Seaga JDL-2 COMBO Building instructions

1JDL V1.0 8 2022

2JDL V1.0 8 2022
INTRODUCTION
Congratulaons on the purchase of your vending machine. This vending machine has been designed to give
you many years of dependable service. It requires lile maintenance and is easy to set up and operate.
READ THIS MANUAL COMPLETELY
Your vending machine is designed to operate simply and reliably, but to take full advantage of your vendor,
please read this owner’s manual thoroughly. It contains important informaon regarding installaon and
operaons, as well as a brief trouble- shoong guide.
EQUIPMENT INSPECTION
Aer you have received your vendor and have it out of the box, place it on a secure surface for further in-
specon. Note: Any damages that may have occurred during shipping must be reported to the delivery carrier
immediately. Reporng damages and the seeking of restuon is the responsibility of the equipment owner.
The factory is willing to assist you in this process in any way possible. Feel free to contact our Customer Care
Department with quesons you may have on this process.
It is important that you keep the original packaging for your vending machine at least through the warranty
period. If your machine needs to be returned for repair, you may have to purchase this packaging if it is not
retained.
Vendor must be located a minimum of ve(5) inches away from walls and obstrucons on the right side to
allow the doors to fully open for loading products and maintenance purposes.
Once you have your vendor located, we suggest that you keep this manual for future reference, or you
can view this manual online at www.seaga.com. Should any problems occur, refer to the secon entled
“TROUBLESHOOTING”. It is designed to help you quickly idenfy a problem and correct it.
seaga.com
For Service and Customer Care in the US:
8:00 a.m. - 5:00 p.m. CST. Mon thru Fri
815.297.9500 opon 1
email: customercar[email protected]om
Seaga Manufacturing, Inc.
700 Seaga Drive Freeport, IL 61032 U.S.A.

3JDL V1.0 8 2022
Table Contents
INTRODUCTION 2
READ THIS MANUAL COMPLETELY 2
EQUIPMENT INSPECTION 2
SPECIFICATIONS 4
CAUTIONS 4
OVERVIEW 5
RECEIVING, INSPECTION, UNPACKING AND TESTING 6
LOCK 6
INSTALLATION 7
LOADING PRODUCT TRAYS 10
PRODUCT LOADING 11
COIL ADJUSTMENT 12
LOADING BEVERAGE LANES 14
DISPLAY 19
SERVICE MODE 20
SERVICE MODE NAVIGATION 20
VMC – VENDING MACHINE CONTROLLER 21
MENU HIERARCHY 22
SERVICE MODE 23
ERROR CODE MESSAGES 50
VEND MOTORS 53
PAYMENT SYSTEMS 54
BILL VALIDATOR 58
REFRIGERATION DECK 61
COMMON QUESTIONS AND ANSWERS 63
FREQUENTLY ASKED QUESTIONS 66
EXPLODED VIEWS 68
WIRING DIAGRAM (Refrigeration Deck) 77
LIMITED WARRANTY 78

4JDL V1.0 8 2022
SPECIFICATIONS
The vending machine is comprised of two(2) units - Snack Unit (JDLS) and Beverage Unit (JDLD). Installaon
and setup of these units is explained in the next secons of this manual.
Machine Descripon Snack Unit Beverage Unit
Model Number JDL2S
(115VAC)
JDL2S
(230VAC)
JDL2B
(115VAC)
JDL2B
(230VAC)
Height (in) 28.5” (72.4 cm) 28.5” (72.4 cm) 41.6” (105.7 cm) 41.6” (105.7 cm)
Width (in) 30.2” (76.7 cm) 30.2” (76.7 cm) 30.2” (76.7 cm) 30.2” (76.7 cm)
Depth (in) 28.6” (73 cm) 28.6” (73 cm) 28.6” (73 cm) 28.6” (73 cm)
Volts (V) 115 V 230 V 115 V 230 V
Frequency (Hz) 60 Hz 50 Hz 60 Hz 50 Hz
Was (W) 46 W 49 W 295 W 290 W
Current (A)* 0.4 A 0.22 A 3.6 A 1.87 A
Refrigerant Type NA NA R290 R134a
Refrigerant Charge NA NA 45 grams/1.59 oz 200 grams/7.05 oz
* - Current draw varies depending on Operang Condions and Load and are subject to change.
The vending machine is designed for use in indoor condions only. The recommended operang
environment is 75° F and 40% RH.
CAUTIONS
Your vender is intended for indoor use only.
Excessive heat, cold or humidity levels will void your warranty; install only in climate
controlled, indoor environments. For indoor machines the temperature range must be no
higher than 32°C/90°F and no lower than 10°C/50°F with a relave humidity (Rh) level of no
greater than 40%.
Your vender must be set on a level, well-supported locaon.
Always remove products before transporng it.
CAUTION!
It is important that this machine is hooked up to the proper voltage. Verify the voltage before
connecng the machine to a wall outlet.
CAUTION!
Dierent countries may have dierent power arrangements. Ensure that the machine is
properly grounded before operang.

5JDL V1.0 8 2022
OVERVIEW
This manual covers Installaon, Setup, Programming and Service instrucons. It is extremely important that
this manual be read thoroughly prior to commissioning the vending machine in the eld. This will ensure a
sasfactory long-term performance.
The vending machine consists of two (2) separate cabinets that are installed together via mechanical means
and connected via electrical connecons to operate as ONE unit.
The Snack Vendor (JDLS) consists of three (3) trays. The rst and second trays have 4 selecons each (Tray 1
– 111, 113, 115, 117, Tray 2 – 121, 123, 125, 127). The third tray has 8 selecons (130 through 137). The top
two trays are normally used for products that are wider such as chips, pastries etc. and the third tray is used
for Confeconary items such as candy bars. The Snack Vendor (JDLS) also houses all the payment mechanisms
and electronic Vending Machine Controller (VMC) on the right side of the cabinet. The payment mechanisms,
electronic components (such as VMC) and transformer are installed on a vercal shelf that slides out for easy
access. The connectors to connect the Beverage Unit (JDLD) are also provided in this vercal shelf of the Snack
Vendor (JDLS).
The Beverage Vendor (JDLD) is designed with a vercal drop system. The Beverage Vendor also houses
the removable Refrigeraon System. The cabinet of the Beverage Vendor has a delivery system that has 7
selecons for Cans or Boles (140 through 146). The loading instrucons are given in subsequent secons.
CAUTION!
If the power cord is damaged, it must be replaced by the manufacturer, authorized service
agent or a similarly qualied person to avoid electrical hazards.
ATTENTION!
This dispensing machine is very heavy. Ensure that sucient personnel are available for
liing or transporng the machine. Use proper liing procedures and equipment.
CAUTION!
Certain components of this machine are sensive to stac electricity. Precauons for
handling sensive devices should be observed when handling these items.
ATTENTION!
Leave at least 2” (5cm) between the back of the dispensing machine and the wall to allow for
air ow.
CAUTION!
R290 refrigerant is used in this machine. R290 is a puried form of propane and can cause a
re or minor explosion if precauons are not observed.

6JDL V1.0 8 2022
The refrigeraon system is installed at the boom of the Beverage Vendor and there is a foamed separaon
between the cabinet interior and the refrigeraon system. The installaon, setup and funconality of the
refrigeraon system is explained in the secon tled Refrigeraon.
RECEIVING, INSPECTION, UNPACKING AND TESTING
Aer you have received your vending machine, inspect all three individual vendor components. Note: Any
damages that may have occurred during shipping must be reported to the delivery carrier immediately.
Reporng damages and the seeking of restuon is the responsibility of the equipment owner. The factory
is willing to assist you in this process in any way possible. Feel free to contact Seaga Customer Care with
quesons you may have on this process. Once you have your vending machine located, we suggest that you
keep this manual for future reference.
The vending machine is placed on a wooden pallet and stretch-wrapped. Please exercise cauon while cung
into the stretch-wrap with a sharp tool such as a ulity knife, as it may cause scratch marks on the machine.
The Snack and Beverage Units are boxed in two (2) separate cardboard boxes. The Snack Unit box is placed
on top of the Beverage Unit. Aer removing the stretch wrap, remove the Snack Unit and place it aside. USE
EXTREME CAUTION AS THE TOP OF THE BOX IS NOT ATTACHED TO THE BOTTOM OF THE BOX. The top of
both the snack and beverage units slide up for removal. Remove the Beverage Unit from its box and place it
in the desired vending locaon. Remove the Snack Unit from its box and place it on top of the Beverage Unit
carefully. Please use proper liing and safety precauons while placing the Snack Unit on top of Beverage Unit.
Open all Unit doors and remove the packing materials. Keys can be found in the white envelope placed in the
vend area of the Snack Unit. Remove the tape on the tray levers of the Snack unit. Also remove the protecve
paper from under each coil as well as es securing the ends of the coils during shipping. Remove all protecve
plasc from the window lenses.
Remember: at least two people are necessary to move any of the components of the vending machine. Follow
proper safety standard for liing and working with electronic/refrigerated equipment.
LOCK
Your vendor has two Locks, more commonly known as a T-handle lock. The keys for the T-handle locks are in a
white parts envelope in the vend bin.
To unlock the front door of the snack unit (top secon), insert key and turn clockwise ¼ turn. When unlocked
the ‘T’ of the Lock will pop out from its base. Turn the ‘T’ clockwise ¼ turn to unlock the door. To lock the door,
close it and turn the ‘T’ counterclockwise ¼ turn and push the ‘T’ into the base. Remove the key.
To unlock the front door of the beverage unit (boom secon), insert the and turn clockwise ¼ turn. When
unlocked the ‘T’ of the Lock will pop out from its base. Turn the ‘T’ counterclockwise unl door opens.
To lock the door, rmly close the door and turn the ‘T’ handle clockwise 1 to 2 mes and then pull on the door
to test that the lock has engaged. If so, then push the ‘T’ into the base to lock the door. Remove the key. Note:
Do not over-ghten when locking – this could strip the threads and damage your machine.

7JDL V1.0 8 2022
INSTALLATION
Once the machines have been unpacked and placed in their permanent locaon, the electrical connecon and
mechanical connecon must be made. Tools required: Adjustable wrench and Philips screwdriver. For opmal
installaon, follow the order of connecons as outlined below:
1.Mechanical Connecon between Snack and Beverage Units:
The Snack and Beverage units must be screwed together for safety purposes. Two screws are
provided in the white envelope found in the vend area of the Snack unit. Square the fronts and sides
of the Snack and Beverage units. Open the Snack unit door and locate the two holes at the boom of
the unit. Insert both screws and ghten.
2.Electrical Connecon between Snack and Beverage Units and Beverage Display Lighng Connecon:
Cut an opening in the Styrofoam in the upper right (front) corner and save the foam for reinseron.
Open the Beverage unit door and locate the beverage main harness and refrigeraon harnesses. Insert
harnesses through the opening up into the Snack cabinet (Figure 1).
Figure 1 – Installing Refrigeraon Harnesses
Beverage and
Refrigeraon
Harnesses
Insert Beverage
and Refrigeraon
Harnesses
through here

8JDL V1.0 8 2022
Connect the refrigeraon harnesses to the two connectors found in the snack unit that are ed together, see
Figure 2 below. (Note: the single harness located inside the snack unit is for the LED lighng which will be
covered in following steps).
Connect the Beverage Main harness to the boom port on the electrical panel as shown in Figure 3 below.
Figure 2-
Refrigeraon
Harnesses
Connected
Figure 3- Beverage
main harness
aaches to boom
connector port
MENUS Buon
The Beverage Unit ulizes a Drop Sensor that works on shock and vibraon. This system works to keep both
the customer and the operator happy by assuring that the vend that was requested has been completed
successfully.
The Drop Sensor harness must be passed up through the hole in the insulaon and aached to the VMC board
at the locaon shown in Figure 4.
Figure 4-
Drop Sensor (ELI2310)
Harness connecon
Drop Sensor
(ELI2310)
Harness that
connects to
VMC

9JDL V1.0 8 2022
The Beverage Unit has a live product display that is lit by LED lighng. Locate the LED Light harness, Figure 5,
on the inside of the Beverage Unit Door. Insert the LED Light harness up through the Snack Unit as done for the
other connecons. Connect the LED Light harness to the corresponding connector.
Reinsert the Styrofoam piece for maximum insulaon of the refrigeraon unit.
Figure 5-Beverage
Display LED Light
Harness; insert
through
Connect the snack unit to the beverage unit with the jumper power cord. Posion cord cover over the jumper
cord and aach with four(4) screws into holes provided while ensuring the cord is not pinched or trapped
between the cover and the cabinet. The cord cover is not necessary for the operaon of the machine, but it
does protect the cord and make the machine more aesthecally pleasing.
Then connect the beverage unit power cord to wall socket with power. Using a power strip is recommended.
CAUTION: to avoid risk of electrical shock, the power to the wall socket should be made last of all connecons.
Figure 6 – Main Power Connecon
Jumper Cord – FIRST connect
Snack to Beverage
Power Cord – connect
Beverage to wall socket LAST

10JDL V1.0 8 2022
Figure 7 – Slide-out product trays
LOADING PRODUCT TRAYS
Open the front door of snack unit and push down on the plasc lock lever on the right side of the tray to
unlock. Holding the lever down, grasp the tray and li the front of the tray slightly and pull forward. The tray
will slide out and then lt down to make loading of products easier. Load only one product tray at a me (See
Figure 7).
Push down on the
plasc lock lever Grasp tray while
holding down lever,
li slightly and pull
forward
1. To Load Product in Snack Unit:
a. Pull the desired product tray all the way forward. Product tray will lt down.
Note: Pull out only one (1) product tray at a me
b. Place product in proper size coil.
Note: Boom of product must rest on the product tray and not on the
Coil. Load each column from back to front.
Note: Fill all product trays fully; do not leave any spaces behind or between items
c. Once product tray is fully loaded, li and push it back in.
Repeat steps a through c unl all product trays are fully loaded. Special Note: We suggest that you always
parally ll the tray with product and perform at least ve (5) test vends. Test vends can be performed easily
by entering Service mode and using the test funcon.

11JDL V1.0 8 2022
Incorrect
PRODUCT LOADING
Snack Unit
Wide products such as Chip bags etc. are loaded in Tray 1 and Tray 2. Narrow products such as Candy bars are
loaded in Tray 3. See Figures 8a and 8b.
Figure 8a – Loading Product
Correct – load
product between
coils, resng on the
product tray, never
on the boom loop
of the coil.
Incorrect
Coil
Product Tray
Figure 8b – Loading Product
Correct – load product between coils,
resng on the product tray.
Incorrect

12JDL V1.0 8 2022
COIL ADJUSTMENT
If you are required by a locaon to vend a product that does not t into the standard coil installed, you may
need to order a dierent coil and install it. To replace a coil:
1. Remove the Coil from the Coil Driver by liing the back of the coil up o the coil driver. You will need to
move the boom of the coil clear of the coil driver to completely remove the coil.
2. Align the new coil end with the front of the tray, which gives the coil beer contact with the product.
The posion of the coil in the coil driver is adjustable to assist you in aligning the new coil at the
front of the tray. See Figure 9.
Figure 9 – Removing and Aligning a Coil
Apply pressure to
the straight part
of the coil that is
inserted into the
Coil Driver. Li
up on the Coil to
remove.
Coil Driver
with three (3)
adjustment opons
Back of Product
Tray, Snack or
Entree
If you are experiencing vending issues with certain products, you may need to adjust the coil rotaon to beer
provide the momentum to push the snack o the tray and into the delivery area.
To adjust the coil rotaon:
1.) Squeeze the two plasc tabs on the back of the coil driver and pull the coil driver and coil toward the
front of the tray to remove it.
2.) Turn the coil clockwise 1/8 of a rotaon.
3.) Reinsert the coil driver with coil aached back into the motor, through the back wall of the tray.
4.) Load the tray and perform at least 5 (ve) test vends to ensure a proper vend.
5.) If the item does not vend consistently, repeat another 1/8 of a rotaon unl you are condent of
consistent vend funcon.

13JDL V1.0 8 2022
Figure 10 – Coil Rotaon Adjustment
Squeeze two tabs
on the back of the
Coil Driver
Pull the Coil Driver
and Coil forward;
Rotate 1/8 of a turn
and reinsert back
into product tray.
BEVERAGE UNIT
Figure 11 shows a pictorial view of vending possibilies for your beverage machine. This is NOT how your
machine is set from the factory. For a more comprehensive list of tested products see Figure 16.
Your vending machine has been set by the factory for the following products and groups (see Figure 12):
Selecon 140 – 12 oz. Can – Group 5 – Side Spacer, Large, LH
Selecon 141 – 12 oz. Can – Group 5 – Side Spacer, Large, LH
Selecon 142 – 12 oz. Can – Group 5 – Side Spacer, Large, LH
Selecon 143 – 16.9 oz. Bole – Group 10 – Side Spacer, Large, LH /Auger Insert, Large
Selecon 144 – 16.9 oz. Bole – Group 10 - Side Spacer, Large, LH /Auger Insert, Large
Selecon 145 – 20 oz. Bole – Group 3 – None
Selecon 146 – 20 oz. Bole – Group 1 – Side Spacer, Small, LH

14JDL V1.0 8 2022
Front of machine
Back of machine
1.) For most boles, place boom of the rst bole against the front of the column. Place the top of the
second bole to the back of the column, facing the boom of the bole with the top of the rst bole. See
Figure 13. Load 12 oz. cans boom to boom in the rst two posions, then top to top in the back posion.
Load 16 oz. cans boom to boom. 20 oz. Gatorade boles are loaded boom to top.
2.) To adjust the rear spacer, grasp rmly and li, freeing the spacer from the slots in the column sides. Move
the rear spacer to the closest slot to the back of the bole or can placed in the rear of the column. Insert the
boom le corner rst. The gap between the rear spacer and the rear bole or can must be less than ½ inch.
The slots are in ½ inch increments to let you adjust for many sizes of products. Lower the rear spacer into the
new posion, making sure the spacer is straight vercally.
3.) Finish loading to the top of the column, making sure the items are perfectly horizontal and not lted or
skewed in the column.
LOADING BEVERAGE LANES
The Product Columns in your machine use an Auger that rotates counterclockwise to drop the beverage into
the Product Bin.
1.) Grasp Locking Tab and slide up to allow Retainer to rotate forward into Load Posion.
Figure 13 – Retainer
Retainer
Locking Tab

15JDL V1.0 8 2022
Figure 14 – Retainer in Load Posion
Retainer
2.) 20 oz/591 ml Boles are loaded lying down, two deep in each column. Load the rst bole so that
the top touches the back of the column. The next bole should also be loaded with the top toward
the back of the column, posioned against the boom of the rst bole.
3.)12 oz/355 ml Cans (not slim cans) are loaded lying down, three deep in each column. Load cans with
the top of the rst can touching the back of the column. The boom of the next can should be touching
the boom of the rst can. The third can should be loaded with the top touching the top of the second
can.
4.)Finish loading to the top of the column, not exceeding maximum capacity (see chart), making sure
the items are not lted or skewed in the column.
5.)With column loaded, li the Retainer back into sales posion using the Locking Tab and push down
to lock.

16JDL V1.0 8 2022
Figure 15 – Loaded Product with Retainers Secured
Retainer
Adjusted within ½”
of product
Locking Arm Secured
Refer to Figure 16 below for alternate product requirements and the accessories needed to properly vend
these items.
Size Descripon Product Setup/Accessory Load Capacity Group
20 oz
519 ml Bole
Aquana Water,
Country Time
Lemonade, Lip-
ton Iced or Green
Tea, Coke, Pep-
si, and Various
Brands
Side Spacer, Small, LH Tops to Back 10 1
14 oz
414 ml Bole Nesquik Side Spacer, Small, LH Tops to Back 10 1
18.5 oz
547 ml Bole Pure Leaf Tea Side Spacer, Small, LH Alternate top and boom 10 2
20 oz
519 ml Bole Gatorade, Sobe, Vitamin Water Not Required Tops to Back 10 3
16 oz
473 ml Can Monster, Rock Star
Side Spacer, Small, LH,
Back Spacer
Alternate top and
boom 10 4
15 oz
443 ml Can Starbucks Dou- bleshot Coee
Side Spacer, Small, LH,
Back Spacer
Alternate top and
boom 10 4

17JDL V1.0 8 2022
12 oz
355 ml Can
Most Brands,
Standard Size
Cans
Side Spacer, Large, LH Alternate top and
boom 15 5
13.7 oz
405 ml
Glass
Bole
Starbucks
Frappuccino Side Spacer, Large, LH Alternate top and boom 10 5
12 oz
355 ml Bole Gatorade
Side Spacer, Small, LH
Back Spacer,
Auger Insert, Large
Tops to Front 10 6
9.5 oz
218 ml
Glass
Bole
Starbucks
Frappuccino
Side Spacer, Small, LH
Auger Insert, Large Tops to Back 10 7
11 oz
325 ml
Glass
Bole
Starbucks Iced
Coee
Side Spacer, Large, LH
Auger Insert, Large Tops to Back 10 8
12 oz
355 ml Slim Can
Lipton or
Aquana
Sparkling,
Starbucks
Refreshers
Side Spacer, Large, LH
Side Spacer, RH
Back Spacer,
Auger Insert, Large
Alternate top and
boom 14 9
16.9 oz
500 ml Bole Dasani Water Side Spacer, Large, LH Auger Insert, Large Tops to Back 12 10
Note: There are many variaons of packaging. These instrucons are meant to be a guideline. If you have
packaging that is not menoned or shown, setup and tesng will be necessary to ensure proper vending.
By adjusng the Shims and/or changing the inserts any column can be converted to cans or boles. Contact
Seaga Customer Service if you need assistance.
Setup Accessories used in your beverage machine are shown here (Figure 17, Figure 18 and Figure 19) with
part numbers if interested in ordering addional accessories.
Side Spacer, Small, LH
Figure 17– Side Spacer, Small, LH; Side Spacer, Large, LH and Side Spacer, RH
Side Spacer, Large, LH
Part # SA846 Part # ST691
Side Spacer, Large, LH
Part # SA689

18JDL V1.0 8 2022
Auger Insert, Large
Figure 18 – Auger Insert, Large
Auger Insert,
Narrow Product
Part # PLI2182 Part # PLI2206
Figure 19 –Back Spacer
Part # SA484
Your machine has a live product display shelf for the beverages. Take care to use packaging that is in perfect
condion and products that are sll within their expiraon date to present the best possible adversement to
your potenal customers. To display your products:
1.) Remove the Drink Display Back Panel by loosening and removing the thumb screws located on either
side of the panel.
2.) Place each beverage, in order of selecon, in the display window taking care to make them evenly
spaced and oriented properly toward the front of the machine where the customer will see them.
3.) Reinstall the beverage back panel.
Note: you may wish to apply double sided tape to the boom of the drink packages to keep them in place
when the door is opened and closed.
Figure 20 – Live Drink Display
Thumb Screw
Thumb Screw

19JDL V1.0 8 2022
DISPLAY
The LCD Display is a two line, 20 character text display panel located on the front of your snack machine. The
display interacts with the customer to show the amount of money entered into the vendor and the cost of
their selecon among other informaon as programmed. The display also shows the operator the Service
Mode funcons for seng the vendor.
LCD Display in Sales Mode
Display Formats When in Sales Mode
Top Line of Display Reads
Normal Operaon, no credit available Point of Sale Message
Normal Operaon, some credit available $00.01 – 99.99
Aer Pressing a selecon, if there is no credit
or the credit is less than the selecon’s price,
the price of the selecon is displayed for a few
seconds before reverng to one of the above
credit display formats.
(If a coin or other payment is made the display
reverts immediately to display the credit avail-
able)
Price $00.01 – 99.99
Free Vend Mode (all prices set to zero) Free Vend
If a selecon is out of stock when a selecon is
pressed – this is displayed for a few seconds Sold Out
All Items out of stock Sold Out
Machine Out Of Order Out of Order
During a Vend (Progress bar, dashes) --------------
Exact Change required Exact Change Only
Temperature Display
Press the # key to display T1* ##F (C)
Date and Time are always displayed on the second line in Sales Mode. If a calorie value is set for a selecon,
the value will be displayed when the product is vended or when a selecon is made without any credit.

20JDL V1.0 8 2022
12 3
456
789
*0 #
KEYPAD
* = Exit or Next
# = Save
SERVICE MODE
The operaon of the machine can be adjusted by entering service mode by pressing the MENUS buon on the
VMC circuit board (see Figure 21 for reference) and then accessing the appropriate operaon. Price seng,
audit display and operang modes can be read and adjusted from here. The user can also perform tests on the
machine through this mode. Note: any Credit will be cancelled on entry to Service Mode
SERVICE MODE NAVIGATION
Use the 0 through 9 keys to access the various menus and sub-menus.
Use the “*” key on the keypad to Exit without changing or to go back (Previous).
Use the “#” key on the keypad to Save.
