Smart Charger (6.0A) for 25.9V Li-ion/Polymer Rechargeable
Battery Pack- 110V-240V --- CE / UL Listed (CH-L2596)
User Manual & Technical specification
Warning
1. Please read the following instruction carefully before use.
2. Improper using the charger will cause the damage of
batteries or possible explosions.
3. Must connect to battery pack with correct polarity
according to pin assignment below
Pin assignment for 25.9V 6.0A Li-Ion smart charger charging
terminal


AA Portable Power Corp
www.batteryspace.com, Email: [e-mail]

AAPortablePowerCorp.www.batteryspace.com AAPortablePowerCorp. www.batteryspace.com
1) Product description:
CH‐L2596is a CE/UL listed smart battery charger designed to charge 25.9V Li-Ion /
Polymer battery with capacity ≥1000mAh. It uses CC/CV technology to monitor and
control the charging process.
2) Features:
a) Worldwide input AC power from 100-240V, 50-60Hz, USA AC plug.
b) LED indicator tells if the battery is charging (Red) or fully charged (Green).
c) Trickle charging: it switches to maintenance mode when the battery is fully charged.
3) Operations:
.LED will be green when the charger is connected to AC only. LED will turn red when a
battery is connected to the DC plug and charging. LED will switch to green automatically
when the charging is finished (it takes 2.6-8 hours to finish charging a battery, depends on
the capacity of the battery). Disconnect AC plug and DC plug to stop charging.
Note: You must connect charger to AC power before connect to battery pack. Otherwise,
the charger will NOT charge the pack and you will not get a RED LED indicate charging.
4) Technical Specification:
Rated AC Input: 100-240 VAC 50-60 Hz
Maximum Output power: 179W
Rating Output: 29.8VDC, 6.0A standard (7.1A Max Initial rate)
Efficiency; >70%
Operation Temperature: -10℃-40℃
Operation Humidity: < 90%
Suit Battery: 25.9V Li-ion/polymer battery with capacity ≥10Ah
5) Notice:
a) Use with proper Li-Ion/polymer battery pack only. Please make sure the battery
voltage matches what labels on the charger (25.9V). The battery will be damaged or
will not be charged if the voltage does not match.
b) Never charge other types of batteries besides Li-Ion/Polymer.
c) Please make sure polarity is connected correctly.
d) Always place the charger in well-ventilated, dry environment.
e) Indoor used only, never expose the charger to water such as rain and splash.
f) Never place the charger near radiator, heat register or similar heat source when in
charging.
g) Do not use this charger if any of the following happens:
i) If the power cord or plug is damaged or frayed
ii) If liquid has been spilled into the charger
iii) If the case of the charger is dropped and damaged
iv) If the charger does not behave properly as stated in 3) Operations.

