Aastra 7106A User manual

User Guide
Aastra 7106a -analogue telephone

Aastra 7106a Analogue Telephone 2
EN/LZT 102 4161 R1B
© Aastra Telecom Sweden AB 2011, all rights reserved.

Aastra 7106a Analogue Telephone 3
Table of Contents
Introduction 4
Important User information 5
Telephone Parts 6
Telephone Layout 6
Cable inlets and MW switch 8
Incoming calls 9
Outgoing calls 11
During calls 13
Call forwarding 14
Optional Call handling Features 17
Speed Dial Memory 25
Phone Setting 26
System Dependent Phone Setting 27
Telephone Specification 28
Wall mounting 29

Aastra 7106a Analogue Telephone 4
Introduction
Aastra 7106a is an easily managed line-powered analog phone.
The functions and features available with this telephone are
designed for easy use in all different telephone handling
situations. It supports calls with excellent voice quality.

Aastra 7106a Analogue Telephone 5
Important User information
Safety Instructions
Save these instructions
Read these safety instructions before use!
Note: When using your telephone or connected equipment, the following
basic safety precautions should always be followed to reduce risk of fire,
electrical shock and other personal injury.
•Follow instructions in the equipment's user guide or other documentation.
•Always install equipment in a location and environment for which it is designed.
•Headsets used with this equipment must comply with EN/IEC 60950-1
•Do not make any changes or modifications to equipment without seeking approval
from the party responsible for compliance. Unauthorized changes or modifications
could void the user's authority to operate the equipment.
•Do not use the telephone to report a gas leak in the vicinity of the leak.
•Do not spill liquid of any kind on the product or use the equipment near water, for
example, near a bathtub, washbowl, and kitchen sink, in a wet basement or near
a swimming pool.
•Do not insert any object into equipment slots that is not part of the product or
auxiliary product.
•Do not disassemble the product. Contact a qualified service agency when service
or repair work is required.
•Do not use a telephone (other than cordless type) during an electrical storm.
Disposal of the product
Your product should not be placed in municipal waste. Please check local
regulations for disposal of electronic products.

Aastra 7106a Analogue Telephone 6
Telephone Parts
When you unpack your phone, you should ensure that you have all of the
following items. If any part is missing, contact the supplier of your phone.
Telephone Layout

Aastra 7106a Analogue Telephone 7
Table with Key-symbols
Symbols /
Keys French Spanish German Portuguese Dutch
Speed-dial
M0-M3
Numérotation
abrégée
Touche M0-M3
Teclas
programables
M0-M3
Kurzwahl
M0-M3 Discagem rápida
M0-M3
Snel-kiezen
M0-M3
Flash key
Touche R –
Flash
Tecla Flash R- Taste Flash
Haakcontact
Redial /
Pause key
Touche Rappel /
Mise en attente
Rellamada/
Pausa
Wahlwiederholung /
Pausentaste Rediscagem/tecla de pausa Nummerherhaling / Pauzetoets
0-9, * and #
(dial keys)
0-9, * and #
(touches de
numérotation)
0-9, * and #
(digitos)
0-9, * and #
(Zifferntasten)
0-9, * and #
(Dígitos)
0-9, * and #
(bel toetsen)
Volume keys
Touches de
réglage volume
Volumen Lautstärketasten Volume
Volume toetsen
Mute key
Touche secret -
Act./desactiv-
Micro
(Mute) silencio Stummtaste
Mudo Mute-toets
Save key
Touche de
sauvegarde Salvar Speichertaste Salvar Opslaan
Message
waiting
Message en
attente
Mensaje en
espera Nachricht wartet Mensagem em espera
Wachtend
bericht

Aastra 7106a Analogue Telephone 8
Cable inlets and MW switch
Symbols French Spanish German Portuguese Dutch
Line socket Prise ligne
téléphonique Puerto
conneccion de
linea
Anschlussbuchse Conector de
linha telefônica Lijnpoort
OFF / Hi Volt
/ MW(-) /
MW(+)
ARRET / Haute
Tension / MW(-) /
MW(+)
DE / Alto voltaje /
MW(-) / MW(+)
AUS/Spannung/
MW(-) / MW(+
OFF / Hi Volt /
MW(-) / MW(+)
UIT / Hi Volt /
MW(-) / MW(+)
Handset Jack
Prise pour
combiné Puerto de microtelefono Hörerbuchse Conector do monofone Telefoonhoorn aansluiting

Incoming calls
To answer an incoming call
Lift the handset
Answer a second call
A call waiting tone will inform you, during conversation that a second call
is waiting. You have two options:
Option 1:
1. Replace the handset. The new call will be signaled on your phone
2. Lift the handset to receive the call.
Option 2:
1. Ask the party you are speaking with to wait
2. Press
and replace the handset. The waiting call will start
ringing.
3. Lift the handset to receive the new call
4. Press 2 to return to the first call (Sweden, press )
After finishing the call, replace the handset to receive the first call again
Answer a call from another extension
you can answer a call to another extension from any phone in your office:
1. Lift the handset and call the ringing extension.
2. You receive a busy tone, press numeric key, 8(France: 4.
Sweden: 6)
Mute ring signal
Press to mute the ring signal (LED flashing)

10
Do not disturb, DND
When you activate DND, calls to your extension is not shown.
Outgoing calls can be made as usual.
Activate DND:
Lift the handset and press numeric keys *27#, Replace the handset.
Deactivate DND:
Lift the handset and press numeric keys # 27#Replace the handset.
