ABB TTH200 Installation and operation manual

CI/TTH200-EN TTH200
Commissioning Instruction
Head mounted Temperature Transmitter
TTH200

Neu
Head mounted Temperature Transmitter
TTH200
Commissioning Instruction - EN
CI/TTH200-EN
03.2009
Manufacturer:
ABB Automation Products GmbH
Borsigstraße 2
63755 Alzenau
Germany
Tel.: [phone]
Fax: [phone]
[email protected]b.com
© Copyright 2009 by ABB Automation Products GmbH
Subject to changes without notice
This document is protected by copyright. It assists the user in safe and efficient operation of the device.
The contents of this document, whether whole or in part, may not be copied or reproduced without prior
approval by the copyright holder.
Contents

Contents
2 - EN TTH200 CI/TTH200-EN
1Safety....................................................................................................................................................................4
1.1 General information and notes for the reader ................................................................................................4
1.2 Intended use...................................................................................................................................................4
1.3 Target groups and qualifications ....................................................................................................................5
1.4 Warranty provisions........................................................................................................................................5
1.5 Plates and symbols ........................................................................................................................................6
1.5.1 Safety/warning symbols, note symbols...................................................................................................6
1.5.2 Name plate..............................................................................................................................................7
1.6 Transport safety information ..........................................................................................................................8
1.7 Safety information for electrical installation....................................................................................................8
1.8 Safety information for commissioning ............................................................................................................8
1.9 Operating safety information ..........................................................................................................................8
2Use in potentially explosive atmospheres........................................................................................................9
2.1 Approvals .......................................................................................................................................................9
2.2 Housing degree of protection .........................................................................................................................9
2.3 Electrostatic charging .....................................................................................................................................9
2.4 Grounding.......................................................................................................................................................9
2.5 Interconnection...............................................................................................................................................9
2.6 Configuration ..................................................................................................................................................9
2.7 Ex relevant specifications...............................................................................................................................9
3Mounting ............................................................................................................................................................10
3.1 Installation options........................................................................................................................................10
3.1.1 Installation in the cover of the connection head....................................................................................10
3.1.2 Installation on the measuring inset .......................................................................................................11
3.1.3 Installation on a top hat rail ...................................................................................................................12
3.2 Installing/Removing the optional LCD display..............................................................................................12
4Electrical connection ........................................................................................................................................13
4.1 Conductor material.......................................................................................................................................14
4.2 Electrical connections configuration.............................................................................................................14
4.3 Sensor connection........................................................................................................................................14
4.4 Standard application.....................................................................................................................................15
4.5 Standard application with HART functionality ..............................................................................................15
4.6 Electrical interconnection in explosion hazardous areas .............................................................................16
4.6.1 Installation in explosion hazardous areas .............................................................................................16
4.6.2 Zone 0 ...................................................................................................................................................17
4.6.3 Zone 1 (0)..............................................................................................................................................17
4.6.4 Zone 1 (20)............................................................................................................................................18
4.6.5 Zone 2 ...................................................................................................................................................18
5Ex relevant specifications ................................................................................................................................19
5.1 TTH200-E1, Intrinsic Safety ATEX...............................................................................................................19
5.2 TTH200-H1, Intrinsic Safety IECEx..............................................................................................................19
5.3 Safety specifications for Intrinsic Safety ATEX / IECEx...............................................................................19

Contents
CI/TTH200-EN TTH200 EN - 3
5.4 TTH200-E2, Non-Sparking ATEX ................................................................................................................19
5.5 TTH200-L1, Intrinsically Safe FM.................................................................................................................19
5.6 TTH200-L2, Non-Incendive FM....................................................................................................................19
5.7 TTH200-R1, Intrinsically Safe CSA..............................................................................................................19
5.8 TTH200-R2, Non-Incendive CSA.................................................................................................................19
6HMI LCD display type AS..................................................................................................................................20
6.1 Ex relevant specifications.............................................................................................................................20
6.1.1 Intrinsic Safety ATEX ............................................................................................................................20
6.1.2 Intrinsic Safety IECEx ...........................................................................................................................20
6.1.3 Safety specifications for Intrinsic Safety ATEX / IECEx........................................................................20
6.1.4 Intrinsically Safe FM..............................................................................................................................20
6.1.5 Non-Incendive FM.................................................................................................................................20
6.1.6 Intrinsically Safe CSA............................................................................................................................20
6.1.7 Non-Incendive CSA...............................................................................................................................20
7Appendix ............................................................................................................................................................21
7.1 Additional documents...................................................................................................................................21
7.2 Approvals and certifications .........................................................................................................................21

Safety
4 - EN TTH200 CI/TTH200-EN
1 Safety
1.1 General information and notes for the reader
Read these instructions carefully prior to installing and commissioning the device.
These instructions are an important part of the product and must be kept for later use.
These instructions are intended as an overview and do not contain detailed information on all
designs for this product or every possible aspect of installation, operation and maintenance.
For additional information or in case specific problems occur that are not discussed in these
instructions, contact the manufacturer.
The content of these instructions is neither part of any previous or existing agreement, promise
or legal relationship nor is it intended to change the same.
This product is built based on state-of-the-art technology and is operationally safe. It has been
tested and left the factory in a safe, maintenance-free state. The information in the manual must
be observed and followed in order to maintain this state throughout the period of operation.
Modifications and repairs to the product may only be performed if expressly permitted by these
instructions.
Only by observing all of the safety information and all safety/warning symbols in these
instructions can optimum protection of both personnel and the environment, as well as safe and
fault-free operation of the device, be ensured.
Information and symbols directly on the product must be observed. They may not be removed
and must be fully legible at all times.
1.2 Intended use
To measure the temperature of fluid, pulpy or pasty substances and gases or resistance/voltage
values.
The device is designed for use exclusively within the stated values on the name plate and in the
technical specifications (see the "Specifications" chapter in the operating instructions or on the
data sheet).
• The maximum operating temperature must not be exceeded.
• The permitted operating temperature must not be exceeded.
• The housing protection type must be observed.

Safety
CI/TTH200-EN TTH200 EN - 5
1.3 Target groups and qualifications
Installation, commissioning, and maintenance of the product may only be performed by trained
specialist personnel who have been authorized by the plant operator to do so. The specialist
personnel must have read and understood the manual and comply with its instructions.
Prior to using corrosive and abrasive materials for measurement purposes, the operator must
check the level of resistance of all parts coming into contact with the materials to be measured.
ABB Automation Products GmbH will gladly support you in selecting the materials, but cannot
accept any liability in doing so.
The operators must strictly observe the applicable national regulations with regards to
installation, function tests, repairs, and maintenance of electrical products.
1.4 Warranty provisions
Using the device in a manner that does not fall within the scope of its intended use, disregarding
this instruction, using underqualified personnel, or making unauthorized alterations releases the
manufacturer from liability for any resulting damage. This renders the manufacturer's warranty
null and void.

Safety
6 - EN TTH200 CI/TTH200-EN
1.5 Plates and symbols
1.5.1 Safety/warning symbols, note symbols
DANGER – <Serious damage to health / risk to life>
This symbol in conjunction with the signal word "Danger" indicates an imminent danger.
Failure to observe this safety information will result in death or severe injury.
DANGER – <Serious damage to health / risk to life>
This symbol in conjunction with the signal word "Danger" indicates an imminent electrical
hazard. Failure to observe this safety information will result in death or severe injury.
WARNING – <Bodily injury>
This symbol in conjunction with the signal word “Warning“ indicates a possibly dangerous
situation. Failure to observe this safety information may result in death or severe injury.
WARNING – <Bodily injury>
This symbol in conjunction with the signal word "Warning" indicates a potential electrical
hazard. Failure to observe this safety information may result in death or severe injury.
CAUTION – <Minor injury>
This symbol in conjunction with the signal word “Caution“ indicates a possibly dangerous
situation. Failure to observe this safety information may result in minor or moderate injury.
This may also be used for property damage warnings.
ATTENTION – <Property damage>!
The symbol indicates a potentially damaging situation.
Failure to observe this safety information may result in damage to or destruction of the product
and/or other system components.
IMPORTANT (NOTICE)
This symbol indicates operator tips, particularly useful information, or important information
about the product or its further uses. It does not indicate a dangerous or damaging situation.

Safety
CI/TTH200-EN TTH200 EN - 7
1.5.2 Name plate
The name plate is located on the transmitter housing.
A00236
Automation Products GmbH
Alzenau Germany 2008
TTH200
TTH200
U = +11...30 V, I = 4...20 mA, HART
Cfg: 1 x Pt100 3W; 0...100°C
TAG: 123456
Sa
O-Code: TTH200-E1H 00001234560000
Ser.-No: 123456789012 HW. Rev. 1.06
SW. Rev. 01.00.02
PTB 05 ATEX 2017 X
II 1 G EEx ia IIC T6
II 2(1) G EEx [ia]ib IIC T6
II 2G (1D) Ex [iaD]ib IIC T6
T1...T4 Ta. = -40 °C ... +84 °C (Zone 0) ... +85 °C (Zone1)
T5 Ta. =
T6 Ta. =
TTH200-E1H;
-40 °C ... +56 °C (Zone 0) ... +71 °C (Zone1)
-40 °C ... +44 °C (Zone 0) ... +56 °C (Zone1)
0102
HART®
13
14
10
8
4
7
5
3
2
12
11
6
9
1
Fig. 1
1 Model name
2 Manufacturer of transmitter
3 Country and year of manufacture
4 Order code
5 Serial number
6 Technical data
7 Configuration
8 TAG number
9 Ex mark (optional)
10 Marking of explosion proof design
(optional)
11 Temperature classes of explosion proof
design (optional)
12 Refer to product documentation
13 Software revision number/hardware
revision number
14 CE mark (EC conformity)
Important
The temperature range specified on the name plate (11) refers only to the permissible ambient
temperature range for the transmitter and not to the measuring element used in the measuring
inset.

Safety
8 - EN TTH200 CI/TTH200-EN
1.6 Transport safety information
Observe the following information:
• Do not expose the device to moisture during transport. Pack the device accordingly.
• Pack the device so that it is protected from vibration during transport, e.g. through air-
cushioned packaging.
1.7 Safety information for electrical installation
The electrical connections may only be performed by authorized specialist personnel according
to the electrical plans.
Comply with electrical connection information in the instruction. Otherwise, the electrical
protection class can be affected.
The secure separation of contact-dangerous electrical circuits is only ensured when the
connected devices fulfil the requirements of the DIN EN 61140 (VDE 0140 Part 1) (basic
requirements for secure separation).
For secure separation, run the supply lines separated from contact-dangerous electrical circuits
or additionally insulate them.
1.8 Safety information for commissioning
The transmitter is immediately ready for operation after mounting and installation of the
connections. The parameters are set at the factory.
The connected lines must be checked for firm seating. Only firmly seated lines ensure full
functionality.
1.9 Operating safety information
Before switching on, ensure that the specified environmental conditions in the “Technical
Specifications” chapter and in the data sheet are complied with and that the power supply
voltage corresponds with the voltage of the transmitter.
When there is a chance that safe operation is no longer possible, put the device out of operation
and secure against unintended operation.

Use in potentially explosive atmospheres
CI/TTH200-EN TTH200 EN - 9
2 Use in potentially explosive atmospheres
Special regulations must be observed in potentially explosive atmospheres for the power
supply, signal inputs/outputs and ground connection. The information relating specifically to
explosion protection that appears within the individual sections must be observed.
Notice - Potential damage to parts
All parts must be installed in accordance with the manufacturer's specifications, as well as
relevant standards and regulations.
Commissioning and operation must comply with EN 60079-14 (Installation of equipment in
potentially explosive atmospheres).
2.1 Approvals
The approvals for use of the TTH200-E1H temperature transmitter in potentially explosive
atmospheres can be found in the section of the operating instructions titled "Ex relevant
specifications".
2.2 Housing degree of protection
The connection parts of the TTH200-E1H temperature transmitter and the HMI type AS LCD
display must be installed so that a housing degree of protection type of at least IP 20 as per
IEC 60529:1989 is achieved.
2.3 Electrostatic charging
When using the transmitter in Zone 0, please ensure that impermissible electrostatic charging of
the TTH200-E1H temperature transmitter and the LCD display is prevented (observe the
warnings on the device).
2.4 Grounding
If, for functional reasons, the intrinsically safe circuit needs to be grounded by means of
connection to the equipotential bonding, it may only be grounded at one point.
2.5 Interconnection
If transmitters are operated in an intrinsically safe circuit, proof that the interconnection is
intrinsically safe must be provided in accordance with DIN VDE 0165/Part 1 (EN 60079-25/2004
and IEC 60079-25/2003). An interconnection certificate must always be provided for intrinsically
safe circuits.
2.6 Configuration
The TTH200-E1H transmitter can be configured in the potentially explosive atmosphere in
compliance with the interconnection certificate, both directly in the potentially explosive
atmosphere using approved handheld HART terminals and by coupling an Ex modem into the
circuit outside the potentially explosive atmosphere.
2.7 Ex relevant specifications
See chapter „Ex relevant specifications“ in the operating instructions.

Mounting
10 - EN TTH200 CI/TTH200-EN
3 Mounting
3.1 Installation options
There are three options for mounting the transmitter in the temperature sensor heads:
• in the cover of the connection head (without springs)
• directly on the measuring inset (spring mounted)
• on a top hat rail
3.1.1 Installation in the cover of the connection head
1
2
3
A00067
Fig. 2
1. Release the screw plug (3) for the cover of the connection head.
2. Open the cover (1).
3. Secure the transmitter (2) at the proper position on the cover, using the captive screws found
in the transmitter.

Mounting
CI/TTH200-EN TTH200 EN - 11
3.1.2 Installation on the measuring inset
A00066
1
2
3
4
Fig. 3
Important
Before mounting the transmitter on the measuring inset, remove the ceramic block on the
measuring inset and the captive screws in the transmitter.
To install the transmitter on the measuring inset, cambered toothed discs and the
corresponding mounting screws are required; these must be ordered as separate accessories:
Measuring inset installation set (2 mounting screws, 2 springs, 2 toothed discs)
Order number: 215882
1. Remove the ceramic block from the measuring inset (3).
2. Remove the screws from the transmitter (2). Remove the sleeves from the screw holes and
then remove the screws.
3. Insert new mounting screws (1) from above in the installation holes of the transmitter.
4. Place the cambered toothed discs (4) with curve facing upward on the downward protruding
screw thread.
5. Connect the power supply cable to the transmitter according to connection diagram.
6. Place the transmitter in the housing on the measuring inset and secure it.
Important
The toothed discs between measuring inset and transmitter are straightened when the screws
are tightened. This enables them to grip the mounting screws.

Mounting
12 - EN TTH200 CI/TTH200-EN
3.1.3 Installation on a top hat rail
When mounted on a top hat rail, the transmitter can be placed at a distance from the sensor in a
housing that is suitable for the ambient conditions.
A00103
Fig. 4
3.2 Installing/Removing the optional LCD display
A00087
Ø 49,2 / 1,94
35,80 / 1,41
40,80 / 1,60
Fig. 5: HMI type AS LCD display
Thanks to the LCD display interface, the TTH200 can be operated freely with the HMI type AS
LCD-display, enabling process data to be visualized.
Important
The LCD display with HMI type A configuration function, used with the TTx300 series, is not
suitable for the TTH200.
The display must be removed to enable electrical connection of the sensor or the power supply:
- Carefully remove the LCD display from the transmitter inset. The LCD display is held
firmly in place. You may have to use the tip of a screwdriver to pry the LCD display loose.
Take care to avoid any mechanical damage.

Electrical connection
CI/TTH200-EN TTH200 EN - 13
No tools are required to insert the LCD display:
1. Carefully insert the guide pins for the LCD display in the guide holes of the transmitter
inset. Make sure the black connection socket fits into the terminal on the transmitter inset.
2. Then press the LCD display in as far as it will go. Make sure that the guide pins and
connection socket are fully inserted.
The position of the LCD display can be adjusted to suit the installation position of the
transmitter, to ensure that the display is legible.
The LCD display has twelve positions that can be set in 30° increments.
Caution - Potential damage to parts
Make sure the flat ribbon cable does not get twisted or torn when rotating the LCD display.
1. Carefully turn the LCD display to the left to release it from its mount.
2. Use caution when positioning the LCD display.
3. Insert the LCD display back into the mount and turn it to the right until it snaps into place.
4 Electrical connection
Warning - Dangerous electrical current
The relevant guidelines must be observed during electrical installation. Connections must only
be established in a dead-voltage state.
The transmitter has no switch-off elements. Therefore, overvoltage protection devices,
lightning protection, or voltage disconnection options must be provided at the plant.
The power supply and signal are routed in the same line and must be implemented as a SELV
or PELV circuit in accordance with the standard (standard version). For the Ex version, the
guidelines stipulated by the Ex standard must to be adhered to.
A check must be carried out as to whether the existing power supply corresponds to the
specifications both on the name plate and in the technical specifications in the “Technical
specifications" section or the data sheet.
Important
The signal cable wires must be provided with wire end sleeves.
The slotted screws of the connection terminals are tightened with a size 1 screwdriver (3.5 or
4 mm).

Electrical connection
14 - EN TTH200 CI/TTH200-EN
4.1 Conductor material
• Power supply cable: flexible standard conductor material
• Maximum wire cross-section: 1.5 mm2(16 AWG)
Notice - Potential damage to parts
Using rigid conductor material may cause line breaks.
4.2 Electrical connections configuration
Sensor connection Signal/supply connection
A00231
7
8
4
3
2
1
+
-
4
1
2
3
Interface for HMI LCD display type AS
Fig. 6
4.3 Sensor connection
Depending on the sensor model, a variety of conductor materials can be used for sensor
connections. The integrated internal reference junction makes it possible to directly connect
thermal compensating cables.
For the solder terminal, a soldering tag is provided at each terminal.
JJ
J
7
8
4
3
2
1
4
2 2 2
3 3 3 3 3 3
4
1 1 1 1 1 1
2
11 … 30(Ex) 42 VDC / 4 …20mA
123456
A00237
4
+
-
1
2
3
+
-
7
2
1
+
-
8
2
1
Fig. 7
1 Potentiometer, Four-wire circuit
2 Potentiometer, Three-wire circuit
3 Potentiometer, Two-wire circuit
4 RTD, Four-wire circuit
5 RTD, Three-wire circuit
6 RTD, Two-wire circuit
7 Voltage measurement
8 Thermocouple

Electrical connection
CI/TTH200-EN TTH200 EN - 15
4.4 Standard application
s
Field Control room
AB
+
-
UM
+
US
-
RLtg
A00094
Fig. 8
A Transmitter B Supply isolator/PLC input with supply
When connecting these components, observe the following condition:
UMmin ≤USmin + 0.02 A x RLtg
Where:
UMmin: Minimum operating voltage of transmitter
USmin: Minimum supply voltage of repeater supply isolater / PLC input
RLtg: Line resistance between transmitter and supply isolator
For HART functionality, use supply isolators or PLC input cards with HART mark. If this is not
possible, the interconnection must have a resistance ≥250 (< 1100 ).
The signal line can be connected with or without ground. When connecting the ground (minus
side), make sure that only one side of the contact is connected to the equipotential bonding
system.
4.5 Standard application with HART functionality
Field Control room
AB
+
-
UM
+
US
-
RLtg
A00095
R250
Fig. 9
A Transmitter B Supply isolator/PLC input with supply
Adding resistance R250 increases the minimum supply voltage:
UMmin ≤USmin + 0.02 A x (RLtg + R250)
Where:
UMmin: Minimum operating voltage of transmitter
USmin: Minimum supply voltage of repeater supply isolator / PLC input
RLtg: Line resistance between transmitter and supply isolator
R250: Resistance for HART functionality

Electrical connection
16 - EN TTH200 CI/TTH200-EN
4.6 Electrical interconnection in explosion hazardous areas
Depending on the safety requirements, special interconnections are required for use in
explosion hazardous areas.
Important
Observe the "Ex relevant specifications" chapter (see data sheet or operating instructions).
Intrinsic safety
The supply isolators/PLC inputs must feature intrinsically safe input protection circuits in order to
eliminate hazards (spark formation). The interconnection must be inspected. In order to provide
proof of intrinsic safety, the electrical limit values must be used as the basis for the EC type-
examination test certificates of the equipment (devices); this includes the capacitance and
inductance values of the cables. Proof of intrinsic safety is said to have been provided if the
following conditions are fulfilled when a comparison is carried out in relation to the limit values of
the equipment:
Transmitter
(intrinsically safe equipment)
Supply isolator/PLC input
(related equipment)
UiU
o
IiI
o
PiP
o
Li+ Lc(cable) L
o
Ci+ Cc(cable) C
o
Field (explosion hazardous area) Control room (secure area)
AB
+
-
+
-
A00096
Fig. 10
A Transmitter B Supply isolator/PLC input with supply
4.6.1 Installation in explosion hazardous areas
Transmitters can be installed in all kinds of industrial sectors. Explosion hazardous areas are
divided into zones, meaning that a wide range of different instruments are also required. The Ex
relevant specifications are stipulated in the section titled " Ex relevant specifications ".

Electrical connection
CI/TTH200-EN TTH200 EN - 17
4.6.2 Zone 0
Transmitter design: II 1 G Ex ia IIC T6
Zone 0 Ex Zone 0 Safe area
A00146
BC
ia
ia
J
A
D
ia
Fig. 11
A Sensor
B Transmitter in housing with IP 20 degree
of protection
C Supply isolator [Ex ia]
D Interface for HMI LCD Display type AS
For instruments in Zone 0, the transmitter must be installed in a suitable housing with IP 20
degree of protection. The input for the supply isolator must have an [Ex ia] design.
When using the transmitter in Zone 0, you must ensure that impermissible electrostatic charging
of the temperature transmitter is prevented (observe the warnings on the device).
The user must ensure that sensor instrumentation meets the requirements of applicable Ex
standards.
4.6.3 Zone 1 (0)
Transmitter design: II 2 (1) G Ex [ia] ib IIC T6
Zone 0 or Zone 1 Ex Zone 1 Safe area
A00146
BC
ib
ia
J
A
D
i
a
Fig. 12
A Sensor
B Transmitter in housing with IP 20 degree
of protection
C Supply isolator [Ex ib]
D Interface for HMI LCD Display type AS
For instruments in Zone 1, the transmitter must be installed in a suitable housing with IP 20
degree of protection. The input for the supply isolator must have an [Ex ib] design.
The user must ensure that sensor instrumentation meets the requirements of applicable Ex
standards. It can be installed in Zone 1 or Zone 0.

Electrical connection
18 - EN TTH200 CI/TTH200-EN
4.6.4 Zone 1 (20)
Transmitter design: II 2 G (1D) Ex [iaD] ib IIC T6
Zone 0, Zone 1,
Zone 20
Ex Zone 1 Safe area
ib
BC
ib
A00147
ia
J
A
D
i
a
Fig. 13
A Sensor
B Transmitter in housing with IP 20 degree
of protection
C Supply isolator [Ex ib]
D Interface for HMI LCD Display type AS
For instruments in Zone 1, the transmitter must be installed in a suitable housing with IP 20
degree of protection. The input for the supply isolator must have an [Ex ib] design.
The user must ensure that sensor instrumentation meets the requirements of applicable Ex
standards. It can be installed in Zone 0, Zone 1, or Zone 20.
4.6.5 Zone 2
Transmitter design: II 3 G Ex nA II T6
Ex Zone 2 Safe area
BC
A00148
J
A
D
Fig. 14
A Sensor
B Transmitter in housing with IP 54 degree
of protection
C Supply isolator
D Interface for HMI LCD Display type AS
For instruments in Zone 2, the transmitter must be installed in a suitable housing with a degree
of protection of at least IP 54.
In the event of a disturbance, it must be ensured that the supply voltage cannot exceed the
normal voltage by more than 40 %.

Ex relevant specifications
CI/TTH200-EN TTH200 EN - 19
5 Ex relevant specifications
Change from one to two colu mns
5.1 TTH200-E1, Intrinsic Safety ATEX
Explosion protection
The TTH200 complies with the requirements of
ATEX directive 94/9/EC
Approved for use in Zone 0
Designation
II 1G EEx ia IIC T6 (Zone 0)
II 2 (1) G EEx [ia] ib IIC T6 (Zone 1 [0])
II 2 G (1D) Ex [iaD] ib IIC T6 (Zone 1 [20])
EC type-examination certificate PTB 05 ATEX 2017 X
5.2 TTH200-H1, Intrinsic Safety IECEx
Explosion protection
Approved for use in Zone 0.
Designation
Ex ia IIC T6 (Zone 0)
Ex [ia] ib IIC T6 (Zone 1 [0])
Ex [iaD] ib IIC T6 (Zone 1 [20])
For further information, see certificate
5.3 Safety specifications for Intrinsic Safety
ATEX / IECEx
Temperature table
Permissible ambient temperature rangeTemperature
class Device category 1
use
Device category 2
use
T6 -50 … 44 °C
(-58 ... 111.2 °F)
-50 … 56 °C
(-58 ... 132.8 °F)
T5 -50 … 56 °C
(-58 ... 132.8 °F)
-50 … 71 °C
(-58 ... 159.8 °F)
T4, T3, T2, T1 -50 … 60 °C
(-58 ... 140.0 °F)
-50 … 85 °C
(-58 ... 185.0 °F)
Protection type Intrinsic Safety Ex ia IIC (Part 1)
Supply circuit Measurement current
circuit / passive
transducer (RTD)
Max. voltage Ui= 30 V Uo= 6.5 V
Short circuit current Ii= 130 mA Io= 25 mA
Max. power Pi= 0.8 W Po= 38 mW
Internal inductance Li= 0.5 mH Li= 0 mH
Internal capacitance Ci= 5 nF Ci= 49 nF
Maximum permissible
external inductance Lo= 5 mH
Maximum permissible
external capacitance Co= 1.55 µF
Protection type Intrinsic Safety Ex ia IIC (Part 2)
Measurement
current circuit /
active
transducer (TC)
Display interface
Max. voltage Uo= 1,2 V Uo= 6,2 V
Short circuit current Io= 50 mA Io= 65.2 mA
Max. power Po= 60 mW Po= 101 mW
Internal inductance Li= 0 mH Li= 0 mH
Internal capacitance Ci= 49 nF Ci= 0 nF
Maximum permissible
external inductance Lo= 5 mH Lo= 5 mH
Maximum permissible
external capacitance Co= 1.05 µF Co= 1.4 µF
5.4 TTH200-E2, Non-Sparking ATEX
Explosion protection
The TTH200 complies with the requirements of
ATEX directive 94/9/EC
Approved for use in Zone 2.
Designation
II 3G EEx nA II T6
ABB manufacturer's declaration in accordance with ATEX directive
Temperature table
Temperature
class
Device category 2 use
T6 -50 … 56 °C (-58 ... 132.8 °F)
T5 -50 … 71 °C (-58 ... 159.8 °F)
T4 -50 … 85 °C (-58 ... 185.0 °F)
5.5 TTH200-L1, Intrinsically Safe FM
Class I, Div. 1 + 2, Groups A, B, C, D
Class I, Zone 0, AEx ia IIC T6
Control drawing: TTH200-L1H
5.6 TTH200-L2, Non-Incendive FM
Class I, Div. 2, Groups A, B, C, D
Control drawing: TTH200-L2H
5.7 TTH200-R1, Intrinsically Safe CSA
Class I, Div. 1 + 2, Groups A, B, C, D
Class I, Zone 0, Ex ia Group IIC T6
Control drawing: TTH200-R1H
5.8 TTH200-R2, Non-Incendive CSA
Class I, Div. 2, Groups A, B, C, D
Control drawing: TTH200-R2H (1)
Control drawing: TTH200-R2H (2) (no conduit)
