ABB REU 610 User manual

Voltage Relay
REU 610
Operator's Manual - ANSI Version

3
Contents
1. Introduction.... ..................................................................... 7
1.1. This manual.................................................................... ...... 7
1.2. Use of symbols.... .......................................................... ...... 7
1.3. Intended audience.......................................................... ...... 7
1.4. Product documentation.... .............................................. ...... 8
1.5. Document conventions.... .............................................. ...... 8
2. Safety information.... .......................................................... 9
3. Product overview.............................................................. 11
3.1. Use of the relay.............................................................. .... 11
3.2. Features.......................................................................... .... 11
4. Operation.... ....................................................................... 13
4.1. HMI features................................................................... .... 13
4.1.1. Front panel.... .................................................... .... 13
4.1.2. Display.... ........................................................... .... 14
4.1.2.1. Display test at power up.... ................ .... 14
4.1.2.2. Display modes.... ................................ .... 14
4.1.2.3. Display backlight.... ............................ .... 15
4.1.2.4. How to adjust the display contrast.... .... 15
4.1.3. How to use the push buttons............................ .... 15
4.1.4. Main menu......................................................... .... 16
4.1.5. Submenu.... ....................................................... .... 17
4.1.6. HMI password.... ............................................... .... 17
4.1.7. SPA password.... ............................................... .... 18
4.1.8. How to select language.... ................................ .... 19
4.1.9. How to set the real-time clock.... ...................... .... 20
4.1.10. How to reset the trip lockout function............... .... 21
4.1.11. How to switch between front and rear
connection.... ..................................................... .... 22
4.1.11.1. Target LED for front communication........ 23
4.1.12. How to select the protocol for rear
communication.... .............................................. .... 23
4.2. HMI operation levels.... .................................................. .... 24
4.2.1. User level........................................................... .... 24
4.2.1.1. Menu groups of the user level.... ....... .... 24
4.2.1.2. How to monitor measured values...... .... 25
4.2.1.3. How to monitor recorded data.... ....... .... 27
4.2.1.4. INFO menu group............................... .... 28
4.2.2. Technical level.... ............................................... .... 29
4.2.2.1. Menu system of parameters.... .......... .... 29
4.2.2.2. How to change settings.... ................. .... 30
4.2.2.3. Configuration.... .................................. .... 34
Voltage Relay
Operator's Manual - ANSI Version
REU 610
1MRS755971
Issued: 31.01.2006
Version: A/01.02.2006

4.2.2.4. How to acknowledge and reset
targets, output contacts and
memorized values.... .......................... .... 36
4.3. Protection relay targets.... .............................................. .... 37
4.3.1. Target LEDs....................................................... .... 37
4.3.1.1. Green target LED.... ........................... .... 37
4.3.1.2. Yellow target LED............................... .... 38
4.3.1.3. Red target LED................................... .... 38
4.3.1.4. Programmable target LEDs.... ........... .... 39
4.3.2. Target messages.... ........................................... .... 39
4.3.2.1. Operation target messages................ .... 39
4.3.2.2. Disturbance recorder target.... ........... .... 40
4.3.2.3. Self-supervision.... .............................. .... 41
4.4. Detachable plug-in unit.... .............................................. .... 44
4.4.1. Identifying the product....................................... .... 44
4.4.2. Detaching and installing the plug-in unit.... ...... .... 45
4.4.3. Inserting and changing the battery.... ............... .... 46
5. Commissioning and maintenance.................................. 49
5.1. Commissioning instructions.... ....................................... .... 50
5.2. Maintenance instructions.... ........................................... .... 50
5.2.1. Relay verification.... ........................................... .... 51
5.2.2. Preventive parts replacement.... ....................... .... 51
5.3. Measurements verification.... ......................................... .... 51
5.4. Function test................................................................... .... 52
5.5. Digital input test.............................................................. .... 53
5.6. Testing protection functions.... ....................................... .... 53
5.6.1. Testing overvoltage protection.... ...................... .... 54
5.6.2. Testing residual voltage protection.... ............... .... 54
6. Spare parts.... .................................................................... 55
6.1. Plug-in unit.... ................................................................. .... 55
6.2. Battery............................................................................. .... 55
7. Repair.... ............................................................................. 57
8. Ordering information........................................................ 59
9. Abbreviations.... ................................................................ 61
4
REU 610 Voltage Relay
Operator's Manual - ANSI Version
1MRS755971

5
Copyrights
The information in this document is subject to change without notice and
should not be construed as a commitment by ABB Oy. ABB Oy assumes no
responsibility for any errors that may appear in this document.
In no event shall ABB Oy be liable for direct, indirect, special, incidental or
consequential damages of any nature or kind arising from the use of this
document, nor shall ABB Oy be liable for incidental or consequential
damages arising from use of any software or hardware described in this
document.
This document and parts thereof must not be reproduced or copied without
written permission from ABB Oy, and the contents thereof must not be
imparted to a third party nor used for any unauthorized purpose.
The software or hardware described in this document is furnished under a
license and may be used, copied, or disclosed only in accordance with the
terms of such license.
Copyright © 2006 ABB Oy
All rights reserved.
Trademarks
ABB is a registered trademark of ABB Group. All other brand or product
names mentioned in this document may be trademarks or registered
trademarks of their respective holders.
Warranty
Please inquire about the terms of warranty from your nearest ABB
representative.
1MRS755971 Voltage Relay
Operator's Manual - ANSI Version
REU 610

6

7
1. Introduction
1.1. This manual
This manual provides basic information on the voltage relay REU 610 and
presents detailed instructions on how to use the human-machine interface
(HMI) of the relay. In addition to the instructive part, a short chapter on
commissioning and maintenance of the relay is included.
1.2. Use of symbols
This publication includes the following icons that point out safety-related
conditions or other important information:
The electrical warning icon indicates the presence of a hazard
which could result in electrical shock.
The warning icon indicates the presence of a hazard which could
result in personal injury.
The caution icon indicates important information or warning
related to the concept discussed in the text. It might indicate the
presence of a hazard which could result in corruption of software
or damage to equipment or property.
The information icon alerts the reader to relevant facts and
conditions.
The tip icon indicates advice on, for example, how to design
your project or how to use a certain function.
Although warning hazards are related to personal injury, it should be
understood that operation of damaged equipment could, under certain
operational conditions, result in degraded process performance leading to
personal injury or death. Therefore, comply fully with all warning and
caution notices.
1.3. Intended audience
This manual is intended for operators, supervisors and administrators to
support normal use of the product.
1MRS755971 Voltage Relay
Operator's Manual - ANSI Version
REU 610

1.4. Product documentation
In addition to the relay and this manual, the delivery contains the following
relay-specific documentation:
Table 1.4.-1 REU 610 product documentation
Name Document ID
Certificate of verification 1MRS081662
Installation Manual 1MRS752265-MUM
Technical Reference Manual 1MRS755972
1.5. Document conventions
The following conventions are used for the presentation of material:
*Push button navigation in the human-machine interface (HMI) menu
structure is presented by using the push button icons, for example:
To navigate between the options, use and .
*HMI menu paths are presented as follows:
Use the arrow buttons to select CONFIGURATION\COMMUNICATION
\SPA SETTINGS\PASSWORD SPA.
*Parameter names, menu names, relay target messages and relay's HMI
views are shown in a Courier font, for example:
Use the arrow buttons to monitor other measured values in the menus
DEMAND VALUES and HISTORY DATA.
*HMI messages are shown inside quotation marks when it is good to point
out them for the user, for example:
When you store a new password, the relay confirms the storage by
flashing “---”once on the display.
8
REU 610 Voltage Relay
Operator's Manual - ANSI Version
1MRS755971

9
2. Safety information
Dangerous voltages can occur on the connectors, even though
the auxiliary voltage has been disconnected.
Non-observance can result in death, personal injury or
substantial property damage.
Only a competent electrician is allowed to carry out the electrical
installation.
National and local electrical safety regulations must always be
followed.
The frame of the device has to be carefully grounded.
When the plug-in unit has been detached from the case, do not
touch the inside of the case. The relay case internals may contain
high voltage potential and touching these may cause personal
injury.
The device contains components which are sensitive to
electrostatic discharge. Unnecessary touching of electronic
components must therefore be avoided.
Breaking the sealing tape on the upper handle of the device will
result in loss of guarantee and proper operation will no longer be
insured.
1MRS755971 Voltage Relay
Operator's Manual - ANSI Version
REU 610

10

11
3. Product overview
3.1. Use of the relay
The voltage relay REU 610 is a versatile multifunction protection relay
mainly designed for overvoltage and undervoltage protection and for
supervision of medium voltage distribution networks. The relay can also be
used for protecting generators, motors and transformers.
The relay is based on a microprocessor environment. A self-supervision
system continuously monitors the operation of the relay.
The HMI includes a liquid crystal display (LCD) which makes the local use
of the relay safe and easy.
Local control of the relay via serial communication can be carried out with a
computer connected to the front communication port. Remote control can be
carried out via the rear connector connected to the control and monitoring
system through the serial communication bus.
3.2. Features
*Overvoltage protection with definite-time or IDMT characteristic, low-set
element
*Overvoltage protection with definite-time or IDMT characteristic, high-set
element
*Based on phase-to-phase voltage measurement or negative phase-
sequence (NPS) voltage
*Undervoltage protection with definite-time or IDMT characteristic, low-
set element
*Can also be used as alarm element
*Undervoltage protection with definite-time or IDMT characteristic, high-
set element
*Based on phase-to-phase voltage measurement or positive phase-
sequence (PPS) voltage
*Residual overvoltage protection with definite-time characteristic, low-set
element
*Residual overvoltage protection with definite-time characteristic, high-set
element
*Circuit-breaker failure protection
*Trip counters for circuit-breaker condition monitoring
*Trip-circuit supervision with possibility to route the warning signal to a
non-trip output
*Trip lockout function
*Four accurate voltage inputs
*User-selectable rated voltage 100/110/115/120 V
*User-selectable rated frequency 50/60 Hz
1MRS755971 Voltage Relay
Operator's Manual - ANSI Version
REU 610

*Three normally open trip contacts
*Two change-over (form c) non-trip contacts and three additional change-
over (form c) non-trip contacts on the optional I/O module
*Output contact functions freely configurable for wanted operation
*Two galvanically isolated digital inputs and three additional galvanically
isolated digital inputs on the optional I/O module
*Disturbance recorder:
*Recording time up to 80 seconds
*Triggering by one or several internal or digital input signals
*Records four analog channels and up to eight user-selectable digital
channels
*Adjustable sampling rate
*Non-volatile memory for:
*Up to 100 event codes with time stamp
*Setting values
*Disturbance recorder data
*Recorded data of the five last events with time stamp
*Number of pickups for protection elements
*Operation target messages and LEDs showing the status at the moment
of power failure
*HMI with an alphanumeric LCD and navigation buttons
*Eight programmable LEDs
*Multi-language support
*User-selectable password protection for the HMI
*Display of primary voltage values
*All settings can be modified with a PC
*Optical front communication connection: wirelessly or via cable
*Optional rear communication module with plastic fibre-optic, combined
fibre-optic (plastic and glass) or RS-485 connection for system
communication using the SPA-bus, IEC 60870-5-103 or Modbus (RTU
and ASCII) communication protocol
*Optional DNP 3.0 rear communication module with RS-485 connection
for system communication using the DNP 3.0 communication protocol
*Battery back-up for real-time clock
*Time synchronization via a digital input
*Battery charge supervision
*Continuous self-supervision of electronics and software
*At an internal relay fault, all protection elements and outputs are
locked
*Detachable plug-in unit
12
REU 610 Voltage Relay
Operator's Manual - ANSI Version
1MRS755971

13
4. Operation
4.1. HMI features
4.1.1. Front panel
The front panel of the relay contains:
*Alphanumeric 2 × 16 characters’LCD with backlight and automatic
contrast control
*Three target LEDs (green, yellow, red) with fixed functionality
*Eight programmable target LEDs (red)
*HMI push-button section with four arrow buttons and buttons for clear/
cancel and enter, used in navigating in the menu structure and in adjusting
setting values
*Optically isolated serial communication port with a target LED.
For further information on the HMI, refer to the Operator’s Manual.
1
2
3
4
5
6
A052082
Fig. 4.1.1.-1 Front view of the relay
1) LCD
2) HMI push-button section
3) Programmable target LEDs (red)
4) Target LEDs:
*Left: Ready (green)
*Center: Pickup/Alarm (yellow)
*Right: Trip (red)
5) Target LED for front communication
6) Front communication port (infrared)
1MRS755971 Voltage Relay
Operator's Manual - ANSI Version
REU 610

4.1.2. Display
4.1.2.1. Display test at power up
When connecting the auxiliary voltage to the relay:
1. The backlight is turned on after the relay has performed the internal
power-up tests and entered into the protection mode.
2. The display is tested by inverting it for approximately three seconds, see
Fig. 4.1.2.1.-1.
3. The display is returned to the idle mode and the backlight is turned off if
no operation target message is displayed. However, if the non-volatile
function is active, a message shown on the display before the auxiliary
voltage was disconnected reappears on the display.
A040216
Fig. 4.1.2.1.-1 Display test at power up, display inverted
4.1.2.2. Display modes
When the display is in the idle mode, the name of the feeder is displayed,
which by default is - ABB -. To change the name of the feeder, use SPA
parameter M20.
- ABB -
A040217
Fig. 4.1.2.2.-1 Display in the idle mode
When the display is in the view mode, you can only view the settings.
SETTINGS
*GRP1 :1.20
A051574
Fig. 4.1.2.2.-2 Display in the view mode
When the display is in the setting mode, you can also edit the settings.
14
REU 610 Voltage Relay
Operator's Manual - ANSI Version
1MRS755971

15
SETTINGS
*GRP1 :1.2 1
A051575
Fig. 4.1.2.2.-3 Display in the setting mode
4.1.2.3. Display backlight
Normally the backlight of the display is off.
*Turn the backlight on by pressing an arrow button on the HMI. If the HMI
panel is not used for approximately five minutes, the backlight is turned
off automatically.
*Activating the power-saving built-in feature by pressing turns the
backlight off within 20 seconds.
4.1.2.4. How to adjust the display contrast
The display contrast is dependent on the temperature. The relay automatically
adjusts the contrast for optimum readability. When the display is in the idle
mode, you can also adjust the contrast manually.
*To increase the contrast, hold down and adjust the contrast using .
*To decrease the contrast, hold down and adjust the contrast using .
After power pickup of the relay, the factory default value of the display
contrast is automatically restored.
4.1.3. How to use the push buttons
The HMI contains push buttons for navigating in the menu.
Left Up Dow Right E ter Clear/
Ca cel
Clear/
Ca cel
A040225
Fig. 4.1.3.-1 Navigation push buttons
Use the navigation buttons to view, select and edit the wanted menu items.
*Activate the main menu by pressing an arrow button.
*Move between the menu levels and menu items by using the arrow
buttons.
*Select the item to be edited or store a new value by pressing .
1MRS755971 Voltage Relay
Operator's Manual - ANSI Version
REU 610

*Increase or decrease the activated digit, shift the activated decimal point,
or navigate between options by using and .
*Cancel and return the display to the previous mode (view mode or idle
mode), by pressing
Table 4.1.3.-1 Button navigation and editing
Wanted step or operation Push button
Step downward in the main menu or a submenu
Step upward in the main menu or a submenu
Entering a submenu from the main menu or a higher submenu
Leaving a submenu for the main menu or a higher submenu
Increasing a value in the setting mode
Decreasing a value in the setting mode
Moving the cursor in the setting mode or
Selecting the front connection at power up and
Entering or leaving the setting mode, storing a new value
Entering the monitoring state and
Adjusting the display contrast and or
Resetting or canceling, leaving the setting mode without storing
a new value
Resetting latched output contacts in the idle mode for 5 s
Acknowledging and resetting targets, latched output contacts
and memorized values
and
4.1.4. Main menu
The main menu contains six main groups:
*MEASUREMENTS
*RECORDED DATA
*OPERATION
*SETTINGS
*CONFIGURATION
*INFO
MEASUREMENTS MEASUREMENTS
A040228
Fig. 4.1.4.-1 Display showing the first main menu group
*Navigate between the main menu groups by using and .
*Return the display to the idle mode by pressing .
The display is returned to the idle mode on expiration of the time out.
16
REU 610 Voltage Relay
Operator's Manual - ANSI Version
1MRS755971

17
4.1.5. Submenu
The menu structure contains several subgroups. The name of the main menu
group is always shown on the first line. The second line displays either the
name of the group menu, the name of the parameter and the parameter value,
or just the parameter value, in which case it is also the name of the parameter.
Uab VT x 0.00
MEASUREMENTS
A051587
Fig. 4.1.5.-1 Display showing the first submenu
*Enter a submenu by pressing ; exit by pressing .
*Navigate between the main levels in the submenus by using or .
*Press to return the display to the idle mode.
4.1.6. HMI password
The HMI password protects all user-changeable values on the technical level
from being changed by an unauthorized person. The password function
remains inactive until the default password is replaced. The default HMI
password is 999. You can also change the password from a remote unit via
parameter V162, but you can only read the password via the HMI.
As soon as you have replaced the default HMI password, the new password is
required for altering parameter values. Once you have given the valid
password, the display remains in the setting mode until returned to the idle
mode.
PASSWORD :000
SETTINGS
A040230
Fig. 4.1.6.-1 Password request for editing setting parameters
Change the HMI password as follows:
1. Press an arrow button to access the main menu.
2. Use the arrow buttons to select CONFIGURATION\PASSWORD HMI and
press .
3. Press to enter the setting mode and give the current HMI password if
required. If the default password 999 is still valid, no password is required.
4. The first digit of the password to be edited starts to flash. Set the digit
using and .
5. Activate the next digit to be set by pressing or .
1MRS755971 Voltage Relay
Operator's Manual - ANSI Version
REU 610

6. To store the new password and return the display to the view mode, press
. The display confirms the storage by flashing “---”once on the
display.
Alternatively, to exit the setting mode without storing the password
change, press once before confirming and the display returns to the
view mode.
7. Press to return the display to the idle mode.
TRIP CIRCUIT SUP
Mai Me u Group Me u Parameter Me u
SETTINGS
CONFIGURATION
MEASUREMENTS
RECORDED DATA
PASSWORD HMI
TIME
FREQUENCY
CONFIGURATION
FUNCTION TEST/DI
COMMUNICATION
LANGUAGE
MEMORY SETTINGS
PASSWORD HMI :999
CONFIGURATION Scroll for the digit
Set the digit
Co firm
Ca cel
INFO
U NOMINAL
OPERATION
A051583
Fig. 4.1.6.-2 Changing HMI password
4.1.7. SPA password
The password for SPA bus communication is required for altering parameter
values via the SPA bus. The default password is 001. You can change the SPA
password either via the HMI or the SPA bus by first entering the currently
valid password into parameter V160 and then entering the new password into
parameter V161.
Change the SPA password as follows:
1. Press an arrow button to access the main menu
2. Use the arrow buttons to select CONFIGURATION\COMMUNICATION
\SPA SETTINGS\PASSWORD SPA and press .
3. Press to enter the setting mode and give the current HMI password if
required. If the default password 001 is still valid, no password is required.
4. The first digit of the password to be edited starts to flash. Set the digit
using and .
5. Activate the next digit to be set by pressing or .
18
REU 610 Voltage Relay
Operator's Manual - ANSI Version
1MRS755971

19
6. To store the new SPA password and return the display to the view mode,
press . The display confirms the storage by flashing "---" once on
the display.
Alternatively, to exit the setting mode without storing the SPA password
change, press once before confirming and the display returns to the
view mode.
7. Press to return the display to the idle mode.
PASSWORD HMI
TIME
LINE-IDLE STATE
CONNECTION TYPE
TRIP CIRCUIT SUP
Mai Me u Group Me u Parameter Me us
SETTINGS
CONFIGURATION
MEASUREMENTS
RECORDED DATA
COUNTER :000
UNIT ADDRESS :000
MODBUS SETTINGS
SPA SETTINGS
REAR PROTOCOL
FREQUENCY
CONFIGURATION
FUNCTION TEST/DI
COMMUNICATION
LANGUAGE
REAR CONNECTION
CONFIGURATION
MEMORY SETTINGS
IEC103 SETTINGS
PASSWORD SPA :000
CONFIGURATION
REAR COM. MODULE Co firm
Ca cel
Scroll for the digit
Set the digit
INFO
U NOMINAL
OPERATION
A051584
Fig. 4.1.7.-1 Changing SPA password
4.1.8. How to select language
The relay allows you to choose among several different languages. The
default language is English.
Change the display language as follows:
1. Press an arrow button to access the main menu.
2. Use the arrow buttons to select CONFIGURATION\LANGUAGE and press
to enter the currently valid language.
3. Press to enter the setting mode and give the password if required. The
second line starts to flash indicating that you are allowed to set the
language.
4. Use or to move the cursor to the wanted language.
5. Press to confirm the selection. The selected language is shown on the
display.
6. Press to return the display to the idle mode.
By pressing before confirming the selection, the former language remains
active and the display is returned to the view mode. Pressing again returns
the display to the idle mode.
1MRS755971 Voltage Relay
Operator's Manual - ANSI Version
REU 610

TRIP CIRCUIT SUP
Mai Me u Group Me u Parameter Me u
Co firm
Ca cel
SETTINGS
CONFIGURATION
MEASUREMENTS
RECORDED DATA
FUNCTION TEST/DI
COMMUNICATION
LANGUAGE
FREQUENCY
CONFIGURATION
CONFIGURATION
MEMORY SETTINGS
PASSWORD HMI
TIME
INFO ENGLISH
ESPANOL
PORTUGESE
U NOMINAL
OPERATION
A051585
Fig. 4.1.8.-1 Selecting language
The list of languages in the language selection menu differs
depending on the HMI language set number in the order number.
4.1.9. How to set the real-time clock
The real-time clock used for time-stamped events is set via two different
settings, one for Year-Month-Day and another for Hours-Minutes-Seconds.
To change one setting or both settings:
1. Press an arrow button to access the main menu.
2. Use the arrow buttons to select CONFIGURATION\TIME and press .
3. Use or to select the parameter to be edited.
4. Press to enter the setting mode and give the password if required. If the
default password 999 is still valid, no password is required.
5. The first digit of the setting value of the parameter to be edited starts to
flash. Use and to move the cursor and and to increase or
decrease the value. The setting range (for example Year or Minutes) is
shown on the right-hand side of the second line of the display.
6. To store a new value and return the display to the view mode, press .
7. To exit the setting mode without storing the changes, press once before
confirming and the display is returned to the view mode.
8. Press to return the display to the idle mode.
20
REU 610 Voltage Relay
Operator's Manual - ANSI Version
1MRS755971
