A&D UA-851 User manual

UA-851
Fuzzy logic control
Constant speed
exhaust valve
Automatic exhaust by
electromagnetic valve
UA-852
Digital, LCD 20/13 mm character height,
Pressure/pulse displayed simultaneously
90
Maximum 90 data average
of systolic and diastolic values
SlimFit cuff, gray
UA-854UA-853
Oscillometric
20 – 280 mmHg (pressure)
40 – 180 pulse/minute (pulse)
±3 mmHg or 2%, whichever is greater (pressure)
± 5% (pulse)
Intellitronics fully automatic control
Electric control exhaust valve (ECEV2)
4 Type AA batteries (R6P)
Approximately 600 measurements (alkaline battery)
Maximum 90 data average of systolic
and diastolic values with AM/PM selection
+10°C~+40°C (+50°F~104°F)
30%RH to 85%RH
−10°C~+ 60°C (14°F~140°F)
30%RH to 85%RH
Approximately 350g (0.66lb)
62(H) x 163(W) x 112(D) mm
Dust cover, instruction manual &batteries
Specifications
Method
Display
Measurement Range
Accuracy
Pressurization
Depressurization
Deflation
Power supply
Battery life
Memory
Average memory data
Cuff
Operating environment
Storage environment
Weight
Dimension
Standard accessories
UA-855
Digital, LCD 17/15mm character height,
Pressure/pulse displayed simultaneously
120 x 2
All, 1 month &1 week average
with AM/PM selection
Easy cuff (new e-cuff ), gray
Approx. 550g (1.2lb)
Blood Pressure Monitors
UA-85X
Series
Overview of UA-85X Series
Accessories:
TB-233C AC adapter 100-240VAC C plug
TB-233BF AC adapter 100-240VAC BF plug
Model
Cuff
Clock, Calendar
Memory
Average reading
AM/PM memory recall w/average
IHB indicator
Histogram of memory data
BP classification
BP classification annunciator
2 person independent memory
Illuminated button
Alarm
Room temperature
Intellitronics fully automatic control
ECEV2
UA-851
90
●
●
WHO
●
UA-853
●
90
●
●
●
WHO
●
●
●
●
UA-854
New e-Cuff, gray
●
90
●
●
●
WHO
●
●
●
●
●
UA-855
●
120 x 2
●
●
●
●
WHO, graphical
Color LED
●
●
●
●
●
●
UA-852
SlimFit, gray
●
90
●
●
WHO
●
●
●
●
Technology You Can Trust
http://www.aandd.jp
UA-85X
Series
Blood Pressure Monitors
Many people have a tough time understanding their blood pressure measurements
taken from their own home monitor.
Is my measurement ok or is it too high? Did I take my measurement in the morning or in the afternoon?
A&D has taken the guesswork out of blood pressure monitoring by offering three innovative features with our
new premium line of blood pressure monitors:
The entire UA-85X series provides physicians with the necessary information to better diagnose and treat hypertension, and is
especially helpful for people taking medication.
n All units offer the World Health Organization (WHO) blood pressure classification indicator which color-codes
measurement classifications and eliminates the risk of misunderstanding your BP results.
n The UA-854 and UA-853 are equipped with AM/PM TimeWise™ Tracking Technology, which automatically
categorizes AM and PM measurements, and can average AM, PM and daily measurements.
n The UA-855 provides you with even more detailed information about your blood pressure level. Its unique
histogram display comprehensively shows variations in your blood pressure level.
Understanding Your BP Results Just Got Easier
Understanding Your BP Results Just Got Easier
UA-851/UA-852/UA-853/UA-854/UA-855
*UA85X-ADCC-02-PR2-08101
REF*ADC-UA85X
3-23-14 Higashi-Ikebukuro,Toshima-ku,Tokyo 170-0013 Japan
Telephone:[81](3)5391-6132 Fax:[81](3)5391-6148
1-243, Asahi,Kitamoto-shi,Saitama, 364-8585 Japan
Telephone:[81](0485)93-1111 Fax:[81](0485)93-1119
(EN46001 Certified Factory)
http://www.aandd.jp
1756 Automation Parkway, San Jose, CA 95131 U.S.A.
Telephone:[1][phone] Fax:[1][phone]
Unit 24/26 Blacklands Way Abingdon Business Park,
Abingdon, Oxon OX14 1DY United Kingdom
Telephone:[44](1235) 550420 Fax:[44](1235) 550485
(Authorized Representative Established in the European Community)
Medica
Medical/
LifeSource
LifeSource
32 Dew Street, Thebarton, South Australia 5031 AUSTRALIA
Telephone:[61](8)8301-8100 Fax:[61](8)8352-7409
Korp.134A, D.29, UL. Vereiskaya, Moscow, 121357
RUSSIAN FEDERATION
Telephone: [7] [phone] Fax: [7] [phone]
Manhattan Bldg. 8F, 36-2 Yoido-dong, Youngdeungpo-gu, Seoul, KOREA
Telephone:[82](2) 780-4101 Fax:[82](2) 782-4280
Understanding Your BP Results Just Got Easier
UA-851/UA-852/UA-853/UA-854/UA-855
Worrying about your blood pressure level?
Intellitronics :
Intellitronics is A&D’s new technology
that makes taking your blood pressure
less painful by maximizing your blood
pressure measurements. Intellitronics is
easier, faster and more precise!
Intellitronics is a fully automated
control function that automatically
controls all the processes for blood
pressure measurements once the START
button is pressed. Intellitronics utilizes
blood pressure information more
efficiently than conventional blood
pressure monitors, reducing the time it
takes for blood pressure readings.
Quicker, more precise blood pressure
readings mean less discomfort and
anxiety for patients.

UA-854 Blood pressure result display
Memory recall
display
Standby mode
display
Histogram display
Display while not in use
The UA-854 has an extra parameter for monitoring your blood
pressure and it can display your room temperature at anytime!
Knowing the temperature in your room makes it easier than ever to
maintain your health. The UA-854 maintains all the features of the
UA-853. AM/PM TimeWise™ Tracking allows for the close monitoring
of your BP trend.
UA-855
This is the first blood pressure monitor that makes a large memory
meaningful. A World Health Organization (WHO) classification
graphic indicator and colored LED indicator, a histogram of stored data
and a room temperature display help you understand the meaning of
your readings. It is also possible to share this unit with a family
member since it is equipped with two-person independent memory.
Calendar
Time
Room temperature
Easy cuff (new e-cuff)
Arm size: 22 – 42cm
AM/PM TimeWise™ Tracking
memory recall buttons
AM PM
Color LED BP classification indicator
Memory recall period selection
Easy cuff (new e-cuff)
Arm size: 22 – 42cm
Systolic BP value
Person 1
Diastolic BP value
Pulse/min.
Average Systolic
value
One month is selected.
Only AM data is
selected this month.
Data in memory
Blood pressure classification (WHO)
Irregular Heart Beat (IHB) indicator
Systolic is selected.
X: Systolic ranges / Y: percentage
Blood pressure result display
Systolic BP value
Irregular Heart Beat
(IHB) indicator
Diastolic BP value
Pulse/min.
Blood pressure indicator (WHO classification)
UA-853
AM/PM TimeWise™Tracking
The UA-853 is equipped with AM/PM TimeWise™ Tracking
Technology memory recall. This function allows you to recall
your morning (AM) or afternoon (PM) measurements as well as
your average AM, PM or daily measurements, providing users
with a detailed daily BP analysis.
UA-852
Closer Monitoring with Regular
Measurements
The UA-852 promises fast and easy measurement
for your daily monitoring. You can set 3 reminders
within a 24-hour period to alert you of your ideal
measurement times.
UA-851
More Information with More
Measurements
This intelligently designed unit is equipped with the
latest technology for convenient blood pressure
monitoring. A large memory can store your BP
measurements and your BP trend is also readily stored
in the built-in memory.
Your Supporter to Monitor Long Term Trends Closer Monitoring of Your Ambience
IHB indicator
Easy
Cuff Alarm
BP
classification
WHO
Room
temperature
°C
Memory
90
12 0 x2
AM/PM memory
recall w/average
2-person
independent
memory
Clock,
Calendar
10/15
Histogram
of memory
data
BP
classification
annunciator
LED
Average
reading
Intellitronics fully
automatic control
WHO
90
12 0 x2
10/ 15
LED
WHO
90
12 0 x2
10/ 15
LED
WHO
90
12 0 x2
10/ 15
LED
WHO
90
12 0 x2
10/ 15
LED
WHO
90
12 0 x2
10/ 15
LED
Average
Systolic
value
Average
Diastolic
value
Data in
memory
Two-person selection for
independent memories (120x2)
Display selection /
parameter setting buttons
Illuminated
button
START
START
START START
START
START
