Aaeon ECM-5716 Series User manual

Part No. 2047571600
User’s Manual
ECM-5716 Series
All-in-One Pentium-M Single Board
with LVDS, TMDS,AC97 Audio, IEEE-1394A, PCMCIA,
Dual 10/100Base-Tx Ethernet Interfaces, 4USB 2.0, 2COMs & Intel
Gigabit Ethernet Interface (optional)
3rdEd. –16 November 2004

ECM-5716 Series
Evalue Technology Inc.
FCC STATEMENT
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS SUBJECT TO
THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE
RECEIVED INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION
AGAINTST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

User’s Manual
Evalue Technology Inc.
Copyright Notice
Copyright 2004Evalue Technology Inc., ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in any
form or by any means, electronic or mechanical, for any purpose, without the prior written
permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective
owners.
Disclaimer
Evalue Technology Inc. reserves the right to make changes, without notice, to any product,
including circuits and/or software described or contained in this manual in order to
improve design and/or performance. Evalue Technology assumes no responsibility or
liability for the use of the described product(s) and conveys no license or title under any
patent, copyright or mask work rights to these products, and makes no representations or
warranties that these products are free from patent, copyright, or mask work right
infringement, unless otherwise specified. Applications that are described in this manual
are for illustration purposes only. Evalue Technology Inc. makes no representation or
warranty that such application will be suitable for the specified use without further testing
or modification.
Life Support Policy
Evalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN
LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL
OF Evalue Technology Inc.
As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for
surgical implant into body, or (b) support or sustain life and whose failure to perform,
when properly used in accordance with instructions for use provided in the labelling,
can be reasonably expected to result in significant injury to the user.
2. A critical component is any component of a life support device or system whose failure
to perform can be reasonably expected to cause the failure of the life support device or
system, or to affect its safety or effectiveness.

ECM-5716 Series
Evalue Technology Inc.
A Message to the Customer
Evalue Customer Services
Each and every Evalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Evalue device is destined for the laboratory or the
factory floor, you can be assured that your product will provide the reliability and ease of
operation for which the name Evalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Evalue’s customer services.
To ensure you get the full benefit of our services, please follow the instructions below
carefully.

User’s Manual
Evalue Technology Inc.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you
can easily find answers in your product documentation. These answers are normally a lot
more detailed than the ones we can give over the phone. So please consult this manual
first.
To receive the latest version of the user manual, please visit our Web site at:
http://www.evalue-tech.com/
If you still cannot find the answer, gather all the information or questions that apply to your
problem, and with the product close at hand, call your dealer. Our dealers are well trained
and ready to give you the support you need to get the most from your Evalue’s products.
In fact, most problems reported are minor and are able to be easily solved over the phone.
In addition, free technical support is available from Evalue’s engineers every business
day. We are always ready to give advice on application requirements or specific
information on the installation and operation of any of our products. Please do not
hesitate to call or e-mail us.
Headquarters
Evalue Technology Inc.
7F, 228, Lian-Cheng Road,
Chung-ho City, Taipei,
Taiwan
Tel: [phone]
Fax: [phone]
http://www.evalue-tech.com
E-mail: [e-mail]
Europe Branch Office
Evalue Europe A/S
Nordre Strandvej 119C,
3150 Hellebaek,
Denmark
Tel : [phone]
Fax : [phone]
http://www.evalue-tech.com
E-mail: [e-mail]
China Branch Office
Evalue Technology Shanghai Inc.
Room 909, 9F, Section B, No.900,
Yisan Road, Caohejing Hi-tech Park,
Shanghai 200233, China
Tel : [phone]
Fax : [phone]
http://www.evalue-tech.com
E-mail: [e-mail]
US Branch Office
Evalue Technology Inc.
Suite 210, 200 Tornillo Way,
Tinton Falls, NJ 07712
USA
Tel: [phone]
Fax: [phone]
http://www.evalue-tech.com
E-mail: [e-mail]

ECM-5716 Series
Evalue Technology Inc.
Product Warranty
Evalue warrants to you, the original purchaser, that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Evalue, or which have been subject to
misuse, abuse, accident or improper installation. Evalue assumes no liability under the
terms of this warranty as a consequence of such events. Because of Evalue’s high
quality-control standards and rigorous testing, most of our customers never need to use
our repair service. If an Evalue’s product is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will be billed
according to the cost of replacement materials, service time, and freight. Please consult
your dealer for more details. If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU type
and speed, Evalue’s products model name, hardware & BIOS revision number, other
hardware and software used, etc.) Note anything abnormal and list any on-screen
messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual, product, and
any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return material authorization)
number from your dealer. This allows us to process your good return more quickly.
4. Carefully pack the defective product, a complete Repair and Replacement Order Card
and a photocopy proof of purchase date (such as your sales receipt) in a shippable
container. A product returned without proof of the purchase date is not eligible for
warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid to
your dealer.

User’s Manual
Evalue Technology Inc.
Packing List
Before you begin installing your single board, please make sure that the following
materials have been shipped:
n1 ECM-5716 series All-in-One Pentium-M Computing Module
n1 Quick Installation Guide
n1 CD-ROM contains the followings:
—User’s Manual (this manual in PDF file)
—Ethernet driver and utilities
—VGA drivers and utilities
—Audio drivers and utilities
nCable set includes the followings:
—1 ATA100 IDE cable (40-pin, pitch 2.54mm)
—1 FDD cable (34-pin, pitch 2.54mm)
—1 Daughter board supports Audio / 2USB (P/N: 9697000105)
—1 Flat cable for audio (16-pin, pitch 2.0mm/16-pin, 2.54mm)
—1 Flat cable for USB 2.0 (10-pin, pitch 2.54mm)
—1 Bracket with 1 serial & 1 printer cable (10-pin 2.54mm/26-pin 2.54mm)
—1 PS/2 KB/Mouse Y cable
If any of these items are missing or damaged, please contact your distributor or sales
representative immediately.

ECM-5716 Series
Evalue Technology Inc.
1. MANUAL OBJECTIVES ............................................................................................ 1
2. INTRODUCTION........................................................................................................ 2
2.1 System Overview................................................................................................... 2
2.2 System Specifications.......................................................................................... 3
2.3 Architecture Overview .......................................................................................... 6
2.3.1 855GME and 82801DB............................................................................................... 7
2.3.2 DRAM Interface........................................................................................................... 9
2.3.3 Chrontel CH7301 DVI Transmitter............................................................................... 9
2.3.4 PCI Interface............................................................................................................... 9
2.3.5 IDE Interface (Bus Master Capability and Synchronous DMA Mode).......................... 9
2.3.6 USB 2.0..................................................................................................................... 10
2.3.7 Ethernet .................................................................................................................... 11
2.3.8 Winbond W83627HF ................................................................................................ 13
2.3.9 RICOH R5C551 IEEE1394A Host & PCMCIA Controller .......................................... 13
2.3.10 Compact Flash Interface........................................................................................... 14
3. HARDWARE CONFIGURATION............................................................................. 15
3.1 Installation Procedure......................................................................................... 15
3.2 Safety Precautions.............................................................................................. 15
3.2.1 Warning! ................................................................................................................... 15
3.2.2 Caution!..................................................................................................................... 15
3.3 Socket 479 Processor......................................................................................... 16
3.3.1 Installing Pentium M CPU.......................................................................................... 16
3.3.2 Removing CPU ......................................................................................................... 16
3.4 Main Memory ....................................................................................................... 16
3.5 Jumper & Connector........................................................................................... 17
3.5.1 Jumper & Connector Layout ..................................................................................... 17
3.5.2 Jumper & Connector List........................................................................................... 18
Connectors ................................................................................................................... 19
3.6 Setting Jumpers.................................................................................................. 20
3.6.1 Clear CMOS (JBAT).................................................................................................. 21
3.6.2 COM2 RS-232/422/485 Select (JP1, JP2)................................................................ 21
3.6.3 COM1 Pin 9 Signal Select (JP3)............................................................................... 21
3.7 Connector Definitions......................................................................................... 22
3.7.1 ATX Power Connector (ATX).................................................................................... 22
3.7.2 Serial Port 1 Connector (COM1) ............................................................................... 22
3.7.3 Signal Description –Serial Port 1 Connector (COM1)............................................... 23
3.7.4 CPU Fan Connector (FAN1) ..................................................................................... 23
3.7.5 Signal Description –CPU Fan Connector................................................................. 23

User’s Manual
Evalue Technology Inc.
3.7.6 Floppy Connector (FLP)............................................................................................ 24
3.7.7 Signal Description –Floppy Disk Connector (FLP) ................................................... 25
3.7.8 Primary IDE Connector (IDE_1)................................................................................ 26
3.7.9 Secondary IDE Connector (IDE_2) ........................................................................... 27
3.7.10 Signal Description –IDE Device Connector (IDE_1 / IDE_2).................................... 28
3.7.11 Audio Connector (JAUDIO)....................................................................................... 29
3.7.12 Signal Description –Audio Connector (JAUDIO) ...................................................... 29
3.7.13 LCD Inverter Connector (JBKL)................................................................................. 29
3.7.14 Signal Description –LCD Inverter Connector (JBKL)................................................ 29
3.7.15 Serial Port 2 Connector (JCOM2).............................................................................. 30
3.7.16 Signal Description –Serial Port 2 Connector in RS-232 Mode (JCOM2).................. 30
3.7.17 Pin Header Serial Port 2 Connector in RS-422 Mode (JCOM2)................................ 30
3.7.18 Signal Description –Serial Port 2 in RS-422 Mode (JCOM2).................................... 30
3.7.19 Pin Header Serial Port 2 Connector in RS-485 Mode (JCOM2)................................ 31
3.7.20 Signal Description –Serial Port 2 in RS-485 Mode (JCOM2).................................... 31
3.7.21 Front Panel Connector (JFP) .................................................................................... 31
3.7.22 IrDA Connector (JIR)................................................................................................. 32
3.7.23 Signal Description –IR Connector (JIR).................................................................... 32
3.7.24 Keyboard and PS/2 mouse connector (JKBMS) ....................................................... 32
3.7.25 Signal Description –Keyboard and PS/2 Mouse Connector (JKBMS)...................... 32
3.7.26 Miscellaneous Setting Connector (JMISC)................................................................ 33
3.7.27 Signal Description –JMISC Connector..................................................................... 33
3.7.28 LVDS Connector (JLVDS)......................................................................................... 34
3.7.29 Signal Description –LVDS Connector (JLVDS)..........................錯誤! 尚未定義書籤。
3.7.30 TMDS Connector (JTMDS)........................................................................................ 35
3.7.31 Signal Description –TMDS Connector (JTMDS)....................................................... 35
3.7.32 USB Connector (JUSB)............................................................................................. 36
3.7.33 Signal Description –USB Connector (JUSB)............................................................ 36
3.7.34 PS/2 Keyboard & Mouse Connector (KB_MS).......................................................... 36
3.7.35 Signal Description –PS/2 Keyboard & Mouse Connector......................................... 36
3.7.36 10/100 BASE-Tx Ethernet Connector (LAN1/LAN2)................................................. 37
3.7.37 Signal Description –10/100Base-Tx Ethernet Connector......................................... 37
3.7.38 10/100/1000 BASE-Tx Ethernet Connector (LAN2: 82540EM Optional)................... 37
3.7.39 Signal Description –10/100/1000Base-Tx Ethernet Connector................................ 38
3.7.40 Parallel Port Connector (LPT)................................................................................... 38
3.7.41 DB25 Parallel Port Connector (LPT) ......................................................................... 39
3.7.42 Signal Description –Parallel Port (LPT).................................................................... 40
3.7.43 System Fan Connector 1 (S_FAN1).......................................................................... 40
3.7.44 System Fan Connector 2 (S_FAN2).......................................................................... 40
3.7.45 Signal Description –System Fan Connector............................................................. 40
3.7.46VGA Connector (VGA).............................................................................................. 41
3.7.47 Signal Description –VGA Connector (VGA) ............................................................. 41
3.7.48 IEEE1394 Port Connector (J1394/1394)................................................................... 41
3.7.49 Signal Description –IEEE1394 Port Connector (J1394/1394).................................. 41
4. AWARD BIOS SETUP............................................................................................. 42
4.1 Starting Setup...................................................................................................... 42
4.2 Using Setup ......................................................................................................... 43
4.2.1 Navigating Through The Menu Bar........................................................................... 43
4.2.2 To Display a Sub Menu............................................................................................. 43
4.3 Getting Help......................................................................................................... 44

ECM-5716 Series
Evalue Technology Inc.
4.4 In Case of Problems............................................................................................ 44
4.5 Main Menu............................................................................................................ 44
4.5.1 Setup Items............................................................................................................... 44
4.5.2 Standard CMOS Setup ............................................................................................. 46
4.5.3 Advanced BIOS Features ......................................................................................... 49
4.5.4 Advanced Chipset Features...................................................................................... 52
4.5.5 Integrated Peripherals............................................................................................... 54
4.5.6 Power Management Setup........................................................................................ 57
4.5.7 PnP/PCI Configuration Setup.................................................................................... 60
4.5.8 PC Health Status....................................................................................................... 62
4.5.9 Frequency / Voltage Control ..................................................................................... 62
4.5.10 Load Fail-Safe Defaults ............................................................................................ 63
4.5.11 Load Optimized Defaults........................................................................................... 63
4.5.12 Supervisor / User Password Setting.......................................................................... 64
4.5.13 Exit Selecting ............................................................................................................ 65
5.DRIVER INSTALLATION......................................................................................... 67
5.1 Driver Installation for Ethernet Adapter ............................................................ 67
5.1.1 Windows 9x............................................................................................................... 67
5.1.2 Windows 2000 , XP Ethernet Installation.................................................................. 74
5.2 Driver Installation for Display Adapter.............................................................. 83
5.2.1 Windows 9x............................................................................................................... 83
5.2.2 Windows 2000 or Windows XP Display Installation.................................................. 86
5.3 Driver Installation for Audio Adapter................................................................. 89
5.3.1 Windows 9x, Windows 2000, Windows XP............................................................... 89
5.4 Driver Installation for Intel 855 Chipset............................................................. 91
6. POST MESSAGES .................................................................................................. 93
6.1 POST Beep........................................................................................................... 93
6.2 Error Messages ................................................................................................... 93
6.2.1 CMOS BATTERY HAS FAILED ................................................................................ 93
6.2.2 CMOS CHECKSUM ERROR .................................................................................... 93
6.2.3 DISK BOOT FAILURE, INSERT SYSTEM DISK AND PRESS ENTER..................... 93
6.2.4 DISKETTE DRIVES OR TYPES MISMATCH ERROR -RUN SETUP....................... 93
6.2.5 DISPLAY SWITCH IS SET INCORRECTLY ............................................................. 94
6.2.6 DISPLAY TYPE HAS CHANGED SINCE LAST BOOT............................................. 94
6.2.7 EISA Configuration Checksum Error PLEASE RUN EISA CONFIGURATION UTILITY94
6.2.8 EISA Configuration Is Not Complete PLEASE RUN EISA CONFIGURATION UTILITY94
6.2.9 ERROR ENCOUNTERED INITIALIZING HARD DRIVE............................................ 94
6.2.10 ERROR INITIALIZING HARD DISK CONTROLLER.................................................. 94
6.2.11 FLOPPY DISK CNTRLR ERROR OR NO CNTRLR PRESENT................................ 94
6.2.12 Invalid EISA Configuration PLEASE RUN EISA CONFIGURATION UTILITY........... 95
6.2.13 KEYBOARD ERROR OR NO KEYBOARD PRESENT ............................................. 95
6.2.14 Memory Address Error at ... ...................................................................................... 95
6.2.15 Memory parity Error at .............................................................................................. 95
6.2.16 MEMORY SIZE HAS CHANGED SINCE LAST BOOT.............................................. 95
6.2.17 Memory Verify Error at ............................................................................................. 95

User’s Manual
Evalue Technology Inc.
6.2.18 OFFENDING ADDRESS NOT FOUND..................................................................... 95
6.2.19 OFFENDING SEGMENT:.......................................................................................... 95
6.2.20 PRESS A KEY TO REBOOT .................................................................................... 96
6.2.21 PRESS F1 TO DISABLE NMI, F2 TO REBOOT ....................................................... 96
6.2.22 RAM PARITY ERROR -CHECKING FOR SEGMENT ............................................. 96
6.2.23 Should Be Empty But EISA Board Found PLEASE RUN EISA CONFIGURATION
UTILITY.................................................................................................................................. 96
6.2.24 Should Have EISA Board But Not Found PLEASE RUN EISA CONFIGURATION
UTILITY.................................................................................................................................. 96
6.2.25 Slot Not Empty.......................................................................................................... 96
6.2.26 SYSTEM HALTED, (CTRL-ALT-DEL) TO REBOOT ................................................ 96
6.2.27 Wrong Board In Slot PLEASE RUN EISA CONFIGURATION UTILITY .................... 97
6.2.28 FLOPPY DISK(S) fail (80) →Unable to reset floppy subsystem............................... 97
6.2.29 FLOPPY DISK(S) fail (40) →Floppy Type dismatch................................................. 97
6.2.30 Hard Disk(s) fail (80) →HDD reset failed.............................................................. 97
6.2.31 Hard Disk(s) fail (40) →HDD controller diagnostics failed.................................... 97
6.2.32 Hard Disk(s) fail (20) →HDD initialization error. ................................................... 97
6.2.33 Hard Disk(s) fail (10) →Unable to recalibrate fixed disk....................................... 97
6.2.34 Hard Disk(s) fail (08) →Sector Verify failed.......................................................... 97
6.2.35 Keyboard is locked out -Unlock the key................................................................... 97
6.2.36 Keyboard error or no keyboard present. ................................................................... 97
6.2.37 Manufacturing POST loop......................................................................................... 97
6.2.38 BIOS ROM checksum error -System halted............................................................. 97
6.2.39 Memory test fail......................................................................................................... 97
6. MEASUREMENT DRAWING................................................................................... 98
APPENDIX A: BIOS REVISIONS ................................................................................... 100
APPENDIX B: SYSTEM RESOURCES.......................................................................... 101
Memory Map........................................................................................................................ 101
I/O –Map............................................................................................................................. 102
Interrupt Usage.................................................................................................................... 104
DMA-channel Usage............................................................................................................ 105
APPENDIX C: AWARD BIOS POST MESSAGES ......................................................... 106
POST Beep ................................................................................................................. 106
Error Messages .......................................................................................................... 106
CMOS BATTERY HAS FAILED........................................................................................... 106
CMOS CHECKSUM ERROR ............................................................................................... 106
DISK BOOT FAILURE, INSERT SYSTEM DISK AND PRESS ENTER ............................... 106
DISKETTE DRIVES OR TYPES MISMATCH ERROR -RUN SETUP ................................. 106
DISPLAY SWITCH IS SET INCORRECTLY........................................................................ 107
DISPLAY TYPE HAS CHANGED SINCE LAST BOOT........................................................ 107
EISA Configuration Checksum Error PLEASE RUN EISA CONFIGURATION UTILITY....... 107
EISA Configuration Is Not Complete PLEASE RUN EISA CONFIGURATION UTILITY....... 107
ERROR ENCOUNTERED INITIALIZING HARD DRIVE....................................................... 107
ERROR INITIALIZING HARD DISK CONTROLLER ............................................................ 107
FLOPPY DISK CNTRLR ERROR OR NO CNTRLR PRESENT........................................... 107
Invalid EISA Configuration PLEASE RUN EISA CONFIGURATION UTILITY...................... 108
KEYBOARD ERROR OR NO KEYBOARD PRESENT........................................................ 108

ECM-5716 Series
Evalue Technology Inc.
Memory Address Error at .................................................................................................... 108
Memory parity Error at ......................................................................................................... 108
MEMORY SIZE HAS CHANGED SINCE LAST BOOT ........................................................ 108
Memory Verify Error at ........................................................................................................ 108
OFFENDING ADDRESS NOT FOUND................................................................................ 108
OFFENDING SEGMENT:..................................................................................................... 108
PRESS A KEY TO REBOOT ............................................................................................... 109
PRESS F1 TO DISABLE NMI, F2 TO REBOOT.................................................................. 109
RAM PARITY ERROR -CHECKING FOR SEGMENT ........................................................ 109
Should Be Empty But EISA Board Found PLEASE RUN EISA CONFIGURATION UTILITY109
Should Have EISA Board But Not Found PLEASE RUN EISA CONFIGURATION UTILITY109
Slot Not Empty..................................................................................................................... 109
SYSTEM HALTED, (CTRL-ALT-DEL) TO REBOOT ........................................................... 109
Wrong Board In Slot PLEASE RUN EISA CONFIGURATION UTILITY............................... 110
FLOPPY DISK(S) fail (80) →Unable to reset floppy subsystem.......................................... 110
FLOPPY DISK(S) fail (40) →Floppy Type dismatch............................................................ 110
Hard Disk(s) fail (80) →HDD reset failed......................................................................... 110
Hard Disk(s) fail (40) →HDD controller diagnostics failed............................................... 110
Hard Disk(s) fail (20) →HDD initialization error. .............................................................. 110
Hard Disk(s) fail (10) →Unable to recalibrate fixed disk.................................................. 110
Hard Disk(s) fail (08) →Sector Verify failed..................................................................... 110
Keyboard is locked out -Unlock the key.............................................................................. 110
Keyboard error or no keyboard present............................................................................... 110
Manufacturing POST loop.................................................................................................... 110
BIOS ROM checksum error -System halted........................................................................ 110
Memory test fail.................................................................................................................... 110
POST CODES................................................................................................................. 111
APPENDIX E: AUDIO / USB DAUGHTER BOARD USER’S GUIDE............................. 117
Jumper & Connector Layout......................................................... 錯誤! 尚未定義書籤。
Jumper & Connector List ..............................................................錯誤! 尚未定義書籤。
Measurement Drawing................................................................... 錯誤! 尚未定義書籤。

User’s Manual
Evalue Technology Inc.
Document Amendment History
Revision
Date By Comment
1st Feb. 2004.
Stephen Tsao
Initial Release
2nd June, 2004
Stephen Tsao
Modify
1. JCOM2 RS422/485 pin definition
2. JTMDS pin 19, 20
3rd Nov. 2004 Leo Chen Modify
1. TMDS Connector pin signal
2. Jumper & Connector layout list
3. USB Connector pin define
4. Add in 3.3 Pentium M processor
5. Headquarters address updated.
6. US branch added.
7. Latest BIOS deleted.
8. APPENDIX F: AUDIO / USB DAUGHTER
BOARD USER’S MANUAL updated.

ECM-5716 Series
ECM-5716 Series User’s Manual 1
1. Manual Objectives
This manual describes in detail the Evalue Technology ECM-5716 series Single Board.
We have tried to include as much information as possible but we have not duplicated
information that is provided in the standard IBM Technical References, unless it proved to
be necessary to aid in the understanding of this board.
We strongly recommend that you study this manual carefully before attempting to
interface with ECM-5716 series or change the standard configurations. Whilst all the
necessary information is available in this manual we would recommend that unless you
are confident, you contact your supplier for guidance.
Please be aware that it is possible to create configurations within the CMOS RAM that
make booting impossible. If this should happen, clear the CMOS settings, (see the
description of the Jumper Settings for details).
If you have any suggestions or find any errors concerning this manual and want to inform
us of these, please contact our Customer Service department with the relevant details.

User’s Manual
2ECM-5716 Series User’s Manual
2. Introduction
2.1 System Overview
The ECM-5716 series is a compact 5.25” CD-ROM size Single Board Computer that
equips with Intel Banias Chipset, LCD Interfaces, AC97 Audio, dual 10/100Base-Tx
Ethernet, four USB2.0interfaces, dual IEEE1394 interfaces, PCMCIA, and Compact Flash.
The ECM-5716 series support Intel Pentium M series CPU, which are powerful in
performance and low power in system consumption. Its display is bolstered up with the
chipset Intel 855GME Integrated graphics which supports LVDS flat panel, DVO, and CRT
interfaces. This makes this PC engine a perfect solution for Retail / Financial Transaction
Terminals, and high-end multimedia POS / KIOSK Terminals.
Furthermore, the ECM-5716 series is outstanding in a 5.25" form factors designed with
Intel 82801DB ICH4 built-in and 82551ER or Intel 82551QM PCI-bus Ethernet
10/100Base-Tx Ethernet controllers (optional an Intel 82540EM PCI-bus Ethernet
controller onboard support Gigabit Ethernet function) making it the ideal solution for
popular networking devices like Gateway, Router, Thin Server, Firewall and E-Box. In
addition, the on board IEEE1394 and 4USB2.0interfaces make the ECM-5716 series
also ideal for demanding high-end Entertainment Devices that require high integration
multimedia Single Board Computer.
Other impressive features include a built-in 40-pin TFT LCD interface (LVDS), a TMDS
interface, the AC97 Audio, a Compact Flash socket for type I/ II Compact Flash storage
card, one parallel port, one PCMCIA socket, and one 184-pin DDR SDRAM DIMM sockets
allowing for up to 1GB of DDR SDRAM to be installed, and a PCI slot for future expansion.

ECM-5716 Series
ECM-5716 Series User’s Manual 3
2.2 System Specifications
General Functions
•CPU: Supports Intel Pentium-M series processors
•BIOS: Award 512 KB FWH BIOS
•Chipset: Intel 855GME + Intel 82801DB (ICH4)
•I/O Chipset: Winbond W83627HF-AW
•Memory: Onboard one DDR SDRAM socket supports up to 1 Gbytes DDR
333/266/200 SDRAM
•Enhanced IDE: Supports up to four IDE devices. Supports Ultra DMA/100 mode
with data transfer rate up to 100MB/sec. (Primary: 20 x 2 box header; Secondary:
22 x 2, pitch 2.0mm box header onboard for DiskOnModule)
•FDD Interface: Supports up to two floppy disk drives, 5.25" (360KB and 1.2MB)
and /or 3.5" (720KB, 1.44MB, and 2.88MB). Supports Mode-3 FDD
•Parallel Port: An Internal header for bi-directional parallel port x 1. Supports SPP,
ECP, and EPP modes
•Serial Port: Supports Two RS-232 serial ports. Ports can be configured as COM1,
COM2, COM3, COM4, or disabled individually. (16C550 equivalent) (COM1 with D-
Sub 9, COM2 with 5 x 2, pitch 2.54 box header) COM2 can be set as RS-
232/422/485.
•IR Interface: Supports one IrDA Tx/Rx header
•KB/Mouse Connector: External mini-DIN PS2 Keyboard/Mouse connector x 1,
Internal KB/Mouse connector 4X2 header pitch 2.54mm
•USB 2.0 Connectors: Two external USB 2.0 connectors. One 5 x 2, pitch 2.54mm
header supports additional dual USB 2.0
•Watchdog Timer: Can generate a system reset, IRQ10/11 or NMI. Software
selectable time out interval (1 sec. ~ 255 min., 1 sec. or 1 min. /step)
•Power Management: Supports ATX power supply. Supports PC97, LAN wake up
and modem ring-in functions. I/O peripheral devices support power saving and
doze/standby/suspend modes. ACPI 2.0 & APM 1.2 compliant.

User’s Manual
4ECM-5716 Series User’s Manual
IEEE1394 Interface
•Chipset: RICOH R5C551
•IEEE1394 Interface: Integrated 400 Mbit 2-Port PHY supports 2 IEEE1394A Ports
Flat Panel/CRT Interface
•Chipset: Intel 855 Chipset Graphics Memory Controller Hub (GMCH) integrated
AGP high performance 256-bit GUI, 3D engine
•Display Memory: Programmable frame buffer size up to 64MBytes
•Display Type: Simultaneously supports CRT and TFT displays
•Resolution: CRT displays support up to 1600 x 1200 @ 85-Hz
PanelLink Interface
•Chipset: Chrontel CH7301A DVI / TV output device
•Display Type: DVI display at a pixel rate of up to 165MHz, supporting UXGA
resolution displays.
LVDS Interface
•Chipset: Intel 855GME Chipset
•Display Memory: Programmable frame buffer size up to 64MBytes
•Display Type: 24-bit to 48-bit flat panel displays
•Scalable bandwidth:Single or dual channel LVDS panel support up to UXGA
panel solution with frequency range from 25 MHz to 112 MHz per channel.
Audio Interface
•Chipset: Intel ICH4integrated Audio controller with AC97 interface
•AC97 Codec: VIA VT1616
•Audio Controller: AC97 ver. 2.3 compliant interface. Supports Audio Out
(5.1channel playback)

ECM-5716 Series
ECM-5716 Series User’s Manual 5
Ethernet Interface
•Chipset: Intel 82801DB (ICH4) built-in and 82551ER PCI-bus Ethernet controller
onboard support dual Ethernet function
•Ethernet Interface: PCI 100/10 Mbps, IEEE 802.3U compatible
Gigabit Ethernet Interface (Optional)
•Chipset: Intel 82540EM PCI-bus Ethernet controller onboard support Gigabit
Ethernet function
•Ethernet Interface: PCI 1000/100/10 Mbps, IEEE 802.3x compatible.
SSD Interface
One CF socket supports Type I/II Compact Flash memory devices
Expansion Interface
•PCI Slot: One 32-bit PCI slot onboard
Mechanical and Environmental
•Power Supply Voltage: ATX type, +5V and +12V
•Operating Temperature: 32 to 140°F (0 to 60°C)
•Board Size: 8"(L) x 5.75"(W) (203mm x 146mm)
•Weight: 0.5 Kg

User’s Manual
6ECM-5716 Series User’s Manual
2.3 Architecture Overview
The following block diagram shows the architecture and main components of ECM-5716
series.
The following sections provide detail information about the functions provided onboard.

ECM-5716 Series
ECM-5716 Series User’s Manual 7
2.3.1 855GME and 82801DB
The Intel 855GM/855GME GMCH components provide the processor interface, DDR
SDRAM interface, display interface, and Hub interface. The Intel 855GME also has an
option for AGP external graphics port, in addition to integrated graphics support for added
board flexibility options.
The Intel 855GM GMCH is in a 732-pin Micro-FCBGA package and contains the following
functionality listed below:
AGTL+hostbussupporting 32•-bit host addressing with Enhanced Intel SpeedStep
technology support
SupportsasinglechannelofDDR SDRAMmemory•
SystemmemorysupportsDDR200/266 MHz(SSTL_2)DDR SDRAM•
Integrated graphics capabilities:DisplayCore•frequency at 133 MHz or 200 MHz
RenderCorefrequency at100 MHz,133 MHz,and 200 MHz•
•Provides supports four display ports: one progressive scan analog monitor, dual
channel LVDS interface and two DVO port.
The Intel 855GME GMCH is in a 732-pin Micro-FCBGA package and contains all features
listed above and the additional functionality list below:
DisplayCorefrequency at133 MHz,200 MHz,or250 MHz•
RenderCorefrequency at100 MHz,133 MHz,166 MHz,200 MHz,or250 MHz•
Systemmemorysupports2•00/266/333-MHz (SSTL_2) DDR SDRAM.
Enhanced PowerManagementGraphics features•
The GMCH IGD provides a highly integrated graphics accelerator delivering high
performance 2D, 3D, and video capabilities. With its interfaces to UMA using a DVMT
configuration, an analog display, a LVDS port, and two digital display ports (e.g. flat
panel), the GMCH can provide a complete graphics solution.
The GMCH also provides 2D hardware acceleration for block transfers of data (BLTs).
The BLT engine provides the ability to copy a source block of data to a destination and
perform raster operations (e.g., ROP1, ROP2, and ROP3) on the data using a pattern,
and/or another destination. Performing these common tasks in hardware reduces CPU
load, and thus improves performance. High bandwidth access to data is provided through
the system memory interface. The GMCH uses Tiling architecture to increase system
memory efficiency and thus maximize effective rendering bandwidth. The Intel
855GM/855GME GMCH improves 3D performance and quality with 3D Zone rendering
technology. The Intel 855GME GMCH also supports Video Mixer rendering, and Bi-Cubic
filtering.
The Intel 855GM/855GME GMCH has four display ports, one analog and three digital.
With these interfaces, the GMCH can provide support for a progressive scan analog
monitor, a dedicated dual channel LVDS LCD panel, and two DVO devices. Each port can
transmit data according to one or more protocols. The data that is sent out the display port
is selected from one of the two possible sources, Pipe A or Pipe B.
