1.产品介绍/Product Introduction
VDB1617 是一款蓝牙 5.0 信标设备。蓝牙信标使用 BLE 低功耗蓝牙广播的方法，利用其支持的通用
属性配置文件在第 37、38、39 三个信道上连续发送无定向性的广播包。其广播内容可由我司研发团队开
发的 APP“95POWER_xbeacon”读取，包括 UUID、Major、Minor、RSSI 等信息。
VDB1617 is a Bluetooth 5.0 Beacon device. It uses a broadcasting protocol which is based on BLE
(Bluetooth Low Energy ). VDB1617 broadcasts its general cofig parameters like UUID, Major, Minor,
RSSI etc. to surroundings over 37, 38 and 39 BLE channels continuously and non-directionally . The
broadcasting information can be read by “95POWER_xbeacon” APP, which is designed by our R&D
Team.
VDB1617 基于 Nordic BLE 5.0 芯片 nRF52840。其内部由 2节ER14250 电池供电，电池续航时间
与VDB1617 广播参数有关。
VDB1617 is based on Nordic Bluetooth 5.0 chip nRF52840.
It is powered by 2 ER14250 batteries. Its battery life is related to the internal broadcasting parameters.
Figure 1:VDB1617 正视图/Top View

深圳市微能信息科技有限公司
95Power Information Technology Co., Ltd
6/28 VDB1617-UM-005,A/1
VDB1617-使用手册/User Manual
1.1 VDB1617 特性/features
◆ 低功耗/ Low Power Consumption
◆ 体积小、重量轻、造型美观/ Small,Lightweight,Beautiful appearance
◆APP 可灵活配置参数/ Flexible Application
◆ 安装方便(3M 胶安装) / Easy to Install(use 3M sticky tape)
◆ 广播范围最大可达 100 米/ Advertise Range up to 100 Meters
◆ 符合 RoHS (无铅)/ RoHS compliance (Lead-free)
◆ 符合 FCC, CE/ FCC,CE compliance
1.2 VDB1617 应用/application
◆ 室内定位/ Indoor Positioning
◆ 信息推送/ Information Push
◆ 身份识别/ Identification
◆ 微信摇一摇/ WeChat Shake

深圳市微能信息科技有限公司
95Power Information Technology Co., Ltd
7/28 VDB1617-UM-005,A/1
VDB1617-使用手册/User Manual
2. 硬件参数/Hardware parameters
2.1 产品参数/Product Parameter
硬件特性/ Hardware Features
型号/ Model
VDB1617
天线类型/ Antenna Type
PCB 天线/ PCB Antenna
电池/ Battery
ER14250 2 * 1200 mAh
标称电压 Voltage
1.8~3.6 v
尺寸(直径×厚度)/ Dimension(D×H)
52.0 * 23.2(±0.3)mm
无线功能/ Wireless Features
无线标准/ Wireless Standards
蓝牙®5.0/ Bluetooth ®5.0
频率范围/ Frequency Range
2400MHz——-2483.5MHz
数据速率/ Data Rates
125kbps/ 250 kbps/ 500kbps/ 1 Mbps/ 2 Mbps
调制技术/ Modulation Technique
GFSK 调制
无线安全/ Wireless Security
AES
传输功率/ Transmit Power
-20~+8 dBm 可调，步长 4 dB
Tx Power -20 to +8 dBm in 4 dB Steps
灵敏度/ Sensitivity
-95dBm at 1Mbps BLE
工作模式/ Work Mode
从机/ Peripheral
其他/ Others
工作环境/ Environment
工作温度:-40℃~ 85℃/
Operating Temperature: -40℃~85℃
储存温度:-40℃~ 85℃/
Storage Temperature: -40℃~85℃
工作湿度:10%~90%不凝结/
Operating Humidity: 10%~90% Non-condensing
储存湿度:5%~90%不凝结/
Storage Humidity: 5%~90% Non-condensing

深圳市微能信息科技有限公司
95Power Information Technology Co., Ltd
8/28 VDB1617-UM-005,A/1
VDB1617-使用手册/User Manual
2.2 电池寿命 Battery life
发射功率/
TX Power
广播距离/
Adv. Distance
广播间隔 ms/
Adv. interval
每天功耗 mA*h/
Power
consumption per
day
VDB01 待
机天数/
Battery life
(day)
VDB01
待机年数
/
Battery
life
(year)
8dBm
100m
100
12.5892
190.6
0.5
200
6.4746
370.7
1.0
500
2.80584
855.4
2.3
800
1.88865
1270.7
3.5
1000
1.58292
1516.2
4.2
4dBm
70m
100
8.9892
267.0
0.7
200
4.6746
513.4
1.4
500
2.08584
1150.6
3.2
800
1.43865
1668.2
4.6
1000
1.22292
1962.5
5.4
0dBm
50m
100
5.3892
445.3
1.2
200
2.8746
834.9
2.3
500
1.36584
1757.2
4.8
800
0.98865
2427.6
6.7
1000
0.86292
2781.3
7.6
注：以上数据可能因环境不同而有所改变，且未计入电池损耗，仅供参考。
Note: The above data may differ from different environments. It is caculated by current-test (Battery
Loss not included) and just for reference.

深圳市微能信息科技有限公司
95Power Information Technology Co., Ltd
9/28 VDB1617-UM-005,A/1
VDB1617-使用手册/User Manual
3. 硬件使用说明/Hardware Instructions
3.1 VDB1617 开机/Power on
VDB1617 安装电池后就会自动开机。默认情况下，出厂时已安装 2节ER14250 电池。
VDB1617 will power on as soon as any one of its 2 batteries is correctly installed. By default , 2
CR14250 battery will be pre-installed before it arrives at customers’ hand.
如果您需要更换电池，请遵循以下说明:
If you need to change its batteries, please follow the instruction below:
a.用十字螺丝刀拆卸 4颗螺丝
Remove 4 screws with a Phillips screwdriver
b.打开 VDB1617 的底部外壳，对准正负极，更换 2节ER14250 锂电池。
Open the bottom shell of theVDB1617, follow the Battery polarity on the bottom of the battery cell,
and replace its 2 CR14250 Li-Batteries.
c.安装底壳，用橡胶针对准上壳周围的凹槽
Close the bottom shell with its rubber needling aligned to the sink around the side-shell.
d.用十字螺丝刀安装 4个螺丝
Install 4 screws with a Phillips screwdriver.

深圳市微能信息科技有限公司
95Power Information Technology Co., Ltd
10 /28 VDB1617-UM-005,A/1
VDB1617-使用手册/User Manual
3.2 VDB1617 Installation instructions
a. 把VDB1617 有螺丝的一面擦拭干净
Clean up VDB1617 bottom side (screw side).
b.把3M 胶圆片从油纸贴上揭掉，贴到 VDB1617 有螺丝的一面
Tear off 3M round tape from the oil-paper and sticky it to the bottom side.
c.把VDB1617 贴3M 胶一面放到平面上（如桌子上）均匀按压 5~10 秒
Press evenly for 5-10 seconds, make VDB1617 bottom side and 3M tape fully bonded.
d.撕掉 3M 胶保护膜，并把 VDB1617 有3M 胶一面贴到目标安装位置（选择合适贴装位置，目标位置
如果有灰尘或油渍需要提前清理干净，并保持干燥）。然后均匀施力按压 5~10 秒。
Remove the protective oilpaper on the other side of the 3M tape and install VDB1617 to target
installation location (if there is dust or grease stain in the target location, it needs to be cleaned
anddried in before install). Press evenly for 5-10 seconds.
4. 软件使用说明/Software Instructions
95POWER_xbeacon 是95POWER 研发团队开发的一款蓝牙 Beacon 软件，支持 iBeacon 和
Eddystone 两种模式，可灵活配置常用参数。
95POWER_ xbeacon is a Bluetooth Beacon software developed by 95POWER research and
development team. It supports iBeacon and Eddystone modes and can flexibly configure common
parameters
4.1 下载应用程序/Download APP
目前 APP 尚未上架，请联系销售人员提供，APP 名称 95POWER_xbeacon。
95power_xbeacon hasn’t been put into the market yet. Please contact our salesman for this APP.

深圳市微能信息科技有限公司
95Power Information Technology Co., Ltd
11 /28 VDB1617-UM-005,A/1
VDB1617-使用手册/User Manual
4.2 扫描蓝牙信标/Scan Bluetooth beacons
打开 APP，如果手机提示打开蓝牙，请允许，手机自动开始扫描周围的蓝牙信标。
Open the APP, if cell phone ask for permission to open bluetooth please select yes. Then it will begin to
scan the surrounding Bluetooth 4.2 Beacons.

深圳市微能信息科技有限公司
95Power Information Technology Co., Ltd
12 /28 VDB1617-UM-005,A/1
VDB1617-使用手册/User Manual
4.3 连接蓝牙信标/Connect Bluetooth 4.2 Beacon
点击要连接的蓝牙信标，30 秒内输入密码，即可获得操作权限。(出厂密码:1234)
Click the Bluetooth 4.2 Beacon to be connected, enter the password within 30 seconds, in order to
obtain operating privileges .(Factory Password:1234)

深圳市微能信息科技有限公司
95Power Information Technology Co., Ltd
13 /28 VDB1617-UM-005,A/1
VDB1617-使用手册/User Manual
4.4 配置介绍/Configuration Introduction
介绍/ Introductions:
MAC: MAC 地址/ Chip MAC address
Name: 所选蓝牙信标的名称/ The name of the Bluetooth 4.2 Beacon which is selected.
UUID: 按照 ISO/IEC11578:1996 标准的 128 位标识符(16 字节)/
128-bit identifier according to ISO/IEC11578:1996 standard (32 hexadecimal digits)
User service data:用户数据，24 个16 进制数字 User data, 24 hexadecimal digits
Major: 16 位标识符(0-65535)/ set 16-bit identifier (0-65535)
Minor: 16 位标识符(0-65535)/ set 16-bit identifier (0-65535)
Measured Power: 距离 1米时的参考信号强度/ Signal strength at 1 meter（VDB1617 transmission
power is 0dBm）
Trasmit Power: VDB1617 发射功率/ VDB1617 transmit power
Advertise Interval: VDB1617 广播间隔/ VDB1617 advertise interval
Battery Level: VDB1617 电池电量/ VDB1617 battery Capacity
Password: VDB1617 密码（默认 1234）/ VDB1617 connection password
配置好信息后，蓝牙连接断开，配置将生效。
After the information is configured ,the configuration will take effect after the bluetooth connection is
disconnected.

深圳市微能信息科技有限公司
95Power Information Technology Co., Ltd
14 /28 VDB1617-UM-005,A/1
VDB1617-使用手册/User Manual
4.5 修改蓝牙信标名称/Modify Bluetooth 4.2 Beacon Name
点击“Device Name”，出现以下 UI，然后在“输入一个名称”框中输入长度小于 12 位的英文字符名称，
也可以在“或者选一个”里选一个名称。然后点击“确认修改”。
Click the “Device Name”, the following UI will be opened. Then enter a length of less than 12-bit English
characters as VDB1617 device name in the following “Enter a Name” box. Then click “confirm to modify”.

深圳市微能信息科技有限公司
95Power Information Technology Co., Ltd
15 /28 VDB1617-UM-005,A/1
VDB1617-使用手册/User Manual
4.6 修改 UUID/Modify UUID
点击“UUID”，出现以下 UI，然后在“输入一个 UUID 值”框中输满 16 个字节（32 个十六进制字符）作
为VDB1617 的UUID。然后点击“确认修改”。
Click the “UUID”, ,the following UI will be opened. Then and then enter a 32-byte string of sixteen as the
UUID of VDB1617 in the following “Enter an UUID” box. Then click “confirm to modify”.

深圳市微能信息科技有限公司
95Power Information Technology Co., Ltd
16 /28 VDB1617-UM-005,A/1
VDB1617-使用手册/User Manual
4.7 修改 User service data/Modify User service data
点击“User service data”，出现如下界面，在“输入用户数据”中输入 24 个16 进制字符。然后点击“确
认修改”。
Click the " User service data ", the following interface will be opened. Then enter a Hexadecimal
string of 24 word . Then click “confirm to modify”.

深圳市微能信息科技有限公司
95Power Information Technology Co., Ltd
17 /28 VDB1617-UM-005,A/1
VDB1617-使用手册/User Manual
4.8 修改 Major、Minor/Modify Major、Minor
点击“Major”，出现如下界面，设置 0~65535 为设备的 Major 值。然后点击“确认修改”。Minor 类似，
点击 Minor 进入修改即可。
Click the "Major"/"Minor" ,the following UI will be opened. Then set a value between 0~65535 as the
Major/Minor value of the device. Then click “confirm to modify”. Minor is similar, click Minor to enter
modify.

深圳市微能信息科技有限公司
95Power Information Technology Co., Ltd
18 /28 VDB1617-UM-005,A/1
VDB1617-使用手册/User Manual
4.9 修改 Measured Power/Modify Measured Power
点击“Measured Power”，出现如下 UI，在距离 VDB1617 1 米远处，设置测量功率，可调范围
-100dBm~-30dBm，默认为-61dBm。然后点击“确认修改”。
Click the “Measured Power”, ,the following UI will be opened. Then select a measured power range from
-100dBm to -30dBm. The default is -61dBm. Then click “confirm to modify”.
Measured Power 含义为，当接收设备接收到的信号强度为-61dBm 时，可认为该设备距离 VDB1617
约为 1米。
Measured Power means, when a phone’s RSSI is -61dBm, it is about 1 meter from VDB1617.

深圳市微能信息科技有限公司
95Power Information Technology Co., Ltd
19 /28 VDB1617-UM-005,A/1
VDB1617-使用手册/User Manual
4.10 修改发射功率/Modify Transmitting Power
点击“Transmission Power”出现如下 UI，设置 VDB1617 的发射功率。功率可设置为:-30dBm，
-20dBm，-16dBm，-12dBm，-8dBm，-4dBm, 0dBm, 4dBm。默认是 0 dBm。然后点击“确认修改”。
Click the "Transmitting Power" ,the following UI will be opened. Then set a transmitting power, which can
be set to: -30dBm, -20dBm, -16dBm, -12dBm, -8dBm, -4dBm, 0dBm, 4dBm and 8dBm. Default Power is
0dBm. Then click “confirm to modify”.

深圳市微能信息科技有限公司
95Power Information Technology Co., Ltd
20 /28 VDB1617-UM-005,A/1
VDB1617-使用手册/User Manual
4.11 修改广播间隔/Modify Advertise Interval
点击“广播间隔”出现如下 UI，设置广播间隔，广播间隔可以设置为 100ms、200ms、300ms、400ms、
500ms、600ms、700ms、800ms、900ms 和1000ms。默认为 500ms。然后点击“确认修改”。
Click the "Advertise Interval" ,the following UI will be opened. Then set a advertise interval. Broadcasting
interval can be set to 100ms, 200ms, 300ms, 400ms, 500ms, 600ms ,700ms, 800ms, 900ms and
1000ms. The default is 500ms. Then click “confirm to modify”.
