Abee V11 User manual

Menu
Product Features.......................................................1
Notes..........................................................................2
Product Appearance .................................................3
Hardware Installation Guideline...............................4
Operational Guideline...............................................6
i. Turn on / Turn off....................................................................................... 6
ii. Recording.................................................................................................. 6
iii. Emergency Recording ............................................................................. 7
iv. Video playback/Locked file/Unlock/Delete............................................. 8
v. Menu function......................................................................................... 10
vi. Memory card (Micro SD) PC connection instruction............................11
vii.DVR Player program ADR Player: software operational, file playback
and access instruction ................................................................................11
Specifications..........................................................21

1
V11 Car Recorder Manual
產品特色
●High-definition video recording in HD 720P @ 30fps
●Auto loop recording with No Interval Time File Saving Technology to record every
second
●Emergency record function to protect important incidents.
●Low-light CMOS HD Sensor for better night vision
●140° ultra wide angle lens
●Collision detection by G-sensor to activate automatic recording
●Motion detection automatically recording 5-10 seconds before the motion is detected
until the motion stops
●Great night vision due to auto black/white mode in a low light environment to sharpen
images
●2.4" TFT LCD display providing clearer image, convenient for installation adjustment
and video playback
●Automatic recording to start recording and stop and save according to engine
●Date information for the record
●White balance and light sensing auto adjustment for exact exposure
●High temperature resistant parts and battery that passed high temperature testing for
safety concerns
●Built-in high temperature resistant Lithium polymer battery for off-care usage
●Memory card slots supporting up to 32GB
●ROHS complied, CE/FCC/BSMI certified
●DVR Player：
‧Lets you browse, play and save all stored data directly on PC without any extra installation
and data format issues
‧Enables setting a password for your Micro SD card to ensure data security
‧Repairs damaged videos resulting from suddenly pulled out SD card or a power
outage for further reassurance
‧Show G-Sensor information during video playback
Product Features
English

2
V11 Car Recorder Manual
注意事項
Usage
1. Please use Class6 (or above) Micro SD card to avoid the lag of image.
2. Please format the memory card with V11 before use
3. Please use Abee V11 original car charger and accessories.
4. When your engine is off, it is recommended to unplug the cigarette charger and Abee
V11 to prevent unnecessary draining of your car battery.
5. After the engine is off or when the power supply is cut off or any event that interrupts
the power supply, the built-in battery allows continuous recording to the memory card.
Do not remove the Micro SD memory card before the saving procedure is completed
or the file may be damaged.
6. Do not expose your product to direct sunlight.
7. Do not connect car adaptor to car battery power directly (this would void your
product warranty).
8. Do not disassemble or modify your product. Consult your dealer or our customer
service center in case of a problem.
9. Do not drop or subject the product to blows or force. Do not press hard on the LCD
screen. This may damage it or cause it to malfunction.
10.To manually activate Abee V11 emergency recording function, press the record button
to enter emergency recording mode. A “Lock”icon will show immediately on the
upper right corner of the screen indicating the file is protected. The file will not be
deleted from loop recording. A 4G memory card can save up to 5 emergency video
files; 8G memory card (or above) can save up to 10 emergency video files. Please refer
to the manual for details of the emergency recording feature.
11.Do not expose your product to flame or moisture, please keep your hand dry when
operate the device.
12.Do not clean the product with cleaners containing strong acid or alkaline.
13. Before using your device, please read the user manual carefully.
Micro SD memory card
1. Please use Micro SDHC memory cards, class 6 or above. 4G or more of memory space
is recommended and the device supports up to 32G.
2. Please format the memory card with V11 before use.
Notes
English

3
V11 Car Recorder Manual
產品外觀示意圖
○
1 On/Off Key
○
2 Menu/Exit Key
○
3 Up/Play/Delete Key
○
4 Down/Stop/Lock 、Unlock
○
5 Record/Lock/OK/Pause、Resume
○
6 Display
○
7 Recording indicator
○
8 Bracket slot
○
9 Memory card slot（Micro SD）
○
10 Mini USB port
○
11 RESET
○
12 Lens
○
13 Speaker
○
14 Microphone
Product Appearance
English

4
V11 Car Recorder Manual
硬體安裝指南
Installation
1. Connect the device with the bracket by inserting the screw hole on top of
your device in the screw of the bracket; turn the screw knob clockwise until
firmly installed.
2. Place your Car Camera Recorder in the
proper position, stick the suction plate to
the windshield, and press the plate button
to secure the stand.
3. After installing the bracket, release the
adjacent knob below the suction plate to
adjust the filming angle.
4. After adjustment, turn the adjacent knob
until the position of the device is firmly
locked.
5. Insert Micro SD card into SD card slot.
6. Insert car charger into cigarette socket
and connect to V11.
Uninstall
Hardware Installation Guideline
English

5
V11 Car Recorder Manual
1. Uninstall the device: hold the bracket firmly, turn the device clockwise.
2. Uninstall car bracket: Pull up the car stand suction plate button to remove it。
Installation Recommendations
1. Install your product as close as possible to the rear view mirror in your car to get the
best view.
2. The lens should be within the wipers’cleaning area on the windshield to get good
image quality on a rainy day.
3. Do not install your product in a place that may interfere with operation of the air bags
in your car.
4. Do not place your product in a position that may be blocked by the heat insulation.
5. Clean the bracket suction plate before installation.
※Warning
Do not install Abee products over an air bag cover or within the air bag deployment
zone. The company assumes no responsibility of liability for injury or death as a result of
car crashes and/or air bag deployment.
English

6
V11 Car Recorder Manual
使用說明
i. Turn on / Turn off
1. Turn on：
When the device is not connected to external power, press ON/OFF key
and hold for 2 seconds to turn on the device.
2. Turn off：
When the device is powered on, press ON/OFF key and hold for 2 seconds
to turn off the device.
3. Auto turn on and off：
※When the car charger is powered by the cigarette lighter socket, your device
will automatically turns on when the engine starts.
※When the car charger is powered by the cigarette lighter socket, your device
will automatically turns off when the engine shuts down.
※If your device is powered by the cigarette lighter socket, it will automatically
turn off if the external power is removed (by unplugging the USB cable).
※In cases where the device is still powered by car cigarette charger when the
engine is off, the auto power-off function is not supported.
ii. Recording
1. General recording：
Under general mode, press key, to start recording mode, on the upper
left corner of the screen will show red dot ●and time.
2. Auto Recording：
In the auto recording mode, the device will turns on and enters the recording
mode automatically when the power is connected.
3. Stop Recording：
Under recording mode, press key to stop recording.
4. Stop recording after power off：
Under the recording mod, when turn off the power, the device will stops
recording, saves the file and automatically turns off.
※Trouble shooting
1. Check the memory card (Micro SDHC) is inserted.
2. Please backup files in the memory card and use the device to format your
memory card.
Operational Guideline
English

7
V11 Car Recorder Manual
iii. Emergency Recording
1. Under the recording mode, press key for Lock. The device will
automatically lock the file. A “Lock”icon will be shown on the upper right
corner of the screen immediately and the file will not be deleted by loop
recording. Press key to stop recording.
2. With the collision detection mode is on: when a collision occurs, emergency
recording is automatically triggered to protect the file. “Lock”icon will be shown
on the upper right corner of the screen immediately and the file will not be
deleted by loop recording. Press key to stop recording.
3. When the emergency video files occupies more than 30% of the card capacity,
the message "emergency recording space is less than 30 percent backup locked
movie" will show on the screen during the next emergency recording. Please
refer to the fourth section of this manual regarding unlocking or backing up a
file.
4. When the emergency recording file is full, the next emergency recording screen
will appear “emergency recording file is full, please back up the locked files”.
Please refer to the fourth section of this manual regarding unlocking or backing
up a file.
5. When the emergency recording file is full, press to enter emergency
recording mode, it will show the message “emergency file is full” and the oldest
emergency file will be overwritten.”
6. 4G memory card can save up to 5 emergency video files; 8G memory card (or
above) can save up to 10 emergency video files.
English

8
V11 Car Recorder Manual
iv. Video playback/Locked file/Unlock/Delete
1. Vide preview：
Under general mode, press key to choose Play,to enter the video playback
menu, use key to select the file type Normal Records or Locked
Records，Press key to choose OK, after choosing the type of video, and you
will see the videos playlist. Use key to choose the video, press
key to choose OK, to playback. Press key to choose Back, to return to the
playlist.
2. Lock video：
Under general mode, press key to choose Play, to enter the video playback
menu, use key to select video, Press Normal Records, Press
key to choose OK,after choosing the type of video you will see the videos playlist.
Use key to choose the video you want to lock, press key to
choose OK, to playback. While playing the video press key to choose Pause,
to stop the video, press key to choose Lock,the video will be moved to
emergency video list. The file will not be deleted from loop recording.
3. Unlock video：
Under general mode, press key to choose Play, to enter the video playback
menu, use key to select Locked Records, Press key to
choose OK,after choosing the type of video you will see the videos playlist. Use
key to choose the video you want to unlock, press key to choose
OK,to playback. While playing the video press key to choose Pause,to stop
the video, press key to choose Unlock, the video will be moved to general
video list, and the screen will return to the emergency video playlist.
4. File deleting：
Under general mode, press key to choose Play, to enter the video playback
menu, use key to select the file type Normal Records or Locked
Records, Press key to choose OK, after choosing the type of video you will
see the videos playlist. Use key to choose the video you want to play,
press key to choose OK, to playback. While playing the video press key
