ABB ACS800-11 User manual

ACS800
Hardware Manual
ACS800-11 Drives (5.5 to 110 kW)
ACS800-U11 Drives (7.5 to 125 HP)

ACS800 Single Drive Manuals
HARDWARE MANUALS (appropriate manual is included in the
delivery)
ACS800-01/U1 Hardware Manual 0.55 to 110 kW (0.75 to 150 HP)
3AFE64382101 (English)
ACS800-01/U1 Marine Supplement 3AFE64291275 (English)
ACS800-02/U2 Hardware Manual 90 to 500 kW (125 to 600 HP)
3AFE64567373 (English)
ACS800-11/U11 Hardware Manual 5.5 to110kW(7.5to125HP)
3AFE68367883 (English)
ACS800-04 Hardware Manual 0.55 to 132 kW
3AFE68372984 (English)
ACS800-04/04M/U4 Hardware Manual 45 to 560 kW (60 to
600 HP) 3AFE64671006 (English)
ACS800-04/04M/U4 Cabinet Installation 45 to 560 kW (60 to
600 HP) 3AFE68360323 (English)
ACS800-07/U7 Hardware Manual 45 to 560 kW (50 to 600 HP)
3AFE64702165 (English)
ACS800-07/U7 Dimensional Drawings 45 to 560 kW (50 to
600 HP) 3AFE64775421
ACS800-07 Hardware Manual 500 to 2800 kW
3AFE64731165 (English)
ACS800-17 Hardware Manual 75 to 1120 kW
3AFE64681338 (English)
• Safety instructions
• Electrical installation planning
• Mechanical and electrical installation
• Motor control and I/O board (RMIO)
• Maintenance
• Technical data
• Dimensional drawings
• Resistor braking
FIRMWARE MANUALS, SUPPLEMENTS AND GUIDES
(appropriate documents are included in the delivery)
Standard Application Program Firmware Manual
3AFE64527592 (English)
System Application Program Firmware Manual
3AFE63700177 (English)
Application Program Template Firmware Manual
3AFE64616340 (English)
Master/Follower 3AFE64590430 (English)
PFC Application Program Firmware Manual
3AFE64649337 (English)
Extruder Control Program Supplement 3AFE64648543 (English)
Centrifuge Control Program Supplement 3AFE64667246 (English)
Traverse Control Program Supplement 3AFE64618334 (English)
Crane Control Program Firmware Manual 3BSE11179 (English)
Adaptive Programming Application Guide
3AFE64527274 (English)
OPTION MANUALS (delivered with optional equipment)
Fieldbus Adapters, I/O Extension Modules etc.

ACS800-11 Drives
5.5 to 110 kW
ACS800-U11 Drives
7.5 to 125 HP
Hardware Manual
3AFE68367883 Rev A EN
EFFECTIVE: 5.1.2005
2005 ABB Oy. All Rights Reserved.

Safety instructions
5
Safety instructions
What this chapter contains
This chapter contains the safety instructions which you must follow when installing,
operating and servicing the drive. If ignored, physical injury or death may follow, or
damage may occur to the drive, motor or driven equipment. Read the safety
instructions before you work on the unit.
To which products this chapter applies
This chapter applies to the ACS800-01/U1, ACS800-11/U11, ACS800-02/U2 and
ACS800-04/04M/U4 of frame sizes R7 and R8.
Use of warnings and notes
There are two types of safety instructions throughout this manual: warnings and
notes. Warnings caution you about conditions which can result in serious injury or
death and/or damage to the equipment. They also tell you how to avoid the danger.
Notes draw attention to a particular condition or fact, or give information on a
subject. The warning symbols are used as follows:
Dangerous voltage warning warns of high voltage which can cause
physical injury and/or damage to the equipment.
General warning warns about conditions, other than those caused by
electricity, which can result in physical injury and/or damage to the
equipment.
Electrostatic discharge warning warns of electrostatic discharge which
can damage the equipment.

Safety instructions
6
Installation and maintenance work
These warnings are intended for all who work on the drive, motor cable or motor.
WARNING! Ignoring the following instructions can cause physical injury or death, or
damage to the equipment:
•Only qualified electricians are allowed to install and maintain the drive.
•Never work on the drive, motor cable or motor when main power is applied.
After disconnecting the input power, always wait for 5 min to let the intermediate
circuit capacitors discharge before you start working on the drive, motor or
motor cable.
Always ensure by measuring with a multimeter (impedance at least 1 Mohm)
that:
1. voltage between drive input phases U1, V1 and W1 and the frame is close to
0V.
2. voltage between terminals UDC+ and UDC- and the frame is close to 0 V.
•Do not work on the control cables when power is applied to the drive or to the
external control circuits. Externally supplied control circuits may cause
dangerous voltages inside the drive even when the main power on the drive is
switched off.
•Do not make any insulation or voltage withstand tests on the drive or drive
modules.
•When reconnecting the motor cable, always check that the phase order is
correct.
Note:
•The motor cable terminals on the drive are at a dangerously high voltage when
the input power is on, regardless of whether the motor is running or not.
•The brake control terminals (UDC+, UDC-, R+ and R- terminals) carry a
dangerous DC voltage (over 500 V).
•Depending on the external wiring, dangerous voltages (115 V, 220 V or 230 V)
may be present on the terminals of relay outputs RO1 to RO3.
•ACS800-02 with enclosure extension: The main switch on the cabinet door
does not remove the voltage from the input busbars of the drive. Before working
on the drive, isolate the whole drive from the supply.
•The Prevention of Unexpected Start function does not remove the voltage from
the main and auxiliary circuits.

Safety instructions
7
Grounding
These instructions are intended for all who are responsible for the grounding of the
drive.
WARNING! Ignoring the following instructions can cause physical injury, death,
increased electromagnetic interference and equipment malfunction:
•Ground the drive, motor and adjoining equipment to ensure personnel safety in
all circumstances, and to reduce electromagnetic emission and pick-up.
•Make sure that grounding conductors are adequately sized as required by
safety regulations.
•In a multiple-drive installation, connect each drive separately to protective
earth (PE).
•ACS800-01, ACS800-11: In European CE compliant installations and in other
installations where EMC emissions must be minimized, make a 360° high
frequency grounding of cable entries in order to suppress electromagnetic
disturbances. In addition, connect the cable shields to protective earth (PE) in
order to meet safety regulations.
ACS800-04 (45 to 560 kW) and ACS800-02 in first environment: make a 360°
high frequency grounding of motor cable entries at the cabinet lead-through.
•Do not install a drive with EMC filter option +E202 or +E200 (available for
ACS800-01 and ACS800-11 only) on an ungrounded power system or a high-
resistance-grounded (over 30 ohms) power system.
Note:
•Power cable shields are suitable for equipment grounding conductors only
when adequately sized to meet safety regulations.
•As the normal leakage current of the drive is higher than 3.5 mA AC or 10 mA
DC (stated by EN 50178, 5.2.11.1), a fixed protective earth connection is
required.

Safety instructions
8
Mechanical installation and maintenance
These instructions are intended for all who install and service the drive.
WARNING! Ignoring the following instructions can cause physical injury or death,
or damage to the equipment:
•Handle the unit carefully.
•ACS800-01, ACS800-11: The drive is heavy. Do not lift it alone. Do not lift the
unit by the front cover. Place the unit only on its back.
ACS800-02, ACS800-04: The drive is heavy. Lift the drive by the lifting lugs
only. Do not tilt the unit. The unit will overturn from a tilt of about 6 degrees.
Use extreme caution when manoeuvring a drive that runs on wheels. An
overturning unit can cause physical injury.
•Beware of hot surfaces. Some parts, such as heatsinks of power
semiconductors, remain hot for a while after disconnection of the electrical
supply.
•Make sure that dust from drilling does not enter the drive when installing.
Electrically conductive dust inside the unit may cause damage or
malfunctioning.
•Ensure sufficient cooling.
•Do not fasten the drive by riveting or welding.
Do not tilt!

Safety instructions
9
Printed circuit boards
Fibre optic cables
WARNING! Ignoring the following instructions can cause damage to the printed
circuit boards:
•The printed circuit boards contain components sensitive to electrostatic
discharge. Wear a grounding wrist band when handling the boards. Do not
touch the boards unnecessarily.
WARNING! Ignoring the following instructions can cause equipment malfunction
and damage to the fibre optic cables:
•Handle the fibre optic cables with care. When unplugging optic cables, always
grab the connector, not the cable itself. Do not touch the ends of the fibres with
bare hands as the fibre is extremely sensitive to dirt. The minimum allowed
bend radius is 35 mm (1.4 in.).

Safety instructions
10
Operation
These warnings are intended for all who plan the operation of the drive or operate
the drive.
WARNING! Ignoring the following instructions can cause physical injury or death,
or damage to the equipment:
•Before adjusting the drive and putting it into service, make sure that the motor
and all driven equipment are suitable for operation throughout the speed range
provided by the drive. The drive can be adjusted to operate the motor at
speeds above and below the speed provided by connecting the motor directly
to the power line.
•Do not activate automatic fault reset functions of the Standard Application
Program if dangerous situations can occur. When activated, these functions
will reset the drive and resume operation after a fault.
•Do not control the motor with the disconnecting device (disconnecting means);
instead, use the control panel keys and , or commands via the I/O
board of the drive. The maximum allowed number of charging cycles of the DC
capacitors (i.e. power-ups by applying power) is five in ten minutes.
•Do not use the optional Prevention of Unexpected Start function for stopping
the drive when the drive is running. Give a Stop command instead.
Note:
•If an external source for start command is selected and it is ON, the drive (with
Standard Application Program) will start immediately after fault reset unless the
drive is configured for 3-wire (a pulse) start/stop.
•When the control location is not set to Local (L not shown in the status row of
the display), the stop key on the control panel will not stop the drive. To stop
the drive using the control panel, press the LOC/REM key and then the stop
key .
