ABSCO SHEDS Premier 30232GK-PTX User manual

ASSEMBLY INSTRUCTION - MODEL: 30232GK-PTXABSCO INDUSTRIES PAGE 1 23/09/19
ABSCO PREMIER SHED
MODEL: 30232GK-PTX
10’ W x 7.5’ D x 7’ H Australian Made
Premier Garden Shed
Assembly Instructions
Model: J30232G
CONCRETE SLAB
PAGE 1
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J30232G 26/02/14
FRONT: 9' 10 7⁄64"
SIDE: 7' 4 31⁄32"
HEIGHT: 6' 10 43⁄64"
10' 2 3⁄64"
7' 8 29⁄32"
We thank you for choosing an Australian Made Shed. For further assistance please
visit our detailed instructional video library at
www.abscosheds.com.au/USA
At ABSCO Industries we are always looking to be number ONE, so please let us
know what you think of our instructions. Feedback makes us better.
[email protected]
WHEN LAYING YOUR CONCRETE
SLAB, ENSURE THERE IS A REBATED
EDGE 1" DEEP AROUND THE PERIMETER
CONCRETE
SLAB
REBATED EDGE
CHANNEL
CONCRETE SLAB
3" WIDE
REBATE
THIS WILL HELP
WATER EGRESS FROM
THE BASE OF THE SHED
AU: 1800 029 701
N Z: 0800 466 444
[email protected]
www.abscosheds.com.au
[phone]
10’ 2”
7’ 9”
4”

ASSEMBLY INSTRUCTION - MODEL: 30232GK-PTXABSCO INDUSTRIES PAGE 2 23/09/19
ABSCO PREMIER SHED
MODEL: 30232GK-PTX
10’ W x 7.5’ D x 7’ H Australian Made
Premier Garden Shed - Model: J30232G
PAGE 2
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J30232G 26/02/14
GENERAL INSTRUCTIONS
A NOTE ON SAFETY
The site for the shed must be level.
It is recommended that the shed be set on a 4" concrete slab and
anchored down appropriately (refer last page for details).
Anchor sets are not supplied as standard items with this product.
Before commencing any assembly, read through these instructions in
detail to gain a thorough understanding of assembly methods and
associated details.
Unpack the carton and carefully identify and check off all the parts
against the parts described and illustrated on pages three and four.
Some parts may have sharp edges. It is advisable to wear gloves when
handling these items and safety glasses if drilling holes. Sensible shoes
are highly recommended.
Do not erect your shed in windy conditions, ensure that the shed is
securely anchored to a solid foundation immediately after construction is
completed.
It is highly recommended to erect the shed with two or more people.
TOOLS REQUIRED
SITE PREPARATION
Normal 1/8", 11/64"
Masonry 25/64"
Normal 25/64"
OPTIONAL
Standard 1/8”
and 11/69” Standard 25/64”
Masonary 25/64”
80+ lbs

ASSEMBLY INSTRUCTION - MODEL: 30232GK-PTXABSCO INDUSTRIES PAGE 3 23/09/19
ABSCO PREMIER SHED
MODEL: 30232GK-PTX
10’ W x 7.5’ D x 7’ H Australian Made
COMPONENTS PACKING LIST - CHECK OFF ALL COMPONENTS
Premier Garden Shed - Model: J30232G
PAGE 3
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J30232G 26/02/14
COMPONENT
DESCRIPTION
PART
No. CHECK COMPONENT
DESCRIPTION
PART
No. CHECK
QTY
STEEL SHEET
5' 10 9⁄32" Long
2' 6 7⁄16" Wide
STEEL SHEET
5' 10 9⁄32" Long
2' 6 7⁄16" Wide
STEEL SHEET
5' 7 29⁄32" Long
2' 6 7⁄16" Wide
STEEL SHEET
5' 7 29⁄32" Long
2' 6 7⁄16" Wide
STEEL SHEET
3' 10 1⁄16" Long
2' 6 7⁄16" Wide
STEEL SHEET
6' 3 25⁄64" Long
2' 6 7⁄16" Wide
STEEL SHEET
6' 3 25⁄64" Long
2' 6 7⁄16" Wide
STEEL SHEET
6' 5 61⁄64" Long
2' 6 7⁄16" Wide
STEEL SHEET
5' 10 9⁄32" Long
2' 3 63⁄64" Wide
30A
31A
A
B
49A
36L
36R
42D
34A
QTY
89A
90A
89C
91A
86A
15A
JAMB L= 5' 7 29⁄32"
JAMB L= 5' 1 47⁄64"
JAMB L= 5' 7 29⁄32"
JAMB L= 3' 8 3⁄32"
LIP TRIM
L= 3' 10 1⁄16"
2
1
1
4
4
2
2
2
1
1
8
2
2
2
2
PEAK BRACE
1' 7 19⁄64"
Part No. Here
Part No. Here
Part No. Here
Part No. Here
INSTRUCTIONAL
VIDEOS

ASSEMBLY INSTRUCTION - MODEL: 30232GK-PTXABSCO INDUSTRIES PAGE 4 23/09/19
ABSCO PREMIER SHED
MODEL: 30232GK-PTX
10’ W x 7.5’ D x 7’ H Australian Made
COMPONENTS-SPLICEDCHANNEL&RIDGEBEAM
PremierGardenShed- Model: J30232G
PAGE4
ABSCOINDUSTRIES ASSEMBLYINSTRUCTION-MODEL:J30232G26/02/14
COMPONENT
DESCRIPTION
PART
No.CHECK COMPONENT
DESCRIPTION
PART
No.CHECK
QTY
55AL
55CL
55BL
81BL
81AL
81CL
60AL
97AL
CSJ
QTY
55CR
1
1
1
1
2
2
2
1
10
ZARSP
RIDGE
BEAM
THESECOMPONENTS ARETOBE
JOINED
TOTHESECOMPONENTS
1
1
1
1
2
2
2
1
1
CHANNEL
L = 4' 10 59⁄64"
CHANNEL
L = 4' 10 59⁄64"
CHANNEL
L = 4' 10 59⁄64"
CHANNEL
L = 4' 10 59⁄64"
CHANNEL
L = 4' 10 59⁄64"
CHANNEL
L = 3' 811⁄32"
CHANNEL
L = 4' 10 59⁄64"
L = 4' 11 7⁄8"
CHANNEL JOINER
L= 7 7⁄8"
RIDGE BEAM JOINER
L= 1' 5 23⁄32"
55BR
81BR
81AR
81CR
60AR
97AR
55AR
CHANNEL
L = 4' 10 59⁄64"
CHANNEL
L = 4' 10 59⁄64"
CHANNEL
L = 4' 10 59⁄64"
CHANNEL
L = 4' 10 59⁄64"
CHANNEL
L = 4' 10 59⁄64"
CHANNEL
L = 4' 10 59⁄64"
RIDGE
BEAM
CHANNEL
L = 3' 811⁄32"
L = 4' 11 7⁄8"
55AL
55CL
55BL
81BL
81BR
55BR
55CR
55AR
JOIN>>
JOIN>>
JOIN>>
JOIN>>
JOIN>>
JOIN>>
JOIN>>
JOIN>>
COMPONENTS - SPLICED CHANNEL & RIDGE BEAM
Premier Garden Shed - Model: J30232G
PAGE 4
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J30232G 26/02/14
COMPONENT
DESCRIPTION
PART
No. CHECK COMPONENT
DESCRIPTION
PART
No. CHECK
QTY
55AL
55CL
55BL
81BL
81AL
81CL
60AL
97AL
CSJ
QTY
55CR
1
1
1
1
2
2
2
1
10 ZARSP
RIDGE
BEAM
THESE COMPONENTS ARE TO BE
JOINED
TO THESE COMPONENTS
1
1
1
1
2
2
2
1
1
CHANNEL
L = 4' 10 59⁄64"
CHANNEL
L = 4' 10 59⁄64"
CHANNEL
L = 4' 10 59⁄64"
CHANNEL
L = 4' 10 59⁄64"
CHANNEL
L = 4' 10 59⁄64"
CHANNEL
L = 3' 811⁄32"
CHANNEL
L = 4' 10 59⁄64"
L = 4' 11 7⁄8"
CHANNEL JOINER
L= 7 7⁄8"
RIDGE BEAM JOINER
L= 1' 5 23⁄32"
55BR
81BR
81AR
81CR
60AR
97AR
55AR
CHANNEL
L = 4' 10 59⁄64"
CHANNEL
L = 4' 10 59⁄64"
CHANNEL
L = 4' 10 59⁄64"
CHANNEL
L = 4' 10 59⁄64"
CHANNEL
L = 4' 10 59⁄64"
CHANNEL
L = 4' 10 59⁄64"
RIDGE
BEAM
CHANNEL
L = 3' 811⁄32"
L = 4' 11 7⁄8"
55AL
55CL
55BL
81BL
81BR
55BR
55CR
55AR
JOIN >>
JOIN >>
JOIN >>
JOIN >>
JOIN >>
JOIN >>
JOIN >>
JOIN >>

ASSEMBLY INSTRUCTION - MODEL: 30232GK-PTXABSCO INDUSTRIES PAGE 5 23/09/19
ABSCO PREMIER SHED
MODEL: 30232GK-PTX
10’ W x 7.5’ D x 7’ H Australian Made
FULL LENGTH CHANNELS & ACCESSORIES
Premier Garden Shed - Model: J30232G
PAGE 5
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J30232G 26/02/14
79A
1CHANNEL
L = 5' 1 47⁄64"
COMPONENT
DESCRIPTION
PART
No. CHECK COMPONENT
DESCRIPTION
PART
No. CHECK
QTY QTY
83L
2CHANNEL
L = 3' 9"
58A
283R 2CHANNEL
L = 3' 9"
58B
1CHANNEL
L = 5' 7 29⁄32"
58C
4CHANNEL
L = 2' 6 7⁄16"
CHANNEL WITH HINGES
L = 5' 7 29⁄32"
8
3
8
2
12 12
1 1
1
1
14A
2
12A
2
220 SELF TAPPING
SCREWS
SELF DRILLING HEX
HEAD TEK SCREWS (NO
HOLE REQUIRED)
5/32" NUT & BOLT SET
SECURE TWO
PADBOLTS TO DOOR
SHEET
11/64" CSK SCREW &
NUT SECURE HINGES
TO DOOR
1/8" DRILL BIT
ASSEMBLY
INSTRUCTIONS
HEX TEK SCREW
DRIVER BIT
DOOR
PADBOLT
HASP
DOOR
PADBOLT
CAP GABLE
L: 6 11⁄16"
DOOR
STRAP
L: 6 1⁄2"
POP RIVETS SECURE
HINGES TO DOOR
RIVET GUN
(ALTERNATE METHOD)

ASSEMBLY INSTRUCTION - MODEL: 30232GK-PTXABSCO INDUSTRIES PAGE 6 23/09/19
ABSCO PREMIER SHED
MODEL: 30232GK-PTX
10’ W x 7.5’ D x 7’ H Australian Made
PUSH PUSH
Premier Garden Shed - Model: J30232G
PAGE 6
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J30232G 26/02/14
INSTRUCTIONS FOR JOINING SPLICED CHANNELS
CSJ
HIGH-SIDE
CHANNEL
LOW-SIDE
CHANNEL
CSJ
CSJ
CSJ
= =
= =
==
=
=
STEP 1.
Position the channels and the CSJ
joiner channel so the center of the
CSJ is in line with the end of each
channel to be joined together.
STEP 2.
Join the first channel to the CSJ by inserting the center
of the CSJ (on an angle) to the end of the channel
where the JOIN>> text is marked. Push down one side
of the CSJ until you hear a 'click'.
STEP 3.
Join the second channel to the CSJ
by positioning the <<JOIN end of the
channel at the center of the CSJ
(on an angle). Push the CSJ into
the channel until you here a 'click'.
=
The joined channels should now
look like the picture above with the
CSJ positioned equally inside of the
joined channels.
FINISHED CHANNEL
=
NOTE: THE TEXT MARKED ON ALL PARTS MUST BE SHOWN ON THE SAME SIDE AS EACH OTHER.
JOIN>> <<JOIN JOIN>>
JOIN>> SJ
JOIN>>
<<JOIN
JOIN>> <<JOIN
J
CSJ
DRILL 4 x 1/8" (2 PER SIDE)
HOLES TO SECURE SECTIONS
TOGETHER. (THESE SCREWS
MAY HAVE TO BE TEMPORARILY
REMOVED AND REPLACED
DURING LATER ASSEMBLY)
INSTRUCTIONAL
VIDEOS

ASSEMBLY INSTRUCTION - MODEL: 30232GK-PTXABSCO INDUSTRIES PAGE 7 23/09/19
ABSCO PREMIER SHED
MODEL: 30232GK-PTX
10’ W x 7.5’ D x 7’ H Australian Made
Premier Garden Shed - Model: J30232G
PAGE 7
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J30232G 26/02/14
=
=
=
=
=
=
=
2 X 60AR
9' 9 53⁄64"
STEP 1. PRE-ASSEMBLY OF SPLICED CHANNELS
2 x 81A
2 x 60A
1 x 55A
1 x 55C
1 x 55B
1 x 81B
2 x 81C
NOTE: JOIN TOGETHER 20 X CHANNEL SECTIONS USING 10 X CHANNEL JOINERS (PART CSJ)
7' 4 45⁄64"
81BL
81CR
81CL
81BR
55BR
55BL
55CL
55CR
55AR
55AL
60AL
60AR
81AR
81AL
2 X 81AR
2 X 81AL
2 X 60AL
1 X 55AR
1 X 55AL
1 X 55CR
1 X 55CL
1 X 55BR
1 X 55BL
1 X 81BR
1 X 81BL
2 X 81CR
2 X 81CL
NOTE: SOME CHANNELS HAVE
HOLES IN THEM - YOU WILL NEED
TO RE-DRILL HOLES ON ANY
CHANNEL WHERE THE CSJ
JOINING CHANNEL COVERS
HOLES ON THE CHANNELS
YOU ARE CONNECTING
INSTRUCTIONAL
VIDEOS
IMPORTANT:
SOME CHANNELS HAVE

ASSEMBLY INSTRUCTION - MODEL: 30232GK-PTXABSCO INDUSTRIES PAGE 8 23/09/19
ABSCO PREMIER SHED
MODEL: 30232GK-PTX
10’ W x 7.5’ D x 7’ H Australian Made
Premier Garden Shed - Model: J30232G
PAGE 9
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J30232G 26/02/14
TEK SCREW DRIVER BIT
QTY. = 1
QTY. = 8
QTY. = 2
QTY. = 1
SELF DRILLING TEK SCREW
PART ZARSP - 1' 5 23⁄32"
ZARSP
RIDGE BEAM 4' 11 7⁄8"
PARTS 97AL & 97AR
STEP 2. PRE-ASSEMBLY OF SPLICED RIDGE BEAM
97AL
97AR
5/8"
7 7/8"
9 27⁄32"
9' 9 53⁄64" OVERALL LENGTH
(PART 97A)
5/8"
THE TOP SECTIONS OF
CAPPING WILL OVERLAP
EACH OTHER AT THE
JOIN BY 2.0".
INSTRUCTIONAL
VIDEOS

ASSEMBLY INSTRUCTION - MODEL: 30232GK-PTXABSCO INDUSTRIES PAGE 9 23/09/19
ABSCO PREMIER SHED
MODEL: 30232GK-PTX
10’ W x 7.5’ D x 7’ H Australian Made
PAGE 8
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J30232G 26/02/14
STAGE 1: PUSH RIDGE BEAMS TOGETHER, MAKE SURE THERE IS A 2" OVERLAP
OF THE RIDGE CAP
STAGE 2: INSERT RIDGE CAP JOINER INTO CONNECTED RIDGE CAPS.
MAKE SURE JOINER HAS 8 55/64" IN EACH RIDGE CAP.
STAGE 3: TURN RIDGE CAP OVER AND MEASURE 9 27⁄32" FROM THE END
OF EACH RIDGE CAP.
PLACE TEK SCREWS IN 2" INCREMENTS FROM SAID END.
REPEAT THIS PROCESS FOR THE OPPOSING HALF OF RIDGE BEAM
INSTRUCTIONS FOR JOINING SPLICED RIDGE BEAM
2"
8 55⁄64"
2"
2"
Premier Garden Shed - Model: J30232G
INSTRUCTIONAL
VIDEOS

ASSEMBLY INSTRUCTION - MODEL: 30232GK-PTXABSCO INDUSTRIES PAGE 10 23/09/19
ABSCO PREMIER SHED
MODEL: 30232GK-PTX
10’ W x 7.5’ D x 7’ H Australian Made
86A
60A
14A
86A
81A
86A
86A
VIEW OF ROOF COMPONENTS
14A 81A
97A
49A
49A
49A
49A
49A
49A
49A
49A
PAGE 10
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J30232G 26/02/14
Premier Garden Shed - Model: J30232G

ASSEMBLY INSTRUCTION - MODEL: 30232GK-PTXABSCO INDUSTRIES PAGE 11 23/09/19
ABSCO PREMIER SHED
MODEL: 30232GK-PTX
10’ W x 7.5’ D x 7’ H Australian Made
81C
83L
55B
83R
83L
15A
55A
30A
30A
31A
31A
81B 81C
36L
42D
36R 34A
A
B
91A
79A
55C
91A
89A
89A
83R
90A
36R
42D
36L
34A
VIEW OF WALL COMPONENTS
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J30232G 26/02/14
Premier GardenShed Model: J30232G
PAGE 11
INSTRUCTIONAL
VIDEOS

ASSEMBLY INSTRUCTION - MODEL: 30232GK-PTXABSCO INDUSTRIES PAGE 12 23/09/19
ABSCO PREMIER SHED
MODEL: 30232GK-PTX
10’ W x 7.5’ D x 7’ H Australian Made
PAGE 12
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: 30152GK 13/04/16
Premier Garden Shed
Model: 30152GK
INSTRUCTIONS
AND VIDEOS
ABSCO ASSEMBLY INTRODUCTION
FASTENING SYMBOLS
The snaptite assembly system locks most perimeter channels to all roof and wall
sheets without the need for tools and fasteners.
To pre-assemble the four wall panels
and two roof panels, the perimeter
channels are secured to the top and
bottom of each panel using the
snaptite system, as detailed on the
following pages wherever you see
the symbol.
Position sheets on timbers,
trestles or partly over edge of
concrete slab.
Each perimeter channel must finish flush with the
edges of the sheets.The snaptite system allows
adjustment for this process by simply tapping the
channel along the sheets until each end is neatly
flush. If you need to remove channels from the
panels, pull the channel along the panel from
opposing ends. You may need someone to help
with this.
Join components together with one screw at this
location only, as some channel sections have extra
holes that are not required for this model of garden
shed
Do not join components together at this location yet,
as the screw may obstruct further assembly of other
components
4mm NUT & BOLT SET
3mm POP RIVETS
PUSH
PUSH
HIGH SIDE
HIGH SIDE
PUSH
HIGH SIDE
HIGH SIDE
After joining sheets together, position channel over one end of the sheets, gently
tapping it over the snaptite lugs, working along the sheets to the other end.
HIGH SIDE
SNAP
T TE
i
SNAP
T TE
i
SNAP
T TE
i
Join components together by pre-drilling the holes
first. Use one component as a template to mark where
the holes are. Drill with 3mm drill bit.
D

ASSEMBLY INSTRUCTION - MODEL: 30232GK-PTXABSCO INDUSTRIES PAGE 13 23/09/19
ABSCO PREMIER SHED
MODEL: 30232GK-PTX
10’ W x 7.5’ D x 7’ H Australian Made
DOOR PANEL ASSEMBLY
25/32" FLANGE
58C
58C
58C
12A
58C
Premier Garden Shed - Model: J30232G
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J30232G 26/02/14
PAGE 13
58A
58A
19/32" FLANGE
A
B
89C
58B
A
B
FOUR HOLE SET
FOR PADBOLT
CONNECTION
ATTACH 58A AND 58B TO SHEET B SO THAT
THE 25/32" SIDE OF THE CHANNELS ARE ON
THE OUTSIDE OF SHEET B
ENSURE CHANNEL 58C
OUTER FLANGE SITS OVER
UPRIGHT CHANNEL FLANGE
ATTACH 58C CHANNELS
AS DESCRIBED ON PAGE 12
ATTACH 89C WITH COLORED
SIDE FACING OUT.
INSTRUCTIONAL
VIDEOS

ASSEMBLY INSTRUCTION - MODEL: 30232GK-PTXABSCO INDUSTRIES PAGE 14 23/09/19
ABSCO PREMIER SHED
MODEL: 30232GK-PTX
10’ W x 7.5’ D x 7’ H Australian Made
INSIDE
OF
SHED
REAR PANEL ASSEMBLY
SIDE PANEL ASSEMBLY
(2 Required)
Premier Garden Shed - Model: J30232G
PAGE 14
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J30232G 26/02/14
30A
31A
31A
30A
55B
81B
36L
42D
36R
83R
81C
83L
15A
ATTACH 55B AND 81B CHANNEL WITH NOTCHED END AS SHOWN
LAY SHEETS OUT AS SHOWN
LAY SHEETS OUT AS SHOWN
ATTACH 81C, 83L AND 83R CHANNEL AS SHOWN
INSTALL PEAK BRACE WITH OVERHANG FITTING INSIDE SHED
INSTRUCTIONAL
VIDEOS

ASSEMBLY INSTRUCTION - MODEL: 30232GK-PTXABSCO INDUSTRIES PAGE 15 23/09/19
ABSCO PREMIER SHED
MODEL: 30232GK-PTX
10’ W x 7.5’ D x 7’ H Australian Made
Premier Garden Shed - Model: J30232G
PAGE 15
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J30232G 26/02/14
2 x PRE-PUNCHED
HOLES TO THIS
END OF EACH
SHEET WITH PART
NO. 81A FITTED
ROOF PANEL ASSEMBLY
(2 Required)
49A
49A
49A
49A
60A
86A
81A
86A
LAY SHEETS OUT AS SHOWN
ATTACH LIPS 86A AS SHOWN.
LIPS SHOULD OVERLAP ROOF
CHANNEL 81A AND 60A.
INSTRUCTIONAL
VIDEOS

ASSEMBLY INSTRUCTION - MODEL: 30232GK-PTXABSCO INDUSTRIES PAGE 16 23/09/19
ABSCO PREMIER SHED
MODEL: 30232GK-PTX
10’ W x 7.5’ D x 7’ H Australian Made
FRONT PANEL ASSEMBLY
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J30232G 26/02/14
89A
89A
55A
90A
79A
55C
34A
34A
PAGE 16
Premier Garden Shed - Model: J30232G
NOTCH ON JAMB 90A FITS OVER JAMB 89A AND 89B
AND NOTCH ON 89B AND 89A FITS OVER 55A
NOTCH ON JAMB 89A AND 89B FITS
OVER CHANNEL 55C AND CHANNEL
79A INSERTS INTO 55C WITH
SHORTEST SIDE FACING OUT.
DO NOT INSTALL THIS SCREW
(OR THE TOP EQUIVALENT)
UNTIL CHANNELS 55A AND 55C
ARE INSTALLED
79A
55C
89A
LAY SHEETS OUT AS SHOWN
55A
55A
90A
89A
INSTRUCTIONAL
VIDEOS

ASSEMBLY INSTRUCTION - MODEL: 30232GK-PTXABSCO INDUSTRIES PAGE 17 23/09/19
ABSCO PREMIER SHED
MODEL: 30232GK-PTX
10’ W x 7.5’ D x 7’ H Australian Made
DOOR PANEL ASSEMBLY
NOTE: Nuts and bolts (supplied) may be
used instead of pop rivets (supplied) by
simply enlarging the hinge hole sets in the
jamb using a 5/32" drill bit
PAGE 17
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: 30152GK 13/04/16
91A
91A
A
B
Premier Garden Shed
Model: 30152GK
INSTRUCTIONS
AND VIDEOS
NOTE: The two holes required to connect the padbolt hasp for ea
NOTE: The two holes required to connect the padbolt hasp for each door have not been pre-punched, to allow for ch door have not been pre-punched, to allow for
proper alignment. position each hasp centrally over the padbolt
proper alignment. position each hasp centrally over the padbolt shaft, and secure with screws. The sheet metal shaft, and secure with screws. The sheet metal
screws supplied have the ability to self drill through the chanscrews supplied have the ability to self drill through the channel, use a continuous firm pressure and high drillnel, use a continuous firm pressure and high drill
speed and the screws will penetrate the sheet metal. If necessaspeed and the screws will penetrate the sheet metal. If necessary a 3mm drill bit can be used.ry a 3mm drill bit can be used (1/8")
padbolt shaft and drill 1/8” holes and secure with screws.

ASSEMBLY INSTRUCTION - MODEL: 30232GK-PTXABSCO INDUSTRIES PAGE 18 23/09/19
ABSCO PREMIER SHED
MODEL: 30232GK-PTX
10’ W x 7.5’ D x 7’ H Australian Made
PANEL CONSTRUCTION
NOTE: Take care to ensure that both front
and rear wall panels are not positioned
upside down. the top channel of each
panel is pre-punched for attaching roof
sheets to, the bottom channels are not.
Side wall panel channels fit
into the notched front and rear
wall panel channels Channel type 60a this end
Channel type 81a
this end
Premier Garden Shed - Model: J30232G
PAGE 18
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J30232G 26/02/14
97A
INSTALL PADBOLT HASP
ON INSIDE OF DOOR
NO PADBOLT HASP
REQUIRED AT TOP
INSTRUCTIONAL
VIDEOS

ASSEMBLY INSTRUCTION - MODEL: 30232GK-PTXABSCO INDUSTRIES PAGE 19 23/09/19
ABSCO PREMIER SHED
MODEL: 30232GK-PTX
10’ W x 7.5’ D x 7’ H Australian Made
Slide the roof panel into position, and
secure with one screw at each corner
only at this stage
Secure peak brace
to ridge beam and
roof panel with one
screw at each end
Move the other roof panel
into position and secure
peak brace to ridge beam
and roof panel with one
screw at each end
ROOF CONSTRUCTION
Premier Garden Shed - Model: J30232G
PAGE 19
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J30232G 26/02/14
INSTRUCTIONAL
VIDEOS

ASSEMBLY INSTRUCTION - MODEL: 30232GK-PTXABSCO INDUSTRIES PAGE 20 23/09/19
ABSCO PREMIER SHED
MODEL: 30232GK-PTX
10’ W x 7.5’ D x 7’ H Australian Made
DYNABOLT
BOLT & NUT
STEEL
ANGLE
SLAB
WALL
SHEET
FINAL CONSTRUCTION
Bend the top and bottom
flanges as shown, then
hook the bottom flanges
under the top channel and
screw the top flanges for
both as shown gable caps
Premier Garden Shed - Model: J30232G
PAGE 20
ABSCO INDUSTRIES ASSEMBLY INSTRUCTION - MODEL: J30232G 26/02/14
14A
- EACH ANCHOR CONSISTS OF ONE NUT, BOLT,
DYNABOLT AND STEEL ANGLE
- DRILL A 25/64" HOLE INTO
THE WALL SHEET
- DRILL A 25/64" HOLE INTO THE
CONCRETE
LOCATION OF 12 CONCRETE
ANCHORS
ANCHORING OF SHED
INSTRUCTIONAL
VIDEOS
