potential negative consequences to the environment and
human health. Please contact the installer or local authorities for more information about
the location as well as terms and conditions of such collection points.
The manufacturer hereby, declares that this equipment is in compliance with the
applicable Directives and European Norms, and amendments. The full text of the
EU declaration of conformity is available at the following internet address: https://
help.70mai.asia/1193.html
Regulatory Compliance Information

10 11
Safety information
Caution
Battery abuse or mishandling can cause overheat, liquid leakage, or an explosion. To avoid possible injury,
do the following:
●Do not open, disassemble, or service any battery.
●Do not attempt to replace the internal rechargeable lithium batteries.
●Do not crush or puncture the battery.
●Do not short-circuit the battery, or expose it to water or other liquids.
●Keep the battery away from children.
●Keep the battery away from fire.
●Do not leave the battery in an extremely high-temperature environment or an extremely low air pressure
environment.
●Stop using the battery if it is damaged, or if you notice any discharge or the buildup of foreign materials
on the battery leads. We recommend that the batteries be charged about once every three months to
prevent overcharge.
●Do not put the battery in trash that is disposed of in landfills. When disposing of the battery, comply with
local laws or regulations.
Specifications
Service: [email protected]
For further information, please go to www.70mai.com
Manufacturer: 70mai Co., Ltd.
Address: Room2220, building2, No.588, Zixingroad, MinHangDistrict, Shanghai, China
Product: Dash Cam Model: A500S Resolution: 2592× 1944
Lens: FOV140°/F1.8 Input: 5V 2A Power Supply: Car cigarette
lighter socket
Battery Type: Lithium polymer
battery Wireless Connectivity: Wi-Fi IEEE 802.11 b/g/n 2.4 GHz Battery Capacity: 500 mAh
FCC ID: 2AOK9-A500S
