ABB Zenith ZTS T Series User manual

OPERATION, MAINTENANCE, AND INSTALLATION GUIDE
Zenith ZTS T-series
For ZTS(D) T-series automatic transfer
switches 1600-3000 A and ZTSCT
T-series automatic transfer switches
100-3000 A, 208-480 Vac

2
1
ZENITH ZTS(D) T-SERIES 1600-3000 A & ZTSCT T-SERIES 100-3000 A

3
1
OPERATION, MAINTENANCE, AND INSTALLATION GUIDE
—
Receiving, handling and storage
Receiving and handling
Upon receipt, carefully inspect the trans-
fer switch for damage that may have oc-
curred during transit. If damage is evi-
dent, or there is visible indication of
rough handling, immediately file a dam-
age claim with the transportation com-
pany, and notify your local ABB sales
office.
Do not remove the shipping packaging
until ready to install the switch.
Storage
If the unit will not be placed into service
immediately, store the transfer switch in
its original package in a clean, dry loca-
tion. To prevent condensation, maintain a
uniform temperature. Store the unit in a
heated building, allowing adequate air
circulation and protection from dirt and
moisture. Storing the unit outdoors could
cause harmful condensation inside the
transfer switch enclosure.
HAZARD OF EQUIPMENT
OVERTURNING
When moving with a fork lift, do not
remove the shipping packaging until the
device is in its final location.
Failure to follow this instruction may
result in personal injury or equipment
damage.
Warning
Indicates a hazardous situation that, if not
avoided, could result in death or serious
injury.

4
1
ZENITH ZTS(D) T-SERIES 1600-3000 A & ZTSCT T-SERIES 100-3000 A
—
Read these safety instructions
carefully before using this product!
HAZARD OF ELECTRIC SHOCK,
EXPLOSION, OR ARC FLASH
• Apply appropriate personal protective
equipment and follow safe electrical
work practices.
• This equipment must only be installed
and serviced by qualified electrical per-
sonnel.
• Before performing visual inspections,
tests, or maintenance on the equip-
ment, disconnect all sources of electric
power. Assume that all circuits are live
unless they are completely de-ener-
gized, tested, grounded, and tagged.
Pay particular attention to the design of
the power system. Consider all sources
of power, including the possibility of
backfeeding.
• Disconnect all sources of electric power
before removing or making source side
or load side connections to the transfer
switch.
• Always use a properly rated voltage
sensing device at all line and load con-
nections to confirm transfer switch is
disconnected from all live electrical
sources.
• Turn off power supplying transfer
switch before doing any other work on
or inside switch.
Failure to follow these instructions could
result in death or serious injury.
Danger
Indicates a hazardous situation that,
if not avoided, will result in death or
serious injury.

5
1
OPERATION, MAINTENANCE, AND INSTALLATION GUIDE
2
—
Operation, maintenance,
and installation
instruction
Automatic transfer
switches, Zenith
ZTS T-series ATS
INSTALLATION INSTRUCTIONS,
ZENITH ZTS T-SERIES ATS,
CHAPTERS 9–11
OPERATION AND MAINTENANCE
INSTRUCTIONS, ZENITH
ZTS T-SERIES ATS,
CHAPTERS 1–8

6
1
ZENITH ZTS(D) T-SERIES 1600-3000 A & ZTSCT T-SERIES 100-3000 A

7
1
OPERATION, MAINTENANCE, AND INSTALLATION GUIDE
—
Operation and
maintenance instruction
Automatic transfer
switches, Zenith
ZTS T-series ATS
1. Introduction 11
1.1 Hazard Categories 11
1.2 Definitions 12
1.3 Warranty 13
1.4 Product Specification 14
2. Product overview 15
2.1 General overview 16
2.1.1 Operation types 18
2.2 HMI 19
2.3 Zenith ZTS T-series features 20
2.4 Typical applications 23
2.5 Sequence of operations 25
2.5.1 Switching sequence / Automatic
(open / delayed transition) 25
2.5.2 Switching sequence / Automatic
(open / delayed transition) 31
2.6 Special features description 35
2.6.1 Automatic configuration 35
2.6.2 In-phase monitor 35
2.6.3 Powering supply scenarios 35

8
1
ZENITH ZTS(D) T-SERIES 1600-3000 A & ZTSCT T-SERIES 100-3000 A
3. General operation 37
3.1 Position indication 37
3.1.1 Position indication - R5 37
3.1.2 Position Indication - 63L 38
3.2 Operating of automatic Transfer Switch
Equipment 39
3.2.1 Operation of Automatic Transfer
Switch equipment -R5 40
3.2.2 Operation of Automatic Transfer
Switch equipment -63L 42
4. Navigating HMI menu 45
4.1 Start Menu 45
4.2 Using main menu and setting parameters 47
4.3 Menus and parameters 48
4.4 Analog meters and Measures 61
5. Electronic accessories 63
5.1 Using Ekip Connect -software 64
5.2 Using Ekip Programming -module 65
5.2.1 LED indications 65
5.3 Auxiliary power supply module 66
5.3.1 Electrical characteristics 66
5.3.2 LED indications 66
5.4 Using Ekip Signalling 2K-_ -module 67
5.4.1 Electrical characteristics of Ekip
Signalling 2K-_ -module 67
5.4.2 Access from the display / Ekip
Signalling 2K-_ -module 67
5.4.3 LED indications and inputs/outputs
of Ekip Signalling 2K-_ -module 71
5.5 Using Ekip Com _ -modules 72
5.5.1 Ekip Com Modbus RTU -module 72
5.5.2 Ekip Com Profibus DP -module 75
5.5.3 Ekip Com DeviceNet -module 78
5.5.4 Ekip Com Modbus TCP -module 82
5.5.5 Ekip Com Profinet -module 86
5.5.6 Ekip Com EtherNet/IP -module 89

9
1
OPERATION, MAINTENANCE, AND INSTALLATION GUIDE
6. Troubleshooting 93
6.1 Alarms 93
6.2 Warnings 95
6.3 Information 96
7. Technical data 97
7.1 General technical data 97
7.2 Circuit diagrams 100
7.3 Overall dimensions 103
8. Maintenance 119
9. Panel installation 111
9.1 Basic Tools for Installation
and Maintenance 112
9.2 Equipment Inspection and Storage 112
9.3 Lifting and mounting the panel 113
9.4 Mounting the automatic transfer switch 117
9.4.1 Mounting hole dimensions 117
9.4.2 Mounting hole dimensions
(stand-alone ATS, no enclosure) 118
9.4.3 HMI Installation 120
9.5 Wire Connection 121
9.6 Final Equipment Inspection 122
9.7 Initial Energizing 123
10. Accessories 125
10.1 Auxiliary power supply and Ekip -modules 125
10.2 HMI protective cover 127
11. Replacement parts 129

10
1
ZENITH ZTS(D) T-SERIES 1600-3000 A & ZTSCT T-SERIES 100-3000 A

11
1
OPERATION, MAINTENANCE, AND INSTALLATION GUIDE
—
1. Introduction
This manual describes the installation,
basic operation, and maintenance of
the Zenith ZTS(D) T-series 1600-3000 A
and ZTSCT T-series 100-3000 A,
208-480 Vac automatic transfer switches,
manufactured by ABB. Installation
instructions for the transfer switch and
available accessories can be found in
Chapters 9 and 10.
—
1.1 Hazard Categories
The following important highlighted
information appears throughout this
document to warn of potential hazards
or to call attention to information that
clarifies a procedure.
Carefully read all instructions and become
familiar with the devices before trying to
install, operate, service or maintain
this equipment.
Danger
Indicates a hazardous situation that, if not
avoided, will result in death or serious injury.
Warning
Indicates a hazardous situation that, if not
avoided, could result in death or serious
injury.
Caution
Indicates a hazardous situation that, if not
avoided, could result in minor or moderate in-
jury. Failure to comply with these instructions
may result in product damage.
Notice
It is used to notify of practices not related to
personal injury. Failure to comply with these
instructions may result in product damage.

12
1
ZENITH ZTS(D) T-SERIES 1600-3000 A & ZTSCT T-SERIES 100-3000 A
—
1.2 Definitions
ATS
Automatic transfer switches
Ekip
Electronic accessories / Ekip-modules;
communication, signaling and
connectivity modules
HMI
Control interface (Human Machine
Interface), operating and configuration
Programming port
Only for Ekip Programming and Ekip
Bluetooth -modules (USB port)
S1
SOURCE 1, power supply
S2
SOURCE 2, power supply
Zenith ZTS T-series ATS
Business, Industrial and Mission critical
enclosed automatic transfer switches,
product name
Load Shed
Digital output function for signaling a
downstream load to disconnect. This
functionality is different than the legacy
Zenith R15 Load Shed which is an input for
the ATS to disconnect generator when
signaled.

13
1
OPERATION, MAINTENANCE, AND INSTALLATION GUIDE
—
1.3 Warranty
This document is based on information
available at the time of its publication.
While efforts have been made to ensure
accuracy, the information contained
herein does not cover all details or
variations in hardware and software,
nor does it provide for every possible
contingency in connection with
installation, operation, and maintenance.
Features may be described herein that are
not present in all hardware and software
systems.
ABB Zenith assumes no obligation of
notice to holders of this document with
respect to changes subsequently made.
ABB Zenith makes no representation or
warranty, expressed, implied, or
statutory, and assumes no responsibility
for the accuracy, completeness,
sufficiency, or usefulness of the
information contained herein. No
warrantees of merchantability or fitness
for purpose shall apply.
Contact your local sales office if further
information is required concerning any
aspect of the automatic transfer switch
operation or maintenance.
Warranty Period
The Warranty Period for ZTS T-series
transfer switch products is twenty-four
(24) months from the date of
shipment.
Notes: This warranty is valid only in the
United States and for products sold and
installed within seller-specified countries.
Replacement parts are warranted for a
period of 90 days when installed by a
factory or an authorized service station.
Contact Service team at: [phone]
or [e-mail] for 24-hour
support.

14
1
ZENITH ZTS(D) T-SERIES 1600-3000 A & ZTSCT T-SERIES 100-3000 A
—
1.4 Product Specification
Quality Assurance
All ABB Zenith automatic transfer
switches have been designed and
manufactured to the highest technical
standards. Strict procedures ensure first-
class product quality.
Product Serial Number
Please have the serial number available
when communicating about the
automatic transfer switch. The serial
number can be found on the product
nameplate affixed to each power panel
assembly. See example below.
Product Rating / Applicable Standards
For UL 1008 ‘withstand’ and ‘close on
short circuit’ ratings, refer to ABB
publication number 1SCC303020C0201.
Fig. 1 Sample nameplate
 ZENITH ZTS
AUTOMATIC TRANSFER SWITCH FOR USE IN EMERGENCY SYSTEMS
Serial number US1150210400001
Model number ZSAC080PS3S5TBXXXX
Voltage
Rated current
Frequency
Phase
Transition type
460 - 480 Vac
800 A
50/60 Hz
3 Phase
Closed
Assembled in US

The available operation types for automatic
transfer switches:
• Open (standard) transition Zenith ZTS
T-series ATS, type codes beginning ZSAO_
from 1600-3000 A, 208-480 Vac
• Delayed transition Zenith ZTSD T-series ATS,
type codes beginning ZSAD_ from
1600-3000 A, 208-480 Vac
• Closed transition Zenith ZTSCT T-series ATS,
type codes beginning ZSAC_from
100-3000 A, 208-480 Vac
—
2. Product overview
Zenith ZTS T-series automatic transfer switches, from
100 A up to 3000 A, are designed for use in Business,
Industrial and Mission critical low voltage automatic
transfer switch applications. Zenith ZTS T-series automatic
transfer switches can be operated electrically by touch
screen control interface (HMI) or manually by using the
handle. Configuration is done by LCD HMI.

16
1
ZENITH ZTS(D) T-SERIES 1600-3000 A & ZTSCT T-SERIES 100-3000 A
—
2.1 General overview
C – Controller
C – 1 Rating plug
C – 2 Source 1
C – 3 Source 2
C – 4 EKIP ACCESS
Communications Module
C-1 C-2
C-3
C-4
A
Programming Port
- only for Ekip Programming and
Ekip Connect Software
C
B
D
(Under cover)
A. Level 4 HMI, ZTS T-Series color touchscreen LCD
B. Automatic transfer switch (ATS)
C. ATS control unit
D. Handle for manual operation
E. Engine start terminal blocks
A. Level 4 HMI, ZTS T-Series color touchscreen LCD
B. Automatic transfer switch (ATS)
C. ATS control unit
D. Handle for manual operation
E. Engine start terminal blocks
F. Document holder (R5 only)
F
B
D
C
E
E

17
1
OPERATION, MAINTENANCE, AND INSTALLATION GUIDE
Standard Transition Shown
B-ATS - R5
1. Customer Auxliary contact connection points
2. SCR Assemblies. Access by removing cover screws on side of panel (63L)
3. Customer manual operating ports
4. Transfer Coil Solenoids
5. Arc Chute Assemblies (Arc Quenching assemblies)
6. Movable Contact Assemblies
7. Position Limit Switches Auxiliary Contact Limit Switches
8. Mechanical Drive Assembly -mechanical interlock system
Source position status
I = contacts closed
O = contacts open
3
Covers Removed
8
4
7
5
1
6
2
1
32
8
7
4
5
6
Covers Removed
B-ATS - 63L
1. Customer Auxliary contact connection points
2. SCR Assemblies. Access by removing cover screws on side of panel (63L)
3. Customer manual operating ports
4. Arc Chute Assemblies (Arc Quenching assemblies)
5. Movable Contact Assemblies
6. Position Limit Switches Auxiliary Contact Limit Switches
7. Mechanical Drive Assembly -mechanical interlock system
8. Transfer Coil Solenoids

18
1
ZENITH ZTS(D) T-SERIES 1600-3000 A & ZTSCT T-SERIES 100-3000 A
Operation types, ZTS T-series ATS Ekip-modules suitable
Delayed transition, ZTSD
Closed transition, ZTSCT Open transition, ZTS
ZTS T-series HMI (with touch screen) and connections of control circuit
Suitable
—
Table 2.1 The differences of level types / operation types and the suitability of Ekip-modules
2.1.1 Operation types
In this table you can find the differences
of the automatic transfer switch open and
delayed transition operation types. Due
to the different transition types, there are
variances with HMI and on wiring of I/O
contacts. For more information on HMIs,
see Chapter 2.2.
l
ON
ll
ON
AUTO
!
S1 S2
LOAD
lll
O
O
OFF
l
ON
ll
ON
AUTO
!
S1 S2
LOAD
lll
IS1 S2
Load
OII II S1 S2
Load
I

19
1
OPERATION, MAINTENANCE, AND INSTALLATION GUIDE
The HMI is the control interface
(Human Machine Interface) of the ATS.
Zenith ZTS T-series has a color touch-
screen LCD HMI with push buttons. The
HMI is used for configuring parameters
for automatic operation.
—
2.2 HMI
I - O - II (or II - O - I)
ZTS:
HMI with
Touch screen
—
Fig. 2.1 The HMI form will correspond to the type of
ZTS T-series - open, delayed, or closed transition
l
ON
ll
ON
AUTO
!
S1 S2
LOAD
lll
O
O
OFF
l
ON
ll
ON
AUTO
!
S1 S2
LOAD
lll

20
1
ZENITH ZTS(D) T-SERIES 1600-3000 A & ZTSCT T-SERIES 100-3000 A
—
2.3 Zenith ZTS(D/CT) T-series features
Feature comparison ZTS(D/CT) controls (Touch screen)
Ampere sizes available


Rated voltage 
Rated frequency 
Phase system Single and Three
Number of poles 
Neutral configuration
Switched Yes
Product type
Open transition (I - II) Yes
Delayed transition (I - O - II or II - O - I) Yes
Closed transition (I - O - II or II - O - I) Yes
Voltage and frequency settings
 
 
 
 
 
 
 
 
Time delay settings
 
 
 
l
ON
ll
ON
AUTO
!
S1 S2
LOAD
lll
l
ON
ll
ON
AUTO
!
S1 S2
LOAD
lll
O
O
OFF
