ABB ITS2.1 User manual

USER MANUAL
ITS2.1
Slimline, InlineII and Standalone ITS2

ITS2.1 User Manual rev.04/1SEP622750P0001 2
TABLE OF CONTENTS
1Product overview.............................................................................................................................3
1.1 Slimline XRG00...............................................................................................................................3
1.2 Slimline XRG1..................................................................................................................................3
1.3 Slimline XRG2 and XRG3................................................................................................................3
1.4 Inline II ZHBM00............................................................................................................................. 4
1.5 Inline II ZHBM123........................................................................................................................... 4
1.6 Standalone ITS................................................................................................................................5
1.7 ITS2.1 Overview..............................................................................................................................5
1.8 Prerequisites................................................................................................................................. 6
1.9 Downloadand install the Ekip Connect software................................................................... 6
1.10 Ekip T&P test and programming unit........................................................................................ 6
2The Ekip connect software.............................................................................................................7
2.1 Starting Ekip connectandcheck for latest update..................................................................7
3Basic parameter setting.............................................................................................................. 8
4Additional parameter settings..................................................................................................11
5ITS Values andstatus information............................................................................................13
5.1 Main page......................................................................................................................................13
5.2 Alarms............................................................................................................................................15
5.3 All Measures..................................................................................................................................16
5.4 Main Measures.............................................................................................................................18
5.5 Min - max Measures.....................................................................................................................19
5.6 Modbus RTU................................................................................................................................ 20
5.7 Modbus TCP .................................................................................................................................21
6Multiplug terminal.......................................................................................................................23
6.1 Slimline XRG and Inline II ZHBM ITS multiplug........................................................................23
6.2 Standalone ITS module multiplug............................................................................................ 24
7modbus RTU.................................................................................................................................25
7.1 Special sequence Modbus telegram.........................................................................................25
7.2 Modbus RTU trouble andfault finding.....................................................................................25
7.3 Modbus RTU cabling.................................................................................................................. 26
7.3.1 Terminatingresistors (TR)........................................................................................................ 26
7.3.2 Grounding of shielding.............................................................................................................. 26
8Ekip com modbus tcp module...................................................................................................27
9Cyber security.............................................................................................................................. 28
10 Power directionsetting............................................................................................................. 29
10.1 Slimline XRG power direction setting...................................................................................... 29
10.2 InlineII ZHBM power direction setting .....................................................................................31
10.3 Power direction for otherswitches..........................................................................................32
11 Technical data..............................................................................................................................33
12 Reference to Supplementary documentation........................................................................ 34
13 XR ITS2.D with ekipdisplay........................................................................................................35
13.1 How to plug in theEkip Display at an XR ITS2.1 unit..............................................................35
14 Ekip Display ..................................................................................................................................37
14.1 Ekip Display power LED..............................................................................................................37
14.2 Ekip Display front overview........................................................................................................37
14.3 Ekip Display Start Menu............................................................................................................. 38
14.4 Ekip Display signaling area ....................................................................................................... 39
14.5 Ekip Display navigation view (menu area)..............................................................................40
15 Trouble shooting........................................................................................................................... 43

ITS2.1 User Manual rev.04/1SEP622750P0001 3
1 PRODUCT OVERVIEW
1.1 Slimline XRG00
Refer the installation instruction for XRG00 ITS2.
1.2 Slimline XRG1
Refer the installation instruction for XRG1 ITS2.
1.3 Slimline XRG2 and XRG3
Refer the installation instruction for XRG23ITS2.

ITS2.1 User Manual rev.04/1SEP622750P0001 4
1.4 Inline II ZHBM00
Refer the installation instruction for InlineIIZHBM-ITS.
1.5 Inline II ZHBM123
Refer the installation instruction for InlineIIZHBM-ITS.

ITS2.1 User Manual rev.04/1SEP622750P0001 5
1.6 Standalone ITS
Refer the installationinstruction for ITS2.1 Standalone.
1.7 ITS2.1 Overview
TEST/Prg
The TEST/Prgis for use ofconfiguration tool
Ekip Connect.
Important: This is NOT an ordinary USB connection,
always use the T&P test and program unit when
connecting a laptop to theITS2.1 unit
Fuse Blown LED
Fuse Blown LED indicates as follows:
-Dark : All fuses are OK
-Lit : One or more fuses are blown
-Flashing:
Nominal line voltage is notset (½ Hz)
Switch opened by motor operationwhen fuse blown
(2 Hz)
Power LED
The power LED canbe configured intwo ways:
-Power indication with a steady light
-Alive indication with a flash rate of ½ Hz.
When configuringthe light is inWINK LED mode (2Hz).
Local/Remoteindicator LED and pushbutton
Local/Remote LED indicates as follows (2):
-Dark :Local mode, commands or setting of
parameters are refused
-Lit : Remote mode, commands orsetting of
parameters are accepted
The push button (Rem) selects mode.
Communication LED
The communication LEDindicates as follows:
-Dark : Novalid message received
-Flashing : Validmessagewith wrong address
-Lit : CommunicationOK
If requests from master ends, the LEDwill go dark after
30 s.

ITS2.1 User Manual rev.04/1SEP622750P0001 6
1.8 Prerequisites
Warning
Do not use astandard USB cable. This canlead to hazardous voltage damages atthe
laptop.
Connecting a laptop/computerto theITS unit will requirean Ekip T&P adapter.
1.9 Download and install the Ekip Connect software
1) Go to http://www.abb.com/abblibrary/DownloadCenter
2) Search Ekip Connect
3) Download software
4) Unzip 1SDC20011X3000.zip and run setup
1.10 Ekip T&P test and programming unit
Order code: 1SDA076154R1
Ekip T&P unit is suitable for ITS2.1. You canconnect the module via the programming port as below. The
programming port can only be used withEkipT&P.
Ekip T&P unit allows you to update the software as well as load, set andread the parameters on Ekip Connect
software.
Connect one side of cable Bto the programming unit (A) and theother side of cable B toITS2.1 programing
port. Insertthe USB (A)to your computers USB port, Ekip T&P unit draws its power from thePC.
Ekip T&P unit turns on afterconnecting it to the PC. It is equipped with two LEDS,a green oneindicating that
themodule is on,and an orange oneindicatingactive communication.

ITS2.1 User Manual rev.04/1SEP622750P0001 7
2 THE EKIP CONNECT SOFTWARE
2.1 Starting Ekip connect and check for latest update
Start Ekip Connect. For a more extensive guide,pleaserefer to EkipConnect – user manual.
Searching for latest version of Ekip Connect and Device Description files are quite easy. However, the
computer must have access to internet to check for and downloadan update.

ITS2.1 User Manual rev.04/1SEP622750P0001 8
3BASIC PARAMETER SETTING
Connect the ITS2.1 via EkipT&P unitto yourcomputer and start the Ekip Connect software.
Click on the ‘SCAN’ buttonin the T&P section of the‘CONNECT WITH YOUR DEVICE’ area,the ITS2.1unitwill be
detectedand then click the ‘Classic view’.
Since the ITS2.1unit is powered bythe EkipT&P unit, configuration oftheITS2.1 unitcan be carried outwithout
having it fitted into theswitch.
The following parameters must be set for the ITS2.1 unit:
1. Select «Switch type» according totheactual switch type, five basic switches Slimline XR,InlineII, OS,
OT or Other can beselected, each switch type has severaldifferent current sizes, makesure your
switch type and rated current are all correct.
2. Set «NominalLine Voltage» accordingto the system voltage.If the linevoltage in thesystem is 400 V,
the Nominal Line Voltageshould be set equal, if not correctly set, the Fuse monitoring will not work.
3. Depending on the feeding direction ofthe Slimline XRG or InlineII ZHBM switch, Busbar or terminal
supply, Power direction must beset accordingly.
Note: For standalone ITS, mount the voltage sensing cable on the outgoing side of the switch.

ITS2.1 User Manual rev.04/1SEP622750P0001 9
Slimline XRG
Important for XRG 1,2 and 3: The straps on the fuse boards inside the XRG apparatus must be set
according tothe feeding direction. When changing thepower direction, these must bechanged
accordingly, study chapter 8
Inline II
Busbar Side
Terminal Side
Busbar
s
ide
Terminal
s
ide

ITS2.1 User Manual rev.04/1SEP622750P0001 10
Important for Inline II: The feeding direction can be set by a jumper connector on ITS adapter unit. When
changing the power direction, these must be changed accordingly, studychapter9.
4. Give the ITSunita unique Modbus slaver address (between 1 – 247).
If necessary, the communication parameters mustbe changed to correspond with system builder’s
settings (factory setting is 247).
5. If an Ekip Com Modbus TCP module is connected,the module’s static IPaddresscan be forceset at
Ekip COM Modbus TCP page
Information
Afteryou modified theparameters on each page, click «Apply»buttonto download
the parameters to ITS unit and activate it

ITS2.1 User Manual rev.04/1SEP622750P0001 11
4ADDITIONAL PARAMETER SETTINGS
The parameter settings below can beset according tospecial requirements.
FUSE BLOWN HANDLING
Fuse blown switch open(motor
operated device only)
This functionis relevantonlyif the switch is equippedwith motor operation
.
If ENABLEDthe motor will openthe switchif one ormorefuses areblown.
PREVENTIVEOVERLOADPROTECTION
Protection Enable
If ENABLED,
a
current and time limit ca be set. Whenthe current limit is exceeded
the timerwill start. Onceboth thecurrent limit andthe time limit are exceeded an
alarm willbe signaled orthe motorized switchwillswitchoff. If the current level
goes backto accepted leveltimer will stop and nosignalwill be sent
Fuse protection switch open
Enable
This functionis relevantonlyif the switch is equippedwith motor operation. If
ENABLED, whenthe current exceeds the threshold for a preset time, theswitch
will be drivento open
Threshold
Select a limit for the current, between
-
40% to+40%of the rated current
Time
Set a time limit between 0
-
180min

ITS2.1 User Manual rev.04/1SEP622750P0001 12
ITS STATUS
Operating mode
If set inREMOTEmode, commands sent on
M
odbus are accepted.
R
emote
/Local
indicate LEDin front will be lit. A pushbuttonin front of the ITS unit can be used
to switch between REMOTE/LOCAL
LED mode
ALIVE MODE: Thepower LED in front of the ITS unit is flashing. This is a more
reliable power onindicationsince it requires thesoftwareto be up and running.
POWER MODE: There is a steady light inthe power LED. Ahangup due tosoftware
failure will not be indicated
CUSTOM FIELDS
Tag name
The customer canenter a relevantname
User data
The customer can entera relevant
data
Switch Installation Date
The customer canenter the switchinstallationdate
MINIMUM CURRENT VALUE
Minimum
current value
Sets the threshold forthe minimum value forthe measured currentto be
displayed, 0.5% or 2% of measured range
ERROR CODE
Error code
If a programmingsessionfails,a code relevant tothe wrong parameters isset.
The error code is the Modbus address of the parameter

ITS2.1 User Manual rev.04/1SEP622750P0001 13
5ITS VALUES AND STATUS INFORMATION
5.1 Main page
PRODUCT DETAILS
Rated current (Ie)
160A,
250A,
400A
,
630A
, 800A,
1000A, 1250A, 1600A, 2000A,
2500A
Nominal line voltage
(Ue)
Shows configured nomi
n
al
voltage, NOT measured
ITS2
.1
Serial number
Located on label outside of
unit
Electronic board serial
no.
Located on label on board
Firmware version
-
Firmware subversion
-
CURRENTS
L1, L2, L3
Measured currents

ITS2.1 User Manual rev.04/1SEP622750P0001 14
SWITCH INFORMATION
Switchtype
Indicates
main switch type,
Slimline XRG00, Slimline XRG1,
Slimline XRG2, Slimline XRG3,
InlineII, OT, OS, Other
Switchposition
Indicates
switchstatus, open
or closed
Number of operations
(closed to open)
Counts the n
umber
o
f times
the switch has gone from a
closed to open status
Motor open/close
command failed.
Set if acommand sentto the
switch fails
COMMANDS
Open switch
If equipped with motor,
switch will open when
selected
Closeswitch
If equipped with motor,
switch will close when
selected
Wink
Power LED fl
ashes with 2Hz
when selected
ITS STATUS
Supplyfrom Vaux
Should indicateYES when the
ITS2 unit isfitted into amain
switch and 24 VDC is present
Supplyfrom test
YES
when the ITS2 unit is
connected toa laptopby T&P
Local/Remote
operating mode
Remote: commands on Modbus
is accepted
Local: commands on Modbus
are rejected.
LED alive
If ENABLED, the power LEDwill
flash.
Wink
Used to identify the ITS2 unit
when several units are
connected toa Modbus line. The
Power LED will flashwith 2 Hz

ITS2.1 User Manual rev.04/1SEP622750P0001 15
5.2 Alarms
ALARMS
P
re
ventive overload
protection
Show YES if preventive overload protection occurs
Fuse blown
Show YES if o
ne ormore fusesblown
Motor
operated by
blownfuse ShowsYES if theSlimline XRG orOS switchis equipped with motor operationand
configured to openwhen one or more fuses areblown
Temperature sensor
status
Shows
status of temperature
sensor
Nominal voltage status
The Electronic Fuse Monitor (EFM) uses the measured linevoltagewhen determiningif one
or morefuses are blown or not, hencethe correct nominalline voltagemust be configured
by the user. By factorydefault the nominal line voltage issetto aninvalid value, forcing the
user to configure a correct one
Mainboard CRC Error
Shows status tomainboardCRC result

ITS2.1 User Manual rev.04/1SEP622750P0001 16
5.3 All Measures
CURRENTS
L1, L2, L3 Actual currents
FREQUENCY
Frequency Actual frequency
VOLTAGES
V1N, V2N,V3N Actualphase voltages (1)
V12, V23,V31 Actual line voltages(1)
(1
) Accuracy of measured voltages depend on a
symmetric, equilibrated system.

ITS2.1 User Manual rev.04/1SEP622750P0001 17
POWERS
P1,P2, P3
Calculated active power (kW)
Ptot
Calculated3 phase active power
(kW)
Q1,Q2,Q3
Calculated reactive power (kVAR)
Qtot
Calculated3 phase reactive power
(kVAR)
S1, S2, S3
Calculated complex power (kVA)
Stot
Calculated3 phase complexpower
(kVA)
Cosphi1, 2 ,3
Calculated cos phi for eachphase
Cos phi tot
Calculated3 phase
power factor
TEMPERATURE
Temperature
Actual temperature measured
ENERGIES
Active energy positive
Calculated positive active
energy(kWh)
Active energy negative
Calculated negative active
energy(kWh)
Active energy total
Sum ofpositive and negative
active energy (kWh)
Reactive energy positive
Calculated positive reactive
energy(kvarh)
Reactive energy negative
Calculated negative reactive
energy(kvarh)
Reactive energy total
Sum ofpositive and negative
reactive energy (kvarh)
Apparent energy total
Total Apparent energy(kVAh)
COMMANDS
Energy Reset
Resetenergy counter

ITS2.1 User Manual rev.04/1SEP622750P0001 18
5.4 Main Measures
STATUS
Switchposition
Indicates
switch
status
is open
or closed
Fuse blown
Indicates that oneor
morefuses
are blown
MEASUREMENTS
L1, L2, L3
Actual currents
V1N,V2N,
V3N
Actual phase voltages
(1)
V12, V23, V31
Actual line voltages
(1)
(1
) Accuracy of measured voltages depend on a
symmetric, equilibrated system
Ptot
Calculated 3 phase activepower
(kW)
Qtot
Calculated 3 phase reactive power
(kVAR)
Cosphi tot
Calculated 3 phase power factor
Active energy total
Sumof positive and negative
active energy(kWh)
Temperature
Actual temperature measured on
L2cable terminal

ITS2.1 User Manual rev.04/1SEP622750P0001 19
5.5 Min - max Measures
CURRENTS
L1, L2, L3
min - max
Actual min
-
max currents
VOLTAGES
V1N, V2N,V3N
min - max
Actual min
-
max phase voltages
V12, V23,V31
min - max
Actual min
-
max
line voltages
OTHER MEASURES
Frequency min
-
max
Actual min
–
max frequency
Temperature
min - max
Actual min
-
max temperature
POWERS
P1,P2, P3
min - max
Calculatedmin
–
max active power (kW)
Ptot
min - max
Calculated
min
–
max
3 phase
active
power (kW)
Q1, Q2, Q3
min - max
Calculated
min
–
max
reactivepower
(kVAR)
Qtot
min - max
Calculated
min
–
max
3 phase reactive
power (kVAR)
S1, S2, S3
min - max
Calculated
min
–
max
complex power
(kVA)
Stot
min - max
Calculated
min
–
max
3
phase complex
power (kVA)
COMMANDS
Min
-
m
axReset
Resets allmin
–
max measures

ITS2.1 User Manual rev.04/1SEP622750P0001 20
5.6 Modbus RTU
Modbus RTU communication configuration (Embedded System bus)
Slave address
Set the address of the connected ITS module, 0~247selectable, default
247
Baud rate
Set the baudrate of the connected ITS module,
9600, 19200 selectable, default 19200
Protocoltype
Set the physical protocol
E,8,1
1 EVEN parit
y
bit,8 data bits, 1 STOP bit,default
O,8,1
1 ODD parity bit, 8 data bits, 1 STOP bit
N,8,2
Noparity bit, 8 data bits,2 STOP bi
t
s
N,8,1
No parity bit, 8 data bits, 1 STOP bit
Modbus communication statistics (Embedded System bus)
N. ofmessages
received
Number of messages received by Ekip connect from ITS
N. ofmessages
receivedwith CRC error
Number of messages received by Ekip connect with CRCerror from ITS
N. of messages sent
Number of
messages sent byEkip connect to ITS
N. of messages sent
-
Exception
Number of messages sent byEkip connect to ITS and received byITS successfully
N. of messages sent
-
Exception: Slave Device
Busy
Number of messages sent byEkip connect to ITS but not rec
eived by ITS because ITS busy
