ABBERFIELD NPD600 Installation instructions

MANUAL # 035-11
PACKET
VENDING
MACHINE
Model
NPD600
INSTALLATION
& OPERATION
INSTRUCTIONS
ABBERFIELD INDUSTRIES
32 Cross Street, Brookvale, Sydney, Australia
Tel: [phone] Fax: [phone]
Email: [email protected]

INDEX
Section Page
DESCRIPTION 3
CONSTRUCTION 4
INSTALLATION 6
Fitting Card Displays 8
Fitting Optional Display 8
Fitting Optional Pedestal 8
OPERATION 9
Programming Packet Price 11
ABBERFIELD PACKET DISPENSING MACHINE - model NPD600 OPERATIONS MANUAL # 059-1 page 2
32 Cross St, Brookvale, Sydney NSW 2100, Australia Tel: [phone] Fax: [phone] Email: [email protected]
PACKET VENDING MACHINE
Model NPD600

ABBERFIELD PACKET DISPENSING MACHINE - model NPD600 OPERATIONS MANUAL # 059-1 page 3
32 Cross St, Brookvale, Sydney NSW 2100, Australia Tel: [phone] Fax: [phone] Email: [email protected]
zThe equipment allows for dispensing packets on insertion of notes.
zEquipment is 230 / 240V operated, reducing to safe 12 Volt throughout
the working modules of the note validator and packet dispensers.
zEquipment can be mounted upon a wall, upon a bench or upon a plinth.
zCable entry can be through the side, rear or bottom, plus a preferred
method of plugging directly into a power point over which the cabinet is
mounted.
zEach of the parts are modular, allowing easy service and permitting
continued operation of the remaining packet dispensers, if one or more
are out of stock or out of service.
zThe equipment is fitted with an alarm to acitvate if the door is opened. To
turn off alarm press Reset button when door is open. The alarm can be
disabled by reprogramming.
Note: The machine on power up briefly displays a number. This refers to the
operating software and should be quoted relating to service difficulties.
DESCRIPTION

ABBERFIELD PACKET DISPENSING MACHINE - model NPD600 OPERATIONS MANUAL # 059-1 page 4
32 Cross St, Brookvale, Sydney NSW 2100, Australia Tel: [phone] Fax: [phone] Email: [email protected]
Outer Cabinet Inner Frame
Mounting Screws
Packet Dispensers Note Validator
CONSTRUCTION
These slide into place and
automatically plug into a cradle. This plugs into a cradle and the
front portion is held by two screws.

ABBERFIELD PACKET DISPENSING MACHINE - model NPD600 OPERATIONS MANUAL # 059-1 page 5
32 Cross St, Brookvale, Sydney NSW 2100, Australia Tel: [phone] Fax: [phone] Email: [email protected]
Construction continued....
Power Supply
Mounted under the Inner frame
Power supply label
Universal input 110 Volts to 240 Volts, 50 - 60 cycles.
Control Module & Fascia
Incorporates push buttons and the control electronics, bolts to the cabinet by
nuts and screws from inside.
Lead
Connects control modules to back panel.

ABBERFIELD PACKET DISPENSING MACHINE - model NPD600 OPERATIONS MANUAL # 059-1 page 6
The equipment is supplied ready to use, if operated from a standard power
point.
To access the mounting holes: -
1. Undo the screws to the top of the Inner Frame.
2. Lift out the inner frame, but take care as it is connected by cables to the
cabinet.
3. Unplug the three leads going to the Inner Frame circuit board.
4. Access is now made to the wall or bench mounting holes.
5. Use the frame as a template to mark the mounting holes. Then remove
and drill the wall or bench.
Note: If the installation is in a very secure area, it may be sufficient to mount
the equipment to a wall by the top two bolt holes only. These can be
accessed without removing the Inner Frame.
If the double insulation of the mains wiring is in any way put at
risk, through alteration to the equipment, it is mandatory that the
cabinet is earthed. A screw for this purpose is positioned under
the Inner Frame.
Also under the inner frame is a terminal block for use in a permanently wired
application. If the fixed incoming mains wiring is through the existing cable
entry hole it may be acceptable to relocate the power supply elsewhere,
sitting loose under the inner frame. In this case the plastic cable clamp
provided may be useful to secure the mains wiring.
Take care when re-assembling the Inner Frame to tuck all wires into the free
space provided. Make sure none are caught under the Inner feet or on top of
the power supply, or this will lift the inner module and the packet being
dispensed may not line up with the fascia.
Remount the equipment taking care to ensure no masonry or dust or other
dirt is left behind.
INSTALLATION
32 Cross St, Brookvale, Sydney NSW 2100, Australia Tel: [phone] Fax: [phone] Email: [email protected]

ABBERFIELD PACKET DISPENSING MACHINE - model NPD600 OPERATIONS MANUAL # 059-1 page 7
Installation continued....
Rear Mounting
Bench Mounting
32 Cross St, Brookvale, Sydney NSW 2100, Australia Tel: [phone] Fax: [phone] Email: [email protected]
741mm
671mm
335.5mm
335.5mm
336.50mm
266mm Cut out for power point
(optional)
Bench or plinth mounting
(optional)
Mains lead totally
concealed in cabinet
or
Cable exit in corner for
side, bottom or rear exit
273.50mm
234mm
336.50mm
260mm
266mm

Installation continued....
FITTING DISPLAYS
Above the controller is a panel window that can be fitted depicting the
product being vended.
Undo the four screws inside the cabinet front door, corresponding to the four
outside corners of the fascia moulding. This leaves the fascia and control
electronics held in place by the centrally positioned M4 nuts.
Held in this way it is possible to gently bend the top section of the fascia
forward, just enough to slide the panel into place. It is recommended that the
backing card or label is held at the edges with sticky tape. This ensures that
it will not move once installed. Then replace the four corner screws.
FITTING OPTIONAL DISPLAY
This advertising frame bolts to the cabinet back plate and the cover fits over
the point of attachment.
FITTING OPTIONAL PEDESTAL
1. Bolt the ground plate to the floor securely.
2. Fit over the Pedestal casting and column.
3. Securely bolt down the ground plate tie bolt.
4. Using a template, drill the base of the cabinet to accommodate mounting
bolts for the plinth.
5. Use the bolts supplied to secure the cabinet as if bench mounting.
Note: It is possible to run the mains cables down the pedestal and exit at
floor level, through a cut out in the rear of the pedestal. In this
application it is necessary to earth the cabinet and the pedestal stand
by cutting and terminating mains cable inside the cabinet.
ABBERFIELD PACKET DISPENSING MACHINE - model NPD600 OPERATIONS MANUAL # 059-1 page 8
32 Cross St, Brookvale, Sydney NSW 2100, Australia Tel: [phone] Fax: [phone] Email: [email protected]

Information for programming any option is displayed on the front of the
machine.
Push the “Function” button and select the desired option.
Available options are:
Prog
Audt
Test (dispenser 1 & 2 only)
Oper
Select “Prog” and then push “Enter”
Options for Prog are:
Prog unit Price
Prog Beep
Prog Blip
Prog Brightness
Select “Audt” and then push “Enter”
Options for Audt are:
Sub total unit sold
Sub total cash
Total units sold
Total cash
Unit price
Clear subs
ABBERFIELD PACKET DISPENSING MACHINE - model NPD600 OPERATIONS MANUAL # 059-1 page 9
32 Cross St, Brookvale, Sydney NSW 2100, Australia Tel: [phone] Fax: [phone] Email: [email protected]
OPERATION

ABBERFIELD PACKET DISPENSING MACHINE - model NPD600 OPERATIONS MANUAL # 059-1 page 10
32 Cross St, Brookvale, Sydney NSW 2100, Australia Tel: [phone] Fax: [phone] Email: [email protected]
Operation continued....
Select “Test” then push “Enter”
Option for Test are:
Push enter to test 1 (Dispenser)
Push reset to test 2 (Dispenser)
Select “Oper” then “Enter”
Unit is now in normal operation mode.

Operation continued....
PROGRAMMING DISPENSE PRICE
The following is an example of how to programme the unit price for a packet.
Push “Function” button until “Prog” is displayed.
Push the “Enter” button
“Press reset to scroll through options then press enter”
Push the “Reset” button
“to prog unit price”
Push the “Enter” button
“to program unit put note in then push enter”
Now insert amount required (eg. $10), then press the ”Enter” button
“done” appears in the display
Push “Function” until “Oper” is displayed, then push “Enter”
“Insert notes” is now displayed
The machine is now in normal operation mode and programmed with a $10
unit price.
