70mai Dash Cam M500 User Manual

01
7
8
9
1 2 3 4 65
①① Type-C power portType-C power port
② Camera
③ Microphone
④ Ventilation holes
⑤ Indicator
⑥ Power button
⑦ Heat resistant adhesive
⑧⑧ MountMount
⑨⑨ Power cable holePower cable hole
Dash Cam
Bracket
Product overview
Please read this manual carefully before using the product and keep it in a safe place.
Note: Illustrations of the product, accessories, and user interface in the user manual are for reference purposes only. The actual product and
functions may vary due to product enhancements.

02
2. Inserting the dash cam to the bracket
Insert the dash dam into the bracket with the power port facing inside until you
hear a click sound. And then the dash cam is well installed.
3. Connecting the power cord
Connect the power cord to the Type-C power portType-C power port of the dasm cam. Pull the
power cord to ensure that it is well connected.
Installation
1. Installing the electrostatic sticker
Clean your windshield and put the electrostatic sticker on the recommended
area as shown in the figure. Avoid the edge of the windshield and select the
flat and smooth area for the installation.
Make sure you remove air bubbles between the sticker and the glass.

03
5. Connecting the power supply
As shown in the figure, run the power cord along the top of the windshield, down the
A-pillar, and around the glove compartment, so that the power connector is near the
cigarette lighter. Connect the power cord to the car charger, then plug the charger into
the cigarette lighter socket.
Notes:
● Use the included crowbar to hide the power cord underneath the vehicle’s headliner and rubber
seal along the A-pillar.
● Depending on the vehicle, the cigarette lighter socket may be located in a different position.
The figure provided is for reference only.
6. Adjusting the dash cam angle
Connect the dash cam with the 70mai app following the instructions on the user manual.
Turn on the dash cam and adjust the camera angle based on the preview screen on the
app to ensure that the camera is facing the front of the vehicle.
4. Pasting the bracket
Rotate the mount of the bracket and make the heat resistant adhesive face toward the
front windshield.
Peel off the protective film from the heat resistant adhesive, and paste the bracket onto
the electrostatic sticker in the dotted area.
Press the bracket to make sure it is firmly attached on the electrostatic sticker.

04
Button functions
Press the power button a different number of times to perform different functions.
Status Operation Function
Turned off Press once Turn on the device
Turned on
Press once Turn the Wi-Fi on/off
Press 4 times in a row Format the built-in memory card
Press 5 times in a row Reset factory settings
Press and hold for about 3 seconds Turn off the device
Receiving the connection request Press once Confirm the connection authorization
During the operation process Press and hold for about 15 seconds Force shut down the device
Specifications
Product: Dash Cam
Model: M500
Resolution: 2592 × 1944
Lens: FOV 170°/ F2.0
Input: 5V 2A
Power Supply: Car cigarette lighter
Battery Type:Li-ion Battery

05
Downloading 70mai app
Online guide
Scan the QR code to access the online guide. The guide provides detailed product information
including descriptions of functions. Please carefully read this guide before use in order to avoid
damage due to incorrect use.
This product may be used in conjunction with the 70mai app. Please search for "70mai" in the app
stores or scan the QR code to download and install the app.
Note: Android 4.4 & iOS 9.0 or above is required to connect to the dash cam’s Wi-Fi hotspot with a mobile phone.
70mai Dash Cam M500 Wi-Fi hotspot information
Hotspot name: 70mai_M500_XXXX (Please check the label on the device for the hotspot name.)
Default password: 12345678
Please refer to the online guide for how to establish a connection.
Packing list
1. 70mai Dash Cam M500 × 1
2. Power cord × 1
3. Dual USB car charger × 1
4. Module × 1
5. Electrostatic sticker × 2
6. 4. Wiring crowbar × 1
7. Adhesive sticker × 2 (pre-applied to the mount)
8. User manual × 1

06
Precautions
Before using this dash cam, please read all the precautions and the online guide to ensure correct and safe use.

●This dash cam is intended to assist drivers with the purpose of recording the environment outside the vehicle. The dash cam does not guarantee
the user’s driving safety. We shall not be held liable for any accident, damage, or loss of information caused by operating the dash cam while
driving.

●Due to differences in vehicle conditions, driving style, driving environment, etc., some functions may not work properly. A power failure, usage in
environments outside the normal operating temperature or humidity range, or a collision may cause the dash cam to function abnormally. There
is no guarantee that this dash cam will function normally under all circumstances. Videos recorded by this dash cam are for reference only.

●The eMMC (Embedded Multi Media Card) is built in the dash cam for storage. You can find the memory capacity information on the label and the
package.

●Install this dash cam correctly, and do not block the driver’s line of sight, nor block the vehicle’s airbag, in order to avoid product failure or
personal injury.

●Use the included car charger, power cord, and other accessories in order to avoid product failure due to non-conformance. We shall not be held
liable for any loss or damage caused by the use of a non-genuine car charger or power cord.

●The dash cam is equipped with a built-in battery that cannot be removed. Do not disassemble the dash cam. Do not expose batteries or battery
packs to sunlight, fire, or environments where the ambient temperature is extreme heat. There is a risk of explosion if the battery is incorrectly
installed, therefore only use and replace with the same or an equivalent type of battery.

●Keep the dash cam dry and away from water or splash to avoid battery malfunction.

●If the battery becomes deformed, swollen, or starts leaking during use or storage, stop using the dash cam immediately in order to avoid safety
issues, and contact after-sales service.

●Never wash the dash cam with chemical solvent or cleaner.

●Keep this dash cam away from any strong magnetic fields, as they may cause damage to the dash cam.

●Do not use this dash cam in environments with temperatures over 60°C or below -10°C.

●When the dash cam has been working for a while, the temperature of the outer surface may rise. Touch the surface with caution.

●Only use this dash cam within the scope permitted by law.

07
WEEE Information
EU Declaration of Conformity
All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive 2012/19/EU) which should
not be mixed with unsorted household waste. Instead, you should protect human health and the environment by handing over
your waste equipment to a designated collection point for the recycling of waste electrical and electronic equipment, appointed
by the government or local authorities. Correct disposal and recycling will help prevent potential negative consequences to the
environment and human health. Please contact the installer or local authorities for more information about the location as well as
terms and conditions of such collection points.
The manufacturer hereby, declares that this equipment is in compliance with the applicable Directives and European Norms, and
amendments. The full text of the EU declaration of conformity is available at the following internet address: https://help.70mai.
asia/1193.html
Regulatory Compliance Information
Caution
Battery abuse or mishandling can cause overheat, liquid leakage, or an explosion. To avoid possible injury, do the following:

●Do not open, disassemble, or service any battery.

●Do not attempt to replace the internal rechargeable lithium batteries.

●Do not crush or puncture the battery.

●Do not short-circuit the battery, or expose it to water or other liquids.

●Keep the battery away from children.

●Keep the battery away from fire.

●Do not leave the battery in an extremely high-temperature environment or an extremely low air pressure environment.

●Stop using the battery if it is damaged, or if you notice any discharge or the buildup of foreign materials on the battery leads. We recommend
that the batteries be charged about once every three months to prevent overcharge.

●Do not put the battery in trash that is disposed of in landfills. When disposing of the battery, comply with local laws or regulations.
Safety Information

08
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and
operated with a minimum distance of 20 cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.
FCC Caution
FCC ID: 2AOK9-M500

V1.0-20211015
Service: [email protected]
For further information, please go to www.70mai.com
Manufacturer: 70mai Co., Ltd.
Address: Room 2220, Building 2, No. 588, Zixing Road, Minhang District, Shanghai, China
