ABB Zenith ZTG 30 User manual

OPERATION, MAINTENANCE, AND INSTALLATION GUIDE
Zenith ZTG series
For ZTG(D) series automatic transfer
switches, 30-1200 A, 200-480 Vac

3
1
—
Receiving, handling and storage
Receiving and handling
Upon receipt, carefully inspect the trans-
fer switch for damage that may have oc-
curred during transit. If damage is evi-
dent, or there is visible indication of
rough handling, immediately file a dam-
age claim with the transportation com-
pany, and notify your local ABB sales
office.
Do not remove the shipping packaging
until ready to install the switch.
Storage
If the unit will not be placed into service
immediately, store the transfer switch in
its original package in a clean, dry loca-
tion. To prevent condensation, maintain a
uniform temperature. Store the unit in a
heated building, allowing adequate air cir-
culation and protection from dirt and
moisture. Storing the unit outdoors could
cause harmful condensation inside the
transfer switch enclosure.
HAZARD OF EQUIPMENT
OVERTURNING
When moving with a fork lift, do not re-
move the shipping packaging until the de-
vice is in its final location.
Failure to follow this instruction may
result in personal injury or equipment
damage.
Warning
Indicates a hazardous situation that,
if not avoided, could result in death or
serious injury.

4
Zenith ZTG Series ATS, OPERATION, MAINTENANCE, AND INSTALLATION GUIDE
—
Read these safety instructions
carefully before using this product!
HAZARD OF ELECTRIC SHOCK,
EXPLOSION, OR ARC FLASH
• Apply appropriate personal protective
equipment and follow safe electrical
work practices.
• This equipment must only be installed
and serviced by qualified electrical per-
sonnel.
• Before performing visual inspections,
tests, or maintenance on the equip-
ment, disconnect all sources of electric
power. Assume that all circuits are live
unless they are completely de-ener-
gized, tested, grounded, and tagged.
Pay particular attention to the design of
the power system. Consider all sources
of power, including the possibility of
backfeeding.
• Disconnect all sources of electric power
before removing or making source side
or load side connections to the transfer
switch.
• Always use a properly rated voltage
sensing device at all line and load con-
nections to confirm transfer switch is
disconnected from all live electrical
sources.
• Turn off power supplying transfer
switch before doing any other work on
or inside switch.
Failure to follow these instructions could
result in death or serious injury.
Danger
Indicates a hazardous situation that,
if not avoided, will result in death or
serious injury.

5
12
—
Operation, maintenance,
and installation
instruction
Automatic transfer
switches, Zenith ZTG
series ATS
INSTALLATION INSTRUCTIONS,
ZENITH ZTG SERIES ATS,
CHAPTERS 9–11
OPERATION AND MAINTENANCE
INSTRUCTIONS, ZENITH
ZTG SERIES ATS,
CHAPTERS 1–8

6
Zenith ZTG Series ATS, OPERATION, MAINTENANCE, AND INSTALLATION GUIDE
1

7
1
—
Operation and
maintenance instruction
Automatic transfer
switches, Zenith ZTG
series ATS
1. Introduction 11
1.1 Hazard Categories 11
1.2 Definitions 12
1.3 Warranty 13
1.4 Product Specification 14
2. Product overview 15
2.1 General overview 16
2.1.1 Operation types 17
2.2 HMI 18
2.3 Zenith ZTG series features 19
2.4 Typical applications 22
2.5 Sequence of operations 24
2.5.1 Switching sequence / Automatic 24
2.6 Special features description 30
2.6.1 Automatic configuration 30
2.6.2 In-phase monitor 30
2.6.3 Powering supply scenarios 30

8
Zenith ZTG Series ATS, OPERATION, MAINTENANCE, AND INSTALLATION GUIDE
1
3. General operation 31
3.1 Position indication 31
3.2 Operating and locking 32
3.3 Manual handle operation 33
3.4 Return to automatic mode,
operating by HMI 35
3.5 LED functionality in HMI 36
3.6 Using HMI 38
3.6.1 Keypad 38
3.6.2 Navigating in menu 38
4. Navigating HMI menu 39
4.1 Start screens 39
4.2 Using main menu and setting parameters 41
4.3 Menus and parameters 42
5. Electronic accessories 53
5.1 Using Ekip Connect -software 54
5.2 Using Ekip Bluetooth-module 55
5.2.1 LED indications 55
5.3 Using Ekip Programming -module 56
5.3.1 LED indications 56
5.4 Auxiliary power supply module 57
5.4.1 Electrical characteristics 57
5.4.2 LED indications 57

9
1
5.5 Using Ekip Signalling 2K-_ -module 58
5.5.1 Electrical characteristics of 58
Ekip Signalling 2K-_ -module
5.5.2 Access from the display / 58
Ekip Signalling 2K-_ -module
5.5.3 LED indications and inputs/outputs 61
of Ekip Signalling 2K-_ -module
5.6 Using Ekip Com _ -modules 62
5.6.1 Ekip Com Modbus RTU -module 62
5.6.2 Ekip Com Profibus DP -module 65
5.6.3 Ekip Com DeviceNet -module 68
5.6.4 Ekip Com Modbus TCP -module 72
5.6.5 Ekip Com Profinet -module 76
5.6.6 Ekip Com EtherNet/IP -module 79
6. Troubleshooting 83
6.1 Alarms 83
6.2 Warnings 85
6.3 Information 86
7. Technical data 87
7.1 General technical data 87
7.2 Circuit diagrams 90
7.3 Overall dimensions 92
8. Maintenance 95

10
Zenith ZTG Series ATS, OPERATION, MAINTENANCE, AND INSTALLATION GUIDE
1

11
1
—
1. Introduction
This manual describes the installation,
basic operation, and maintenance of
the Zenith ZTG series (30-1200A, 200-
480Vac) automatic transfer switches,
manufactured by ABB. Installation in-
structions for the transfer switch and
available accessories can be found in
chapters 9 and 10.
—
1.1 Hazard Categories
The following important highlighted in-
formation appears throughout this docu-
ment to warn of potential hazards or to
call attention to information that clarifies
a procedure.
Carefully read all instructions and become
familiar with the devices before trying to
install, operate, service or maintain
this equipment.
Danger
Indicates a hazardous situation that, if not
avoided, will result in death or serious injury.
Warning
Indicates a hazardous situation that, if not
avoided, could result in death or serious
injury.
Caution
Indicates a hazardous situation that, if not
avoided, could result in minor or moderate in-
jury. Failure to comply with these instructions
may result in product damage.
Notice
It is used to notify of practices not related to
personal injury. Failure to comply with these
instructions may result in product damage.

12
Zenith ZTG Series ATS, OPERATION, MAINTENANCE, AND INSTALLATION GUIDE
1
—
1.2 Definitions
ATS
Automatic transfer switches
Ekip
Electronic accessories / Ekip-modules;
communication, signaling and
connectivity modules
HMI
Control interface (Human Machine
Interface), operating and configuration
Programming port
Only for Ekip Programming and Ekip
Bluetooth -modules (USB port)
Slide switch
Switch for operating mode selection
(Hand - Locking - AUTO)
S1
SOURCE 1, power supply
S2
SOURCE 2, power supply
Zenith ZTG series ATS
General purpose commecial & industrial
enclosed automatic transfer switches,
product name

13
1
—
1.3 Warranty
This document is based on information
available at the time of its publication.
While efforts have been made to ensure
accuracy, the information contained
herein does not cover all details or
variations in hardware and software,
nor does it provide for every possible
contingency in connection with
installation, operation, and maintenance.
Features may be described herein that are
not present in all hardware and software
systems.
ABB Zenith assumes no obligation of
notice to holders of this document with
respect to changes subsequently made.
ABB Zenith makes no representation or
warranty, expressed, implied, or
statutory, and assumes no responsibility
for the accuracy, completeness,
sufficiency, or usefulness of the
information contained herein. No
warrantees of merchantability or fitness
for purpose shall apply.
Contact your local sales office if further
information is required concerning any
aspect of the automatic transfer switch
operation or maintenance.
Warranty Period
The Warranty Period for ZTG series
transfer switch products is twenty-four
(24) months from the date of
shipment.
Notes: This warranty is valid only in the
United States and for products sold and
installed within seller-specified countries.
Replacement parts are warranted for a
period of 90 days when installed by a
factory or an authorized service station.
Contact Service team at: [phone]

14
Zenith ZTG Series ATS, OPERATION, MAINTENANCE, AND INSTALLATION GUIDE
1
—
1.4 Product Specification
Quality Assurance
All ABB Zenith automatic transfer
switches have been designed and
manufactured to the highest technical
standards. Strict procedures ensure first-
class product quality.
Product Serial Number
Please have the serial number available
when communicating about the
automatic transfer switch. The serial
number can be found on the product
nameplate affixed to each power panel
assembly. See example below.
Product Rating / Applicable Standards
For UL 1008 ‘withstand’ and ‘close on
short circuit’ ratings, refer to ABB
publication number TB-1102
Figure 1.1: Sample nameplate
—
 ZENITH ZTG
AUTOMATIC TRANSFER SWITCH FOR USE IN EMERGENCY SYSTEMS
Serial number US1150191900001
Model number ZGOM3XX12-CX3XE4XX
Voltage
Rated current
Frequency
Phase
Transition type
200 - 480 Vac
800 A
50/60 Hz
3 Phase
Open
Country of Origin Finland
UL/Rating Label

15
1
The available operation types for automatic
transfer switches:
• Standard transition Zenith ZTG series ATS,
type codes beginning ZGO_from 30-1200 A,
200-480 Vac
• Delayed transition Zenith ZTGD series ATS,
type codes beginning ZGD_from 30-1200 A,
200-480 Vac
—
2. Product overview
—
Zenith ZTG series automatic transfer switches, from 30 A
up to 1200 A, are designed for use in general purpose
commercial and industrial low voltage automatic transfer
switch applications. Zenith ZTG series automatic transfer
switches can be operated electrically by LCD control
interface (HMI) or manually by using the handle. You can
select the operating mode by the slide switch (Hand -
Locking - AUTO) on switch front. Configuration is done
by LCD HMI.

16
1
Zenith ZTG Series ATS, OPERATION, MAINTENANCE, AND INSTALLATION GUIDE
1 Automatic transfer switch
2 Embedded ATS control unit and mechanism
3 HMI unit, two types (ZTX DIP and ZTG LCD)
4 Slide switch (Hand - Locking - AUTO) for selection of the operation mode
5 Padlocking the automatic transfer switch to prevent automatic and
manual operation
6 Handle for manual operation
7 Position indication
8 Terminals for control circuit connections (behind the cover)
9 Place for connectivity modules (aux power supply, com and signaling)
10 Place for auxiliary contact block
11 Location of product identification label
12 Programming port, only for Ekip Programming module and Ekip Connect software
—
Fig. 2.1 Automatic transfer switch, Zenith ZTG powered by TrueONE®
—
2.1 General overview
2 8 9 4 6 110
12
11
3
5 7

17
1
2.1.1 Operation types
In this table you can find the differences of
the automatic transfer switch open and de-
layed transition operation types. Due to the
different transition types, there are differ-
ences are on HMI and on wiring of I/O con-
tacts. For more information on HMIs, see
chapter 2.2 and for wiring, see chapter 7.
Operation types, ZTG series ATS Ekip-modules suitable
Delayed transition, ZTGD Open transition, ZTG
IS1 S2
Load
OII IIS1 S2
Load
OI
IS1 S2
Load
II
ZTG series HMI (with LCD-screen) and connections of control circuit
l
ON
ll
ON
Auto
Alarm reset
AUTO
!
S1 S2
LOAD
lll
O
O
OFF
Esc
l
ON
ll
ON
Auto
Alarm reset
AUTO
!
S1 S2
LOAD
lll
Esc
Suitable
CC NO NC C
10 1 1 12 1 3 141 2 3 65
G
O1 I1 I2
+-
FIRE
24V C I1C NO NC O1C
12 131 2 3 65
G
—
Table 2.1 The differences of level types / operation types and the suitability of Ekip-modules

18
1
Zenith ZTG Series ATS, OPERATION, MAINTENANCE, AND INSTALLATION GUIDE
The HMI is the control interface
(Human Machine Interface) of the ATS.
Zenith ZTG series has an LCD HMI
with push buttons. The HMI is used
for configuring parameters for
automatic operation.
—
2.2 HMI
I - O - II (or II - O - I) I - II (or II - I)
l
ON
ll
ON
Auto
Alarm reset
AUTO
!
S1 S2
LOAD
lll
Esc
l
ON
ll
ON
Auto
Alarm reset
AUTO
!
S1 S2
LOAD
lll
O
O
OFF
Esc
ZTG:
HMI with
LCD-screen
—
Fig. 2.2 The HMI form will correspond to the type
of ZTG series - open or delayed transition

19
1
—
2.3 Zenith ZTG series features
Feature comparison ZTG(D) controls (LCD)
l
ON
ll
ON
Auto
Alarmreset
AUTO
!
S1 S2
LOAD
lll
O
O
OFF
Esc
l
ON
ll
ON
Auto
Alarmreset
AUTO
!
S1 S2
LOAD
lll
Esc
Ampere sizes available UL: 30...1200 A
Rated voltage 200...480 Vac
Rated frequency 50 / 60 Hz
Phase system Single and Three
Number of poles 2, 3 and 4
Neutral configuration
Switched Yes
Product type
Open transition (I-II) Yes
Delayed transition (I - O - II or II - O - I) Yes
Voltage and frequency settings
Pick up SOURCE 1 Voltage 81…99%, 101…119%
Drop out SOURCE 1 Voltage 80…98%, 102…120%
Pick up SOURCE 2 Voltage 81…99%, 101…119%
Drop out SOURCE 2 Voltage 80…98%, 102…120%
Pick up SOURCE 1 Frequency 80,5…99,5%, 100,5…119,5%
Drop out SOURCE 1 Frequency 80…99%, 101…120%
Pick up SOURCE 2 Frequency 80,5…99,5%, 100,5…119,5%
Drop out SOURCE 2 Frequency 80…99%, 101…120%
Time delay settings
Override momentary SOURCE 1 Outage, sec 0…60
Transfer from SOURCE 1 to SOURCE 2, sec 0…3600
Override momentary SOURCE 2 Outage, sec 0…60
Transfer from SOURCE 2 to SOURCE 1, min 0…120
Generator stop delay, min 0…60
Center-OFF delay, sec 0…300

20
1
Zenith ZTG Series ATS, OPERATION, MAINTENANCE, AND INSTALLATION GUIDE
Feature comparison ZTG(D) controls (LCD)
l
ON
ll
ON
Auto
Alarmreset
AUTO
!
S1 S2
LOAD
lll
O
O
OFF
Esc
l
ON
ll
ON
Auto
Alarmreset
AUTO
!
S1 S2
LOAD
lll
Esc
Pre-transfer delay S1 to S2, sec 0…60
Post-transfer delay S1 to S2 , sec 0…60
Pre-transfer delay S2 to S1, sec 0…60
Post-transfer delay S2 to S1, sec 0…60
Load shed delay, sec 0…60
Source failure detections
No voltage Yes
Undervoltage Yes
Overvoltage Yes
Phase missing Yes
Voltage unbalance Yes
Invalid frequency Yes
Incorrect phase sequence Yes
Features
Controls LCD + keys
LED indications for ATS, S1 and S2 status Yes
Open transition - Standard digital inputs/outputs 1 / 1
Delayed transition - Standard digital inputs/
outputs
1 / 2
Programmable digital inputs/outputs Yes
Auto config (voltage, frequency, phase system) Yes
Source priority SOURCE 1/2, No priority
Manual re-transfer Yes
In-phase monitor Yes
Genset exercising: on-load, off-load Yes
In-built power meter module No
Load shedding Yes
Real time clock Yes
Event log Yes
