Half-size 486 All-in-One CPU Card
with Cache
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

FCC STATEMENT
THISDEVICECOMPLIESWITHPART15FCCRULES.OPERA-
TIONISSUBJECTTOTHEFOLLOWINGTWOCONDITIONS:
(1)THISDEVICEMAYNOTCAUSEHARMFULINTERFER-
ENCE.(2)THISDEVICEMUSTACCEPTANYINTERFERENCE
RECEIVEDINCLUDINGINTERFERENCETHATMAYCAUSE
UNDESIREDOPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO
COMPLY WITH THE LIMITS FOR A CLASS"A" DIGITAL
DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASON-
ABLE PROTECTION AGAINTST HARMFUL INTERFER-
ENCEWHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENER-
ATES,USES, AND CAN RADIATE RADIO FREQENCY
ENERGYAND, IFNOT INSTATLLEDAND USED IN ACCOR-
DANCEWITH THE INSTRUCTION MANUAL, MAY CAUSE
HARMFUL INTERFERENCE TO RADIO COMMUNICA-
TIONS.OPERATION OF THIS EQUIPMENT IN A RESIDEN-
TIALAREA IS LIKELY TO CAUSE HARMFUL INTERFER-
ENCE IN WHICH CASE THE USER WILL BE REQUIRED
TOCORRECT THE INTERFERENCE AT HIS OWN EX-
PENSE.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Acknowledgements
ALI is a trademark of Acer Laboratories, Inc.
AMD is a trademark of Advanced Micro Devices, Inc.
AMI is a trademark of American Megatrends, Inc.
CyrixisatrademarkofCyrixCorporation.
IBM, PC/AT, PS/2 and VGA are trademarks of International
Business Machines Corporation.
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows ®is a registered trademark of Microsoft Corp.
SMC is a trademark of Standard Microsystems Corporation.
UMC is a trademark of United Microelectronics Corporation.
All other product names or trademarks are properties of their
respective owners.
Part No. 2007410001 2nd Edition
Printed in Taiwan May 1997
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Packing list
Before you begin installing your card, please make sure that the
following materials have been shipped:
• 1 SBC-410CPU card
• 1 6-pin mini-DIN dual outlet adapter for keyboard and PS/2
mouse
• 1 3½" Hard disk drive (IDE) interface cable (40 pin)
• 1 2½" Hard disk drive (IDE) interface cable (44 pin)
• 1 Floppy disk drive interface cable (34 pin)
• 1 Parallel port adapter (26 pin)
• PC/104 Expansion connector converter (pin headers)
• PC/104 Module mounting supports
If any of these items are missing or damaged, contact your distribu-
tor or sales representative immediately.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Contents
Chapter 1: General Information ................................ 1
Introduction ............................................................................ 2
Features ................................................................................... 3
Specifications .......................................................................... 4
Board layout ........................................................................... 6
Carddimensions ..................................................................... 7
Chapter 2: Installation ................................................ 9
Jumpersandconnectors ...................................................... 10
Locating jumpers and connectors........................................11
Setting jumpers ..................................................................... 12
Safety Precations ............................................................. 13
Installing the CPU ................................................................ 13
Removing a CPU .................................................................... 13
Installinga CPU...................................................................... 14
CPU type select (JP1, JP2, JP3) ............................................ 15
CPU Vcc select (JP7) ............................................................. 16
CPU clock select (JP6, JP8)................................................... 16
Installing DRAM (SIMMs) .................................................. 17
InstallingSIMMs .................................................................... 17
RemovingSIMMs................................................................... 17
Selecting cache memory size................................................ 18
Cache memory select (JP11) .................................................. 18
IDE harddrive connections (Primary/Secondary IDE) .... 19
Connecting the hard drive ....................................................... 19
IDE LED(CN3)....... . ........................................................20
Floppy drive connections (FDC CON)................................ 22
Connecting thefloppy drive .................................................... 22
Parallelport (PRINTER) ..................................................... 23
Installingthe retainingbracket................................................. 23
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Power supply connections.................................................... 24
Power supply connector (POWER CON) .............................. 24
CN1,2,3,8,9,11,JP4 AND JP5 locations ................................. 24
Keyboard and PS/2 mouse connectors (KB-CON)............ 25
Key board or PS/3 mouse select (JP8) ................................... 25
Serialports ............................................................................ 26
RS-232/422/485 select for COMB
(JP12, JP13, JP14, JP15, JP16).....................................26
RS-232/422/485 serial port connections (COMA, COMB) ....26
RS-422signal wiring................................................................28
RS-485signal wiring................................................................28
Watchdog timer setup......................................................... 29
Watchdog timer time-out signal select (JP4)...........................29
Watchdog timer programming .................................................29
SMI(System management interrupt) switch (CN11) ..............30
External Switches and LEDs............................................. 31
Power LED and keylock (CN9) .............................................31
External speaker (CN10) ........................................................31
Reset switch (CN1) ................................................................32
Turbo LED (CN2)...................................................................32
Turbo switch (CN8) ................................................................32
Clear CMOS (JP9) .................................................................33
Flash BIOS Protect (JP10) .....................................................33
Flash BIOS Write-enable Voltage (JP17) ...............................33
Chapter 3: AMIBIOS Setup ......................................... 35
Generalinformation ............................................................. 36
StartingAMIBIOS setup......................................................... 36
AMIBIOS main menu............................................................. 36
Using a mouse with AMIBIOS setup...................................... 37
Using the keyboard with AMIBIOS setup .............................. 37
StandardSetup ..................................................................... 38
AdvancedSetup .................................................................... 40
Chipset Setup ........................................................................ 46
PowerManagementSetup ................................................... 48
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PCI/PnPSetup ...................................................................... 49
PeripheralSetup ................................................................... 53
Utility..................................................................................... 56
Security.................................................................................. 57
AMIBIOS password support .................................................. 57
Anti-virus ................................................................................ 59
Default ................................................................................... 60
Original ................................................................................... 60
Optimal ................................................................................... 60
Fail-Safe.................................................................................. 60
ExitingAMIBIOS ................................................................. 61
Appendix A: Watchdog Timer Demo Program .......63
Appendix B: Installing PC/104 Modules ................... 67
InstallingPC/104modules............................................ 68
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Chapter 1 General Information 1
CHAPTER
1
General
Information
This chapter gives background informa-
tionon the SBC-410.
Sections include:
• Card specifications
• Board layout
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2SBC-410 User'sManual
Introduction
The SBC-410 is an all-in-one CPU card that supports L2 cache
sizes from 128 KB to 512 KB (32 KB x 8, 64 KB x 8, or 128 KB x
8). This CPU card uses the M1489/M1487 chipsets, which accept
Intel, AMD, Cyrix, or other compatible 486-based CPUs. The SBC-
410 is fully PC/AT compatible, so your software will run without
modifications.
On-board features include two high-speed serial ports (RS-232 and
RS-232/422/485) with 16C550 UARTs, one bi-directional parallel port,
and a floppy drive controller. If program execution is halted by a
program bug or EMI, the board's 15-stage watchdog timer can
automatically reset the CPU or generate an interrupt. This ensures
reliability in unmanned or stand-alone systems.
The SBC-410 is built with two high speed local bus Enhanced IDE
controllers. This controller supports (through ATA PIO) mode 3 and
mode 4 hard disks, which enable data transfer rates of over 11 MB/
second. It connects up to four IDE devices, including large hard disks,
CD-ROM drives, tape backup drives, etc. The built-in enhanced IDE
controller provides a 4-layer 32-bit posted write-buffer and a 4-layer 32-
bit read-prefetch-buffer to boost IDE performance.
TheSBC-410supports 5VEDODRAM.It also provides two 72-pin
SIMM (Single In-line Memory Module) sockets for on-board DRAM.
This gives you the flexibility to configure your system memory from 1
~ 64 MB using the most economical combination of SIMMs.
TheSBC-410 also features power management to minimize power
consumption. It uses CMOS components and complies with the
"GreenFunction" standard.
If you need any additional functions, you can add industry-standard
PC/104 expansion modules. We provide numerous PC/104 modules to
meet your system requirements.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Chapter 1 General Information 3
Features
•Accepts any Intel, AMD, Cyrix, or other compatible processor
•Half-size ISA bus CPU card, fully 486SX/DX/DX2/DX4/5x86/Pentium
Over Drive compatible
•Built-in 128 KB secondary cache, up to 512 KB
•Up to 64 MB of on-board DRAM; supports 5V EDO DRAM
•Built-in IDE (AT bus) hard disk drive interface, floppy drive controller
•One RS-232 and one RS-232/422/485 selectable serial port; uses
16C550 UARTs with 16-byte FIFO
•One bi-directional parallel port
•32 to 140oF (0 to 60oC) operating temperature
•Watchdog timer, software programmable from 2 to 32 seconds
(15 steps, 2 seconds per step)
•On-board keyboard connector and/or PS/2 mouse
•IDE HDD auto-detection
•Connectors for PC/104 module expansion
•Single +5V power supply
•"Green" function, supports power management
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4SBC-410 User'sManual
Specifications
• CPU:Intel 486SX/DX/DX2/DX4/Pentium Over Drive;
AMDAm486DX/DX2/DX4/5x86;
IBM/SGS/CyrixCx486DX/DX2/M7/5x86;
TI486DX2/DX4
•Businterface: ISA (PC/AT) bus
• Databus:32bit
• Processingability: 32 bit
• Chipset:ALI1489/1487
• RAMmemory:1MBto64MB,two72-pinsockets
• Shadow RAM memory: Supports system and video BIOS up
to256KBin32KBblocks
• L2 Cache memory: On-board 128 KB, up to 512 KB (DIP package)
• Enhanced IDE HDD interface: Supports up to four enhanced IDE
(ATA-2 bus) large hard disk drives or other enhanced IDE devices.
Supports mode 3 and mode 4 hard disks (minimum data transfer
rate of 11.1 MB/sec).
• Floppydisk drive interface: Supports up to two floppy disk drives,
5.25"(360KBand1.2 MB) and/or 3.5" (720 KB, 1.44 and 2.88MB).
• Bi-directionalparallelport: SPP/EPP/ECP standards.
• Serialports:OneserialRS-232portand one serial RS-232/RS-422/
RS-485port,jumperselectable.Bothwith16C550UARTs with
16-byteFIFObuffer.
• IRQ SELECTION FOR COM PORTS:
COMA: Supports COM 1/2/3/4 & address is selectable;
COMB: Supports COM 1/2/3/4 & address is selectable;
• BIOS:AMIFlashWinBIOS
• Watchdog timer: The time interval is softwareselectablefrom 2 to 32
seconds (15 steps, 2 seconds per step). Can generate a system reset or
IRQ15.
• PC/104: 104-pin connector for a 16-bit bus
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Chapter 1 General Information 5
• DMA channels: 7
• Interrupt levels: 15
• Keyboard connector: A 6-pin mini DIN keyboard connector is located
on the mounting bracket for easy access. An on-board keyboard 5-pin
header connector is also available.
• PS/2 Mouse connector: Shared with keyboard connector.
• Bus speed: 8 MHz
• System performance: 325 MHz in 80486DX4-100 (Landmark V2.0)
• Max. power requirements: +5 V @ 2.5 A
• Power supply voltage: Single +5 V (4.75 V to 5.25 V)
• Operating temperature: 32 to 140oF (0 to 60oC); must use a cooling fan
when using a DX4-100 CPU or above
• Boardsize:7.3" (L)x4.8"(W)(185 mmx122mm)
• Boardweight:1.2 lbs (0.5Kg)
• GreenFunction:Yes
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

6SBC-410 User'sManual
Board layout
SMC
FDC37C665
ODIN
OEC12C887
ALI
M1489
14.318
24MHz
SC464
IMI
MAX211 MAX211
MEGA-KB
ALI
M1487
SBC-410 486DX4/5X86 CPU CARD REV:.A1
32K8 CACHE RAM 32K8 CACHE RAM 32K8 CACHE RAM 32K8 CACHE RAM
16V8
AMERICAN MEGATRENDS
AMIBIOS
486PCI ISA
9644S
UM61256FS-15
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Chapter 1 General Information 7
Card dimensions
Units=mm
PC/104 Module
185.00 178.00
98.50
122.00
80.65
73.66 26.00
19.00
19.50
D4x4
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

8SBC-410 User'sManual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Chapter 2 Installation 9
2
Installation
This chapter describes how to set up the
SBC-410 hardware, including instruc-
tions on setting jumpers and connecting
peripherals, switches and indicators. Be
sure to read all safety precautions before
you begin the installation procedure.
CHAPTER
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

10 SBC-410 User's Manual
Jumpers and connectors
Connectors on the board link it to external devices such as hard
disk drives, a keyboard or floppy drives. In addition, the board has
a number of jumpers that allow you to configure your system to
suit your applications.
The table below lists the function of each of the board jumpers
and connectors.
Jumpers and connectors
Label Function
CN1 Reset switch
CN2 Turbo LED
CN3 IDE LED
CN8 Turbo switch
CN9 Power LED and keylock voltage
CN10 External speaker
CN11 SMI SWITCH
JP1, 2, 3 CPU type select
JP4 Watchdog timer time-out signal select
JP6,8 CPU clock select
JP7 CPU Vcc select
JP9 Clear CMOS
JP10 Flash BIOS Protect
JP11 Cache memory select
JP12, 13, 14, 15, 16 RS-232/422/485 select
JP17 Flash BIOS Write-enable
JP18 Keyboard or PS/2 mouse select
PRIMARYIDE Primary Enhanced IDE connector
SECONDARY IDE Secondary Enhanced IDE connector
FDC CON FDD connector
PRINTER Parallel connector
POWER CON Power connector
KB-CON External keyboard connector
KB-CON Keyboard and/or PS/2 mouse connector
COMA Serial port 1
COMB Serial port 2
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Chapter 2 Installation 11
SMC
FDC37C665
ODIN
OEC12C887
ALI
M1489
14.318
24MHz
SC464
IMI
MAX211 MAX211
MEGA-KB
ALI
M1487
SBC-410 486DX4/5X86 CPU CARD REV:.A1
32K8 CACHE RAM 32K8 CACHE RAM 32K8 CACHE RAM 32K8 CACHE RAM
16V8
AMERICAN MEGATRENDS
AMIBIOS
486PCI ISA
9644S
UM61256FS-15
Locating jumpers and connectors
POWER CON JP10 COMA COMB KB-COM
PRINTER
JP17
JP9
CN1,2,3,8,9,10,11
and JP4,5
FDC CON
JP 6,8
JP1,2,3
JP7
PRIMARY IDE
SECONDARY IDE
KB-COM
JP12,13,14,15,16
JP18
JP11
SIMM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

12 SBC-410 User's Manual
Setting jumpers
You configure your card to match the needs of your application by
setting jumpers. A jumper is the simplest kind of electric switch.
It consists of two metal pins and a small metal clip (often
protected by a plastic cover) that slides over the pins to connect
them. To "close" a jumper you connect the pins with the clip. To
"open" a jumper you remove the clip. Sometimes a jumper will
have three pins, labeled 1, 2 and 3. In this case you would connect
either pins 1 and 2 or 2 and 3.
The jumper settings are schematically depicted in this manual as
follows:
A pair of needle-nose pliers may be helpful when working with
jumpers.
If you have any doubts about the best hardware configuration for
your application, contact your local distributor or sales represen-
tative before you make any changes.
Generally, you simply need a standard cable to make most
connections.
13
2
Open Closed Closed2-3
Open Closed Closed2-3
1 2 3
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
