Relion® 670 series
Transformer protection RET670 2.0
Product guide

Contents
1. Application..................................................................... 3
2. Available functions........................................................10
3. Differential protection....................................................23
4. Impedance protection.................................................. 25
5. Current protection........................................................ 29
6. Voltage protection........................................................ 31
7. Frequency protection....................................................32
8. Multipurpose protection................................................32
9. Secondary system supervision..................................... 33
10. Control........................................................................ 33
11. Scheme communication..............................................35
12. Logic...........................................................................35
13. Monitoring...................................................................36
14. Metering......................................................................38
15. Human machine interface............................................39
16. Basic IED functions..................................................... 39
17. Station communication ...............................................39
18. Remote communication.............................................. 40
19. Hardware description.................................................. 40
20. Connection diagrams.................................................. 43
21. Technical data.............................................................44
22. Ordering for customized IED......................................104
23. Ordering for pre-configured IED.................................115
24. Ordering for Accessories........................................... 121
Disclaimer
The information in this document is subject to change without notice and should not be construed as a commitment by ABB. ABB assumes no responsibility for any errors
that may appear in this document. Drawings and diagrams are not binding.
© Copyright 2014 ABB.
All rights reserved.
Trademarks
ABB and Relion are registered trademarks of the ABB Group. All other brand or product names mentioned in this document may be trademarks or registered trademarks
of their respective holders.
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
2 ABB

1. Application
RET670 provides fast and selective protection, monitoring and
control for two- and three-winding transformers,
autotransformers, step-up transformers and generator-
transformer block units, phase shifting transformers, special
railway transformers and shunt reactors. The IED is designed to
operate correctly over a wide frequency range in order to
accommodate power system frequency variations during
disturbances and generator start-up and shut-down.
RET670 has a fast, low-impedance differential protection
function with very low requirements on the CTs.It is suitable for
differential applications with multi-breaker arrangements with
up to six restraint CT inputs. The differential protection function
is provided with a 2nd harmonic and waveform-block restraint
feature to avoid tripping for CT saturation and transformer
inrush current, and 5th harmonic restraint to avoid tripping for
transformer overexcitation.
The differential function offers a high sensitivity for low-level
internal faults by using a sensitive differential protection feature
based on an amplitude measurement and directional
comparison of the negative sequence components.
Multiple low impedance restricted earth-fault protection
functions are available as a sensitive and fast main protection
against winding earth faults. This function includes a internal/
external fault discriminator for additional security.
Additionally, a high impedance differential protection function is
available. It can be used for different applications including
restricted earth fault protection as winding protection,
autotransformer differential protection, shunt reactor
protection, T-feeder protection, busbar protection and
generator differential protection.
Tripping and alarm signals from pressure relief, Buchholz and
temperature devices can be sent directly to RET670 via binary
input channels for alarm and back-up purposes. The binary
inputs are highly stabilized against disturbances to prevent
incorrect operation due to, for example, DC system capacitive
discharges or DC earth faults.
Distance protection functionality is available as back-up
protection for faults within the transformer and in the connected
power system.
Positive, negative and zero sequence overcurrent functions,
which can optionally be made directional and/or voltage
controlled, provide further alternative backup protection.
Thermal overload, overexcitation, over/under voltage and over/
under frequency protection functions are also available.
Breaker failure protection for each transformer breaker allows
high speed back-up tripping of surrounding breakers.
A built-in disturbance and event recorder provides valuable
data to the user about status and operation for post-fault
disturbance analysis.
RET670 can optionally be provided with full control and
interlocking functionality including a synchrocheck function to
allow integration of the main or local back-up control
functionality.
A pole slip protection function is also available in RET670 to
detect, evaluate, and take the required action for pole slipping
occurrences in the power system. The electrical system parts
swinging to each other can be separated with the line(s) closest
to the centre of the power swing, allowing the two systems to
be stable when separated.
RET670 can be used in applications with the IEC 61850-9-2LE
process bus with up to six merging units (MU).
The advanced logic capability, where user logic is prepared
with a graphical tool, allows for special applications such as
automatic opening of disconnectors in multi-breaker
arrangements, closing of breaker rings and load transfer logic.
Logic can be monitored and debugged online in real time for
testing and commissioning.
Communication via optical connections ensures immunity
against disturbances.
Six packages have been defined for the following applications:
• Transformer back-up protection (A10)
• Voltage control (A25)
• Two-winding transformer in single breaker arrangements
(A30)
• Two-winding transformer in multi breaker arrangements
(B30)
• Three-winding transformer in single breaker arrangements
(A40)
• Three-winding transformer in multi breaker arrangements
(B40)
Optional functions are not configured but a maximum
configuration with all optional functions are available as
template in the graphical configuration tool. An alternative for
Autotransformers is also available as a configuration template.
Analog and tripping IO has been pre-defined for basic use on
the, as standard supplied one binary input module and one
binary output module. Add binary I/O as required for your
application at ordering. Other signals need to be applied as
required for each application.
For details on included basic functions, refer to chapter "Basic
IED functions"
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0 Issued: July 2016
Revision: C
ABB 3

Description of configuration A30
RET670 A30 –2 Winding Transformer in single
breaker arrangement 12AI (9I+3U)
W2_QA1
W1_QB2W1_QB1
W1_QA1
W1
W2
PH PIOC
50 3I>>
OC4 PTOC
51 4(3I>)
CC RBRF
50BF 3I>BF
OC4 PTOC
51 3I>
CC RBRF
50BF 3I>BF
FUF SPVC
U>/I<
SMP PTRC
94 1 → 0
ETP MMTR
MET W/Varh
C MSQI
MET Isqi
TR PTTR
49 θ>
EF4 PTOC
51N 4(IN>)
T2W PDIF
87T 3Id/I>
C MSQI
MET Isqi
LOV PTUV
27 3U<
SMP PTRC
94 1 → 0
TCM YLTC
84 ↑↓
DRP RDRE
DFR/SER DR
V MMXU
MET U
OV2 PTOV
59 2(3U>)
REF PDIF
87N IdN/I
REF PDIF
87N IdN/I
C MMXU
MET I
UV2 PTUV
27 2(3U<)
C MMXU
MET I
EF PIOC
50N IN>>
CV MMXN
MET P/Q
EF4 PTOC
51N_67N 4(IN>)
V MSQI
MET Usqi
WA1
WA2
W1_CT
W1_NCT
W2_NCT
W2_CT
W2_VT
WA1
Other Functions available from the function library
Optional Functions
CC PDSC
52PD PD
BRC PTOC
46 Iub>
VDC PTOV
60 Ud>
EC PSCH
85
Q CBAY
3 Control
CCS SPVC
87 INd/I
ECRW PSCH
85
S SIMG
63
87 Id>
HZ PDIF ZMH PDIS
21 Z<
NS4 PTOC
46I2 4(I2>)
TR1 ATCC
90 ↑↓
CV GAPC
2(I>/U<)
SA PFRC
81 df/dt <>
SA PTOF
81 f>
SA PTUF
81 f<
OEX PVPH
24 U/f>
ZMQ PDIS
21 Z<
ZM RPSB
68 Zpsb 32 P>
GOP PDOP
GUP PDUP
37 P<
TR8 ATCC
90 ↑↓
TCL YLTC
84 ↑↓
SDE PSDE
67N IN>
S CILO
3 Control
S CSWI
3 Control
S XSWI
3 Control
S XCBR
3 Control
S SIML
71
Q CRSV
3 Control
S SCBR FDPS PDIS
21
VD SPVC
60 Ud>
ZDM RDIR
21D Z<_>
ZDA RDIR
21 Z<_>
ZD RDIR
21D Z<_>
ZMM PDIS
21 Z<
ZGV PDIS
21 Z<
ZMMA PDIS
21 Z<
ZMQA PDIS
21 Z<
ZSM GAPC
FMPS PDIS
21
VN MMXU
MET UN
IEC05000848-3-en.vsd
IEC05000848 V4 EN
Figure 1. Configuration diagram for configuration A30
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
4 ABB

Description of configuration B30
RET670 B30 - 2 Winding Transformer in multi
breaker arrangement 24AI (9I+3U, 9I+3U)
QB9
PH PIOC
50 3I>>
EF PIOC
50N IN>>
W1_QB2
W1_QB1
TCM YLTC
84 ↑↓
OC4 PTOC
51 4(3I>)
CC RBRF
50BF 3I> BF
W1_QA2
W1_QA1
QB61 QB62
CC RBRF
50BF 3I> BF
CC PDSC
52PD PD
C MSQI
MET Isqi
C MMXU
MET I
CC PDSC
52PD PD
W2_QA1
DRP RDRE
DFR/DER DR
V MMXU
MET U
V MSQI
MET Usqi
LOV PTUV
27 3U<
UV2 PTUV
27 2(3U<)
OV2 PTOV
59 2(3U>)
ETP MMTR
MET W/Varh
CV MMXN
MET P/Q
EF4 PTOC
51N 4(IN>)
REF PDIF
87N IdN/I
CC RBRF
50BF 3I> BF 51 4(3I>)
OC4 PTOC TR PTTR
49 θ>
C MMXU
MET I
C MSQI
MET Isqi
FUF SPVC
U>/I<
W1
W2
SMP PTRC
94 1 → 0
SMP PTRC
94 1 → 0
94 1 → 0
SMP PTRC
Other Functions available from the function library
Optional Functions
BRC PTOC
46 Iub>
VDC PTOV
60 Ud>
EC PSCH
85
Q CBAY
3 Control
CCS SPVC
87 INd/I
ECRW PSCH
85
S SIMG
63
87 Id>
HZ PDIF ZMH PDIS
21 Z<
NS4 PTOC
46I2 4(I2>)
TR1 ATCC
90 ↑↓
CV GAPC
2(I>/U<)
SA PFRC
81 df/dt <>
SA PTOF
81 f>
SA PTUF
81 f<
OEX PVPH
24 U/f>
ZMQ PDIS
21 Z<
ZM RPSB
68 Zpsb 32 P>
GOP PDOP
GUP PDUP
37 P<
TR8 ATCC
90 ↑↓
TCL YLTC
84 ↑↓
SDE PSDE
67N IN>
S CILO
3 Control
S CSWI
3 Control
S XSWI
3 Control
S XCBR
3 Control
S SIML
71
Q CRSV
3 Control
S SCBR FDPS PDIS
21
VD SPVC
60 Ud>
ZDM RDIR
21D Z<_>
ZDA RDIR
21 Z<_>
ZD RDIR
21D Z<_>
ZMM PDIS
21 Z<
ZGV PDIS
21 Z<
ZMMA PDIS
21 Z<
ZMQA PDIS
21 Z<
ZSM GAPC
FMPS PDIS
21
VN MMXU
MET UN
EF4 PTOC
51N_67N 4(IN>)
WA1 WA2
W1_CT2
W1_CT1
W1_NCT
W2_NCT
W2_CT
W2_VT
WA1
W2_WA1_VT
T2W PDIF
87T 3Id/I>
REF PDIF
87N IdN/I
VN MMXU
MET UN
SES RSYN
25 SC/VC
IEC05000849-3-en.vsd
IEC05000849 V4 EN
Figure 2. Configuration diagram for configuration B30
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
ABB 5

Description of configuration A40
RET670 A40 –3 Winding Transformer in single
breaker arrangement 24AI (9I+3U, 9I+3U)
W2_QA1
W1_QB2W1_QB1
W3_QA1
W1_QA1
Other Functions available from the function library
Optional Functions
W1
W2
W3
PH PIOC
50 3I>>
OC4 PTOC
51 4(3I>)
CC RBRF
50BF 3I>BF
OC4 PTOC
51 4(3I>)
CC RBRF
50BF 3I>BF
OC4 PTOC
51 3I>
CC RBRF
50BF 3I>BF
FUF SPVC
U>/I<
SMP PTRC
94 1 → 0
SMP PTRC
94 1 → 0
ETP MMTR
MET W/Varh
C MSQI
MET Isqi
C MMXU
MET I
TR PTTR
49 θ>
EF4 PTOC
51N 4(IN>)
CC PDSC
52PD PD
T3W PDIF
87T 3Id/I>
C MSQI
MET Isqi
TR PTTR
49 θ>
LOV PTUV
27 3U<
BRC PTOC
46 Iub>
VDC PTOV
60 Ud>
EC PSCH
85
Q CBAY
3 Control
CCS SPVC
87 INd/I
ECRW PSCH
85
S SIMG
63
87 Id>
HZ PDIF ZMH PDIS
21 Z<
NS4 PTOC
46I2 4(I2>)
TR1 ATCC
90 ↑↓
CV GAPC
2(I>/U<)
SA PFRC
81 df/dt <>
SA PTOF
81 f>
SA PTUF
81 f<
OEX PVPH
24 U/f>
SMP PTRC
94 1 → 0
TCM YLTC
84 ↑↓
DRP RDRE
DFR/SER DR
V MMXU
MET U
OV2 PTOV
59 2(3U>)
REF PDIF
87N IdN/I
REF PDIF
87N IdN/I
EF4 PTOC
51N_67N 4(IN>)
C MMXU
MET I
ZMQ PDIS
21 Z<
ZM RPSB
68 Zpsb 32 P>
GOP PDOP
UV2 PTUV
27 2(3U<)
C MMXU
MET I
EF PIOC
50N IN>>
C MSQI
MET Isqi
GUP PDUP
37 P<
TR8 ATCC
90 ↑↓
ROV2 PTOV
59N 2(U0>)
CV MMXN
MET P/Q
TCL YLTC
84 ↑↓
SDE PSDE
67N IN>
S CILO
3 Control
S CSWI
3 Control
S XSWI
3 Control
S XCBR
3 Control
EF4 PTOC
51N_67N 4(IN>)
VN MMXU
MET UN
V MSQI
MET Usqi
VN MMXU
MET UN
S SIML
71
Q CRSV
3 Control
S SCBR FDPS PDIS
21
VD SPVC
60 Ud>
ZDM RDIR
21D Z<_>
ZDA RDIR
21 Z<_>
ZD RDIR
21D Z<_>
ZMM PDIS
21 Z<
ZGV PDIS
21 Z<
ZMMA PDIS
21 Z<
ZMQA PDIS
21 Z<
ZSM GAPC
FMPS PDIS
21
WA1
WA2
W1_CT
W1_NCT
W2_NCT
W3_CT
W2_CT
W2_VT
W3_VT_3U0
W2_WA1_VT
WA1
WA1
VN MMXU
MET UN
SES RSYN
25 SC/VC
IEC05000850-3-en.vsd
IEC05000850 V4 EN
Figure 3. Configuration diagram for configuration A40
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
6 ABB

Description of configuration B40
RET670 B40 - 3 Winding Transformer in multi
breaker arrangement 24AI (9I+3U, 9I+3U)
QB9
PH PIOC
50 3I>>
EF PIOC
50N IN>>
W1_QB2
W1_QB1
TCM YLTC
84 ↑↓
OC4 PTOC
51 4(3I>)
CC RBRF
50BF 3I> BF
W1_QA2
W1_QA1
QB61 QB62
CC RBRF
50BF 3I> BF
CC PDSC
52PD PD
C MSQI
MET Isqi
C MMXU
MET I
CC PDSC
52PD PD
W2_QA1
W3_QA1
DRP RDRE
DFR/DER DR
V MMXU
MET U
V MSQI
MET Usqi
LOV PTUV
27 3U<
UV2 PTUV
27 2(3U<)
OV2 PTOV
59 2(3U>)
ETP MMTR
MET W/Varh
CV MMXN
MET P/Q
ROV2 PTOV
59N 2(U0>)
EF4 PTOC
51N_67N 4(IN>)
EF4 PTOC
51N 4(IN>)
REF PDIF
87N IdN/I
CC RBRF
50BF 3I> BF
OC4 PTOC
51 4(3I>)
TR PTTR
49 θ>
C MMXU
MET I
C MSQI
MET Isqi
CC RBRF
50BF 3I> BF 51 4(3I>)
OC4 PTOC TR PTTR
49 θ>
C MMXU
MET I
C MSQI
MET Isqi
FUF SPVC
U>/I<
W1
W2
W3
94 1 → 0
SMP PTRC
SMP PTRC
94 1 → 0
SMP PTRC
94 1 → 0
94 1 → 0
SMP PTRC
REF PDIF
87N IdN/I
T3W PDIF
87T 3Id/I>
Other Functions available from the function library
Optional Functions
BRC PTOC
46 Iub>
VDC PTOV
60 Ud>
EC PSCH
85
Q CBAY
3 Control
CCS SPVC
87 INd/I
ECRW PSCH
85
S SIMG
63
87 Id>
HZ PDIF ZMH PDIS
21 Z<
NS4 PTOC
46I2 4(I2>)
TR1 ATCC
90 ↑↓
CV GAPC
2(I>/U<)
SA PFRC
81 df/dt <>
SA PTOF
81 f>
SA PTUF
81 f<
OEX PVPH
24 U/f>
ZMQ PDIS
21 Z<
ZM RPSB
68 Zpsb 32 P>
GOP PDOP
GUP PDUP
37 P<
TR8 ATCC
90 ↑↓
TCL YLTC
84 ↑↓
SDE PSDE
67N IN>
S CILO
3 Control
S CSWI
3 Control
S XSWI
3 Control
S XCBR
3 Control
S SIML
71
Q CRSV
3 Control
S SCBR FDPS PDIS
21
VD SPVC
60 Ud>
ZDM RDIR
21D Z<_>
ZDA RDIR
21 Z<_>
ZD RDIR
21D Z<_>
ZMM PDIS
21 Z<
ZGV PDIS
21 Z<
ZMMA PDIS
21 Z<
ZMQA PDIS
21 Z<
ZSM GAPC
FMPS PDIS
21
VN MMXU
MET UN
VN MMXU
MET UN
EF4 PTOC
51N_67N 4(IN>)
WA1 WA2
W1_CT2
W1_CT1
W1_NCT
W2_NCT
W3_VT_3U0
W3_CT
W2_CT
W2_VT
WA1
W2_WA1_VT
WA1
VN MMXU
MET UN
SES RSYN
25 SC/VC
IEC05000851-3-en.vsd
IEC05000851 V4 EN
Figure 4. Configuration diagram for configuration B 40
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
ABB 7

Description of configuration A10
RET670 A10 –Transformer backup protection
12AI (9I+3U)
W2_QA1
W1_QB2W1_QB1
W3_QA1
W1_QA1
W1
W2
W3
PH PIOC
50 3I>>
OC4 PTOC
51 4(3I>)
CC RBRF
50BF 3I>BF
OC4 PTOC
51 4(3I>)
CC RBRF
50BF 3I>BF
OC4 PTOC
51 3I>
CC RBRF
50BF 3I>BF
SMP PTRC
94 1 → 0
SMP PTRC
94 1 → 0
C MSQI
MET Isqi
C MMXU
MET I
TR PTTR
49 θ>
C MSQI
MET Isqi
SMP PTRC
94 1 → 0
DRP RDRE
DFR/SER DR
EF4 PTOC
51N 4(IN>)
C MMXU
MET I
C MMXU
MET I
EF PIOC
50N IN>>
C MSQI
MET Isqi
VN MMXU
MET UN
WA1
WA2
W1_CT
W3_CT
W2_CT
W2_VT
W2_WA1_VT
WA1
WA1
EF4 PTOC
51N 4(IN>)
Other Functions available from the function library
Optional Functions
V MSQI
MET UN
ETP MMTR
MET W/Varh
S SIMG
63
V MMXU
MET U
LOV PTUV
27 3U<
SDE PSDE
67N IN>
HZ PDIF
87 Id>
ROV2 PTOV
59N 2(U0>)
NS4 PTOC
46I2 4(I2>)
SA PFRC
81 df/dt<>
SA PTOF
81 f>
SA PTUF
81 f<
UV2 PTUV
27 2(3U<)
OV2 PTOV
59 2(3U>)
REF PDIF
87N IdN/I
VDC PTOV
60 Ud>
BRC PTOC
46 Iub>
VD SPVC
60 Ud>
S SCBR
S SIML
71
Q CBAY
3 Control
VN MMXU
MET UN
EF4 PTOC
51N 4(IN>)
SES RSYN
25 SC/VC
CV MMXN
MET P/Q
IEC07000191-3-en.vsd
IEC07000191 V4 EN
Figure 5. Configuration diagram for configuration A10
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
8 ABB

Description of configuration A25
RET670 A25 –Voltage Control 12AI (6I+6U)
TCM YLTC
84 ↑↓
C MMXU
MET I
TCM YLTC
84 ↑↓
DRP RDRE
DFR/SER DR
TRF1_W2_QA1
QA11
CCS SPVC
87 INd/I
Other Functions available from the function library
Optional Functions
LOV PTUV
27 3U<
ETP MMTR
MET W/Varh
VDC PTOV
60 Ud>
SMP PTRC
94 1 → 0
EF PIOC
50N IN>>
PH PIOC
50 3I>>
TCL YLTC
84 ↑↓
SDE PSDE
67N IN>
NS4 PTOC
46I2 4(I2>)
OC4 PTOC
51_67 4(3I>)
UV2 PTUV
27 2(3U<)
OV2 PTOV
59 2(3U>)
ROV2 PTOV
59N 2(U0>)
S SIMG
63
S CILO
3 Control
S CSWI
3 Control
S XSWI
3 Control
S XCBR
3 Control
BRC PTOC
46 Iub>
TR1 ATCC
90 ↑↓
TR8 ATCC
90 ↑↓
TR8 ATCC
90 ↑↓
C MSQI
MET Isqi
CV MMXN
P/QMET
CV MMXN
MET P/Q
C MSQI
MET Isqi
C MMXU
MET I
V MMXU
MET U
Q CBAY
3 Control
S SIML
71
EF4 PTOC
51N_67N 4(IN>)
Q CRSV
3 Control
VD SPVC
60 Ud>
TRF1_W2_VT
TRF2_W2_VT
TRF1_W2_CT
TRF2_W2_CT
W1
W2
TRF1
W1
W2
TRF2
TRF2_W2_QA1
VN MMXU
MET UN
V MSQI
UsqiMET
VN MMXU
MET UN
V MMXU
MET U
V MSQI
UsqiMET
IEC07000192 V3 EN
Figure 6. Configuration diagram for configuration A25
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
ABB 9

2. Available functions
Main protection functions
2 = number of basic instances
0-3 = option quantities
3-A03 = optional function included in packages A03 (refer to ordering details)
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
10 ABB

IEC 61850 ANSI Function description Transformer
RET670
RET670 (A10) RET670 (A30)
RET670 (B30)
RET670 (A40)
RET670 (B40)
RET670 (A25)
Differential protection
T2WPDIF 87T Transformer differential
protection, two winding
1-2 1 1
T3WPDIF 87T Transformer differential
protection, three winding
1-2 1 1
HZPDIF 87 1Ph high impedance differential
protection
0-6 1 3-A02 3-A02 3-A02 3-A02
REFPDIF 87N Restricted earth fault protection,
low impedance
0-3 1 2 2 2-B
1-A01
2-B
1-A01
LDRGFC 11REL Additional security logic for
differential protection
0-1
Impedance protection
ZMQPDIS,
ZMQAPDIS
21 Distance protection zone,
quadrilateral characteristic
0-5 4-B12 4-B12 4-B12 4-B12
ZDRDIR 21D Directional impedance
quadrilateral
0-2 2-B12 2-B12 2-B12 2-B12
ZMCAPDIS 21 Additional distance measuring
zone, quadrilateral characteristic
ZMCPDIS,
ZMCAPDIS
21 Distance measuring zone,
quadrilateral characteristic for
series compensated lines
0-5
ZDSRDIR 21D Directional impedance
quadrilateral, including series
compensation
0-2
FDPSPDIS 21 Phase selection, quadrilateral
characteristic with fixed angle
0-2 2-B12 2-B12 2-B12 2-B12
ZMHPDIS 21 Fullscheme distance protection,
mho characteristic
0-5 4-B13 4-B13 4-B13 4-B13
ZMMPDIS,
ZMMAPDIS
21 Fullscheme distance protection,
quadrilateral for earth faults
0-5 4-B13 4-B13 4-B13 4-B13
ZDMRDIR 21D Directional impedance element
for mho characteristic
0-2 2-B13 2-B13 2-B13 2-B13
ZDARDIR Additional distance protection
directional function for earth
faults
0-1 1-B13 1-B13 1-B13 1-B13
ZSMGAPC Mho impedance supervision logic 0-1 1-B13 1-B13 1-B13 1-B13
FMPSPDIS 21 Faulty phase identification with
load enchroachment
0-2 2-B13 2-B13 2-B13 2-B13
ZMRPDIS,
ZMRAPDIS
21 Distance protection zone,
quadrilateral characteristic,
separate settings
0-5
FRPSPDIS 21 Phase selection, quadrilateral
characteristic with fixed angle
0-2
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
ABB 11

IEC 61850 ANSI Function description Transformer
RET670
RET670 (A10) RET670 (A30)
RET670 (B30)
RET670 (A40)
RET670 (B40)
RET670 (A25)
ZMFPDIS 21 High speed distance protection 0–1
ZMFCPDIS 21 High speed distance protection
for series compensated lines
0–1
ZMRPSB 68 Power swing detection 0-1 1-B12
1-B13
1-B12
1-B13
1-B12
1-B13
1-B12
1-B13
PSLPSCH Power swing logic 0-1
PSPPPAM 78 Pole slip/out-of-step protection 0-1
OOSPPAM 78 Out-of-step protection 0–1
PPLPHIZ Phase preference logic 0-1
ZGVPDIS 21 Underimpedance for generators
and transformers
0–1 1-B14 1-B14 1-B14 1-B14
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
12 ABB

Back-up protection functions
IEC 61850 ANSI Function description Transformer
RET670
RET670 (A10) RET670 (A30)
RET670 (B30)
RET670 (A40)
RET670 (B40)
RET670 (A25)
Current protection
PHPIOC 50 Instantaneous phase
overcurrent protection
0-8 3 2 2 3 3 2-C19
OC4PTOC 51_671) Four step phase overcurrent
protection
0-8 3 2 2 3 3 2-C19
EFPIOC 50N Instantaneous residual
overcurrent protection
0-8 3 2 2 3 3 2-C19
EF4PTOC 51N
67N2)
Four step residual overcurrent
protection
0-8 3 2 2 3 3 2-C19
NS4PTOC 46I2 Four step directional negative
phase sequence overcurrent
protection
0-8 2-C42 2-C42 2-C42 3-C43 3-C43 2-C19
SDEPSDE 67N Sensitive directional residual
overcurrent and power
protection
0-3 1 1-C16 1-C16 1-C16 1-C16 1-C16
LCPTTR 26 Thermal overload protection,
one time constant, Celsius
0–2
LFPTTR 26 Thermal overload protection,
one time constant, Fahrenheit
0–2
TRPTTR 49 Thermal overload protection,
two time constant
0-6 1 1B
1-C05
1B
1-C05
2B
1-C05
2B
1-C05
CCRBRF 50BF Breaker failure protection 0-6 3 2 4 3 6
CCPDSC 52PD Pole discordance protection 0-2 1 2 1 2
GUPPDUP 37 Directional underpower
protection
0-2 1-C17 1-C17 1-C17 1-C17
GOPPDOP 32 Directional overpower
protection
0-2 1-C17 1-C17 1-C17 1-C17
BRCPTOC 46 Broken conductor check 1 1 1 1 1 1 1
CBPGAPC Capacitor bank protection 0-6
NS2PTOC 46I2 Negative sequence time
overcurrent protection for
machines
0-2
VRPVOC 51V Voltage restrained overcurrent
protection
0-3
Voltage protection
UV2PTUV 27 Two step undervoltage
protection
0-3 1-D01 1B
1-D01
1B
1-D01
1B
2-D02
1B
2-D02
2-D02
OV2PTOV 59 Two step overvoltage protection 0-3 1-D01 1B
1-D01
1B
1-D01
1B
1-D02
1B
1-D02
2-D02
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
ABB 13

IEC 61850 ANSI Function description Transformer
RET670
RET670 (A10) RET670 (A30)
RET670 (B30)
RET670 (A40)
RET670 (B40)
RET670 (A25)
ROV2PTOV 59N Two step residual overvoltage
protection
0-3 1-D01 1B
1-D01
1B
1-D01
1B
1-D02
1B
1-D02
2-D02
OEXPVPH 24 Overexcitation protection 0-2 1-D03 1-D03 2-D04 2-D04
VDCPTOV 60 Voltage differential protection 0-2 2 2 2 2 2 2
LOVPTUV 27 Loss of voltage check 1 1 1 1 1 1 1
Frequency protection
SAPTUF 81 Underfrequency protection 0-6 6-E01 6-E01 6-E01 6-E01 6-E01
SAPTOF 81 Overfrequency protection 0-6 6-E01 6-E01 6-E01 6-E01 6-E01
SAPFRC 81 Rate-of-change frequency
protection
0-6 6-E01 6-E01 6-E01 6-E01 6-E01
Multipurpose protection
CVGAPC General current and voltage
protection
0-9 6-F02 6-F02 6-F02 6-F02
General calculation
SMAIHPAC Multipurpose filter 0-6
1) 67 requires voltage
2) 67N requires voltage
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
14 ABB

Control and monitoring functions
IEC 61850 ANSI Function description Transformer
RET670
RET670 (A10) RET670 (A30)
RET670 (B30)
RET670 (A40)
RET670 (B40)
RET670 (A25)
Control
SESRSYN 25 Synchrocheck, energizing check and
synchronizing
0-6 1 1 1-B, 2-
H01
1-B, 3-
H02
1-B, 4-
H03
APC30 3 Apparatus control for up to 6 bays, max
30 apparatuses (6CBs) incl.
interlocking
0-1 1-H09 1-H09 1-H09 1-H09 1-H09
QCBAY Apparatus control 1+5/APC30 1 1+5/
APC30
1+5/
APC30
1+5/
APC30
1+5/
APC30
1+5/
APC30
LOCREM Handling of LRswitch positions 1+5/APC30 1 1+5/
APC30
1+5/
APC30
1+5/
APC30
1+5/
APC30
1+5/
APC30
LOCREMCTRL LHMI control of PSTO 1+5/APC30 1 1+5/
APC30
1+5/
APC30
1+5/
APC30
1+5/
APC30
1+5/
APC30
TR1ATCC 90 Automatic voltage control for tap
changer, single control
0-4 1-H11 1-H11 1-H11,
2-H16
1-H11,
2-H16
2
2-H16
TR8ATCC 90 Automatic voltage control for tap
changer, parallel control
0-4 1-H15 1-H15 1-H15,
2-H18
1-H15,
2-H18
2
2-H18
TCMYLTC 84 Tap changer control and supervision, 6
binary inputs
0-4 4 4 4 4 4
TCLYLTC 84 Tap changer control and supervision,
32 binary inputs
0-4 4 4 4 4 4
SLGAPC Logic rotating switch for function
selection and LHMI presentation
15 15 15 15 15 15 15
VSGAPC Selector mini switch 20 20 20 20 20 20 20
DPGAPC Generic communication function for
Double Point indication
16 16 16 16 16 16 16
SPC8GAPC Single point generic control 8 signals 5 5 5 5 5 5 5
AUTOBITS AutomationBits, command function for
DNP3.0
3 3 3 3 3 3 3
SINGLECMD Single command, 16 signals 4 4 4 4 4 4 4
VCTRSEND Horizontal communication via GOOSE
for VCTR
1 1 1 1 1 1 1
GOOSEVCTRRC
V
Horizontal communication via GOOSE
for VCTR
7 7 7 7 7 7 7
I103CMD Function commands for IEC
60870-5-103
1 1 1 1 1 1 1
I103GENCMD Function commands generic for IEC
60870-5-103
50 50 50 50 50 50 50
I103POSCMD IED commands with position and select
for IEC 60870-5-103
50 50 50 50 50 50 50
I103IEDCMD IED commands for IEC 60870-5-103 1 1 1 1 1 1 1
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
ABB 15

IEC 61850 ANSI Function description Transformer
RET670
RET670 (A10) RET670 (A30)
RET670 (B30)
RET670 (A40)
RET670 (B40)
RET670 (A25)
I103USRCMD Function commands user defined for
IEC 60870-5-103
1 1 1 1 1 1 1
Secondary system supervision
CCSSPVC 87 Current circuit supervision 0-5 2 3 3 5 4
FUFSPVC Fuse failure supervision 0-4 1 3 3 3 3
VDSPVC 60 Fuse failure supervision based on
voltage difference
0-4 1-G03 1-G03 1-G03 1-G03 1-G03 1-G03
Logic
SMPPTRC 94 Tripping logic 1-6 6 6 6 6 6 6
TMAGAPC Trip matrix logic 12 12 12 12 12 12 12
ALMCALH Logic for group alarm 5 5 5 5 5 5 5
WRNCALH Logic for group warning 5 5 5 5 5 5 5
INDCALH Logic for group indication 5 5 5 5 5 5 5
AND, OR, INV,
PULSETIMER,
GATE,
TIMERSET, XOR,
LLD,
SRMEMORY,
RSMEMORY
Configurable logic blocks 40-280 40-280 40-280 40-280 40-280 40-280 40-280
ANDQT, ORQT,
INVERTERQT,
XORQT,
SRMEMORYQT,
RSMEMORYQT,
TIMERSETQT,
PULSETIMERQT,
INVALIDQT,
INDCOMBSPQT,
INDEXTSPQT
Configurable logic blocks Q/T 0–1
SLGAPC,
VSGAPC, AND,
OR,
PULSETIMER,
GATE,
TIMERSET, XOR,
LLD,
SRMEMORY, INV
Extension logic package 0–1
FXDSIGN Fixed signal function block 1 1 1 1 1 1 1
B16I Boolean 16 to Integer conversion 18 18 18 18 18 18 18
BTIGAPC Boolean 16 to Integer conversion with
Logic Node representation
16 16 16 16 16 16 16
IB16 Integer to Boolean 16 conversion 18 18 18 18 18 18 18
ITBGAPC Integer to Boolean 16 conversion with
Logic Node representation
16 16 16 16 16 16 16
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
16 ABB

IEC 61850 ANSI Function description Transformer
RET670
RET670 (A10) RET670 (A30)
RET670 (B30)
RET670 (A40)
RET670 (B40)
RET670 (A25)
TEIGAPC Elapsed time integrator with limit
transgression and overflow supervision
12 12 12 12 12 12 12
Monitoring
CVMMXN,
CMMXU,
VMMXU, CMSQI,
VMSQI, VNMMXU
Measurements 6 6 6 6 6 6 6
AISVBAS Function block for service value
presentation of secondary analog
inputs
1 1 1 1 1 1 1
EVENT Event function 20 20 20 20 20 20 20
DRPRDRE,
A1RADR,
A2RADR,
A3RADR,
A4RADR,
B1RBDR,
B2RBDR,
B3RBDR,
B4RBDR,
B5RBDR,
B6RBDR
Disturbance report 1 1 1 1 1 1 1
SPGAPC Generic communication function for
Single Point indication
64 64 64 64 64 64 64
SP16GAPC Generic communication function for
Single Point indication 16 inputs
16 16 16 16 16 16 16
MVGAPC Generic communication function for
Measured Value
24 24 24 24 24 24 24
BINSTATREP Logical signal status report 3 3 3 3 3 3 3
RANGE_XP Measured value expander block 66 66 66 66 66 66 66
SSIMG 63 Gas medium supervision 21 21 21 21 21 21 21
SSIML 71 Liquid medium supervision 3 3 3 3 3 3 3
SSCBR Circuit breaker monitoring 0-6 3-M13 2-M12 4-M14 3-M13 6-M15
I103MEAS Measurands for IEC 60870-5-103 1 1 1 1 1 1 1
I103MEASUSR Measurands user defined signals for
IEC 60870-5-103
3 3 3 3 3 3 3
I103AR Function status auto-recloser for IEC
60870-5-103
1 1 1 1 1 1 1
I103EF Function status earth-fault for IEC
60870-5-103
1 1 1 1 1 1 1
I103FLTPROT Function status fault protection for IEC
60870-5-103
1 1 1 1 1 1 1
I103IED IED status for IEC 60870-5-103 1 1 1 1 1 1 1
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
ABB 17

IEC 61850 ANSI Function description Transformer
RET670
RET670 (A10) RET670 (A30)
RET670 (B30)
RET670 (A40)
RET670 (B40)
RET670 (A25)
I103SUPERV Supervison status for IEC 60870-5-103 1 1 1 1 1 1 1
I103USRDEF Status for user defiend signals for IEC
60870-5-103
20 20 20 20 20 20 20
L4UFCNT Event counter with limit supervision 30 30 30 30 30 30 30
Metering
PCFCNT Pulse-counter logic 16 16 16 16 16 16 16
ETPMMTR Function for energy calculation and
demand handling
6 6 6 6 6 6 6
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
18 ABB

Communication
IEC 61850 ANSI Function description Transformer
RET670
RET670 (A10) RET670 (A30)
RET670 (B30)
RET670 (A40)
RET670 (B40)
RET670 (A25)
Station communication
LONSPA, SPA SPA communication protocol 1 1 1 1 1 1 1
ADE LON communication protocol 1 1 1 1 1 1 1
HORZCOMM Network variables via LON 1 1 1 1 1 1 1
PROTOCOL Operation selection between
SPA and IEC 60870-5-103 for
SLM
1 1 1 1 1 1 1
RS485PROT Operation selection for RS485 1 1 1 1 1 1 1
RS485GEN RS485 1 1 1 1 1 1 1
DNPGEN DNP3.0 communication general
protocol
1 1 1 1 1 1 1
DNPGENTCP DNP3.0 communication general
TCP protocol
1 1 1 1 1 1 1
CHSERRS485 DNP3.0 for EIA-485
communication protocol
1 1 1 1 1 1 1
CH1TCP,
CH2TCP,
CH3TCP,
CH4TCP
DNP3.0 for TCP/IP
communication protocol
1 1 1 1 1 1 1
CHSEROPT DNP3.0 for TCP/IP and EIA-485
communication protocol
1 1 1 1 1 1 1
MST1TCP,
MST2TCP,
MST3TCP,
MST4TCP
DNP3.0 for serial
communication protocol
1 1 1 1 1 1 1
DNPFREC DNP3.0 fault records for TCP/IP
and EIA-485 communication
protocol
1 1 1 1 1 1 1
IEC61850-8-1 Parameter setting function for
IEC 61850
1 1 1 1 1 1 1
GOOSEINTLKRC
V
Horizontal communication via
GOOSE for interlocking
59 59 59 59 59 59 59
GOOSEBINRCV Goose binary receive 16 16 16 16 16 16 16
GOOSEDPRCV GOOSE function block to
receive a double point value
64 64 64 64 64 64 64
GOOSEINTRCV GOOSE function block to
receive an integer value
32 32 32 32 32 32 32
GOOSEMVRCV GOOSE function block to
receive a measurand value
60 60 60 60 60 60 60
GOOSESPRCV GOOSE function block to
receive a single point value
64 64 64 64 64 64 64
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
ABB 19

IEC 61850 ANSI Function description Transformer
RET670
RET670 (A10) RET670 (A30)
RET670 (B30)
RET670 (A40)
RET670 (B40)
RET670 (A25)
GOOSEVCTRCO
NF
GOOSE VCTR configuration for
send and receive
1 1 1 1 1 1 1
VCTRSEND Horizontal communication via
GOOSE for VCTR
1 1 1 1 1 1 1
GOOSEVCTRRC
V
Horizontal communication via
GOOSE for VCTR
7 7 7 7 7 7 7
MULTICMDRCV,
MULTICMDSND
Multiple command and transmit 60/10 60/10 60/10 60/10 60/10 60/10 60/10
FRONT, LANABI,
LANAB, LANCDI,
LANCD
Ethernet configuration of links 1 1 1 1 1 1 1
GATEWAY Ethernet configuration of link
one
1 1 1 1 1 1 1
OPTICAL103 IEC 60870-5-103 Optical serial
communication
1 1 1 1 1 1 1
RS485103 IEC 60870-5-103 serial
communication for RS485
1 1 1 1 1 1 1
AGSAL Generic security application
component
1 1 1 1 1 1 1
LD0LLN0 IEC 61850 LD0 LLN0 1 1 1 1 1 1 1
SYSLLN0 IEC 61850 SYS LLN0 1 1 1 1 1 1 1
LPHD Physical device information 1 1 1 1 1 1 1
PCMACCS IED Configuration Protocol 1 1 1 1 1 1 1
SECALARM Component for mapping
security events on protocols
such as DNP3 and IEC103
1 1 1 1 1 1 1
FSTACCS Field service tool access via
SPA protocol over ethernet
communication
1 1 1 1 1 1 1
ACTIVLOG Activity logging parameters 1 1 1 1 1 1 1
ALTRK Service Tracking 1 1 1 1 1 1 1
SINGLELCCH Single ethernet port link status 1 1 1 1 1 1 1
PRPSTATUS Dual ethernet port link status 1 1 1 1 1 1 1
Process bus communication
IEC 61850-9-2 1)
PRP IEC 62439-3 parallel
redundancy protocol (only in
F00)
0-1 1-P03 1-P03 1-P03 1-P03 1-P03 1-P03
Remote communication
Binary signal transfer receive/
transmit
6/36 6/36 6/36 6/36 6/36 6/36 6/36
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
20 ABB
