Aaeon MB-662 User manual

MB-662
LPX- size Intel FC-370 Pentium III
CPU Card with LCD, LAN, Audio,
4 COMs & SSD.

Copyright Notice
This document is copyrighted, 2000. All rights are reserved. The
originalmanufacturerreservestherighttomakeimprovementsto
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permissionoftheoriginalmanufacturer.Informationprovidedin
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, nor for
any infringements upon the rights of third parties which may result
fromitsuse.
The material in this document is for information only and is subject
to change without notice. While resonable efforts have been made
in the preparation of this docement to assure its accuracy, AAEON,
assumes no liabilities resulting from errors or omissions in this
docuement, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.
Acknowledgements
AMDis atrademark ofAdvanced MicroDevices, Inc.
AMIisatrademarkof American Megatrends, Inc.
AwardisatrademarkofAwardSoftwareInternational,Inc.
IBM,PC/AT,PS/2,andVGAaretrademarksofInternational
Business Machines Corporation.
IntelandPentiumIIIaretrademarksofIntelCorporation.
Microsoft Windows®is a registered trademark of Microsoft Corp.
SMCisatrademarkofStandardMicrosystems Corporation.
RTLisatrademarkofRealtekSemi-ConductorCo.,Ltd.
PartNo. 2047662000 MB-662 A0.1 1st. Edition
Printedin Taiwan Dec., 2000

A Message to the Customer
AAEON Customer Services
Each and every AAEON product is built to the most exacting
specifications to ensure reliable performance in the harsh and
demanding conditions typical of industrial environments. Whether
your new AAEON equipment is destined for the laboratory or the
factory floor, you can be assured that your product will provide the
reliabilityand ease ofoperation forwhichthe nameAAEONhas
come to be known.
Your satisfaction is our primary concern. Here is a guide to
AAEON's customer services. To ensure you get the full benefit of
our services, please follow the instructions below carefully.
Technical Support
Wewant you to getthemaximumperformancefrom your products.
Soif yourun intotechnical difficulties,we are here to help. For the
most frequently asked questions, you can easily find answers in
your product documentation. These answers are normally more
detailed than the ones we can give over the phone.
So please consult this manual first. If you still cannot find the
answer, gather all the information or questions that apply to your
problem, and with the product close at hand, call your dealer. Our
dealers are well trained and ready to give you the support you need
to get the most from your AAEON products. In fact, most problems
reported are minor and are able to be easily solved over the phone.
Inaddition,freetechnicalsupportisavailablefromAAEON
engineers every business day. We are always ready to give advice
onapplicationrequirementsorspecificinformationontheinstalla-
tion and operation of any of our products.

Product Warranty
AAEON warrants to you, the original purchaser, that each of its
productswillbefreefromdefectsinmaterialsandworkmanshipfor
two years from the date of shipment.
This warranty does not apply to any products which have been
repaired or altered by persons other than repair personnel autho-
rized by AAEON, or which have been subject to misuse, abuse,
accidentorimproperinstallation.AAEONassumesnoliability
under the terms of this warranty as a consequence of such events.
Because of AAEON's high quality-control standards and rigorous
testing, most of our customers never need to use our repair service.
IfanAAEON product isdefective,itwillberepairedorreplacedat
no charge during the warranty period. For out-of-warranty repairs,
youwillbebilledaccording to the costofreplacementmaterials,
servicetime,andfreight. Please consultyourdealerformore
details.
If you think you have a defective product, follow these steps:
1. Collectalltheinformationabouttheproblemencountered.(For
example, CPU type and speed, AAEON products used, other
hardware and software used, etc.) Note anything abnormal and
list any on-screen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your
manual,product,andanyhelpfulinformationreadilyavailable.
3. If your product is diagnosed as defective, obtain an RMA
(returnmaterialauthorization)numberfromyourdealer.This
allows us to process your return more quickly.
4. Carefullypackthedefectiveproduct,afully-completedRepair
and Replacement Order Card and a photocopy proof of pur-
chase date (such as your sales receipt) in a shippable container.
A product returned without proof of the purchase date is not
eligibleforwarrantyservice.
5. Write the RMA number visibly on the outside of the package
and ship it prepaid to your dealer.

C&Tisatrademark of ChipsandTechnologies,Inc.
UMCisatrademarkofUnitedMicroelectronicsCorporation.
ITEisatrademarkofIntegratedTechnologyExpress,Inc.
SiSisatrademarkofSiliconIntegratedSystemsCorp.
VIAisatrademarkofVIATechnology,Inc.
IntelisatrademarkofIntel
All other product names or trademarks are properties of their
respective owners.
Packing list
Before you begin installing your card, please make sure that the
followingmaterialshavebeenshipped:
• 1MB-662LPX-sizeSingleBoardComputerCard
• 1QuickInstallationGuide
• 1Support CDcontains the followings:
--User'sManual(thismanualinPDFfile)
--Ethernet,Audio,VGAdriversandutilities
• 1harddiskdrive(IDE)interfacecable(44-pin,pitch2.0mm)
• 1floppydiskdriveinterfacecable(34-pin,pitch2.0mm)
• 1 IDEcable(40-pin,pitch2.54mm)
• 1parallelport(26-25-pin,pitch2.0mm)andserialport(10-9pin,
pitch2.0mm)adapterkit.
• 1 bag of screws and miscellaneous parts
If any of these items are missing or damaged, contact your distribu-
tororsalesrepresentativeimmediately.

Notice
DearCustomer,
Thank you for purchasing the MB-662 board. This user's
manual is designed to help you to get the most out of the MB-662,
please read it thoroughly before you install and use the board. The
product that you have purchased comes with an two-year limited
warranty, but AAEON will not be responsible for misuse of the
product. Therefore, we strongly urge you to first read the manual
before using the product.
To receive the lastest version of the user manual, please visit our
Web site at:
http://www.aaeon.com

Contents
Chapter 1: General Information............................................. 1
Introduction ........................................................................... 2
Features.................................................................................. 3
Specifications ......................................................................... 4
Board layout........................................................................... 7
Board dimensions ................................................................. 8
Chapter 2: Installation .............................................................. 9
Setting Jumpers .................................................................. 10
CPU installing and upgrading.........................................11
Installing DRAM (DIMMs) .............................................. 13
Locating Jumpers and Connectors ..........................................14
List of Jumpers........................................................................15
List of Connectors...................................................................16
Clear CMOS (JP1) ............................................................. 17
LCD Panel Voltage Setting (JP6).............................................17
LCD Clock Signal Selection (JP7) ..........................................18
Ethernet Tx/Rx/Link LED Connector (JP8).................. 18
COM4 RS-232/422/485 Selection (JP10) ....................... 19
Speaker/Buzzer (JP12)...................................................... 19
System Status LED Pin Header (JP13) ...........................20
DOC Address Selection (JP15)........................................ 21
IR Touch Screen Power Pin Header (JP16) ................... 22
100/66 MHz Frequency Selection (JP17) ...............................22
Keyboard Lock (JP18)............................................................22
ATX Power Connector (CN2) ........................................... 23
Display Connectors (CN3,12) ........................................... 23
VGA Display Connector (CN3)..............................................24
LCD Display Connector (CN12) ............................................25
USB Connector (CN6) ....................................................... 26
Floppy Drive Connector (CN7, 9) .................................... 27

IrDA Connector (CN8) ...................................................... 28
Floppy Drive Connector (CN9) ........................................29
Parallel Port 1 & 2 (CN10, 21).......................................... 29
Keyboard and Mouse Connector (CN11) ....................... 31
CPU and System Fan Power Connector (CN13, 24) .....31
RJ-45 Ethernet Connector (CN14).................................. 32
IDE hard drive connector (CN16 & 17) .................................33
Serial Port COM1 (CN22)................................................. 36
LCD Inverter Backlight Power Connector (CN25)................36
Digital I/O Connector (CN29).................................................37
Serial Port COM2 Connectors(CN30) ............................ 37
Serial Port COM3 Connectors(CN32)...........................38
Serial Port COM4 Connectors(CN31)..........................38
Joystick/MIDI Port (CN33) .............................................. 39
Audio Connector for CD_In (CN34)..............................39
Phone Jack for Line_Out (CN35)..................................40
Phone Jack for MIC (CN36)..........................................40
Phone Jack for Line_In (CN37).....................................41
Chapter 3: Award BIOS Setup........................................... . 42
Starting setup..................................................................43
Setup keys.......................................................................44
Getting help ......................................................................... 45
In case of problem...................................................................45
Main setup menu ................................................................ 46
Standard CMOS setup ....................................................... 48
BIOS features setup........................................................... 54
CHIPSET features setup ................................................... 59
Power management setup.................................................. 64
PNP/PCI congfiguration setup .......................................... 69
Load BIOS defaults/Load setup defaults ........................ 71
Integrated peripherals setup............................................. 72

Supervisor/User password setting ................................... 76
IDE HDD auto detection ................................................... 78
Save & exit setup................................................................ 79
Chapter 4: Flat Panel/CRT controller Display Drivers
and Utilities............................................................ 80
Software drives .................................................................... 81
Hardware configuration ..........................................................81
Necessary prerequisites ..........................................................82
Before you begin .....................................................................82
Windows 95 .......................................................................... 83
Driverinstallation ....................................................................83
Windows 3.1......................................................................... 91
OS/2.................................................................................92
Windows 3.51..................................................................94
Windows 98.......................................................................95
Windows NT 4.0 .................................................................. 96
Driverinstallation ....................................................................96
Chapter 5: Ethernet Software configuration .............................
............................................................................97
Windows 98 Driver Installation..................................98
Ethernet software configuration ........................................99
Chapter 6: Audio Software configuration....................100
Audio Software configuration..............................................101
Windows 98.......................................................................101
Windows NT 4.0.................................................................104
Appendix A: Programming the Watchdog Timer...........105
Programming the watchdog timer ..................................106
Watchdogtimer .....................................................................106
Configurationregister............................................................107

Chapter 1 General Information 1
1
General
Information
This chapter gives background
informationofthemainboard.
Sections Include:
•BoardSpecifications
• Layout and Dimensions
CHAPTER

2MB-662 User Manual
Introduction
TheMB-662isanall-in-oneCeleron/PentiumIIIFC-chipprocessor
basedLPX-sizesingleboardcomputer(SBC)withaPCIFlatPanel
controller,aPCI100Base-TEthernetinterface.WhenusinganIntel
Pentium III processors, the MB-662 achieves outstanding perfor-
mance that surpasses any other SBC in its class. In addition, the
onboardSSDinterfacesupportsM-SystemsDiskOnChip2000
series,memorycapacityupto288MB.
Onboardfeaturesincludefourserialports(threeRS-232,oneRS-
232/422/485),twobi-directionalparallel(ECP/EPP/SPP)port,pin
headerfortwoUSB(UniversalSerialBus)ports,afloppydrive
controller,anda keyboard/PS/2mouseinterface.Thebuilt-inhigh
speed 2 EIDE channels can support up to 4 Ultra DMA/33 mode.
Up to four IDE devices can be connected, including large hard
disks, CD-ROM drives, and tape backup drives, etc.
TheMB-662alsofeaturespowermanagementtominimizepower
consumption. It complies with and supports three types of power
saving features: Doze mode, Standby mode, and Suspend mode. In
addition, the board's watchdog timer can automatically reset the
system or generate an interrupt in case the system stops due to a
programbugorEMI.
Highly integrated LPX-size SBC
TheMB-662isahighlyintegratedLPX-sizeSBCthatcombines,
video, and network functions on a single computer board. It
providesupto1024x768resolution@64Kcolorswithon-chip
2MBSDRAMdisplaymemory.MajoronboarddevicesadoptPCI
technology to achieve outstanding computing performance making
theMB-662oneoftheworld'sbestandmostpowerful LPX-size
SingleBoardComputer.

Chapter 1 General Information 3
Features
• SupportsIntelCeleron/PentiumIIIFC-370
• SupportsDiskOnChip(SSD)upto288MB
• C&T69000LCDcontrollersupports36-bitTFTPanels
• RealtekRTL8139C10/100Base-TFastEthernet
• Supports H/W status monitoring

4MB-662 User Manual
Specifications
StandardLPX-size SBC functions
•CPU:FC-370PentiumIII(Coppermine),Celeron,andcompatibleCPUs
(Withsystembusfrequenciesof66/100MHz).
•CPUsocket:370pinsSocket
•BIOS:Award256KBFlashBIOS
•Chipset:Intel440BX
•I/Ochipset:ITEIT8661F/WinbondW83977ATF.
•Memory : Onboard two 168 pinsDIMM socketsupports upto
512MbytesSDRAM.
•EnhancedIDE:TwoEIDEchannels. Supportsupto4UltraDMA/33
deviceswithdatatransfer rate of33MB/sec..With one44and40pinIDE
connectors power enhanced
•FDDinterface:Supportstwofloppydiskdrives,5.25"(360KBand
1.2MB)and/or3.5"(720KB,1.44MB,and2.88MB),withonestandard
type connector and one FPC connector.
•Parallelport:Twobi-directionalparallelports. SupportsSPP,ECP,and
EPPmodes.Oneexternal25-pinD-subconnectorandone13x2pin
headerforLPT1.
•Serialport:ThreeRS-232andOneRS-232/422/485serialport. Portscan
beconfiguredasCOM1,COM2,COM3,COM4,ordisabledindividually.
16C550serialUARTs.3externalD-subconnectors,1internal5x2pin
header supporting COM2.
•IRinterface:SupportsoneIrDATx/Rxheader(FIR/SIR,IrDA1.0spec.).
•KB/Mouseconnector:6-pinmini-DINconnectorsupportsPC/AT
keyboard and PS/2 mouse.
•USBconnectors:6-pinonboardconn.supportsdual USB externalports.
•Battery:Lithiumbatteryfordataretention
•CMOSBackup:CMOSdatabackupinflashmemory,autosystemreload
when data is loss.

Chapter 1 General Information 5
•Watchdogtimer:Cangenerateasystemreset,IRQ15,orIRQ10andIRQ
11. Softwareselectabletime-outinterval(1sec.~255min.,1sec./step)
•DMA:7DMAchannels(8237equivalent)
•Interrupt: 15interruptlevels(8259equivalent)
•Powermanagement:I/Operipheraldevicessupportpowersavingand
doze/standby/suspend modes. APM 1.2 ocmpliant. Supports ATX
powersupply,PC97andmodemring-infunction.
•H/Wstatusmonitoring:WinbondW83781DH/WstatusmonitoringIC
supports power supply voltages, fan speed control and temperature
monitoring.
•LEDstatuspinheader:LEDstatusindicatorforpower,CPUfan,Aux.
fan,HDD,lowtemperarature,hightemperatureandLAN.
Flat Panel/CRT Interface
•Chipset:C&T69000
•Displaymemory:2MBSDRAMbuiltinchip
•Displaytype:Supportsnon-interlacedCRTandLCD(TFT,DSTN,and
Mono) displays. Can display both CRT and Flat Panel simultaneously.
•Resolution:Upto1024x768@64Kcolors.
Audio Interface
•Chipset:ESSES1938(Solo-1)
•Audiointerface:16-bitstereoVLSIchip,PCIbasedAC97DigitalAudio
Processor, Sound Blaster /Proemulation.
Ethernet Interface
•Chipset: RealtekRTL8139C10/100Base-TFastEthernetcontroller.
•Ethernetinterface:Onboard10/100Base-TxRJ-45connectoroptional
RemoteBootROMFunction.

6MB-662 User Manual
SSD Interface
•One 32 pinsDIP socket supportsM-SystemsDiskOnChip 2000seriesup
to288MB.
ExpansionSlots
•PCI/ISAslotandPC/104screwsholeforLVDSmodule:OnePCI/ISA
slotonboard.ReservedforAaeon'sPCM-3524LVDSmodule.
Mechanical and environmental
•Powersupplyvoltage: +5V(4.75Vto5.25V),
+12V(11.4Vto12.6V)
•Operatingtemperature:32to140oF(0to60oC)
•Boardsize:8.9"(L)x8.7"(W)(225mmx220mm)
•Weight:1.2lb.(0.52Kg)

Chapter 1 General Information 7
Board Layout
JP13
CN16
CN9
CN12
CN8
JP18
CN7
JP16
JP7 JP3
JP17
DIMM1
DIMM2
JP14
JP15
CN21
CN13
CN6
CN11
CN35
CN37
CN36
CN33
CN32
CN30
CN22
CN3
CN10
CN14
JP10
JP1
CN2 CN25 CN17 CN24
CPU1
JP6
EISA1
JP12
CN34
CN31
CN29
JP2
JP8

8MB-662 User Manual
Board Dimensions
0
0 0
0

Chapter 2 Installation 9
2
Installation
This chapter describes how to set up the
mainboardhardware,includinginstruc-
tions on setting jumpers and connecting
peripherals, switches, and indicators. Be
sure to read all the safety precautions
before you begin the installation proce-
dure.
CHAPTER

10 MB-662 User Manual
Setting jumpers
You can configure your card to match the needs of your application
bysetting jumpers. Ajumper isthesimplest kindofelectric switch.
It consists of two metal pins and a small metal clip (often protected
by a plastic cover) that slides over the pins to connect them. To
“close” a jumper you connect the pins with the clip. To “open” a
jumperyouremovetheclip.Sometimesajumperwillhavethree
pins, labeled 1, 2, and 3. In this case you would connect either pins
1and2 or 2and3.
The jumper settings are schematically depicted in this manual as
follows:
A pair of needle-nose pliers may be helpful when working with
jumpers.
If you have any doubts about the best hardware configuration for
your application, contact your local distributor or sales representa-
tive before you make any changes.
13
2
Open Closed Closed 2-3
Open Closed Closed 2-3
1 2 3

Chapter 2 Installation 11
CPU installing and upgrading
YoucanupgradetoamorepowerfulCeleronCPUatanytime.
Simplyremove theold CPU, install the newone, andset the
jumpersforthenewCPU speed.
Warning! Alwaysdisconnectthepower cord fromyour
chassis when you are working on it. Do not
make connections while the power is on as
sensitive electronic components can be dam-
aged by the sudden rush of power. Only experi-
encedelectronicspersonnel should openthe
system chassis.
Caution! Alwaysgroundyourself to removeanystatic
charge before touching the system board.
Modernelectronicdevices are verysensitiveto
static electric charges. Use a grounding wrist
strap at all times. Place all electronic components
on a static-dissipative surface or in a static-
shielded bag when they are not in the chassis.
Install a CPU in the FC-370 socket
MB-622SeriesprovidesaFlip-Chip(FC)socketforeasyCPU
installation.
1. Make sure the FC-370 socket lever is in the upright position. To
raise the lever, pull it out to the side a little and raise it as far as
itwillgo.
2. Place the CPU in the empty socket. Follow the instructions that
came wth the CPU. If you have no instructions, do the follow-
ing:Carefullyalign the CPUsoitis parallel tothesocketand
the notch on the corner of the CPU corresponds with the notch
on the inside of the socket. Gently slide the CPU in. It should
inserteasily. Ifitdoesn't, pull theleverupa little more.
