95Power VDB1620 User manual

深圳市微能信息科技有限公司
VDB1620 使用手册/User Manual
1/26 VDB1620-UM-005,A/1
VDB1620使用手册
蓝牙信标
VDB1620 User Manual
Bluetooth Beacon
文档信息/document information
标题/ Title
VDB1620 使用手册 蓝牙信标
VDB1620 User Manual Bluetooth Beacon
文档类型/ Document type
使用手册/User Manual
文档编号/ Document number
WN-21120062
版本日期/ Revision and date
V1.01 30-Dec -2021
秘密等级/ Disclosure restriction
公开/Public

深圳市微能信息科技有限公司
VDB1620 使用手册/User Manual
2/26 VDB1620-UM-005,A/1
历史版本/Revision History
修订/ Revision
描述/Description
修改人/Modifier
日期/Date
V1.01
初始版本/Initial release
谢晓博/Sherman
20211230
设备清单/Product List
设备名称/Device Name
型号/Device No.
数量/Number
备注/Remark
蓝牙信标/Bluetooth
Beacon
VDB1620
1 PCS
带防拆按键/With detachable button
电池/Battery
SIZE AA(5 号)
2 PCS
南孚 Excell 工业装，2600mAh
95Power 保留本文档及本文档所包含的信息的所有权利。95Power 拥有本文档所述的产品、名称、标
识和设计的全部知识产权。严禁没有征得 95Power 的许可的情况下复制、使用、修改或向第三方披露本
文档的全部或部分内容。
95Power 对本文档所包含的信息的使用不承担任何责任。没有明示或暗示的保证，包括但不限于关于
信息的准确性、正确性、可靠性和适用性。95Power 可以随时修订这个文档。可以访问
www.95power.com.cn 获得最新的文件。
Copyright © 2021, 深圳市微能信息科技有限公司。
95Power® 是深圳市微能信息科技有限公司在中国的注册商标。
95POWER reserves all rights to this document and the information contained herein. Products, names,
logos and designs described herein may in whole or in part be subject to intellectual property rights.
Reproduction, use, modification or disclosure to third parties of this document or any part thereof without
the express permission of 95POWER is strictly prohibited.
The information contained herein is provided “as is” and95power assumes no liability for the use of the
information. No warranty, either express or implied, is given, including but not limited, with respect to the
accuracy, correctness, reliability and fitness for a particular purpose of the information. This document
may be revised by95power at any time. For most recent documents, visit www.95power.com.cn
Copyright © 2021, 95Power Information Technology Co., Ltd.
95POWER® is a registered trademark of 95Power Information Technology Co., Ltd in China.

深圳市微能信息科技有限公司
VDB1620 使用手册/User Manual
3/26 VDB1620-UM-005,A/1
目录/Contents
1. 产品介绍/Product introduction............................................................................................................................ 4
1.1 VDB1620 内部模块介绍/ VDB1620 Internal Modules...........................................................................5
1.2 VDB1620 特性/ VDB1620 Feature........................................................................................................... 5
1.3 VDB1620 应用/ VDB1620 Application..................................................................................................... 5
2. 硬件参数/Hardware Features............................................................................................................................. 6
3. 电池安装指导/ Battery installation guide...........................................................................................................7
4. 软件使用说明//Software Instructions................................................................................................................. 9
4.1 VDB1620 开机/ Power on.......................................................................................................................... 9
4.2 扫描蓝牙信标/ Scan Bluetooth beacons..................................................................................................9
4.3 连接蓝牙信标/Connect Bluetooth beacon.............................................................................................10
4.4 配置介绍/Configuration Introduction...................................................................................................... 11
4.5 修改蓝牙信标名称/ Modify Bluetooth 4.2 Beacon Name....................................................................12
4.6 修改 UUID/ Modify UUID..........................................................................................................................13
4.7 修改 User service data/ Modify User service data.............................................................................. 14
4.8 修改 Major、Minor/ Modify Major、Minor............................................................................................. 15
4.9 修改 Measured Power/ Modify Measured Power................................................................................ 16
4.10 修改发射功率/ Modify Transmitting Power......................................................................................... 17
4.11 修改广播间隔/ Modify Advertise Interval.............................................................................................18
4.12 修改密码/ Modify Password.................................................................................................................. 19
4.13 切换模式/ Switch mode.......................................................................................................................... 20
4.14 Eddystone 配置页面简介/ Eddystone configuration page Introduction........................................ 21
4.15 修改 URL/ Modify URL.......................................................................................................................... 22
4.16 修改 Other Setting/ Modify Other Setting.......................................................................................... 23
4.17 APP 下载/ Download the APP.............................................................................................................. 25
5. 联系方式/ Content.............................................................................................................................................. 26

深圳市微能信息科技有限公司
VDB1620 使用手册/User Manual
4/26 VDB1620-UM-005,A/1
1. 产品介绍/Product introduction
VDB1620 是一款防拆型资产标签蓝牙信标。其广播协议符合蓝牙 BLE 广播协议，包括 iBeacon
（Apple）和 Eddystone（Google）两种协议。它通常被安装在一个合适的位置，周期性地向它的周围环
境进行广播，从而被其他蓝牙设备如蓝牙网关扫描到其广播内容，并计算出位置信息。通常它是不会被其
他BLE 的主机设备连接上的，但是可以通过手机 APP 进行连接，并修改其广播参数等内容。
The VDB1620 is an anti-disassembly Bluetooth beacon that can be used as an asset tag. Its broadcast
protocol conforms to Bluetooth BLE, including iBeacon (Apple) and Eddystone (Google) . The beacon is
usually installed in a suitable location, periodically broadcast to its surroundings, so that other Bluetooth
devices such as Bluetooth gateways can scan its broadcast content and calculate the location
information. Normally, it is not connected by other BLE host devices, but can be connected through
mobile APP, and modify its broadcast parameters and other contents.
Skylab_xBeacon 是一款 SKYLAB 研发团队研发用于配置 VDB1620 参数的 APP。 用这款 APP 去
连接 VDB1620，可以修改它的广播频率、功率，UUID, Major, Minor 和设备名称等参数。当 VDB1620
处于广播状态时这些参数将被广播出来。
Skylab_xBeacon is an APP developed by SKYLAB R&D team for configuring VDB1620 parameters. If
you connect VDB1620 with this APP, you can modify its broadcast frequency, power, UUID, Major,
Minor, device name and other parameters. These parameters will be broadcast when VDB1620 is in
broadcast state.
Figure 1: VDB1620 产品图/ product picture

深圳市微能信息科技有限公司
VDB1620 使用手册/User Manual
5/26 VDB1620-UM-005,A/1
1.1 VDB1620 内部模块介绍/ VDB1620 Internal Modules
VDB1620 基于 nordic 的nRF52832 芯片，内部支持防拆按键，可以在被拆下时上传报警信息（安装
时需要确保安装面平整，常规安装时把防拆按键按下，按键弹起时会在广播包中增加防拆报警信息）。
VDB1620 is based on Nordic nRF52832 chip, Its internal support anti-disassembly button, and can
upload alarm information when it is disassembled. (During installation, ensure that the installation
surface is flat. Press the anti-disassembly button during conventional installation, and anti-disassembly
alarm information will be added to the broadcast package when the button is pulled up).
VDB1620 内部预留加速度和温湿度传感器，可以采集相应信息并广播出去（默认不贴）。
The VDB1620 reserves acceleration and temperature and humidity sensors to collect and broadcast
information (not displayed by default).
VDB1620 用两节 5号电池（南孚 Excell 工业装）串联供电，方便更换电池。
VDB1620 is powered by two no. 5 batteries (Nanfu Excell Industrial) in series for easy Easy to replace.
1.2 VDB1620 特性/ VDB1620 Feature
低功耗/ Low Energy
IP67 级防尘防水/ IP67
支持二维码，NFC 定制内容/ Support two-dimensional code, NFC customized content
应用灵活/ Flexible application
安装便捷/ Easy to Install
广播距离可达 70 米/ Broadcasting distance can reach 70 meters
符合 RoHS, FCC, CE 标准/Compliance with RoHS, FCC, CE standards
1.3 VDB1620 应用/ VDB1620 Application
资产标签/ Asset tag
室内定位/ Indoor positioning
信息推送/ Information push
身份识别/ Identity recognition
微信摇一摇/ Wechat shake

深圳市微能信息科技有限公司
VDB1620 使用手册/User Manual
6/26 VDB1620-UM-005,A/1
2. 硬件参数/Hardware Features
产品参数/Product parameter
尺寸/Dimensions
72*45*26mm（L*W*H）
电池型号/Battery model
Size AA（5号电池/Excell 工业装 2600mAh 容量）
工作温度/Operating temperature
-40℃~85℃
传感器参数（预留，默认不贴）/Sensor parameters (reserved, not attached by default)
加速度传感器/Acceleration sensor
3轴，±2g/4g/8g/16g 四档可调
湿度度传感器/Humidity sensor
0%RH~100%RH（±%2RH）
温度传感器/ Temperature sensor
-20℃~70℃（±0.2℃）
蓝牙参数/Bluetooth parameters
无线标准/Wireless Standards
蓝牙®4.2/5.0,ANT Bluetooth ®4.2/5.0,ANT
频率范围/Frequency Range
2400MHz---2483.5MHz
数据速率/Data Rates
1Mbps(Bluetooth ®4.2); 2Mbps(Bluetooth ® 5.0)
调制技术/Modulation technique
GFSK 调制
无线安全/Wireless Security
AES HW Encryption
传输功率/Transmit Power
Tx Power-40dBm, -20dBm, -16dBm, -12dBm, -8dBm,
-4dBm, 0dBm, +3dBm and +4dBm.
灵敏度/Sensitivity
-94dBm at 1Mbps BLE
工作模式/Work Mode
Central/ Peripheral

深圳市微能信息科技有限公司
VDB1620 使用手册/User Manual
7/26 VDB1620-UM-005,A/1
注/Note：
功耗数据仅供参考，未考虑电池自放电因素，当计算寿命大于电池寿命（5年）时，以电池寿命为准；
The power consumption data is for reference only, and the battery self-discharge factor is not taken into
account. If the calculated life is longer than the battery life (5 years), the battery life shall be the criterion.
上述计算默认采用南孚 Excell 工业装，2600mAh 作为电量参考。
The above calculation uses nanfu Excell industrial pack by default, 2600mAh as power reference.
3. 电池安装指导/ Battery installation guide
VDB1620 在默认情况下，出厂时已安装 2节5号干电池。如果您需要更换电池，请遵循以下说明。
By default, the VDB1620 is delivered with two no.5 dry batteries. If you need to change its batteries,
please follow the instruction below:
（1）用十字螺丝刀拆卸 4颗螺丝；
Remove 4 screws with a Phillips screwdriver
电池使用寿命/Battery life
广播功率/Broadcasting
power
覆盖范围/coverage area
广播间隔
/Broadcas
t interval
电池使用时间（月）/Battery
life (month)
+4dBm
70m
100ms
10.2
200ms
19.7
500ms
45.1
1000ms
78.9
+0dBm
50m
100ms
13.8
200ms
26.5
500ms
58.9
1000ms
99.2

深圳市微能信息科技有限公司
VDB1620 使用手册/User Manual
8/26 VDB1620-UM-005,A/1
（2）打开 VDB1620 的底部外壳和橡胶垫，对准电池的正负极，安装 2节电池；
Open the bottom shell and rubber pad of theVDB1620, follow the Battery polarity on the bottom of
the battery cell, and replace its 2 batteries.

深圳市微能信息科技有限公司
VDB1620 使用手册/User Manual
9/26 VDB1620-UM-005,A/1
4. 软件使用说明//Software Instructions
4.1 VDB1620 开机/ Power on
打开 VDB1620 的底壳，安装两个 Size AA 电池，再将开关拨到“ON”。此时，VDB1620 开始广播，
再安装 VDB1620 的底壳。如未特殊要求，默认出货样机已提前拨到“ON”上，并装好电池打好螺丝。
Open the bottom shell of the VDB1620 and install two Size AA batteries, and then switch to "ON". At this
point, VDB1620 starts broadcasting, and then install the VDB1620 bottom shell. If there is no special
requirement, the delivery prototype has been dialed to "ON" in advance by default, and the battery and
screws has been installed.
4.2 扫描蓝牙信标/ Scan Bluetooth beacons
打开 APP，如果手机提示打开蓝牙，请允许，手机自动开始扫描周围的蓝牙信标。
Open the APP. If the mobile phone prompts you to turn on Bluetooth, please allow. The mobile phone
automatically starts to scan the Bluetooth beacons around it.

深圳市微能信息科技有限公司
VDB1620 使用手册/User Manual
10 /26 VDB1620-UM-005,A/1
4.3 连接蓝牙信标/Connect Bluetooth beacon
点击要连接的蓝牙信标，30 秒内输入密码，即可获得操作权限。(出厂密码:1234)
Click the Bluetooth beacon you want to connect to, enter your password within 30 seconds, and you will
get the operation permission. (Factory password :1234)

深圳市微能信息科技有限公司
VDB1620 使用手册/User Manual
11 /26 VDB1620-UM-005,A/1
4.4 配置介绍/Configuration Introduction
介绍/ Introductions:
MAC: MAC 地址/ Chip MAC address
Name: 所选蓝牙信标的名称/ The name of the Bluetooth 4.2 Beacon which is selected.
UUID: 按照 ISO/IEC11578:1996 标准的 128 位标识符(16 字节)/
128-bit identifier according to ISO/IEC11578:1996 standard (32 hexadecimal digits)
User service data: 用户数据，24 个16 进制数字 User data, 24 hexadecimal digits
Major: 16 位标识符(0-65535)/ set 16-bit identifier (0-65535)
Minor: 16 位标识符(0-65535)/ set 16-bit identifier (0-65535)
Measured Power: 距离 1米时的参考信号强度/ Signal strength at 1 meter（VDB1620 transmission
power is 0dBm）
Transmit Power: VDB1620 发射功率/ VDB1620 transmit power
Advertise Interval: VDB1620 广播间隔/ VDB1620 advertise interval
Battery Level: VDB1620 电池电量/ VDB1620 battery Capacity
Password: VDB1620 密码（默认 1234）/ VDB1620 connection password
配置好信息后，蓝牙连接断开，配置将生效。
After the information is configured ,the configuration will take effect after the bluetooth connection is
disconnected.

深圳市微能信息科技有限公司
VDB1620 使用手册/User Manual
12 /26 VDB1620-UM-005,A/1
4.5 修改蓝牙信标名称/ Modify Bluetooth 4.2 Beacon Name
点击“Device Name”，出现以下 UI，然后在“输入一个名称”框中输入长度小于 12 位的英文字符名称，
也可以在“或者选一个”里选一个名称。然后点击“确认修改”。
Click the“Device Name”, the following UI will be opened. Then enter a length of less than 12-bit English
characters as VDB1620 device name in the following “Enter a Name” box. Then click “confirm to modify”.

深圳市微能信息科技有限公司
VDB1620 使用手册/User Manual
13 /26 VDB1620-UM-005,A/1
4.6 修改 UUID/ Modify UUID
点击“UUID”，出现以下 UI，然后在“输入一个 UUID 值”框中输满 16 个字节（32 个十六进制字符）作
为VDB1620 的UUID。然后点击“确认修改”。
Click the “UUID”, ,the following UI will be opened. Then and then enter a 32-byte string of sixteen as the
UUID of VDB1620 in the following “Enter an UUID” box. Then click “confirm to modify”.

深圳市微能信息科技有限公司
VDB1620 使用手册/User Manual
14 /26 VDB1620-UM-005,A/1
4.7 修改 User service data/ Modify User service data
点击“User service data”，出现如下界面，在“输入用户数据”中输入 24 个16 进制字符。然后点击“确
认修改”。
Click the " User service data ", the following interface will be opened. Then enter a Hexadecimal string of
24 word . Then click “confirm to modify”.

深圳市微能信息科技有限公司
VDB1620 使用手册/User Manual
15 /26 VDB1620-UM-005,A/1
4.8 修改 Major、Minor/ Modify Major、Minor
点击“Major”，出现如下界面，设置 0~65535 为设备的 Major 值。然后点击“确认修改”。
Click the "Major"/"Minor" ,the following UI will be opened. Then set a value between 0~65535 as the
Major/Minor value of the device.
修改 Minor
同上面 Major 类似，点击 Minor 进入修改即可。

深圳市微能信息科技有限公司
VDB1620 使用手册/User Manual
16 /26 VDB1620-UM-005,A/1
4.9 修改 Measured Power/ Modify Measured Power
点击“Measured Power”，出现如下 UI，在距离 VDB1620 1 米远处，设置测量功率，可调范围
-100dBm~-30dBm，默认为-61dBm。然后点击“确认修改”。
Click the “Measured Power”, ,the following UI will be opened. Then select a measured power range from
-100dBm to -30dBm. The default is -61dBm. Then click “confirm to modify”.
Measured Power 含义为，当接收设备接收到的信号强度为-61dBm 时，可认为该设备距离 VDB1620
约为 1米。
Measured Power means, when a phone’s RSSI is -61dBm, it is about 1 meter from VDB1620.

深圳市微能信息科技有限公司
VDB1620 使用手册/User Manual
17 /26 VDB1620-UM-005,A/1
4.10 修改发射功率/ Modify Transmitting Power
点击“Transmission Power”出现如下 UI，设置 VDB1620 的发射功率。功率可设置为:-30dBm，
-20dBm，-16dBm，-12dBm，-8dBm，-4dBm, 0dBm, 4dBm。默认是 0dBm。然后点击“确认修改”。
Click the "Transmitting Power" ,the following UI will be opened. Then set a transmitting power, which can
be set to: -30dBm, -20dBm, -16dBm, -12dBm, -8dBm, -4dBm, 0dBm, 4dBm and 8dBm. Default Power is
0dBm. Then click “confirm to modify”.

深圳市微能信息科技有限公司
VDB1620 使用手册/User Manual
18 /26 VDB1620-UM-005,A/1
4.11 修改广播间隔/ Modify Advertise Interval
点击“广播间隔”出现如下 UI，设置广播间隔，广播间隔可以设置为 100ms、200ms、300ms、400ms、
500ms、600ms、700ms、800ms、900ms 和1000ms。默认为 500ms。然后点击“确认修改”。
Click the "Advertise Interval" ,the following UI will be opened. Then set a advertise interval. Broadcasting
interval can be set to 100ms, 200ms, 300ms, 400ms, 500ms, 600ms ,700ms, 800ms, 900ms and
1000ms. The default is 500ms. Then click “confirm to modify”.

深圳市微能信息科技有限公司
VDB1620 使用手册/User Manual
19 /26 VDB1620-UM-005,A/1
4.12 修改密码/ Modify Password
点击“Password”，出现如下 UI，然后在“Password”框中输入 4个字符作为连接密码，默认为 1234。
然后点击“确认修改”。
Click the “Password”, ,the following UI will be opened. Then and then enter the 4 characters as a
connection password in the “Password” box, the default is 1234. Then click “confirm to modify”.
注意：请提前保存好您的密码，一旦修改新密码，原密码将失效，必须用新密码才能登陆。
Note:
Please save your password in advance, once you change the new password, the original password will
be invalid, you must use the new password to log in.

深圳市微能信息科技有限公司
VDB1620 使用手册/User Manual
20 /26 VDB1620-UM-005,A/1
4.13 切换模式/ Switch mode
点击右上角切换模式文字，出现模式选择窗口，点选 Eddystone。
Click “ switch mode” on the upper right corner, the mode selection window will be openend. Then you
can choose iBeacon or Eddystone mode. Default mode is iBeacon.
