Aaeon AMB-2020HT-E Series User manual

AMB-2020HT(T)-E User’s Manual
1
AMB-2020HT(T)-ESeries
Open Frame Modular Industrial Panel PCs
Version 1.0
Industrial Panel PCs
Industrial Panel PCs for Industrial Automation
User’s Manual

AMB-2020HT(T)-E User’s Manual
2
Copyright Notice
This document is copyrighted, 2002. All rights are reserved. The original manufacturer reserves the right
to make improvements to the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means
without the prior written permission of the original manufacturer. Information provided in this manual is
intended to be accurate and reliable. However, the original manufacturer assumes no responsibility for its
use, nor for any infringements upon the rights of third parties which may result from its use.
The material is this document is for product information only and is subject to change without notice.
While reasonable efforts have been made in the preparation of this document to assure its accuracy,
AAEON, assumes no liabilities resulting from errors or omissions in this document, or from the use of the
information contained herein.
AAEON reserves the right to make changes in the product design without notice to its users.
Acknowledgments
Award is a registered trademark of Award Software International, Inc.
C&T is a trademark of Chips and Technologies, Inc.
IBM, PC/AT, PS/2 are trademarks of International Business Machines Corporation.
Intel®and Pentium®are registered trademarks of Intel®Corporation.
Microsoft Windows is a registered trademark of Microsoft Corporation.
Winbond is a registered trademark of Winbond Electronics Corporation.
All other product names or trademarks are properties of their respective owners.

AMB-2020HT(T)-E User’s Manual
3
Packing List
Before installing your Panel PC, please check if the package contains the following items.
nAMB-2020HT(T)-Eseries Panel PC
nCD-ROM
For User’s Manual, Drivers and Utilities
nAccessory
-Metal cover for LCD connector
-CD-ROM and Floppy drive’s cover
-Power cablesfor HDD & FDD
-Screws bag
-50-pin Cable (1M)
-Power cord (1.8 M)
-Wire cable for external power
-Mounting kits
-Waterproof sponge
With the touchscreen option
-Touch pen
If any of these items are missing or damaged, you should contact your distributor or sales
representative immediately.

AMB-2020HT(T)-E User’s Manual
4
Safety & Warranty
1. Read these safety instructions carefully.
2. Keep this user's manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents
for cleaning. Use a damp cloth.
4. For pluggable equipment, the power outlet must be installed near the equipment and must be easily
accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause
damage.
7. The openings on the enclosure are for air convection. Protect the equipment from overheating. DO
NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the equipment to the power
outlet.
9. Position the power cord so that people cannot step on it. Do not place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by
transient over-voltage.
12. Never pour any liquid into an opening. This could cause fire or electrical shock.
13. Never open the equipment. For safety reasons, only qualified service personnel should open the
equipment.
14. If any of the following situations arises, get the equipment checked by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work according to the users
manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED ENVIRONMENT WHERE THE
STORAGE TEMPERATURE IS BELOW -20° C (-4°F) OR ABOVE 60° C (140° F). IT MAY
DAMAGE THE EQUIPMENT.
These products will CE certification No. C071101 and FCC certification No. F071101.

AMB-2020HT(T)-E User’s Manual
5
Contents
Copyright Notice....................................................................................................................................... 2
Packing List............................................................................................................................................... 3
Safety & Warranty..................................................................................................................................... 4
Chapter1 General Information ......................................................................................................... 6
1.1 Introduction............................................................................................................................... 7
1.2 Specifications............................................................................................................................ 8
1.3 Touchscreen (Optional) ........................................................................................................... 10
1.4 LCD Specifications................................................................................................................. 10
1.5 Dimensions...............................................................................................................................11
1.6 Panel Mounting....................................................................................................................... 12
1.7 Waterproof Sponge Position................................................................................................... 13
Chapter 2 Jumper Settings............................................................................................................... 14
2.1 Jumpers on the EI5CM ................................................................................................................. 15
Chapter 3 BIOS Configuration ............................................................................................................ 18
BIOS Introduction............................................................................................................................... 19
BIOS Setup ......................................................................................................................................... 20
Standard CMOS Setup ........................................................................................................................ 21
BIOS Features Setup ........................................................................................................................... 24
Chipset Features Setup........................................................................................................................ 27
Power Management Setup .................................................................................................................. 29

AMB-2020HT(T)-E User’s Manual
6
1
Chapter1 General Information

AMB-2020HT(T)-E User’s Manual
7
1.1 Introduction
The AMB-2020HT(T)-Eseries modular system panel PCs, is the PC-base industrial computer that
specially designed to keep normal operation under harsh environment, which meet the entire requirement
as an industrial man machine interface (MMI).
It is afull-function PC-base system with a 12.1”SVGA (800 x 600) color TFT hi-brightness, long-life
time LCD display, and compact with different control modules. The compact dimensions are ideal for
automation applications when the installation space is critical.
These PCs are characterized by their space saving, there is one free slot for PCI/ ISA AMB-2020HT(T)-E
is heavy-duty steel chassis and optional aluminum front panel, which meets the toughest industrial and
environmental standards. All the controls and connectors are placed on the rear panel; you can connect
the panel PCs to other devices via them.

AMB-2020HT(T)-E User’s Manual
8
1.2 Specifications
Features
AMB-2020HT(T)-E Features (12.1”open frame frontpanel + ACS-2300 Control Box)
n12.1” SVGA color TFTLCD display
nOpen frame architecture with heavy-dutysteel chassis
nAll-in-one SBC, MediaGX 233MHz(optional)
nFour 16C550 RS-232C port, one RS-232C port can be set as RS-422/485 also
nAdjustment-panel on the rear panel
nDisk Driver Space for CD-ROM, FDD and HDD
nDiskOnChip flash disk socket
nResistive touchscreen (optional)
nRotatable Mounting mechanism (optional)
nAluminum front bezel (optional)
Features of EI5CM Single Board Computer
n Processor: Cyrix MediaGXLV MMX™ ENHANCED
n Chipset: Cyrix Cx5530
n Memory: Up to 128MB in SDRAM
n VGA: Support XpressGRAPHICS™ and integrated on the process
n Audio: Support XpressAUDIO and integrated on the processor.
n High speed bi-directional SPP/ECP/EPP parallel port
n Four serial ports (three RS-232, one RS-232/422/485)

AMB-2020HT(T)-E User’s Manual
9
General
nConstruction:Heavy-duty steel chassis
nDisk drive housing:
a 3.5" HDD or
a 2.5”HDD and Slim CD-ROM or
a 2.5”HDD and Slim FDD.
nDimensions: 350(W) x 275(H) x 116mm(D)
nGross Weight: 10.3 Kg
Environmental
nOperating temperature: 0° to 45℃
nVibration: Random Non-operation 2G5 ~ 500Hz
nShock: 15G-peak acceleration (11-msec. duration)
nEMI: FCC/CE Class A
Specifications
AMB-2020HT(T)-E (12.1” open frame front panel + ACS-2300ControlBox)
lConstruction: Heavy-duty steel chassis & openframe front panel.
lCPU: Supports NS Geode GX 233MHz
lMemory: Supports up to 128MB
lDisplay: 12.1” SVGA (800 x 600) TFT color LCD
lLCD/CRT controller:
NS Cx5530 Chipset
UMA supports up to 2.5MB display memory
lNetwork(LAN): Realtek RTL8139B 10/100 Base-T Ethernet controller
lI/O ports:
4 serial ports: 3 x RS-232, 1 x RS-232/422/485 (one is reserved for touchscreen)
1 parallel port (supports ECP/EPP)
1 PS/2 keyboard interface
1 PS/2 mouse interface
lDisk Driver Housing: 3.5”HDD or 2.5”HDD and 3.5”FDD or 2.5”HDD and Slim
CD-ROM
lUSBconnector: Dual USB ports
lMounting: Panel, Rear, Handle mount or Wall mount (Control Box only, optional)
lPowersupply: Universal 70W switching power supply
Power Supply Selection Table
Max. Output Current
Mode Input voltage +5V +12V -12V
Universal/70W 85-265VAC 12A2.5A 0.3A
24VDC/70W 10-30VDC 12A2.5A 0.3A

AMB-2020HT(T)-E User’s Manual
10
1.3 Touchscreen (Optional)
lType:8-wire,analog resistive
lResolution: 1024 x 1024
lLight transmi
lssion: >75%
lLifetime: 1 million activations
lOperating pressure: 50g average for finger, 25g average with non-metal stylus.
lController: RS-232 interface
lOS support: MS DOS, Windows 98/SE, Windows ME, Windows NT 4.0.
1.4 LCD Specifications
Model AMB-2020HT-E
Displaytype TFT color LCD
Size (diagonal) 12.1”
NumberofPixels 800(W) x 600(H)
Dotsize
(mm x mm) 0.3075(W) x 0.3075
Contrast ratio 250
View angle (Horizontal) 120°
View angle (Vertical)90°
Luminance (cd/m2)250
LCDmodel Toshiba
LTM12C289
Operating Temperature 0 ~ 50 °C
Backlight Life-time(Hrs) 50,000

AMB-2020HT(T)-E User’s Manual
11
1.5 Dimensions
330
298
291
Front Bezel Size
366
AMB-2020-E
255
Chassis Cutout Size:333*258 mm
220
174
116
Unit:mm
350 7070 100 100
275
11575 75
30
LCD Cutout Size:248.4*186.9 mm
248.4
186.9
6
6

AMB-2020HT(T)-E User’s Manual
12
1.6 Panel Mounting
These display panels can be placed on a shelf or table, or mounted onto the wall. To mount them onto the
wall, you need the mounting brackets, which you will find in the accessory box. Follows the steps
described below:
1. Slide the display panel onto the wall
2. Tighten the brackets until the display panel is firmly secured to the wall。

AMB-2020HT(T)-E User’s Manual
13
1.7 Waterproof Sponge Position
Insidesponge (thesmallerone):
a. Tear off the protection paper on the self-adhesive side of the inside sponge.
b. Stick the sponge on the recessed area of the Aluminum bezel or customer’s own bezel.
Adhesive Inner Sponge
Outside sponge ：
Press close the outside sponge to the edge of the Panel PC
Front Bezel
Back Side
Outer Sponge
Sponge with adhesive
Front Bezel

AMB-2020HT(T)-E User’s Manual
14
2
Chapter 2Jumper Settings
This chapter provides information on how to use the jumpers and connectors on the EI5CM in order to set up a workable
system. The topics covered are:
Jumpers on the EI5CM………………………………………………………………………………22
Connectors on the EI5CM……………………………………….…………………………………..26

AMB-2020HT(T)-E User’s Manual
15
2.1 Jumpers on the EI5CM
The jumpers on EI5CM allow you to configure your system to your applications. The following table lists
the jumper functions on the board.
Jumper Locations on the EI5CM 15
SW3: CPU Voltage Selector 16
JP10: RS232/422/485 (COM2) Selection 16
JP12: Clear CMOS 17
JP16: DiskOnChip BIOS Expansion Address Select 17
JP14: Reset Button Connector 17
Remarks: The following conventions are used in this section:
off off on on
OPEN SHORT
Jumper Locations on the EI5CM
DISK ON CHIP

AMB-2020HT(T)-E User’s Manual
16
SW3: CPU Voltage Selector
CPU
Voltage SW3 Short Jumpers
CPU
Voltage SW3 ShortJumpers CPU Voltage SW3 Short Jumpers
1.3V 9-10 2.1V 1-2 2.9V 1-2, 7-8
1.4V 3-4, 9-10 2.2V 3-4 3.0V 3-4, 7-8
1.5V 5-6, 9-10 2.3V 1-2, 3-4 3.1V 1-2, 3-4, 7-8
1.6V 3-4, 5-6, 9-10 2.4V 5-6 3.2V 5-6, 7-8
1.7V 7-8, 9-10 2.5V1-2, 5-6 3.3V 1-2, 5-6, 7-8
1.8V 3-4, 7-8, 9-10 2.6V 2-4, 5-6 3.4V 3-4, 5-6, 7-8
1.9V 5-6, 7-8, 9-10 2.7V 3-4, 5-6 3.5V 1-2, 3-4, 5-6, 7-8
2.0V All Open 2.8V 1-2, 3-4, 5-6
JP10: RS232/422/485 (COM2-J6) Selection
COM1 is fixed for RS-232 use only.
COM2 is selectable for RS232, RS-422 and RS-485.
The following table describes the connectors’ jumper settings.
COM2
Function RS-232 RS-422 RS-485
Jumper
Setting
(pin closed) all
jumpers
open
1-2
3-4
5-6
7-8
11-12
15-16
17-18
19-20
23-24
1-2
3-4
5-6
7-8
9-10
11-12
13-14
15-16
17-18
19-20
21-22
Jumper
Illustration

AMB-2020HT(T)-E User’s Manual
17
JP12: Clear CMOS
Follow steps to clear CMOS data.
1. Disconnect the AC power cord.
2. Short JP12 (1-2) and wait for 3 seconds.
3. Short JP12 (2-3) and replace the AC power cord.
4. Turn on the system.
JP16: DiskOnChip BIOS Expansion Address Select
JP16 Address
D0000-D7FFF
D8000-DFFFF (default)
JP14: Reset Button Connector
JP14 is a 2-pin headers for the reset button used to restart the system without turning off the power and
then on again.
JP12 Setting Function
Pin 1-2
Short/Closed
Clear CMOS
Pin 2-3
Short/Closed
Normal

AMB-2020HT(T)-E User’s Manual
18
3
Chapter 3BIOS Configuration
This chapter describes the different settings available in the Award BIOS that comes with the EI5CM
embedded board. The topics covered in this chapter are as follows:

AMB-2020HT(T)-E User’s Manual
19
BIOS Introduction
The Award BIOS (Basic Input/Output System) installed in your system’s ROM supports
Intel/Cyrix/AMD/IDT processors in a standard IBM-AT compatible I/O system. The BIOS provides
critical low-level support for standard devices such as disk drives, parallel port and serial ports. It also
adds virus and password protection, as well as special support for detailed fine-tuning of the chipset
controlling the entire system.

AMB-2020HT(T)-E User’s Manual
20
BIOS Setup
The Award BIOS provides a Setup utility program for specifying the system configurations and settings.
The BIOS ROM of the system stores the Setup utility. When you turn on the computer, the Award BIOS
is immediately activated. Pressing the <Del> key immediately allows you to enter the Setup utility. If you
are a little bit late pressing the <Del> key, POST (Power On Self Test) will continue with its test routines,
thus preventing you from invoking the Setup. If you still wish to enter Setup, restart the system by
pressing the ”Reset” button or simultaneously pressing the <Ctrl>, <Alt> and <Delete> keys. You can
also restart by turning the system Off and back On again. The following message will appear on the
screen:
Press <DEL> to Enter Setup
In general, you press the arrow keys to highlight items, <Enter> to select, the <PgUp> and <PgDn> keys
to change entries, <F1> for help and <Esc> to quit.
When you enter the Setup utility, the Main Menu screen will appear on the screen. The Main Menu
allows you to select from various setup functions and exit choices.
ROM PCI/ISA BIOS
CMOS SETUP UTILITY
AWARD SOFTWARE, INC.
STANDARD CMOS SETUP INTEGRATED PERIPHERALS
BIOS FEATURES SETUP SUPERVISOR PASSWORD
CHIPSET FEATURES SETUP USER PASSWORD
POWER MANAGEMENT SETUP IDE HDD AUTO DETECTION
PNP/PCI CONFIGURATION HDD LOW LEVEL FORMAT
LOAD BIOS DEFAULTS SAVE & EXIT SETUP
LOAD SETUP DEFAULTS EXIT WITHOUT SAVING
ESC : Quit áâàß: Select Item
F10 : Save & Exit Setup (Shift) F2 : Change Color
Time, Date, Hard Disk Type
The section below the setup items of the Main Menu displays the control keys for this menu. At the
bottom of the Main Menu just below the control keys section, there is another section that displays
information about the currently highlighted item in the list.
NOTE:If your computer cannot boot after making and
saving system changes with Setup, the Award BIOS
supports an override to the CMOS settings that
resets your system to its default.
We strongly recommend that you avoid making any
changes to the chipset defaults. These defaults have
been carefully chosen by both Award and your
system manufacturer to provide the absolute
maximum performance and reliability.
