Aastra 9480i Series Manual

Aastra 9480i
Admin Guide
Schmooze Com Inc.
Options
Xfer
ABC DEF
JKL
GHI MNO
TUV
PQRS WXYZ
1 2 3
4 5 6
789
0#
Conf
L1 L2 L3 L4
Services
Icom
Goodbye
9480i
RedialHold

Chapters
Reset to Factory Defaults
How to Find the IP Address and MAC Address
How to Set the TFTP Boot Server
Reset to Factory Defaults
Quick Steps
1. Select the Options button.
2. Select the Admin Menu Option.
© Copyright Schmooze Com, 2012
3. Enter the Admin Password. (Note: The default password is 22222).
4. Select option 4, Factory Default.
5. Press Default on the right hand side of the screen to confirm. The phone will now reboot and
will be defaulted when it starts back up.
How to Find the IP Address and MAC Address
Quick Steps
1. Select the Options button
2. Next select Phone Status, Option 2.
3. You will now select Option 1, IP&MAC Address.
4. You will now be shown the current IP Address and the MAC address of the phone.
How to Set the TFTP Boot Server
Quick Steps
1. Select the Options button
2. Select the Admin Menu Option.
3. Enter the Admin Password. (Note: The default password is 22222).
4. Select Config. Server.
5. Select Option 2, TFTP Settings.
6. Select Primary Server.
7. Use the Keypad to input the IP address of the PBX. Then press the DONE button.
Options
GoodbyeRedialHold

Chapters
Reset to Factory Defaults
How to Find the IP Address and MAC Address
How to Set the TFTP Boot Server
Reset to Factory Defaults
Quick Steps
1. Select the Options button.
2. Select the Admin Menu Option.
3. Enter the Admin Password. (Note: The default password is 22222).
4. Select option 4, Factory Default.
5. Press Default on the right hand side of the screen to confirm. The phone will now reboot and
will be defaulted when it starts back up.
© Copyright Schmooze Com, 2012
How to Find the IP Address and MAC Address
Quick Steps
1. Select the Options button
2. Next select Phone Status, Option 2.
3. You will now select Option 1, IP&MAC Address.
4. You will now be shown the current IP Address and the MAC address of the phone.
How to Set the TFTP Boot Server
Quick Steps
1. Select the Options button
2. Select the Admin Menu Option.
3. Enter the Admin Password. (Note: The default password is 22222).
4. Select Config. Server.
5. Select Option 2, TFTP Settings.
6. Select Primary Server.
7. Use the Keypad to input the IP address of the PBX. Then press the DONE button.

Chapters
Reset to Factory Defaults
How to Find the IP Address and MAC Address
How to Set the TFTP Boot Server
Reset to Factory Defaults
Quick Steps
1. Select the Options button.
2. Select the Admin Menu Option.
3. Enter the Admin Password. (Note: The default password is 22222).
4. Select option 4, Factory Default.
5. Press Default on the right hand side of the screen to confirm. The phone will now reboot and
will be defaulted when it starts back up.
How to Find the IP Address and MAC Address
Quick Steps
1. Select the Options button
2. Next select Phone Status, Option 2.
3. You will now select Option 1, IP&MAC Address.
© Copyright Schmooze Com, 2012
4. You will now be shown the current IP Address and the MAC address of the phone.
How to Set the TFTP Boot Server
Quick Steps
1. Select the Options button
2. Select the Admin Menu Option.
3. Enter the Admin Password. (Note: The default password is 22222).
4. Select Config. Server.
5. Select Option 2, TFTP Settings.
6. Select Primary Server.
7. Use the Keypad to input the IP address of the PBX. Then press the DONE button.
Options
GoodbyeRedialHold

Chapters
Reset to Factory Defaults
How to Find the IP Address and MAC Address
How to Set the TFTP Boot Server
Reset to Factory Defaults
Quick Steps
1. Select the Options button.
2. Select the Admin Menu Option.
3. Enter the Admin Password. (Note: The default password is 22222).
4. Select option 4, Factory Default.
5. Press Default on the right hand side of the screen to confirm. The phone will now reboot and
will be defaulted when it starts back up.
How to Find the IP Address and MAC Address
Quick Steps
1. Select the Options button
2. Next select Phone Status, Option 2.
3. You will now select Option 1, IP&MAC Address.
4. You will now be shown the current IP Address and the MAC address of the phone.
How to Set the TFTP Boot Server
Quick Steps
1. Select the Options button
2. Select the Admin Menu Option.
© Copyright Schmooze Com, 2012
3. Enter the Admin Password. (Note: The default password is 22222).
4. Select Config. Server.
5. Select Option 2, TFTP Settings.
6. Select Primary Server.
7. Use the Keypad to input the IP address of the PBX. Then press the DONE button.
Options
GoodbyeRedialHold

Chapters
Reset to Factory Defaults
How to Find the IP Address and MAC Address
How to Set the TFTP Boot Server
Reset to Factory Defaults
Quick Steps
1. Select the Options button.
2. Select the Admin Menu Option.
3. Enter the Admin Password. (Note: The default password is 22222).
4. Select option 4, Factory Default.
5. Press Default on the right hand side of the screen to confirm. The phone will now reboot and
will be defaulted when it starts back up.
How to Find the IP Address and MAC Address
Quick Steps
1. Select the Options button
2. Next select Phone Status, Option 2.
3. You will now select Option 1, IP&MAC Address.
4. You will now be shown the current IP Address and the MAC address of the phone.
How to Set the TFTP Boot Server
Quick Steps
1. Select the Options button
2. Select the Admin Menu Option.
3. Enter the Admin Password. (Note: The default password is 22222).
4. Select Config. Server.
5. Select Option 2, TFTP Settings.
6. Select Primary Server.
7. Use the Keypad to input the IP address of the PBX. Then press the DONE button.
© Copyright Schmooze Com, 2012

Chapters
Reset to Factory Defaults
How to Find the IP Address and MAC Address
How to Set the TFTP Boot Server
Reset to Factory Defaults
Quick Steps
1. Select the Options button.
2. Select the Admin Menu Option.
3. Enter the Admin Password. (Note: The default password is 22222).
4. Select option 4, Factory Default.
5. Press Default on the right hand side of the screen to confirm. The phone will now reboot and
will be defaulted when it starts back up.
How to Find the IP Address and MAC Address
Quick Steps
1. Select the Options button
2. Next select Phone Status, Option 2.
3. You will now select Option 1, IP&MAC Address.
4. You will now be shown the current IP Address and the MAC address of the phone.
How to Set the TFTP Boot Server
Quick Steps
1. Select the Options button
2. Select the Admin Menu Option.
3. Enter the Admin Password. (Note: The default password is 22222).
4. Select Config. Server.
5. Select Option 2, TFTP Settings.
6. Select Primary Server.
7. Use the Keypad to input the IP address of the PBX. Then press the DONE button.
© Copyright Schmooze Com, 2012
